SDHQ 53-1103-G3 Configuration guide

Latest Revision: 10/31/2019
For questions or help with the installation, please call SDHQ Offroad @ 480-633-2929
Mon.–Fri. 8:00am–5:30pm and Sat. 8:00am–3:30pm Arizona Time. www.sdhqoffroad.com
Page 1of 5
Product Packing List
Product: SDHQ-53-1103-G3
Description: ’07-‘20 Tundra under Bed ARB Compressor
Mount
(1) SDHQ ARB Air Compressor Mount SDHQ-53-1103-G3-A
(1) Hardware Package SDHQ-53-1103-G3-B
(4) M6 - 1.0 x 20mm S.S. Hex Head Screws
(4) ¼” S.S. SAE Washers
(2) 3/8” – 16 x 1 ½” S.S. Hex Head Screws
(4) 3/8” S.S. SAE Washers
(2) 3/8” – 16 S.S. Lock Nuts
(2) Aluminum Spacers
Inspected and Packaged by: Date:

For questions or help with the installation, please call SDHQ Offroad @ 480-633-2929
Mon.–Fri. 8:00am–5:30pm and Sat. 8:00am–3:30pm Arizona Time. www.sdhqoffroad.com
Page 2of 5

For questions or help with the installation, please call SDHQ Offroad @ 480-633-2929
Mon.–Fri. 8:00am–5:30pm and Sat. 8:00am–3:30pm Arizona Time. www.sdhqoffroad.com
Page 3of 5
INSTALLATION INSTRUCTIONS
Product: SDHQ-53-1103-G3
Description: ’07-‘20 Tundra under Bed ARB Compressor
Mount
Tech Notes
**Will only fit Tundras without the spare tire under the bed in stock location**
The SDHQ Tundra in Bed Chase Rack SDHQ-53-1801-G3 allows for 2 spare tires to be mounted
Approximate install time: 30 minutes
Parts List
Hardware List
Required Tools
(1) SDHQ ARB Air Compressor Mount
SDHQ-53-1103-G3-A
(1) SDHQ Hardware Package
SDHQ-53-1103-G3-B
(4) M6 –1.0 x 20 S.S. Hex Head
Screws
(4) ¼” S.S. SAE Washers
(2) 3/8” – 16 x 1 ½” S.S. Hex Head
Screws
(4) 3/8” S.S. SAE Washers
(2) 3/8” – 16 S.S. Lock Nuts
(2) Aluminum Spacers
9/16” wrench
Ratchet
9/16” Socket
10mm socket

For questions or help with the installation, please call SDHQ Offroad @ 480-633-2929
Mon.–Fri. 8:00am–5:30pm and Sat. 8:00am–3:30pm Arizona Time. www.sdhqoffroad.com
Page 4of 5
***READ ALL INSTRUCTIONS THOROUGHLY FROM START TO FINISH BEFORE BEGINNING INSTALLATION! ***
Installation Instructions:
1. Unbox your SDHQ ARB Compressor mount and familiarize yourself with the parts.
2. Preparing your vehicle. Begin by
removing the spare tire (if applicable)
following the instructions from the
Tundra Owner’s Manual.
3. Installing the ARB Compressor.
Line up the holes from the ARB
compressor with the holes on the
SDHQ mount. Insert the provided
ARB hardware into the (4) inside
holes. Next insert the (4) M6 –1.0 x
20 and (4) ¼” SAE washers into the
outside holes.
4. With the ARB compressor mounted to the
SDHQ mount, place the assembly and line
up the (2) main mounting holes with the
Tundra mounting holes as pictured below.
Be sure to place the provided Aluminum
spacers between the bolts and the spare tire
mounting bracket. Use the Drawing at the
top of page 4 as a reference. Tighten the
SDHQ provided hardware using a 9/16”
wrench and a 9/16” socket.

For questions or help with the installation, please call SDHQ Offroad @ 480-633-2929
Mon.–Fri. 8:00am–5:30pm and Sat. 8:00am–3:30pm Arizona Time. www.sdhqoffroad.com
Page 5of 5
***Double check all hardware is installed correctly and tight***
***Re-torque ALL bolts after 100 miles***
