Sea Recovery Aqua Mini 170 User manual

Aqua Whisper Mini 170-750
Owner’s Manual
Revision B - February 2014
Manual PN B651220001B| Revision: 02/25/2014

Sea Recovery Aqua Mini 170, 350, 550 and 750
Owner's Manual
Sea Recovery Corp.
Manual PN B651220001B

Contents
Preface: About this Manual................................................................................................vii
About Sea Recovery........................................................................................................................................................................................vii
Purpose..........................................................................................................................................................................................................vii
References.....................................................................................................................................................................................................vii
Graphics.........................................................................................................................................................................................................vii
Notice of Liability.............................................................................................................................................................................................vii
Trademarks....................................................................................................................................................................................................viii
Terms and Conditions.....................................................................................................................................................................................viii
Copyright.......................................................................................................................................................................................................viii
Revision History..............................................................................................................................................................................................viii
Chapter 1: Introduction......................................................................................................11
Parts Warning................................................................................................................................................................................................11
Warranty and Registration...............................................................................................................................................................................11
Limited Warranty............................................................................................................................................................................................11
Cleaning........................................................................................................................................................................................................12
Product Changes............................................................................................................................................................................................12
Obtaining Warranty Service.............................................................................................................................................................................12
Registration....................................................................................................................................................................................................12
Temperature and Pressure Effects...................................................................................................................................................................12
Safety............................................................................................................................................................................................................13
Disposal.........................................................................................................................................................................................................13
Compliance....................................................................................................................................................................................................13
Chemical Warnings........................................................................................................................................................................................14
Patent Information..........................................................................................................................................................................................15
Chapter 2: Specifications...................................................................................................17
System Specifications.....................................................................................................................................................................................17
Electrical Motor Specifications.........................................................................................................................................................................18
Recommended Power Wire Size to System......................................................................................................................................................19
Recommended Power Wire Size to Booster Pump............................................................................................................................................20
Chapter 3: System and Components Description...............................................................21
Packing List...................................................................................................................................................................................................21
Component Descriptions.................................................................................................................................................................................21
Prefiltration Subsystem...................................................................................................................................................................................21
Aqua Mini 170,350,550,&750 PandID (Piping and Interconnect Diagram).........................................................................................................23
Pressurization Subsystem...............................................................................................................................................................................23
Brine Discharge Subsystem.............................................................................................................................................................................23
Product Water Subsystem...............................................................................................................................................................................24
Fresh Water Flush Subsystem.........................................................................................................................................................................24
Electronic Subsystem......................................................................................................................................................................................24
Chapter 4: System Installation Precautions and Information............................................27
Special Considerations....................................................................................................................................................................................27
Storage Prior to Uncrating...............................................................................................................................................................................27
Uncrating.......................................................................................................................................................................................................27
Installation Cautions.......................................................................................................................................................................................28
Reverse Osmosis Membrane Element Susceptibility to Chemical Attack.............................................................................................................28
Distance Between Components.......................................................................................................................................................................28
High Pressure Pump Preparation.....................................................................................................................................................................29
Tools Required for Installation.........................................................................................................................................................................29
Components Supplied by Installer or Owner.....................................................................................................................................................29
System and Component Mounting ..................................................................................................................................................................30
Plumbing Connections....................................................................................................................................................................................31
Tube Fitting Connections Assembly [24]..........................................................................................................................................................32
UV Light Installation........................................................................................................................................................................................33
Plumbing Requirements..................................................................................................................................................................................34
iii

Installation Procedure.....................................................................................................................................................................................34
System Commissioning...................................................................................................................................................................................36
Start-up Procedure of a New Aqua Mini 170, 350, 550 & 750..........................................................................................................................38
Chapter 5: System Operation.............................................................................................41
System Operation Notes..................................................................................................................................................................................41
Operation Cautions.........................................................................................................................................................................................41
Startup Procedure..........................................................................................................................................................................................41
High/Low Pressure Fault Lamp Explanation......................................................................................................................................................42
Sea Recovery Mini Controller Operations..........................................................................................................................................................43
Display Menu.................................................................................................................................................................................................43
Configuration (Change) Menu..........................................................................................................................................................................44
Configuration (Read) Menu..............................................................................................................................................................................44
Fresh Water Flush button................................................................................................................................................................................45
Chapter 6: System Storage and Cleaning..........................................................................47
R.O Membrane Element Handling and System Storage Cautions........................................................................................................................47
Short Term Shutdown.....................................................................................................................................................................................50
Long Term Shutdown.....................................................................................................................................................................................51
R.O. Membrane Element Cleaning Procedures.................................................................................................................................................52
R.O. Membrane Element Cleaning Water and Chemical Requirements...............................................................................................................53
R.O. Membrane Element Cleaning Instructions.................................................................................................................................................53
Chapter 7: Troubleshooting................................................................................................55
System Shuts Down During Operation..............................................................................................................................................................55
Pressure Readings, Pressure Gauges, and Pressure Switches Abnormalities......................................................................................................56
Product Water Flow and Product Water Quality.................................................................................................................................................57
3-way Product Water Diversion Valve Abnormalities ........................................................................................................................................58
High Pressure Pump Abnormalities..................................................................................................................................................................59
Booster Pump Abnormalities...........................................................................................................................................................................60
Electrical and Electronic Circuit Abnormalities..................................................................................................................................................60
Maintenance and Repair.................................................................................................................................................................................61
Weekly Quick Check.......................................................................................................................................................................................62
Operator Maintenance Intervals.......................................................................................................................................................................62
Chapter 8: Electrical..........................................................................................................65
Electrical Requirements and Information..........................................................................................................................................................65
Power Source Requirements...........................................................................................................................................................................65
Electrical Connections.....................................................................................................................................................................................65
Motor Rotation...............................................................................................................................................................................................66
Recommended Wire Sizes...............................................................................................................................................................................66
Wire Size Cross Reference American Wire Gauge (AWG) vs. Metric Wire Sizes...................................................................................................66
Electrical Line Drawings and Electrical Connections..........................................................................................................................................68
Wiring Diagram Aqua Mini 12vdc....................................................................................................................................................................68
Wiring Diagram Aqua Mini 24vdc....................................................................................................................................................................69
Wiring Diagram Aqua Mini 110/220 VAC single phase......................................................................................................................................70
Aqua Mini 350,550,750 Electrical Diagram......................................................................................................................................................71
Chapter 9: Maintenance and Repair...................................................................................73
Individual Component Maintenance and Repair................................................................................................................................................73
UV Light Maintenance.....................................................................................................................................................................................73
Safety Requirements.......................................................................................................................................................................................74
Unit Maintenance...........................................................................................................................................................................................74
Quartz Sleeve.................................................................................................................................................................................................74
Checking for Leaks.........................................................................................................................................................................................76
Repairing Leaks.............................................................................................................................................................................................76
Measuring Performance..................................................................................................................................................................................77
Verifying Lamp Operation................................................................................................................................................................................77
Obtaining Water Samples................................................................................................................................................................................77
Sampling Procedure.......................................................................................................................................................................................78
Periodic Maintenance Table............................................................................................................................................................................78
Quartz Sleeve Cleaning...................................................................................................................................................................................78
Quartz Sleeve Reassembly..............................................................................................................................................................................78
Ultraviolet Sterilizer [23] .................................................................................................................................................................................79
Charcoal Filter [22] ........................................................................................................................................................................................79
Sea Recovery Aqua Mini 170, 350, 550 and 750iv

The 3-way Product Water Diversion Solenoid Valve [21]...................................................................................................................................79
Solenoid Valve Coil Check...............................................................................................................................................................................80
Flow Meter [20] .............................................................................................................................................................................................80
High Pressure Pump Electric Motor .................................................................................................................................................................81
Back Pressure Regulator [17] .........................................................................................................................................................................81
High Pressure Gauge [15] ..............................................................................................................................................................................81
High Pressure Pump [11]................................................................................................................................................................................81
High Pressure Pump Servicing........................................................................................................................................................................81
Disassembly of the Seal Assembly...................................................................................................................................................................82
Reassembly of Seal Assembly.........................................................................................................................................................................82
Reassembly of the Discharge Valve Assembly..................................................................................................................................................83
Reverse Osmosis Membrane Element Replacement..........................................................................................................................................83
Plankton Filter [5]...........................................................................................................................................................................................85
Pre-filter [6] Element Replacement .................................................................................................................................................................86
Low Pressure Gauge [7] .................................................................................................................................................................................86
Brine Discharge Thru Hull Fitting [1] ...............................................................................................................................................................86
Aqua Mini 350/550/750 Booster Pump with 1/2 Horse Power Electric Motor.....................................................................................................86
Booster Pump Disassembly.............................................................................................................................................................................86
Booster Pump Reassembly..............................................................................................................................................................................87
Chapter 10: System Logs...................................................................................................89
Sea Recovery Aqua Mini 170,350,550,&750 NEW SYSTEM INITIAL READINGS..................................................................................................89
Sea Recovery AquaMini 170,350,550,& 750 System Identification Information..................................................................................................91
Sea Recovery Aqua Mini 170,350,550, & 750 Daily Operation Log System Readings.........................................................................................92
Chapter 11: Glossary..........................................................................................................93
Terms............................................................................................................................................................................................................93
Chapter 12: Exploded Parts View.......................................................................................95
A041C AQUA MINI 170...................................................................................................................................................................................96
A051C AQUA MINI 350...................................................................................................................................................................................97
A051C AQUA MINI 550...................................................................................................................................................................................98
A051C AQUA MINI 750...................................................................................................................................................................................99
A052M AQUA MINI MODULAR......................................................................................................................................................................100
BOOSTER PUMP ASSY AW 170.....................................................................................................................................................................101
B016230003 BOOSTER PUMP ASSY 350 HP75 W-4.75IN IMPELLER.............................................................................................................102
B016230003 BOOSTER PUMP ASSY 350 HP75 W- 4.75 IN IMPELLER...........................................................................................................102
B196220017 MEMBRANE VESSEL ASSY 170................................................................................................................................................103
MEMBRANE VESSEL ASSY AW 350-750.......................................................................................................................................................105
Anatomy of a Spiral Wound Reverse Osmosis Membrane Element...................................................................................................................107
HP PUMP-MOTOR 12VDC-24VDC AW...........................................................................................................................................................108
B156220110 HP PUMP-MOTOR 110-220 50-60 AW 170.............................................................................................................................110
B156230003 HP PUMP-MOTOR 110-220 50-60 1PH...................................................................................................................................112
B156230001 HP PUMP-MOTOR 110-220-60HZ AW350...............................................................................................................................114
B156230003 HP PUMP-MOTOR 110-220 50-60 1PH...................................................................................................................................116
B156230004 HP PUMP-MOTOR 110-220 50-60 AW 550-750 1PH...............................................................................................................118
B502220003 MANIFOLD LP ASSY................................................................................................................................................................120
B156230001M HP PUMP-MOTOR 110-220-60HZ AW350-MODULAR...........................................................................................................121
B156230002M HP PUMP-MOTOR 110-220 50HZ AW 350-MODULAR...........................................................................................................123
B156230004M HP PUMP-MOTOR 110-220 50-60 AW 550-750 1PH-MODULAR...........................................................................................125
B502220003M MANIFOLD LP ASSY.............................................................................................................................................................127
B502230004 CONTROL MANIFOLD ASSY.....................................................................................................................................................128
B502230003 CONTROL MANIFOLD ASSY.....................................................................................................................................................130
B502230003M CONTROL MANIFOLD ASSY MODULAR .................................................................................................................................132
1401096100 3-WAY PRODUCT WATER DIVERSION SOLENOID VALVE............................................................................................................134
B107220002 PREFILTER ASSY 170..............................................................................................................................................................135
B107230001 PREFILTER ASSY DUAL 350.....................................................................................................................................................137
B598000009 FRESH WATER FLUSH 10" HOUSING........................................................................................................................................139
B521220002 CHARCOAL FILTER ASSY 170-350...........................................................................................................................................141
B107230005 COMMERCIAL PREFILTER ASSY...............................................................................................................................................143
B107230010 OIL WATER SEPARATOR ASSY.................................................................................................................................................145
B001220001 INSTALLATION KIT AW/SF 170.................................................................................................................................................147
B001230001 INSTALLATION KIT AW/SF 350-750.........................................................................................................................................148
B611000004 REMOTE ASSY LCD CONTROLLER 80' SRC..............................................................................................................................149
B5262000CV UV STERILIZER........................................................................................................................................................................150
B5968000XX SOFT START ASSY 115-230 V.................................................................................................................................................152
v
Contents

HP HOSE ASSEMBLY....................................................................................................................................................................................154
AVAILABLE TUBES AND FITTINGS..................................................................................................................................................................155
TUBE COMPRESSION FITTINGS REPLACEMENT PARTS..................................................................................................................................158
Clean/Rinse Inlet Valve.................................................................................................................................................................................159
Chapter 13: Appendix.......................................................................................................161
ABS Certificate of Design Assessment...........................................................................................................................................................162
FCC Compliance...........................................................................................................................................................................................163
European Conformite Europene (CE)..............................................................................................................................................................164
Sea Recovery Aqua Mini 170, 350, 550 and 750vi

About this Manual
About Sea Recovery
Since 1981, Sea Recovery Corporation has produced water desalination systems, used in various applications,
for customers around the world. Currently, Sea Recovery Corporation stands apart as a leader in advanced water
desalination systems for leisure marine applications.
Sea Recovery Corp.
P.O. Box 5288
Carson, CA 90745-5288
[email protected]
www.searecovery.com
Purpose
This manual is intended for Sea Recovery’s system technicians, technical support and training personnel. It contains
technical information and instructions for the installation, operation, maintenance and troubleshooting of the Aqua
Mini RO Desalination System. Sea Recovery’s RO desalination systems are designed and engineered to function
as complete, working units and are subject to cascading failure if installation, operation and maintenance instructions
arenotfollowedcorrectly.Thus,theintentofthismanualistofamiliarizeyou,orotherinstaller(s)and/oroperator(s)
with each system component. With a core understanding of the function, importance and normal operation of each
subsystem component, you will be equipped to diagnose minor problems, which, if detected early on, are typically
correctable. Note that if a minor component problem is left uncorrected, it can affect the rest of the system and
lead to more extensive issues and/or damage.
Important: Sea Recovery encourages you to read the Aqua Mini RO Desalination System manual thoroughly
before attempting installation or operation, as well as to keep the manual for future reference. By gaining a
betterunderstandingofyoursystem,youwillbe equipped with the knowledge to achieve optimum performance
and a longer service life.
References
All references in this manual refer to sections within this manual, unless otherwise specified.
Graphics
Graphics used in this manual are for reference and illustration purposes only, and may not represent the actual
part or arrangement of parts in a customized system.
Notice of Liability
The information contained in the manual is distributed on an “as is” basis, without warranty. While every effort has
been taken in the preparation of this manual, Sea Recovery Corporation shall not be held liable with respect to
any liability, loss or damage caused by the instructions contained in this manual. The information contained in this
manual is subject to change without notice.
vii

Trademarks
The Sea Recovery®logo mark is a U.S. Registered Trademark and belongs to Sea Recovery Corporation with all
rights reserved. Sea Recovery®is a U.S. Registered trademark of Sea Recovery Corporation. Aqua Mini™is a
trademark of Sea Recovery Corporation.
Terms and Conditions
The use of this manual acknowledges acceptance of the terms and conditions provided herewith and the agreement
to comply with all applicable laws and regulations pertaining to the use of this manual. In addition, the use of this
manual forms an agreement that Sea Recovery’s trademarked name or Sea Recovery’s trademarked logo mark
are not to be used in any form or manner except with Sea Recovery Corporation’s written permission. Sea Recovery
Corporation holds all rights to its copyrights and trademarks, and to the material contained in this manual. Any use
of such requires the written permission from Sea Recovery Corporation.
Copyright
All content included within this manual, including text, graphics, logos and images, is the property of Sea Recovery
Corporation and protected by U.S. and international copyright laws. The compilation (i.e., the preparation, collection,
arrangementandassembly)ofallcontentwithinthismanualistheexclusivepropertyofSeaRecoveryCorporation
and protected by U.S. and international copyright laws. All software used in the design and manufacture of the
Aqua Mini RO Desalination System is the property of Sea Recovery Corporation and protected by U.S. and
international copyright laws. All computer and logic programming used in the design and manufacture of the Aqua
Mini RO Desalination System is the property of Sea Recovery Corporation and protected by U.S. and international
copyright laws. The content of this manual and the software, programming, and graphics used in the design and
manufacture of the Aqua Mini RO Desalination System is for the purpose of operation, maintaining and repair of
the Aqua Mini RO Desalination System. Any other use, including the reproduction, modification, distribution,
transmission, republication, display or performance, of the content within this manual is strictly prohibited. ©
Copyright Sea Recovery Corporation 2008 - 2014.
Revision History
DescriptionsAffected PageDate
Update wiring diagrams p 8-10. Reported
4/9/08
Sec 7 p 7-10April 15, 2008
Update electrical wiring p 18-21. Reported
7/22/08
Sec 2 p 17-22July 28, 2008
Update PCB graphic illustration p 17.
Reported 7/22/08
Sec 6 p 17-18July 28, 2008
Update electrical wiring and PCB graphic
illustration p 8-10. Reported 7/22/08
Sec 7 p 7-10July 28, 2008
Update PCB graphic illustration p 29.
Reported 7/22/08
Sec 9 p 29-30July 28, 2008
Add UV light installation p i. Add UV light
maintenance p ii. Reported 8/28/08
TOCpiTOCpiiSept 4, 2008
Add reference to UV installation details p 11.
Add UV installation details p 22-24. Reported
8/28/08
Sec2p11Sec2p22Sept 4, 2008
Add reference to UV maintenance details p
15. Add UV maintenance details p 18-22.
Reported 8/28/08
Sec 6 p 15 Sec 6 p 18Sept 4, 2008
Replace Booster PumpSec 9 p 6 and 7 of 30March 22, 2010
Added OW Separator and Commercial Pre
filter for AW-Mini 350
Sec 9, Pages 10-11April 26, 2010
Updated Electrical SpecsPreface Page xviMay 3, 2010
Updated Electrical SpecsSection 7, Page 4May 3, 2010
Sea Recovery Aqua Mini 170, 350, 550 and 750viii

DescriptionsAffected PageDate
Updated New Fresh Water FlushSection 9, Page 25October 22, 2010
Updated HP Pump, and Vessel Drawings -
New 550and750
Section 9August 1, 2011
Revised and reorganized all topics within
manual
Entire ManualJanuary 2014
ix
About this Manual

Chapter 1
Introduction
Parts Warning
The major documented cause of failures and problems are from the use of third-party, non-Sea Recovery parts;
improper installation; and improper operation. Do not use parts, components from any source other than Sea
Recovery! The use of third-party, non-Sea Recovery parts is strongly discouraged and will result in the following
consequences:
• The use of third-party, non-Sea Recovery components, spares and assemblies will damage the Sea Recovery
System and/or specific components within the System.
• The use of third-party, non-Sea Recovery components, spares and assemblies will void any and all warranty of
the System and/or void the affected component within the System.
Important: Sea Recovery Corporation maintains inventory for immediate shipment and our Service Dealers
throughout the world maintain stock of Sea Recovery parts. Always insist on Sea Recovery supplied parts
in order to avoid failures, eliminate problems, and maintain your warranty.
Warranty and Registration
Sea Recovery Corporation guarantees its product, components and replacement parts, and strongly advises that
customers use only Sea Recovery parts. The majority of Aqua Matic RO Desalination System problems derive
from premature failure of unauthorized third party replacement parts.
Attention: Using unauthorized parts will void the Sea Recovery Corporation warranty! Use of non Sea
Recovery Corporation supplied parts and accessories, including but not limited to, maintenance parts, pre-filter
elements, cleaning and storage chemical, spare parts, replacement parts, system components, installation
components and/or system accessories, shall void all warranty expressed or implied.
Limited Warranty
Sea Recovery warrants that the Aqua Matic RO Desalination System performs according to specifications for a
period of 12 months from the date of shipment. Sea Recovery’s liability under this warranty is limited to repair or
replacement of the Aqua Matic RO Desalination System at Sea Recovery Corporation’s discretion. Under no
circumstances is Sea Recovery Corporation liable for consequential damages arising out of or in any way connected
with the failure of the system to perform as set forth herein. This limited warranty is in lieu of all other expressed
or implied warranties, including those of merchantability and fitness for a particular purpose. The warranty period
starts from the date of original shipment by Sea Recovery Corporation, or with proof of purchase from the date of
sale to the original retail purchaser. The following warranty periods apply:
• System and accessories: One (1) year
• Repairs made by Sea Recovery Corporation after the original warranty period has expired: Three (3) months
• Normal, reoccurring user maintenance on the following is not covered by this or any Sea Recovery Corporation
limited warranty: Sea Strainer Element, fuses, instrument calibration, cartridge filter elements and/or the centrifugal
pump seal assemblies
The implied warranties, which the law imposes on the sale of this product, are expressly LIMITED in duration to
the time period above. Sea Recovery Corporation shall not be liable for damages, consequential or otherwise,
resulting from the installation, use, and/or operation of this product or from the breach of this LIMITED WARRANTY.
11

Attention: The Sea Recovery Corporation limited warranty does not cover third-party installation components.
Improper installation resulting in System or component failure/performance decline is not covered by this or
any Sea Recovery Corporation limited warranty. The limited warranty does not extend to any system or
system component which has been subjected to alteration, misuse, neglect, accident, improper installation,
inadequate or improper repair or maintenance or subject to use in violation of instructions furnished by Sea
Recovery Corporation, nor does the warranty extend to components on which the serial number has been
removed, defaced, or changed.
Cleaning
The Aqua Matic RO Desalination System is guaranteed to be cleanable for a minimum of one (1) year from date
of shipment, providing cleaning periods are adhered to, and fouling is acid soluble metal hydroxides and calcium
carbonates or alkaline soluble organic, inorganic substances and microbiological slimes. The Sea Recovery RO
Membrane Element is not guaranteed against iron fouling (rust), chemical or petroleum products attack, extreme
temperatures [over 120°F (49°C) under 32° F (0° C)], drying out, or extreme pressures [over 1000 psig (69 bar)].
In the event of a defect, a malfunction, or failure specifically covered by this warranty and during the warranty
period, Sea Recovery Corporation will repair or replace, at its option, the product or component therein which upon
examination by Sea Recovery Corporation appears to be defective.
Product Changes
Sea Recovery Corporation reserves the right to make changes or improvements in its product, during subsequent
production,withoutincurringtheobligationtoincorporatesuchchangesorimprovementsonpreviouslymanufactured
equipment.
Obtaining Warranty Service
To obtain warranty service, the defective product or part must be returned to an authorized Sea Recovery Corporation
Service Center or direct to Sea Recovery Corporation. An updated listing of Sea Recovery Corporation Factory
Service Centers can be found on the Sea Recovery Corporation web site at http://www.searecovery.com. The
purchaser must pay any transportation or labor expenses incurred in removing and returning the product to the
service center or to Sea Recovery Corporation.
Registration
Sea Recovery Corporation recommends that all customers register their System immediately after delivery to
ensure and guarantee product technical support and warranty.
Temperature and Pressure Effects
Note: Do not use this chart for brackish water systems and applications
As the sea water temperature gets higher, the pressure must be adjusted so that the System does not exceed
100% of its rated product water flow. Product water flow that is greater than 100% of rated capacity causes
premature fouling of the RO Membrane Element, which voids the RO Membrane Element warranty. The System
will also require more frequent cleaning. Please refer to the chart below for pressure adjustments.
Sea Recovery Aqua Mini 170, 350, 550 and 75012

Safety
Parties responsible for the installation, operation, and maintenance of the Aqua Mini RO Desalination System must
read this manual thoroughly and comply with the instructions and safety requirements at all times.
Disposal
If System disposal is necessary, you must comply with all federal and state environmental regulations.
Compliance
• SeaRecovery’s ReverseOsmosisDesalinationSystemsare TypeAcceptedbythe AmericanBureau ofShipping,
ABS.
• Sea Recovery’s Reverse Osmosis Desalination Systems comply with FCC § 15.105
• Sea Recovery’s Reverse Osmosis Desalination Systems have been independently tested and determined to be
in compliance with European CE (Conformité Européne).
Please refer to the Appendix on page 161 for copies of compliance certificates.
13
Introduction

Chemical Warnings
Sea Recovery SRC SC Storage Chemical
WARNING! CONTAINS SODIUM METABISULFITE. HARMFUL IF SWALLOWED, AVOID BREATHING DUST &
FUMES. CAUSES IRRITATION TO EYES & MUCOUS MEMBRANES. DO NOT TAKE INTERNALLY. KEEP
AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, GIVE TAP WATER & INDUCE VOMITING. IN CASE OF
CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES & GET IMMEDIATE MEDICAL
ATTENTION. THOROUGHLY WASH AFFECTED SKIN AFTER HANDLING PRODUCT.
MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC SC”, SYSTEM & MEMBRANE STORAGE
CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS A WEEK, U.S.A. TOLL FREE MEDICAL EMERGENCY
NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
Use with adequate ventilation. Prevent breathing dust and prevent contact with eyes. Thoroughly wash contacted
parts after handling. Do not allow powder to become wetted with small amounts of water. Adding small amounts
of water to power may liberate irritating sulfur dioxide gas. Add powder to above specified amount of water only.
Do not mix with other chemicals or cleaners. If spilled, sweep up as much as possible then flush with water to
drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Sea Recovery SRC MCC-1 Membrane Cleaning Chemical
WARNING: CONTAINS SODIUM METASILICATE. HARMFUL IF SWALLOWED. MAY CAUSE BURNS. AVOID
CONTACT WITH EYES. AVOID PROLONGED CONTACT WITH SKIN. DO NOT TAKE INTERNALLY. KEEP
AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, DO NOT INDUCE VOMITING, GIVE ONE GLASS OF TAP
WATER OR MILK. IN CASE OF CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES &
GETIMMEDIATEMEDICALATTENTION.THOROUGHLYWASHAFFECTEDSKINAFTERHANDLINGPRODUCT.
CONTACT A PHYSICIAN IF IRRITATION PERSISTS.
MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC MCC1”, R.O. MEMBRANE ELEMENT ALKALINE
DETERGENT CLEANING CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS A WEEK, U.S.A. TOLL
FREE MEDICAL EMERGENCY NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
Use with adequate ventilation. Prevent breathing dust & prevent contact with eyes. Thoroughly wash contacted
parts after handling. Do not allow powder to become wetted with small amounts of water. Add powder to above
specified amount of water only. Do not mix with other chemicals or cleaners. If spilled, sweep up as much as
possible then flush with water to drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Sea Recovery SRC MCC-2 Membrane Cleaning Chemical
DANGER:CONTAINSSULFAMICACID. CAUSESBURNS,EYE&SKINIRRITATION. HARMFULIFSWALLOWED.
AVOID BREATHING DUST. DO NOT TAKE INTERNALLY. KEEP AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, DO NOT INDUCE VOMITING, GIVE ONE GLASS OF TAP
WATER OR MILK. IN CASE OF CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES &
GETIMMEDIATEMEDICALATTENTION.THOROUGHLYWASHAFFECTEDSKINAFTERHANDLINGPRODUCT.
CONTACT A PHYSICIAN IF IRRITATION PERSISTS.
MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC MCC2”, R.O. MEMBRANE ELEMENT ACID
CLEANING CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS A WEEK, U.S.A. TOLL FREE MEDICAL
EMERGENCY NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
Sea Recovery Aqua Mini 170, 350, 550 and 75014

DO NOT MIX WITH CHLORINATED SOLUTIONS OR COMPOUNDS. Use with adequate ventilation. Prevent
breathing dust & prevent contact with eyes. Thoroughly wash contacted parts after handling. Do not allow powder
to become wetted with small amounts of water. Add powder to above specified amount of water only. Do not mix
with other chemicals or cleaners. If spilled, sweep up as much as possible then flush with water to drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Sea Recovery SRC MCC-3 Membrane Cleaning Chemical
WARNING: CONTAINS SODIUM METABISULFITE. HARMFUL IF SWALLOWED. AVOID BREATHING DUST
AND FUMES. CAUSES IRRITATION TO EYES AND MUCOUS MEMBRANES. DO NOT TAKE INTERNALLY.
KEEP AWAY FROM FOOD.
FIRST AID: IF SWALLOWED, CALL A PHYSICIAN, GIVE TAP WATER AND INDUCE VOMITING. IN CASE OF
CONTACT IMMEDIATELY FLUSH EYES WITH WATER FOR 15 MINUTES & GET IMMEDIATE MEDICAL
ATTENTION.THOROUGHLYWASHAFFECTEDSKINAFTERHANDLINGPRODUCT. CONTACTA PHYSICIAN
IF IRRITATION PERSISTS.
MEDICAL PERSONNEL FAMILIAR WITH Sea Recovery “SRC MCC3”, R.O. MEMBRANE ELEMENT RUST
REMOVER CLEANING CHEMICAL, ARE AVAILABLE 24 HOURS A DAY, 7 DAYS A WEEK, U.S.A. TOLL FREE
MEDICAL EMERGENCY NUMBER: 1-800-228-5635.
FOR INDUSTRIAL USE ONLY.
Use with adequate ventilation. Prevent breathing dust & prevent contact with eyes. Thoroughly wash contacted
parts after handling. Do not allow powder to become wetted with small amounts of water. Adding small amounts
of water to powder may liberate irritating sulfur dioxide gas. Add powder to above specified amount of water only.
Do not mix with other chemicals or cleaners. If spilled, sweep up as much as possible then flush with water to
drain.
KEEP OUT OF REACH OF CHILDREN
NET CONTENTS 1.5 POUNDS (.68 Kg)
Patent Information
Certain aspects of the Aqua Mini RO Desalination System are protected by U.S. and International Patent Laws.
15
Introduction

Chapter 2
Specifications
System Specifications
PERFORMANCE
PRODUCT WATER PRODUCED PER HOUR AND PER DAY OF OPERATION:
( +-15% at 850 psig / 56 BAR, 77°F / 25°C and 35,000 PPM TDS Feed Water Salinity )
per 24 hours of operation:per 1 hour of operation:Model Number
170 U.S. Gallons / 644 liters7 U.S. Gallons / 26.8 litersSRC Aqua Mini 170
350 U.S. Gallons / 1,325 liters14.6 U.S. Gallons / 55.2 litersSRC Aqua Mini 350
550 U.S. Gallons / 2,082 liters23 U.S. Gallons / 86.7 litersSRC Aqua Mini 550
750 U.S. Gallons / 2,839 liters31.3 U.S. Gallons / 118.3 litersSRC Aqua Mini 750
SALT REJECTION (CHLORIDE ION): Minimum 99.2 %, Average 99.4%
PRODUCT WATER TEMPERATURE: Ambient to feed water temperature
SALINITY MONITORING: Automatic computer controlled electronic monitoring. Temperature compensated with
the Water Quality Indicator. The salinity monitoring components of the system give a continuous readout in
micromhos per cubic centimeter, are temperature compensated and of a fail-safe design.
SALINITY RANGE OF FEED WATER:
Seawater up to 50,000 PPM TDS (NaCl) (typical seawater salinity is 35,000 PPM)
TEMPERATURE RANGE: Max. 122°F / 50°C, Min. 33°F / .5°C
SYSTEM FEED WATER:
Feed Water Flow Per Minute:Power Source and Cycles (Hz)Model Number
0.50 U.S. Gallons / 1.89 litersDC and AC (60Hz)SRC Aqua Mini 170
1.50 U.S. Gallons / 5.68 litersAC (60Hz)SRC Aqua Mini 350
0.42 U.S. Gallons / 1.58 litersAC (50Hz)SRC Aqua Mini 170
1.25 U.S. Gallons / 4.73 litersAC (50Hz)SRC Aqua Mini 350
3.50 U.S. Gallons/ 13.30 litersAC (60Hz)SRC Aqua Mini 550/750
2.90 U.S. Gallons / 11.00 litersAC (50Hz)SRC Aqua Mini 550/750
REVERSE OSMOSIS MEMBRANE
TYPE: Specifically selected High Rejection / High Yield aromatic tri-polyamides, thin film composite, spiral wound,
single pass reverse osmosis membrane element.
CHLORINE TOLERANCE: 0.1 PPM.
pH RANGE: 3-11 (typical seawater pH is 8)
17

SYSTEM PRESSURE
FEED WATER: Minimum 2 psi / .14 bar / .14 Kg/cm2.Maximum 30 psi / 2.07 bar / 2.11 Kg/cm2
OPERATION: Seawater @ 35,000 PPM and 77 F / 25 C:Nominal 850 psi / 58.61 bar / 59.76 Kg/cm2.
DIMENSIONS and WEIGHT
HEIGHTWIDTHLENGTHWEIGHTMODEL
12.2 in / 30 cm17.85 in / 45 cm26 in / 66 cm70 lbs / 32 kgAqua Mini 170
15.78 in / 40
cm
19.68 in / 50 cm37.94 in / 96 cm127 lbs / 58 kgAqua Mini 350
15.78 in / 40
cm
19.68 in / 50 cm37.94 in / 96 cm142 lbs / 64 kgAqua Mini 550
15.78 in / 40
cm
19.68 in / 50 cm46.94 in / 119 cm150 lbs / 68 kgAqua Mini 750
EXTERNAL INSTALLATION WATER CONNECTIONS
Pipe sizes to be supplied by the installer for connection of the Sea Recovery supplied components
Aqua Mini 170
5/8” MNPT Male National Pipe Thread StandardFeed Inlet:
1/2” MNPT Male National Pipe Thread StandardBrine Discharge
1/4” FNPT Female National Pipe Thread StandardProduct
Aqua Mini 350-750
5/8” MNPT Male National Pipe Thread StandardFeed Inlet:
1/2” MNPT Male National Pipe Thread StandardBrine Discharge
1/4” FNPT Female National Pipe Thread StandardProduct
Electrical Motor Specifications
(H.P. = Horse Power; = Full Load Amperes; LRA = Locked Rotor Amperes @ Start Up)
ALTERNATING CURRENT SYSTEMS
Table 1: Aqua Mini 170
Booster Pump MotorHigh Pressure Pump Motor
LRAFLAH.PVACLRAFLAH.PVAC
1551212V95291/312V
82.52424V48141/324V
20.211/8110 - 1152661/3110 - 115
10.51/8220 - 2301331/3220 - 230
Sea Recovery Aqua Mini 170, 350, 550 and 75018
