LT -3600RF LED Controller V3.0 User Instructions Page 1 of 8

LT-3600RF

LED Controller

V3.00

USER INSTRUCTIONS

Pls kindly read through instructions before use

LT -3600RF LED Controller V3.0 User Instructions Page 2 of 8

，Forword，

Thanks for choosing our LT-3600RF Controller. Before installation and use, we

strongly recommend you to read through this manual carefully. If device has

been damaged during transport, please report it to your supplier immediately.

Please don’t take any action without contacting your supplier first.

，After-sales Service，

From the day you purchase our products within a year, if being used properly

in accordance with the instruction, and quality problems occur, we provide free

repair or replacement services except the following cases:

1. Any defects caused by wrong operations..

2. Any damages caused by unauthorized removal, maintenance, modifying

circuit, incorrect connections and replacing chips.

3. Any damages due to transportation, vibration etc after the purchase.

4. Any damages caused by earthquake, fire, lightning strike, pollution and

abnormal voltage.

5. Any damages caused by negligence, inappropriate storing at high

temperature and humidity environment or near harmful chemicals.

6. Product has been updated

，Safety Warnings，

1. Please don’t install this controller in lightening, intense magnetic and

high-voltage fields.

2. To reduce the risk of component damage and fire caused by short circuit,

make sure correct connection

3. Always be sure to mount this unit in an area that will allow proper

ventilation to ensure a fitting temperature.

4. Check if the voltage and power adapter suit the controller & if anode or

cathode definition is the same as the controller’s.

5. Don’t connect cables with power on, make sure a correct connection and

no short circuit checked with instrument before power on.

6. Please don’t attempt any repairs yourself; doing so will void your

manufactures warranty.

For update information, kindly please consult with your supplier.

LT -3600RF LED Controller V3.0 User Instructions Page 3 of 8

Product Brief

LT-3600RF multi function LED controller is a universal RGB controller with

high-performance, adopted the most advanced PWM control technology.

It’s dedicated to control entire RGB color changes of LED lights with 4 wires

(common anode), such as RGB LED module, LED strip, LED tape, LED wall

washer, floodlight, LED under water lamp and other LED lights.

Ⅰ. Technical Specs

Part No：LT-3600RF

Input Voltage：

DC12V-DC24V

Speed：

8 levels

Output current：

6A/CH×3

BRT Adjust：

8 levels

Total output

Power：

1～220W(12V) ;

1～450W(24V)

Working Temp：

-35℃－55℃

Cover Size：

L211×W40×H30(mm)

Changing Mode：

17 modes

Package Size：

L215×W43×H33(mm)

Color Depth：

Max. 256 levels per

RGB

Gross Weight：

210g

Remote

Distance:

50m

Ⅱ. Features

1. Controlled both by manual buttons and its fitting remote controller,

reliable control distance can reach as far as 50m.

2. Automatic switch from DC5-DC24V.

3. Can turn on or off controller by ON/OFF button.

4. 3-Channel RGB full color control, maximum outputs 6A per Channel.

5. 17 modes of color skipping, color gradual changes，with color depth

maximum 256 levels per RGB.

6. Speed and brightness of each mode is adjustable separately from 1-8

levels.

LT -3600RF LED Controller V3.0 User Instructions Page 4 of 8

7. Can rest at current color and color depth by selecting PAUSE function.

8. Can restore to default settings with the newly added RESET button.

9. Used as a standalone controller or to work together with LT-3060,

realizing infinite power expansion to connect any quantity of LED

lights.

Ⅲ. Product Dimension

Ⅳ. Tables of changing modes

Sequence

Modes

Description

Static red
