Sealey MK77 User manual

POLYMASK/MASKING PAPER DISPENSER
1 X 900MM ROLL
MODEL NO: MK77
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLYAND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9 Ensurethedispenserisonareasonablyat,leveloorbeforeloading.
9 Ensurethatallttingsaretightandsecure.
8DO NOTusethedispenserforanypurposeotherthanthatforwhichitisdesigned.
2. INTRODUCTION
Singlerolldispenseraccepts900mmrollsandcanbeusedeitherhorizontallyorvertically.Durablelightweightdesignwithwheelsforeasy
manoeuvrability.
3. SPECIFICATION
Capacity:............................................. 1x900mm(rollwidth)
MaxWeightCapacity:.................................20kg(rollweight)
4. CONTENTS
REFER TO PARTS LIST
5. ASSEMBLY
REFER TO PARTS LIST
NOTE: Beforeassembling,notethelocationofthe“brakebar”(10)mountingholesinthe
 base(3)inrelationtothe“crossbar”(5)andspring(12)mountingholesinthe
 sideframes(1,2).
5.1.  Attachsideframes(1,2)tobase(3)withtwoM8x45mmhexbolts(4).
8DO NOTtightenbolts.
5.2.  Attachfront“crossbar”(5)tolowersetofholesinsideframeswithtwoM8x45mm
 hexbolts(4).Tightenallboltsinbase.
5.3.  Slide“wheelaxle”(6)throughbaseandplacetwoM12atwashersoneachend
 ofthe“wheelaxle”(6).
5.4.  Slide“xedwheels”(8)oneachendofthewheelaxle.
5.5.  Installthetwo“brakebars”(10)tobasewithM8x45mm(4)asshownon
 thepartsdiagram.
5.6.  Hookthesprings(12),withtherubberspacer(13),intoholesoneachsideframe.
5.7.  Installthe“tapereel”(16)toinsideofbothsideframesasshownonthepartsdiagram.
6. MAINTENANCE
6.1. Ifinconstantuse,checkthetightnessofallfixingsonaweeklybasis.
