Sealey DT55BCOMBO1 User manual

MOBILE DISPENSING TANK 55LTR WITH
ADBLUE PUMP - BLUE
MODEL NO: DT55BCOMBO1
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure health & safety, local authority, and general workshop practice regulations are strictly adhered to when using this
equipment.
9 Familiariseyourselfwithproductapplicationandlimitations,aswellasthespecicpotentialhazardspeculiartothisproduct.
9Maintain the pump in good condition (use an authorised service agent).
9Replace or repair damaged parts. Use genuine parts only. Non authorised parts will invalidate the warranty.
9Ensure safety eye protection and protective clothing are worn when using this product.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnonslipshoes.
9Keep children and unauthorised persons away from the working area.
9Dispose of waste liquids in accordance with local authority regulations.
8DO NOT dismantle, tamper with or adapt the pump for any purpose other than for which it is designed.
8DO NOT use the unit if it has been dropped or mishandled, check the unit to ensure there is no damage.
8DO NOTusethepumpasahandletomovetheuiddrum.
9Keep the pump clean and store in a safe, dry, childproof location.
WARNING! DO NOTallowuncontrolleddischargeofuidsthuspollutingtheenvironment.
2. INTRODUCTION
Manufactured from hard wearing and durable polyethylene. 55ltr Capacity suitable for the distribution of Diesel, Oil, AdBlue®, Water and
Antifreeze.Availableinthreecongurationsandcolours,ModelNo.DT55RCOMBO1(Red)issuppliedwithModelNo.TP55OilRotaryPump,
DT55GCOMBO1(Grey)issuppliedwithModelNo.TP9612VDieselPumpKitandDT55BCOMBO1(Blue)issuppliedwithModelNo.TP6607
AdBlue®LeverPump.Unitsarettedwithtworollerwheels,hoseholderandventcaps.Eachtankfeaturesa2”BSPthreadandfourpoint
screwttingsenablingotherpumpstobettedasrequired.
3. ASSEMBLY
3.1.  Extendthesuctiontubesoitreachesthebottomofthetank.Pullitoutandscrew
 itintoplaceonthebottomofthepump(g.3).
3.2.  Turnthelockingringtotherightuntilallthethreadisexposed.Turntheadapterto
 therightuntilitisngertight(g.2).
3.3.  Placethepumpassemblyontoeithertheleftorrighthandsideports(g.1).Start
 turningthepumpassemblytotheright.Theadapterringcanbescreweddownon
 itsownifthepumpbodyfowlsthehandles(g.2).
3.4. Attach the hose to the pump by pushing it onto the spout and securing it with a
 hoseclip(g.1).
3.5. Attach the pump nozzletotheotherendofthehoseinthesameway(g.4and5).
Pump
Body
Locking
Ring
Adapter
g.3
g.2
DT55BCOMBO1Issue108/01/19
Original Language Version
©JackSealeyLimited
Refer to
instructions
g.1
Wear eye
protection
Wear protective
gloves

4. OPERATION
4.1. Thenozzlecanbelatchedopenbypushingthebuttononthebottomofthehandle(g.5).
5. MAINTENANCE
6.2. Checkthetightnessofallttingsregularlyandtightenifnecessary.
6.3. Keepthepumpunitcleantohighlightanyleakswhichmaydevelopinservice.
6. TROUBLESHOOTING
PROBLEM PROBLEM POSSIBLE CAUSE SOLUTION
Lowornoowrate. Low level in source tank. Rellthetank.
Air entering the pump or suction tube. Check seals and connections.
Leakage from the body pump. Seal damaged. ContactyourauthorisedSealeystockist.
Latch
Button
g.4 g.5
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note:Itisourpolicytocontinuallyimproveproductsandassuchwereservetherighttoalterdata,specificationsandcomponentpartswithoutprior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty:Guaranteeis12monthsfrompurchasedate,proofofwhichisrequiredforanyclaim.
Partssupportisavailableforthisproduct.Toobtainparts,pleaselogonto
www.sealey.co.uk,email[e-mail]ortelephone01284757500
