Sealey PEH3001.V2 User manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. ELECTRICAL SAFETY
WARNING! It is the user’s responsibility to check the following:
9Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and all electrical
connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical products.
Electrical safety information. It is important that the following information is read and understood:
9Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
9Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is tted with the correct fuse.
8DO NOT pull or carry the appliance by the power cable.
8DO NOT pull the plug from the socket by the cable.
8DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or is replaced immediately by a
qualied electrician.
If the cable or plug is damaged during use, switch o󰀨 the electricity supply and remove from use.
 Ensurethatrepairsarecarriedoutbyaqualiedelectrician.
If an extension reel is used it should be as short as possible and fully unwound before connection. A reel with an RCD fitted is preferred
since any appliance plugged into it will be protected. The cable core section is important and should be at least 1.5mm², but to be
absolutely sure that the capacity of the reel is suitable for this product and for others which may be used in the other output sockets, we
recommend the use of 2.5mm² section cable.
1.2. GENERAL SAFETY
WARNING! The appliance shall be disconnected from its power source during service and when replacing parts and, if the removal
of the plug is foreseen, it shall be clearly indicated that the removal of the plug has to be such that an operator can check from any
of the points to which they has access that the plug remains removed.
WARNING: DO NOT use this heater in small rooms when they are occupied by persons not capable of leaving the room on their own,
unless constant supervision is provided.
9Servicing or maintenance must only be carried out by an authorised service agent.
9Check that the heater is in sound condition and good working order. Take immediate action to repair or replace damaged parts.
9Use recommended parts only. Unapproved parts may be dangerous and will invalidate the warranty.
8DO NOT attempt to repair a damaged heater, contact an authorised service agent.
WARNING! In order to avoid overheating, DO NOT cover the heater.
1.3. POSITIONING OF HEATER
WARNING: To reduce the risk of fire, keep textiles, curtains, or any flammable material a min. distance of 1m from the air outlet.
WARNING! DO NOT use the heater near ammable material, liquids, solids, gases or compressed gas cylinders etc.
9Use this heater on a horizontal and stable surface, or x it to a wall as applicable.
8DO NOT use this heater in the immediate surroundings of a bath, a shower or a swimming pool.
8DO NOT place the heater up against any surface such as a wall, door or furniture etc.
8The heater must not be located immediately below a socket outlet.
8DO NOT place the heater on a raised surface or anywhere where it could topple over.
8DO NOT get the heater wet or use in areas of high condensation.
8DO NOT allow the power lead to touch hot surfaces.
8DO NOT connect the heater to a timer device or other equipment than can automatically switch the heater on or off.
8DO NOT operate the heater when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8DO NOT stand on the heater.
8DO NOT use the heater with wet hands or when there is water on the power cord.
8DO NOT use the heater for anything other than its intended purpose. It is designed to provide heat in enclosed areas such as
workshops and other industrial areas. It is not suitable for drying clothes or laundry.
9Position the heater at least a minimum of 1m at the front, rear and sides from any walls or objects.
9If an extension cable is required it must be of the same cross section as the heater cable. It must be as short as possible and fully unwound.
9Ensure that the heater is correctly turned o󰀨 when not in use and store in a safe, dry, childproof location.
1.4. OPERATIONAL PRECAUTIONS
9The heater must only be used by people who have read these instructions and have been trained in its use.
8DO NOT obstruct the air inlet and outlet sections of the heater.
3000W INDUSTRIAL PTC FAN HEATER, 230V
MODEL NO: PEH3001.V2
Refer to
Instruction
Manual
Indoor Use
Only Do Not
Cover Hot Surfaces
Original Language Version
© Jack Sealey Limited PEH3001.V2 Issue 2 (1,F) 07/11/23

WARNING! In order to avoid overheating, DO NOT cover the heater.
8DO NOT use the heater without the grille fitted.
8DO NOT use if the heater has been dropped.
8DO NOT use if there are visible signs of damage to the heater.
8DO NOT touch the heater casing or grille when rst switched o󰀨, as these will be very hot and will take time to cool.
NOTE: Children of less than 3 years should be kept away unless supervised continuously.
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it has been placed or installed in its
intended normal operating position and they have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or
perform user maintenance.
CAUTION: Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and
vulnerable people are present.
NOTE: The heater must not be located immediately below a socket output.
2. INTRODUCTION
Industrial fan heaters with PTC heat conducting ceramic elements to achieve an instant, totally dry heat with no condensation, no gas,
no fumes and no smell. Ambient room thermostat maintains temperature at a preset level. Ideal for industrial applications with two heat
settings or fan only. PEH3001 Supplied without plug.
3. SPECIFICATIONS
Model:.......................................................PEH3001.V2
Heated Area:..........................................................60m3
Output:.......................................................10,000Btu/hr
Plug Type:......................................................Bare Wire
Power Supply Cable Length: .................................1.3m
Power: .......................................................1500/3000W
Supply:......................................................... 230V - 16A
IMPORTANT! This unit is designed to raise the ambient temperature of an entire room, the temperature of the air coming out of the
front of the heater will be warmer than the general temperature of the room, but there may not be a signicant increase due to the
large volume of air passing over the element. For the same reason, the element is hot during operation, but does not glow visibly. The
room temperature depends on room size, insulation and the ambient temperature, which will increase as the room gets warmer.
4. OPERATION (FIG.1)
4.1. Position heater in an upright position on a rm surface and at a safe distance from any obstructions, ammable substances etc. Keep
to a minimum of 1m clearance at the rear and sides, and 2m clearance at the front.
4.2. Connect the heater to a suitable mains supply.
4.3. Set the thermostat dial to the maximum setting (fully clockwise).
4.4. The heater will switch on when the power setting selector is set to one of the two power settings.
NOTE: It will take up to three minutes for the heater to reach optimum temperature.
4.5. Once the room reaches the required temperature, heating element will stop working and the fan will stop. Once the temperature
decreases, the heating element and fan will restart working automatically and thus keep the room temperature constant.
4.6. For fan only operation, turn the power/fan selector to the fan only setting and set the thermostat to its minimum setting.
4.7. When not in use, disconnect the heater from the mains supply. Store it in a safe, dry, childproof location.
Fig.1
OFF FAN
ONLY LOW
POWER
HIGH
POWER
THERMOSTAT
5. MAINTENANCE
WARNING! Before attempting any maintenance, ensure that the unit is unplugged from the mains power supply and that it has cooled down.
5.1. Clean the heater with a soft dry cloth only. DO NOT use abrasives or solvents.
5.2. Periodically check the heater grille to ensure that it is not blocked.
5.3. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualied persons in order to avoid
a hazard.
Original Language Version
© Jack Sealey Limited PEH3001.V2 Issue 2 (1,F) 07/11/23

Original Language Version
© Jack Sealey Limited PEH3001.V2 Issue 2 (1,F) 07/11/23
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on [e-mail] or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment. When
the product becomes completely unserviceable and requires disposal, drain any uids (if applicable) into approved
containers and dispose of the product and uids according to local regulations. REGISTER YOUR
PURCHASE HERE

Information requirements for electric local space heaters
* Enter gure or NA
Model identier(s):
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage local space heaters
only (select one)
Nominal heat output Pnom
kW Manual heat charge control, with
Yes No
integrated thermostat
Minimum heat output (indicative)* Pmin kW Manual heat charge control with room Yes No
and/or outdoor temperature feedback
Maximum continuous heat output Pmax,c kW Electronic heat charge control with room Yes No
and/or outdoor temperature feedback
Fan assisted heat output Yes No
Type of heat output/room temperature control (select one)
Single stage heat output and no room Yes No
temperature control
Two or more manual stages, no room Yes No
temperature control
With mechanic thermostat room Yes No
temperature control
With electronic room temperature control Yes No
Electronic room temperature control plus Yes No
day timer
Electronic room temperature control plus Yes No
week timer
Other control options (multiple selections possible)
Room temperature control, with presence Yes No
detection
Room temperature control, with open Yes No
window detection
With distance control option Yes No
With adaptive start control Yes No
With working time limitation Yes No
With black bulb sensor Yes No
Contact details: Sealey Group, Kempson Way, Su󰀨olk Business Park, Bury St Edmunds, Su󰀨olk, IP32 7AR. www.sealey.co.uk
ERP Table 2
Auxiliary electricity consumption
At nominal heat output elmax
kW
At minimum heat output elmin kW
In standby mode elSB kW
PEH3001 v2
NA
NA
NA
3.000
1.500
3.000
v1
