Sealey AS20.V2 User manual

AXLE STANDS (PAIR) 20TONNE CAPACITY PER
STAND
MODEL NO: AS20.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
I
MP
PO
R
RTA
TA
NT:
PLEA
S
E READ THE
S
E IN
S
TRU
C
TI
O
N
S
C
AREFULLY. N
O
TE THE
S
AFE
O
PERATI
O
NAL RE
Q
UIREMENT
S
, WARNIN
GS
&
C
AUTI
O
N
S
. U
S
E
TH
HE
P
PR
O
ODU
C
T
CO
RRE
C
TLY AND WITH
C
ARE F
O
R THE P
U
RP
OS
E F
O
R WHI
C
H IT I
S
INTENDED. FAIL
U
RE T
O
D
O
SO
MAY
C
A
US
E DAMA
G
E AND
/O
R
PE
ER
S
SON
N
AL IN
JU
RY AND WILL INVALIDATE THE WARRANTY. KEEP TH
ESE
IN
STR
UCT
ION
S S
AFE
FO
R F
U
T
U
RE
USE
.
1. SAFETY
WARNING! DO NOT overload Axle stands beyond rated capacity. Overloading can cause damage to, or failure of, the axle
stands. Position load on centre of crutch/saddle only. Always use stands in pairs on hard level surface capable of sustaining
the load. Use of stands on other than hard level surfaces can result in load instability and possible loss of load. DO NOT
use on tarmacadam. Failure to follow these instructions may result in damage to axle stands, loss of load resulting in
property damage, serious personal injury or loss of life.
▲DANGER! Great care must be taken to ensure you lower the vehicle (or other load) slowly and carefully onto the centres of
the crutch/saddle of the axle stands.
9Use only as specified by the manufacturer.
9Ensure the load does not exceed the maximum capacity as marked on the axle stand, per pair.
9Use no more than a single pair of stands either on the front, rear or one side of the vehicle. Use in pairs.
9No alterations or modifications shall be made to this product.
9Use on a hard, level surface, e.g. concrete. Do not use on uneven ground or tarmacadam.
9Securely chock wheels in contact with the ground. Before jacking and placing the stands, apply vehicle handbrake, and place in gear.
(For automatics select the ‘Park’ mode).
9Make sure that each stand is securely located under a strong point on the vehicle; consult the vehicle manufacturer’s
handbook for guidance. Ensure that height adjust locking mechanism is fully located before applying any load to the
axle stand.
9Ensure that the load is located centrally on the saddle, and that the weight is directed through the vertical axis of the
stand.
9Exercise extra care when using with a three wheeled vehicle or a trailer. Refer to vehicle manufacturer’s instructions.
9Once vehicle is supported, ensure that the vehicle and stands are stable before starting work. Ensure that it is not
possible for the vehicle to move before commencing any work.
9Inspect stands before each use.
8DO NOT use if they show signs of damage.
8DO NOT use if it is suspected that they have been overloaded.
9Before commencing any work or going beneath the vehicle, undertake a risk assessment. Ensure that a responsible person is aware
of the work about to be undertaken.
9Replace any labels on the axle stand should they become unreadable. This applies in particular to any warning or operation instruction
labels. If replacement labels are required, contact your Sealey stockist.
8DO NOT use axle stands on the highway, or anywhere else if it is deemed to be unsafe.
8DO NOT push or twist the vehicle/load whilst it is supported on stands.
8DO NOT mix components between stands. Use only as supplied.
8DO NOT allow children or animals in the vicinity of a vehicle supported on axle stands.
8DO NOT leave a vehicle on axle stands in an area that could be considered a hazard to others or property.
9Follow steps 1, 2 and 3 to correctly place vehicle/load onto axle stands.
AS20.V2 Issue 1 24/06/21
Original Language Version
© Jack Sealey Limited
Refer to
instructions
TAKE CARE; you may know the total weight of the load you want to support but you cannot calculate the exact
weight distribution between support points.
For this reason always allow a 40% margin for error.
For example: a load weighing 40tonne could have a single point load of more than 20tonne and two 20tonne
supports would not be adequate.

2. INTRODUCTION
Heavy-duty axle stands to safely support vehicles for extended periods of time. Large crutch for even load distribution. Heavy gauge steel frame
and base plate with welded construction gives superior strength and safety. Supplied with captive, multi-position pin load support. Sold in pairs.
3. SPECIFICATION
Model No:................................................................. AS20.V2
Capacity (each): ........................................................ 20tonne
Capacity (pair):.......................................................... 40tonne
Minimum height:......................................................... 332mm
Maximum height:........................................................ 485mm
4. OPERATION
4.1. Familiarise yourself with the product. Check that the stands are in good condition and that no damage has been sustained during
transit.
4.2. Ensure the maximum load does not exceed 40tonne per pair of axle stands, (20tonne for each stand).
4.3. Refer to vehicle manufacturer’s instructions for recommended support points. Check that the points are in good condition.
4.4. Ensure the vehicle has been placed in gear and that the handbrake has been applied. (For automatics select the ‘Park’ mode).
4.5. Adjust height of stand to correspond with the raised vehicle.
4.6. Check that the locking pin (fig 1 - 3) is correctly pushed all the way through the centre column (fig 1- 1) and out of the other side, then
position stands under vehicle at points recommended by vehicle manufacturer.
4.7. Carefully and slowly lower the load onto stands. Ensure the load bearing points sit in the center of the stand saddle and check that
the stands are stable and not leaning. Also ensure that there are no objects or persons that could impede the safe lowering of the vehicle
onto the stands.
4.8. To remove stands, jack vehicle slightly so that stand can be removed.
4.9. After use, hold the centre column (fig 1 - 1) firmly when removing the locking pin (fig 1 - 3). Failure to do so will allow the center column
to fall freely through the main center tube (fig 1 - 2) with the risk of personal injury.
4.10. When not in use place the locking pin ( fig 1 -3) into it’s circular holder (fig 2 - 1) and leave the centre column (fig 1 - 1) in it’s lowest
position to minimise corrosion.
WARNING! Ensure you follow all instructions carefully. Failure to note these warnings may cause damage, serious injury or loss of life.
5. MAINTENANCE
5.1. Before each use check to ensure stands and stand welds are not cracked, and that there are no missing and/or damaged parts.
WARNING! Any stand that appears to be damaged in any way must be removed from service immediately.
5.1.1. Ensure the locking pins are in good order and condition.
5.1.2. Due to the potential hazards associated with these stands, do not misuse, or make any modification to the stands or components.
5.1.3. It is the responsibility of the stands owner to ensure the operator has read these instructions, and that the operator is familiar with
the stands use and limitations.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice. Please note that other versions of this product are available. If you require documentation for alternative versions, please email or call
our technical team on [e-mail] or 01284 757505.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
fig.1
fig.2
