INSTRUCTIONS FOR
VEHICLE MOVING DOLLY - 2 POST 900KG MAX
LOAD
MODEL NO: VMD001
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Ensure the trolley is in sound condition and good working order. Take action for immediate repair or replacement of damaged parts. Use
genuine parts only. The use of improper parts may be dangerous and will invalidate the warranty.
WARNING! Prepare the vehicle ready for resting and moving on the trolley. Ensure the vehicle will not move, tip, fall etc once it has been
seated on the trolley. Take any necessary precautions to protect persons, property and equipment when using this trolley.
9Locate the trolley in a suitable, well lit working area.
9Keep working area clean and tidy and free from unrelated materials.
9Use trolley on level and solid ground, preferably concrete. Avoid tarmacadam as trolley may sink in.
9Ensure the vehicle engine is switched off .
9Ensure there are no passengers in the vehicle.
9Ensure all non-essential persons keep a safe distance whilst the trolley is in use.
9Only place trolley under those lifting points recommended by vehicle manufacturer (see vehicle hand book).
9Check the lifting point is stable and correctly held in trolley supports.
9Ensure the trolley wheels are free to move and that there are no obstructions.
9Ensure you have a clear view and necessary assistance when transporting vehicle.
9Ensure there are no persons or obstructions beneath the vehicle before moving.
9When stationary, always lock the brake wheels.
8DO NOT operate the trolley if damaged.
8DO NOT allow untrained persons to operate the trolley.
8DO NOT exceed the rated capacity of the trolley.
WARNING! DO NOT use the trolley to hold and move a vehicle which is unstable.
8DO NOT allow the vehicle to move on the trolley.
8DO NOT move vehicle if there is a risk of spillage of fuel, battery acid, or other dangerous substances.
8DO NOT work under the vehicle unless supported by axle stands which have been correctly positioned.
8DO NOT ride on the trolley.
8DO NOT use the trolley without appropriate supports.
8DO NOT use the trolley for purposes other than which it is intended.
9When not in use store trolley in a safe, dry, childproof area.
2. INTRODUCTION
Heavy-duty steel frame suitable for supporting partly dismantled or badly damaged vehicles. Enables easy movement around workshop.
V-crutch supports adjustable for height and overall width. Fitted with four Ø90mm locking nylon castors.
3. SPECIFICATION
Moel No.................................................................... VMD001
Minimum Height ......................................................... 315mm
Maximum Height ........................................................ 495mm
Height increments4X45MM ......................................4X45mm
Minimum Support Width............................................. 350mm
Maximum Support Width .......................................... 1450mm
Width........................................................................ 1500MM
Capacity....................................................................... 900kg
VMD001 | Issue 1 15/09/16
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear safety
footwear

4. ASSEMBLY
 Seeg.1.
4.1. Slide parts (1) into sleeve (2) and bolt together
using 4 bolts suppied, to make cross menber.
4.2. Attach braked castor wheels (4) onto side
supports with bolts, washers and nuts supplied.
4.3. Slide cross member into side supports and clamp
into place using knobs (5).
4.4. Slide “V” crutch supports into side supports adjust
to height required and lock in place using locking
 pin.Securepininplacewithlockingxture.
5. MAINTENANCE
5.1. Before each use check for broken, cracked, bent, or loose parts, or any visible damage. If any suspect item is found remove trolley
from service and take necessary action to remedy the problem.
8DO NOT use the trolley if believed to have been subjected to abnormal load or shock load.
5.2. Keep the trolley clean and periodically oil the wheel bearings.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
