Sealey AP890MHV User manual

HEAVY-DUTY MOBILE TOOL & PARTS
TROLLEY WITH 5 DRAWERS AND LOCKABLE
TOP
MODELS: AP890M & AP890MHV
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
AP890M/HV Issue 2 (3) 11/08/22
Original Language Version
© Jack Sealey Limited
Refer to
instructions
1. SAFETY
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when using this trolley.
9Always load evenly with the centre of gravity of the load as near centre of the trolley as possible.
8DO NOT overload the trolley - see section 3.
9Use the trolley in a suitable work area.
9Keep the work area clean, uncluttered and ensure there is adequate lighting.
9Keep the trolley clean and tidy in accordance with good workshop practice.
8DO NOT use the trolley for any purpose other than that for which it is designed.
8DO NOT stand on the trolley, use it as a ladder or allow others to ride on the trolley.
9Use the wheel locks to prevent the trolley from inadvertently moving.
8DO NOT leave unattended, especially when loaded, unless the wheels are locked, chocked or the trolley otherwise secured.
8DO NOT use trolley on uneven ground and do not run over curbs or steps - use a ramp.
8DO NOT use trolley if any part is significantly damaged, paying particular attention to the wheels.
9Keep children and unauthorised persons away from the work area.
2. INTRODUCTION
Five drawer garage & workshop trolley. With an overall capacity of 320kg evenly distributed. The ve drawers are lined with non-slip liners
and have ball-bearing slides as standard. Features rear locking mechanism which engages once the lockable top lid is closed, adding extra
security. There are extra hand tool storage slots situated on either side within the top compartment. Lined Lower shelf is ideal for larger
parts or tool storage. Fitted with a side handle, two xed castors and two swivel castors with toe brakes to aid manoeuvrability around the
workshop or garage.
3. SPECIFICATION
Model No.: ..........................................................AP890M/HV
Capacity:.........................................................Overall: 320kg
Top tray and Bottom Tray:..................................... 80kg each
2 Small drawers: ...................................................20kg each
Other 3 drawers: ...................................................40kg each
Evenly distributed.
Drawer Size:
Small drawer (x2) (W x D x H): ................ 295 x 430 x 55mm
Small deep drawer (x1):......................... 300 x 430 x 120mm
Medium drawer (x1): ................................624 x 430 x 70mm
Large drawer (x1): ..................................624 x 430 x 120mm
Overall Size: .........................................940 x 515 x 1050mm
Shelf Size (W x D):
Top compartment: ..................................660 x 480 x 120mm
Bottom Tray: ............................................770 x 490 x 90mm

4. ASSEMBLY
NOTE: DO NOT tighten xings until all parts are correctly aligned.
4.1. CASTOR ASSEMBLY
4.1.1. Using items 9, 10 and 11, x locking castors (item 8) to one end
of the underside of bottom tray (item 4).
4.1.2. Using items 9, 10 and 11, x xed castors (item 7) to other end
of the underside of bottom tray (item 4).
4.2.  LEGASSEMBLY(g.1)
NOTE: Holes of 26mm pitch centre are to be tted to outer edge of bottom tray (item 4).
4.2.1. Using items 12 and 13, x legs (item 5) to outer edge of bottom tray (item 4).
4.3.  BRACESASSEMBLY(g.2)
4.3.1. Using items 12 and 13 t braces (items 2 and 3) to legs (items 5).
4.3.2. Using items 12 and 13 t tray (item 18) to brace and leg (item 2 and 5). at locking castor end of unit.
4.4.  DRAWERUNITASSEMBLY(g.3)
4.4.1. Fit drawer unit (item 1) into inside of legs. Place corner sti󰀨ener (item 14) into the corner and x sti󰀨ener and tray in place using
items 12 and 13.
4.5.  ADDITIONALATTACHMENTS(g.4)
4.5.1. Fit lid handle (item 16) to lid using items 17.
4.5.2. Fit side handle (item 6) to frame using items 9 and 13.
4.5.3. Fit gas struts (item 15) between drawer unit and lid using item 11.
Original Language Version
© Jack Sealey Limited
Item Description
1 Drawer Unit
2 Brace (End)
3 Brace (Front)
4 Bottom Tray
5 Leg
6 Side Handle
7 Castor (Fixed)
8 Castor (Locking)
9 Carriage Bolt M8 x 20mm
10 Plain Washer (M8)
11 Nut (M8)
12 Carriage Bolt (M8 x 16mm)
13 Flanged Nut (M8)
14 Corner Sti󰀨ener
15 Gas Strut
16 Lid Handle
17 Bolt M4 x 6mm
18 Can/Tool Tray
12 3 4
5
910 11
12 13 14 15 16
17 18
678
NOTE: Holes of 26mm pitch
centre to be used to x to tray.
g.1
g.2
g.3 g.4
AP890M/HV Issue 2 (3) 11/08/22

5. MAINTENANCE
5.1. Periodically lubricate castors and tighten all hardware.
5.2. Clean the surfaces with a soft cloth and a mild water/detergent solution.
Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
