SeaView SM-18-R User manual

INSTALLATION
INSTRUCTIONS
For Seaview Mast Mount:
SM-18-R
WWW.SEAVIEWGLOBAL.COM
Refer to website for most up to
date instructions and videos.

SMMBL-2
x1
SMMBR-2
x1
5/16” = 8mm 3/16” = 4.7mm
15/16” = 25mm
Tef-Gel or Equivalent
Sharpened dowel pin
X1
X2
X2
X3
X10
X12
X4
X14
X1
X1X1 X2
TOOLS NEEDED
PARTS INCLUDED
Sudbury Elastomeric
Marine Sealant is
recommended. To
purchase call 800-655-7922
or visit
www.seaviewglobal.com
1

SM-AD-ISO
1Please note that when
installing the Seaview Mast
Mount, have it facing the
forward end of the boat.
2
3
If installing on a isomat mast you will need a Seaview isomat
adapter. Part number SM-AD-ISO.
Place the SM-18-R onto the mast and mark all the holes of each
mounting feet. Be sure that the mast mount is level. If the mast
mount feet are not assembled refer to the diagram step 16.
2

4Using a 3/16” drill bit, drill all
the marked holes.
5
6
Use a hole saw to drill a
hole for the cables. Be sure
to drill in the center of the
mast.
Punch a hole through the
rubber grommet using a
sharp dowel.
3

7Insert the rubber grommet
into the hole you drilled for
the cables.
8
9
Put some marine adhesive
sealant into the holes. Do
not apply too much sealant.
Insert the black nylon
shoulder washers into the
correct holes on the mast
mount feet. Use the supplied
rivets to secure the mast
mount to the mast.
4

10
11
Mark two holes to fasten the anchor.
Drill the two holes.
5
12 Apply marine adhesive sealant to the two holes.

6
13 Secure the anchor to the mast using two rivets. Make sure the
lanyard is on the anchor prior to securing rivets.
14 Insert four nylon shoulder washers to the rails of the mast
mount.
Using your own hardware secure the radar to the mast mount.

15 Mount the radar as close to the mast as possible.
7
16 SM-18-R Mast Mount foot assembly.
Stainless
steel washer
Nylon washer
Long nylon
shoulder
washer
Long nylon
shoulder
washer

ISOMAT ADAPTER FLYBRIDGE
ADAPTER
SM-AD-ISO
For masts with an integral track at
the front which makes it dicult
to t a Seaview mast mount. Made
from marine grade aluminum and
powder coated brilliant white.
SM-AD-FB
Adjustable ybridge adapter kit with
35° of adjustment.
OPTIONAL ACCESSORIES
Call 800-655-7922 or visit www.seaviewglobal.com for available accessories.
SS MAST MOUNT GUARDS
Protect your radome from damage
and reduce wear and tear on the
sails with Seaview Mast Mount
Guards. Available for 18” - 24” closed
dome radars.
8

9
THIS PAGE IS INTENTIONALLY
LEFT PLANK.

10
THIS PAGE IS INTENTIONALLY
LEFT PLANK.
