SEI NASSAU SPACESAVER BE7181 User manual

SOUTHERN ENTERPRISES INC.
RELAX...If you can follow a few easy, step-by-stepdirections
in order .YOU CAN ASSEMBLE THIS ITEM.
WHITE STYLE NO:BE7181
NATURAL STYLE NO: BE7581
NASSAU SPACESAVER
PLEASE FIND HARDWARE IN RED POLYBAG BEFORE DISCARDING PACKING MATERIAL.
HARDWARE LIST
(1) WOOD DOWELS 40PCS (8) SHELF SUPPORTS 8PCS
(2) METAL KNOBS 4PCS (9) T-BOLTS 12PCS
(3) LONG FLAT HEAD WOOD SCREWS 6PCS (10) LOCK WASHERS 12PCS
(4) SHORT FLAT HEAD WOOD SCREWS 8PCS (11) LONG MACHINE SCREWS 12PCS
(5) LONG PAN HEAD WOOD SCREWS 16PCS (12) PLASTIC COVERS 8PCS
(6) SHORT PAN HEAD WOOD SCREWS 20PCS (13) SHORT MACHINE SCREWS 4PCS
(7) MAGNET 1PC (14) PLASTIC ANCHORS 2PCS
PARTS LIST
(A) LEFT UPPER SIDE PANEL 1PCS (L) BACK PANEL 1PC
(B) RIGHT UPPER SIDE PANEL 1PCS (M) LEFT SIDE DOOR 1PC

(C) LEFT LOWER SIDE PANEL 1PC (N) RIGHT SIDE DOOR 1PC
(D)RIGHT LOWER SIDE PANEL 1PC (O) LOWER BACK CROSS BRACE 1PC
(E) TOP PANEL 1PC (P)DIVIDER 1PC
(F) BOTTOM PANEL 1PC (Q) LEFT DRAWER FRONT PANEL 1PC
(G)UPPER BACK CROSS BRACE 1PC (R) DRAWER BACK PANELS 2PCS
(H) FRONT CROSS BRACE 1PC (S) DRAWER BOTTOM PANELS 2PCS
(I) MIDDLE BACK CROSS BRACE 1PC (T) DRAWER LEFT SIDE PANELS 2PCS
(J) FIXED SHELF 1PC (U) DRAWER RIGHT SIDE PANELS 2PCS
(K) ADJUSTABLE SHELVES 2PCS (V) RIGHT DRAWER FRONT PANEL 1PC
ASSEMBLY INSTRUCTION
1. SELECT A SMOOTH, SOFT SURFACE TO PREVENT SCRATCHING FINISH.
2. YOU MAY NEED A PHILIP SCREWDRIVER.

3. INSERT WOOD DOWELS (1) INTO ENDS OF UPPER BACK CROSS BRACE (G), FIXED SHELF (J) AND
FIT INTO THE CORRESPONDING HOLES ON INSIDE OF THE LEFT AND RIGHT UPPER SIDE PANELS
(A, B). AS FIGURE 1 AND INSET SHOWN.
4. INSERT WOOD DOWELS (1) INTO EDGES OF UPPER BACK CROSS BRACE (G), LEFT UPPER SIDE
PANEL(A), RIGHT UPPER SIDE PANELS (B) AND FIT INTO CORRESPONDING HOLES ON TOP PANEL
(E). INSERT T-BOLTS (9)INTO THE HOLES NEAR TOP EDGES OF LEFT AND RIGHT UPPER SIDE
PANELS (A, B) WITH SLOT FOR SCREWDRIVER FACING OUTWARD. INSERT LONG MACHINE
SCREWS (11) THROUGH LOCK WASHERS (10), PREDRILLED HOLES ON TOP PANEL (E) AND
TIGHTEN INTO T-BOLTS (9). INSERT WOOD DOWELS (1) INTO TOP EDGE OF DIVIDER (P) AND FIT
INTO CORRESPONDING HOLES ON UNDERSIDE OF FIXED SHELF (J). INSERT WOOD DOWELS (1)
INTO PREDRILLED HOLES ON BOTTOM EDGES OF DIVIDER (P), LEFT AND RIGHT UPPER SIDE
PANELS (A, B) AND FIT INTO CORRESPONDING HOLES ON BOTTOM PANEL (F). INSERT T-BOLTS(9)
INTO THE HOLES NEAR BOTTOM EDGES OF LEFT AND RIGHT UPPER SIDE PANELS (A, B). INSERT
LONG MACHINE SCREWS (11) THROUGH LOCK WASHERS (10), PREDRILLED HOLES ON BOTTOM
PANEL (F) AND TIGHTEN INTO T-BOLTS (9). PLEASE NOTE THAT IF SCREWS DO NOT TIGHTEN,
ROTATE T-BOLTS (9) SO THAT THREADSOF T-BOLTS (9) FACING LONG MACHINE SCREWS (11).
PUSH PLASTIC COVERS 12) INTO HOLES ON TOP PANEL (E) ONLY. AS FIGURE 2 SHOWN.

5. ATTACH BACK PANEL (L) INTO SLOT OF PARTS(A, B, F, G). TIGHTEN SHORT PAN HEAD WOOD
SCREWS (6) THROUGH PREDRILLED HOLES ON BACK PANEL(L)INTOREAR EDGES OFPARTS(A, B,
F,G). AS FIGURE 3 SHOWN.
6. INSERT SHORT PAN HEAD WOOD SCREWS (6) THROUGH ENDS OF MAGNET (7) AND TIGHTEN INTO
PREDRILLED HOLES ON UNDERSIDE OF TOP PANEL (E).INSERT SHORT FLAT HEAD WOOD SCREWS
(4) THROUGH HINGES ON LEFT AND RIGHT UPPER SIDE PANELS (A, B) AND TIGHTEN INTO
PREDRILLED HOLES ON BACK OF LEFT AND RIGHT SIDE DOORS (M, N). INSERT SHORT MACHINE
SCREWS (13) THROUGH BACK OF LEFT AND RIGHT SIDE DOORS (M, N) AND TIGHTEN INTO METAL
KNOBS (2). AS FIGURE 4 AND INSETSHOWN.
7. FIT SHELF SUPPORTS(8) INTO PREDRILLED HOLES ON INSIDE OF LEFT AND RIGHT UPPER SIDE
PANELS (A, B). PUT ADJUSTABLE SHELVES (K) ON EACH SHELF SUPPORT (8) MATCHING THE
POSITION OF GROOVES ON ADJUSTABLE SHELVES (K). AS FIGURE 5 AND INSET SHOWN.

8. INSERT WOOD DOWELS (1) INTO EDGES OF FRONT CROSS BRACE (H), MIDDLE BACK CROSS
BRACE (I), LOWER BACK CROSS BRACE (O) AND FIT INTO CORRESPONDING HOLES ON INSIDE OF
LEFT AND RIGHT LOWER SIDE PANELS (C, D). INSERT T-BOLTS (9) INTO THE HOLES ON ALL CROSS
BRACES (H, I, O) WITH SLOT FOR SCREWDRIVER FACING OUTWARD.INSERT LONG MACHINE
SCREWS (11) THROUGH LOCK WASHERS (10), PREDRILLED HOLES ON OUTSIDE OF LEFT AND
RIGHT LOWER SIDE PANELS (C, D) AND TIGHTEN INTO T-BOLTS (9). PLEASE NOTE THAT IF
SCREWS DO NOT TIGHTEN,ROTAT E T-BOLTS (9) SO THAT THREADS OF T-BOLTS (9) FACING LONG
MACHINE SCREWS (11).PUSHPLASTICCOVERS (12)INTO HOLES ON OUTSIDE OF LEFTANDRIGHT
LOWERSIDEPANELS (C, D). AS FIGURE 6 AND INSET SHOWN.
9. INSERT WOOD DOWELS (1) INTO TOP OF FRONT CROSS BRACE (H), MIDDLE BACK CROSS BRACE
(I), LEFT AND RIGHT LOWER SIDE PANELS (C, D). WITH AN ASSISTANT, LIFT ASSEMBLED UNIT
ABOVE THE BASE AND INSERT WOOD DOWELS (1) EXTENDING FROM THE BASE INTO THE
CORRESPONDING HOLES ON UNDERSIDE OF BOTTOM PANEL(F).INSERT LONG FLAT HEADWOOD
SCREWS (3)THROUGH PREDRILLED HOLES ON WOOD BAR ON LEFT AND RIGHT LOWER SIDE
PANELS (C,D) AND TIGHTEN INTO PREDRILLED HOLES ON UNDERSIDE OF BOTTOM PANEL(F).AS
FIGURE 7 AND INSET SHOWN.

10. INSERT SHORT MACHINE SCREW (13) THROUGH BACK OF LEFT AND RIGHT DRAWER FRONT
PANELS (Q, V) AND TIGHTEN INTO METAL KNOBS (2). INSERT LONG PAN HEAD WOOD SCREWS (5)
THROUGH PREDRILLED HOLES ON OUTSIDE OF DRAWER RIGHT SIDE PANEL (U) AND TIGHTEN
INTO PREDRILLED HOLES ON ENDS OF LEFT DRAWER FRONT PANEL (Q) AND DRAWER BACK
PANEL(R). SLIDE DRAWER BOTTOM PANEL (S) INTO GROOVES ON LEFTDRAWERFRONTPANEL(Q)
AND DRAWER BACK PANEL (R) AND ALIGN WITH GROOVE ON DRAWER RIGHT SIDE PANEL (U).
INSERT LONG PAN HEAD WOOD SCREWS (5) THROUGH PREDRILLED HOLES ON OUTSIDE OF
DRAWER LEFT SIDE PANEL (T) AND TIGHTEN INTO PREDRILLED HOLES ON ENDS OF LEFT
DRAWER FRONT PANEL (Q) AND DRAWER BACK PANEL (R). PERFORM THE SAME WAY TO
ASSEMBLE RIGHT DRAWER FRONT PANEL (V), DRAWER BACK PANEL (R), DRAWER BOTTOM
PANEL (S), DRAWER LEFT AND RIGHT PANELS (T, U). AS FIGURE 8 SHOWN.
11. PLACE THE ASSEMBLED DRAWERS INTO THE SPACE OF THE UNIT. AS FIGURE 9 SHOWN.
12. IN ORDER TO STAND STURDILY. DRILL TWO 1/4” DIAMETER HOLES ON WALL, THE DISTANCE
BETWEEN TWO HOLES SHOULD MATCH TO THE HANGING HOLES ON BACK OF UPPER BACK
CROSS BRACE (G). FIT PLASTIC ANCHORS (14) INTO THE HOLES ON WALL. USE SCREWDRIVER TO
FITLONGFLAT HEAD WOOD SCREWS (3) INTO PLASTIC ANCHORS (14). THEN FIT HANGING HOLES
ON UPPER BACK CROSS BRACE (G) TO THE LONG FLAT HEAD WOOD SCREWS (3). AS FIGURE 9
SHOWN.
YOUR NEW NASSAU SPACESAVER IS FINISHED AND READY TO USE.

Please count, identify and compare parts and hardware list to be sure all parts are present. Extra hardware may
be included. If any items are missing, please contact our parts/ service department at [phone] or in
Dallas [phone]/ 9am-4pm Mon-Fri central time. Missing or damaged hardware and/ or parts will be
replaced free of charge. WE DO NOT SELL PARTS.
WE DO NOT RECOMMEND MODIFYING PRODUCT(S) AND WE ARE NOT RESPONSIBLE FOR
ANY DAMAGES DUE TO PRODUCT MODIFICATION(S).
PARTS REPLACEMENT FORM
WHITE STYLE NO: BE7181
NATURAL STYLE NO:BE7581
CustomerName PARTS
LETTER PART DESCRIPTION QUANTITY NEEDED
Street, City, State, Zip
Phone#
Pleaseindicate where you purchased this item.
Store/website/catalog
/ /
SOUTHERN ENTERPRISES INC.
P.O. Box 59996 Dallas, Texas 75229 Please indicate color/size/style number
/ /
