Sekonic SPEEDMASTER L-858D User manual

Internal Photograph for L-858D February 6, 2017
SEKONIC CORPORATION
Back side without Battery Cover
Transmitter module installation

Basic Internal

Transmitter module installation
The installed position of transmitter module RT-20PW
PW
Connection between antenna PCB and transmitter module
Antenna PCB
Cable connection between
Antenna PCB and transmitter module
12pin Connector for connection of
transmitter module

PCB 1 Top View

PCB 1 Bottom View

Antenna PCB Top View
Antenna PCB Bottom View
