Sekonic STUDIO DELUXE? L-398A User guide

L-398A
STUDIO DELUXE III
70th Anniversary Edition
Startup Guide
Thank you for purchasing L-398A STUDIO DELUXE III 70th Anniversary Edition. Please read
the ”Operating Manual” and ”Safety Precaution” so that you will fully understand the features
and operation of this product.
Keep the documents included in the package in a safe place for future use.
This Startup Guide introduces the basic operations of this light meter.
For details about how to use this light meter, please see the Operating Manual.
For information on how to download the Operating Manual, please see ”1. Download”.
1. Download
Please visit www.sekonic.com to download the latest
version of the operating manual as follows.You can
also use the URL below for direct access to the
operating manual.
URL: http://www.sekonic.com/support/instructionma
nualuserguidedownload.aspx
2. Check Included Items
The following items are included with the meter in the package.
Please be sure to check that all noted items are included.
※If any items are missing, please contact the distributor or the reseller
you purchased the meter from.
Meter Display Box Lumisphere
（For Decoration）
(with rose gold ring)
Lumisphere
(For Measurement)
(with black ring)
High Slide Safety
Precaution
Greeting
Letter
5
1
0
2
0
4
0
8
0
1
6
0
3
2
0
6
4
0
1
.
2
5
k
-
2
-
1
+
1
+
2
-
2
-
1
+
1
+
2
0
1
1
1
2
E
V
S
t
u
d
i
o
D
e
l
u
x
e
L-398A
1
.
2
5
k
6
4
0
3
2
0
1
6
0
8
0
4
0
2
0
1
0
5
0
2
28
4
56
8
11
16
11.4
60
30
15
8
4
2
1
2
8
15
30
60
125
250
500
1
k
1/SEC
8
k
4
k
4
2
k
100
50
200
ISO
8
18
24
64
128
CINE
128
90
64
45
32
22
16
11
8
5.6
2.8
4
2
1
0.7
F
1.4
H
Ⅲ
Safety Precaution

For Proper Operation
Beforeusing this product, please read this "Safety Precautions" for
properoperation.
WARNING
TheWARNING symbol indicates the
possibilityof death or serious injury if the
productis not used properly.
CAUTION
TheCAUTION symbol indicates the
possibilityof minor to moderate personal
injuryor product damage if the product is
notused properly.
NOTICE
TheNOTICE symbol indicates cautions
orrestrictions when using the product.
Pleaseread all notes to avoid errors in
operation.

General Safety Information
•Read the Operating Manual before use.
•Keep the Operating Manual on hand for reference at any
time.
•Stop using this product when there are any abnormalities.
•The modication or disassembly of this product is prohibited.
•Do not attempt to repair this product by yourself.
•This product is intended only for persons with expert
knowledge.
•Monitor children so that they do not touch this product.
•Use this product in a usage environment described in the
OperatingManual.
•This product is not waterproof.
WARNING
Thereis a danger of electrical shock when using high
voltagestrobes.
Avoidcontacting the terminals.
Thisproduct emits electromagnetic waves.
Donot bring this product close to persons with
pacemakers.
Donot use this product in an explosive atmosphere.
Useof devices emitting electromagnetic waves is
prohibitedin hospitals.
CAUTION
•Check the material of the neck strap to see if there is any
riskof allergy.
•Be careful of sudden emission of lights from strobes.
NOTICE
•Do not leave this product on car dashboards in hot weather.
Thismay damage the product.
•Remove the batteries when this product is not in use for a
longperiod of time.
•When the desired performance is not achieved, stop using
thisproduct and contact the service center.
Informationfor Users on Collection and
Disposalof Old Equipment
Toprotect environment, do not through this device
andbatteries away with the normal household waste
atthe end of those life, but bring them in at an
ofcial collection point of your country for recycling.
English June1st,2021
SekonicCorporation
ToOurLoyal Custom er
Congratulationson your recent purchase of the “L-398A Studio Deluxe
III,LimitedEdition” 70th anniversary commemorative light meter.
The value of a light meter in the hands of a photographer or
cinematographerextends far beyond the basic principles of whata light
meterisand what it does in its b asic sense. To the imagemaker, the light
meterisa translation tool,that measures the brightness of a light source
andcommunicatesit into the language of exposure. This commo nly used
languageembodiesthe es sence of capturing the highlights and shadows
usedtodefine the character, the mood, the expression, and the message
conveyedthrough the image.
For70 years, Sekonic Corporation has designed and manufactured the
mostinnovative and sophisticated light measuring instrume nts in the
photographicand Cine/Video industry. Our commit ment to meet and
exceedthedemands of the professional and their expectations continues
withavigorous passi on.
Fromour humble beginnings, when the first Sek onic light meter was
createdin1949 and two years later when the company was established
as“Seiko Electronic Co. Ltd” in 1951, we never lost sight of our design
andengineeringpassion. Throughout the years, Sekon ic diversified into
othermarkets such as 8mm movie cameras and projectors, as well as
industrial Recorders, Plotters, Optical Mark Readers, Surveillance
camerasandother indust rial products.
Overthe years, one produc t became the symbolic hallmark of the
Sekonicbrand,the Studio Deluxe series. Today, the L-398A III continues
tobe a favorite of traditional photographers, educators, and seasoned
cinematographers.
Wearehonored and appreciative, that you have invested in a piece of
ourlonghistory and wi sh you continued success and passion, as you
celebratetheart a nd creativity of the still and moving image.
Strap（Leather） Lumidisc Lumigrid Soft Case
（Leather）
Startup Guide
(This document)
CE Distributor
List
日本語 露出計 スタートアップガイド
English LightMeter StartupGuide
Lichtmessgerät
Deutsch Startanleitung
Français Posemètre Guidede démarrage
Español Fotómetro Guíade inicio
Italiano Esposimetro Guidaintroduttiva
中文 测光表 使用简介
L-398A
STUDIO DELUXE III
70th Anniversary Edition
Country Company Name Address
Austria FotoKoeberlGmbH
sagafoto
Steyrergasse39,8010,
Graz,Austria
Belgium Servix.be Kontichsesteenweg41,
Aartselaar,2630,Belgium
Bulgaria DynaphosLtd Bul.TsvetanLazarov 90,
Sofia1582,Bulgaria
Croatia Prizma d.o.o. Špansko 22, Zagreb, 10090,
Croatia
Czech
Republic PENTACZs.r.o Kosmeticka 450, 387 11 Katovice,Czech Republic
Denmark
Sweden GoeckerA/S Hejrevej372400, Copenhagen,Denmark
DeputyinEU
France
Germany
UK
VitecImaging
Distribution
ViaValsugana100, 36022
Cassola(VI),Italia
Estonia Fotoluks AS Pärnu mnt 134, Tallinn,
11317,Estonia
Greece Konchilakis S.A.
42,VenizelouStr.,
Thessaloniki,546,24,
Greece
Hungary Computer
EmporiumKft.
ReitterFerencu. 132,
Budapest,H-1131,Hungary
Italy ApromastoreSRL Via Achille Grandi 21 20017
MAZZODIRHO (MI), Italy
Latvia SIA ELKOR TRADE 201.Brivibas str, Riga,
LV1039,Latvia
CECountries
English
Light Meter

WARNING
●Keep Lumisphere, Lumidisc, Lumigrid or High-slide out of reach of young
children,as swallowing such objects can cause su󱐯ocation.
●Infants or toddlers may accidentally wrap the strap around their neck,
so please place it in a location out of their reach. There is a danger of
su󱐯ocation.
●If the leather touches the skin directly, itching or rash may occur on
the skin due to leather allergy. If you feel any abnormality, stop using it
immediately and consult a doctor.
CAUTION
●This L-398A has a powerful magnet. Do not place it close
to the following materials, otherwise the data stored may be
damaged or the products may malfunction:
Cash cards, floppy disc, other magnetic cards, TV Set, CRT
display or LCD, and other apparatus sensitive to magnetic
elds.
●Do not touch the sensor inside directly when the light receiving part
is detached, as it may cause the damaged parts and/or incorrect
measurement.
●When using the soft case or strap in the rain, be careful not to get it wet.
Leaving the moisture on the leather for a long time may cause deterioration.
NOTE
The sensor component of L-398A has a protective glass closely adhered
to amorphous silicon. Due to the high degree of adhesion, rainbow-colored
interference fringes appear on the surface, but this does not affect the
measured values and performance.
Leather care
If you do not use the leather product for a long time, please wipe it o󱐯 with a
dry cloth to remove sweat, dirt, and moisture, and store it away from high / low
temperature and high humidity.

3. Part Designations
4. Basic Operation
1）Incident Light Measurement
From position where subject is to be measured, point Lumisphere ❶ in
direction of camera. Set ISO value to use with lm sensitivity knob ⓴. Press
stopper button ⓭. Meter needle ⓲ deects according to brightness. When
the stopper button is released, the meter needle ⓲ becomes xed at the
deected position. If the location is excessively bright and the meter needle
⓲ deects beyond scale, insert the High slide.
Read the foot-candle scale ❸ of the meter
needle ⓲. Transfer foot-candle value to the
dial scale ❼. Rotate the dial ring ⓰ and set the
scale mark ( ▲ ) ❽. If the High slide has been
inserted, set the H scale mark ( ) ❾. At this
time, the shutter speed scale ⓮ and aperture scale ⓯ combination becomes
the correct exposure.
