Selmo Thesis Easy User manual

Pg. 1
The electric resistance is not powered and all
lights are turned off.
"Timer" mode:
This operating mode cyclically repeats every 12 or
24 hours the “Boost” mode.
White
Chrome
THESIS is compliant with the followingEASY
standards:
-Eco-design Directive for Energy-using Products,
2005/32/EC (<0,5W).
-EN 60335-1:2012
-EN 60335-2-30:2011
-EN 60335-2-43:2008
-EN 61000-3-2:2004 - EN 61000-3-3:1995
-EN 55014-2:1998 -EN 55014-1:2008
-EN 50366:2003
Functions
Four operational modes:
"Comfort", "Boost", "Stand-by", "Timer"
•"Comfort" mode:
•
•
•
"Boost" mode:
In “Boost” mode the heating element is activated
for a period of 2 hours. During this time interval,
the electrical resistance warms the room
independently of the configured “Comfort”
settings. The temperature is however
automatically adjusted in order not to exceed
3 °C. At the end of the 27 hours period, the device
returns to previous operational mode.
“Stand-by" mode:
THESIS EASY is a special device that controls the
power output of the heating element between 20% and
100% by acting on the rotation of the knob. An
important element for the safety of people is the useful
presence of the NTC sensor which prevents the
ambient temperature from exceeding 37° C, in
compliance with European legislation. It can be
assembled with different heating elements that can be
easily found or replaced by the major European
manufacturers.
The thermostat manage power of heating
resistance in percentual of time between 20%
amd 100% (MAX).
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018

Pg. 2
Technical specifications
Supply voltage 230VAC - 50Hz
Maximal power 2000W - 230VAC
20% 100%÷
Operational temperature
Selectable power range
-10°C ÷ +40°C
IP degree IP44
Insulation class Class I, Class II
Certification mark CE
Environment WEEE, RoHS
Size 113x73x39mm (plastic case)
Product Electronic control for electric towel radiators
Control type Electronic control
Type of applications Towel radiators
Temperature setting Analog through rotating knob
Signaling Led /
operational modes
-Red/Blue backlit button "On/Stand-by”.
-Amber/green/red Led.
-Operational modes: Comfort, Stand-by, Boost 2h, Timer.
Connector of the heating element 6,3x0.8mm Faston:Neutral, , (Class I)Phase Ground
Temperature sensor 10KOhm a 25°C, Type NTC
Compliant standards EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3,
EN60335-1, EN60335-2-30, EN60335-2-43, EN50336.
Warranty 2years
Plastic box / knobs / buttons ABS-V0 Silver, ABS-V0 White RAL9003
Power cable H05VVF <HAR> L=900mm; 3x1mmq - Class I; 2x1mmq - Class II;
Available electric plugs IT-UK-Shucko-CH (Cable length =1200mm)
White White cable RAL 9003
Available colors
Chrome Gray cable RAL 7001
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018

Pg. 3
WARNING
Preserve with care the present instruction sheet and read carefully before using the device.
• The present device has been designed for exclusive use on a towel radiator.
• The thermostat is designed for heating the liquid contained inside a towel radiator in
combination with a heating element. Any other use is forbidden.
• Before using, carefully ensure that the line voltage is the same as that specified for
the device (see technical specifications).
• Only use heating elements compatible with the type of used towel radiator.
• Disconnect power supply before cleaning or performing maintenance of the product.
• In case of damage of the power supply cable shut down the device and do not tamper
with it. The damaged power supply cables can be replaced exclusively by the
manufacturer or by an authorized service center. Failure to comply with the above
rules could lead to compromised system safety and void the warranty.
• Store and transport the heating element exclusively in the protecting packaging.
• Replacement of the heating element can be done exclusively by the product manufacturer.
RISK OF ELECTRIC SHOCK!
Disconnect power supply before proceeding with installation.
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018

Pg. 4
YES
NO
Installation instructions
"Thesis plus" is an electronically controlled thermostat compatible with the
heating element types showed in the picture below.
IMPORTANT:Pay attention to the maximal length of the
19mm connector (see picture on the left). Longer
connectors could damage the device.
Puls
.
.
CLEANING
• Disconnect the device from the electrical power supply before cleaning or performing maintenance
operations.
•Use only gentlecleaning agentsand no abrasive cleaning t
ool
s.
WARNING:
Disconnect the power supply before proceeding with installation.
The installation has to be performed only by authorized personnel.
Thread
Fastening
area
Insulation
Connector 2 Faston 6,3x0,8mm.
Backlit "On/Stand-by" button
Temperature Sensor
Power supply cable
“Boost” and “Timer” LED
Button for “Boost 2h” and
“Timer” modes
Temperature setting knob
(Range 7°C–32°C)
Wrench
Back fastening screw
Heating element connector
Earth connection (only Class I)
Ring
“O-Ring”
Heating Element
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018

Pg. 5
1. Make sure that the towel radiator does not have leakageor air lock.
2. The device shall not be positioned directly in front of an electric plug.
3. Prevent water jets from hitting the equipment.
4. Connect the temperature controller only to a suitable heating element.
5. Ensure that the mains voltage is the same as indicated in the technical specifications.
6. Make sure that the type of electric resistance is compatible with the model of towel radiator
being used (check the product specifications provided by the manufacturer). The usage of a
heating element with higher power:
- Does not increase the actual power of the towel radiator;
- Might shorten life of the heating element;
- Could damage the equipment.
7. Make sure that the power of the electric resistance does not exceed the maximum power
of the towel radiator (check the label on the heating element).
8. When installed in a room with bathtub or shower, respect the “Protection Zones” according to
IP44 insulation class (in UK according to IEE cabling directives). Furthermore, make sure to
respect all local safety directives.
9. The device has to be protected by a 30mA circuit breaker (RCD).
10. Power the device with the recommended voltage (see technical specifications).
11. If a device is directly connected to a fixed electric installation, install an isolating switch
compliant with local directives for power supply disconnection.
12. Place the "O-Ring" before the fastening area.
13. After ensuring that the "O-Ring" is correctly positioned, screw the electric resistance in the
relevant threaded hole of the towel radiator, properly secure it and insert the cover ring.
14. Extract the connecting cables from the device. The two Faston connectors and the Class I
ground connector.
15. Insert the 2 Faston into the relevant connectors of the heating element.
16. Connect the female Faston connector to Earth (only Class I).
17. Insert the lower part of the heating element into the ready connected thermostat.
18. Align the device to the towel radiator. Warning! Do not rotate the device more than 30
degrees on both directions.
19. Push the device against the base of the heating element to compress the “O-Ring”, properly
fix the related fastener so that the device remains well secured and does not rotate around
the heating element.
20. Connect the power supply cable.
DISPOSAL
This product may not be treated as ordinary household waste. It has to be disposed in proper waste
collection sites. In case of replacement it shall be returned to the distributor.
Such an end-of-life treatment of the product will preserve the environment and will reduce
consumption of natural resources.
This symbol applied to the present product indicates the obligation to bring it to a proper waste
collection site, in order to let it be disposed according to 2002/96 / CE (RAEE - WEEE) directives.
• Disconnect power supply before installation.
• Only qualified personnel can connect the electronic device to the heating element.
• Make sure that the power of the electric resistance does not exceed the maximum power allowed
by the electronic control device.
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018

Pg. 6
Water protection:
The IP44 protection level is
guaranteed by a special
design of the connection
parts.
Cable locking system:
According to the IEC
directives and fulfilling the
IP44 requirements, this
mechanism extends life of
the power cable.
Small dimensions:
Reduced device volume and thickness.
Internal buzzer:
For acoustic
warnings
according to
EN60335-1
directive.
External sensor:
Guarantees a stable room temperature and a prompt reaction in case of strong temperature
variation.
Plastic cover: The
connecting part to the
heating element is kept
hidden by this special
layout, so that the device
fits perfectly to the towel
radiator.
Blue / red backlit button: The
backlight indicates the status of
the system.
Thermostat knob with button:
For easily setting the desired
“Comfort” and forpower
activating the “Boost” and “Timer”
modes.
Red / green / amber Boost Led:
A small light indication informs the user
when “Boost” and “Timer” modes are
active.
Quick Guide
Off
Off
Off
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018

Pg. 7
• “On/Stand-by” button: Pressing the “On/Stand-by” button it is possible to switch between “Stand-by”
mode and “Comfort” mode.
NOTE: When the device goes into “Stand-by” mode it beeps twice for 0.5s.
When the device is activated it beeps once for 1s.
“Stand-by” mode.
“Comfort” mode: Heating element is ON (red light).
“Comfort” mode: Heating element is OFF (blue light).
•Knob rotation:
The rotation of the knob sets the desired power output . A clockwise rotation
increases the set value (power 100%) . tationAn anticlockwise ro decreases the
set vapower lue (20%).
•Knob button:
- “Boost” mode (2h). Press once the knob button in order to activate this operating mode (the
heating element will be activated at maximum power for 2h). To deactivate this operating mode,
press again the button.
“Boost” mode ‘’Boost2h’’for 2 hours of 100% continuous heating;
- “Timer-24h” mode: Press the knob for 3 seconds to activate this function. The control
system activates the heating element for 2 hours regardless of the set temperature
value (the maximal reachable temperature is 3 °C), after that7iOff’’t returns into “
mode and after 22 hours the “Boost” mode is started again for 2 hours. This sequence
will repeat endlessly.
“Timer-24h” mode T24h command starts 2h Boost automatically every day at the same time
- “Timer-12h” mode: Press the knob for 5 seconds to activate this function.
The control system activates the heating element for 2 hours regardless of the set
temperature value (the maximal reachable temperature is 3 °C), after that it returns into7
‘’Off ‘’ mode and after 10 hours the “Boost” mode is started again for 2 hours. This
sequence will repeat endlessly.
“Timer-12h” mode:T12h command starts 2h Boost automatically every 12 hours
Operating mode deactivation: To exit any time from the operating modes “Boost”, “Timer-12h”,
“Timer-24h”, press the knob button or the “On/Stand-by” button.
NOTE. The maximal reachable temperature in “Boost” mode is 3 °C.7
(2h on, 22h off) (typically for morning showers);
(2h on, lOh off, 2h on, lOh off (typically morning and evening showers).
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018

Pg. 8
Backlit on/off button
STATUS
Red led ON Heating element turned on.
Blue led ON Power rating reached
heating element turned off.
Switched off "Stand-by" mode active.
Blinking
Red/Blue
Error message. The
heating element is
turned off. Contact
assistance.
*The duration of the first "Comfort" cycle is of 21h.
** The duration of the first "Comfort" cycle is of 9h.
Repairs carried outby unauthorized personnel invalidate warranty.
The manufacturer reserves the right tomake any changes to the product described in this
manual, at any time, and without prior warning.
Blinking red "Boost" mode active. The heating
element remains active for 2h. For
safety reasons, the maximum
temperature is of 3 °C.7
Control Led
Blinking
green
"Boost" mode active (Timer 24). The
heating element remains active for
2h. For safety reasons, the
maximum temperature is of 3 °C.7
Permanent
green
Back to " " mode for 22h.Off
*
Blinking
amber
"Boost" mode active (Timer 12). The
heating element remains active for
2h. For safety reasons, the
maximum temperature is of 3 °C.7
Permanent
amber
Back to " " mode for 10h.off
**
“Thesis Easy”
Electronic Control for Towel Heaters
Comfort technology division
Selmo
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it(PD) Italy- Tel [phone], Fax [phone] -
Selmo Electronic
Via Pacinotti, 24 - 35030 Rubano www.selmo.it EN
Rev. 01 - Oct. 2018
