Sencor SFH 8990BK Repair manual

EN CERAMIC TOWER HEATER
Translation of the original manual
This product is suitable only for well insulated spaces or occasional use!
SFH 8990BK

SFH 8990BK

A
1
2
3
6
5
4

B
2134567
21
ºC
C
1
2
3
4
5
6

- 1 - 04/2023
2023, .
EN Ceramic tower heater
Important safety instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
• This appliance may be used by children 8 years of age
and older and by persons with physical, sensory or mental
impairments or by inexperienced persons, if they are
properly supervised or have been informed about how to
use of the product in asafe manner and understand the
potential dangers.
• Children must not play with the appliance. Cleaning
and maintenance performed by the user must not be
performed by unsupervised children.
• In the event that the power cord is damaged, have it
repaired at aprofessional service centre to prevent causing
adangerous situation. It is forbidden to use the appliance if
it has adamaged power cord.
• Children younger than 3 years of age should be prevented
from accessing the appliance unless they are under
constant supervision.
• Children from 3 to 8 years of age must only turn this
appliance on/off under the condition that it is located or
installed in its intended normal operating position and
that they are under supervision or were informed about
the safe operation of the appliance and understand the
potential hazards. Children from 3 to 8 years of age must

- 2 - 04/2023
2023, .
not insert the plug into the power socket, regulate or clean
the appliance or carry out maintenance performed by the
user.
ATTENTION:
Certain parts of this product may become very hot
and cause burns. Special attention should be paid
when children and handicapped people are present.
WARNING:
Do not cover. To prevent overheating, do not cover
the heater.
• The heater must not be located directly underneath
apower socket.
• Do not use this heater with aprogram, timer switch,
aremote control system or any other device which
switches the heater on automatically, because there is
adanger of afire if the heater is covered or incorrectly
located.
• Do not use the appliance in the near vicinity of abath,
shower or swimming pool.
• Do not use the appliance if it has fallen down.
• Do not use the appliance if it shows visible signs of
damage.
• Use the appliance on ahorizontal and stable surface. Do
not use mounted on awall.

- 3 - 04/2023
2023, .
WARNING:
Do not use the appliance in small rooms if they are
inhabited by persons that are incapable of leaving
this room on their own unless they are under
permanent supervision.
WARNING:
To limit the risk of afire, keep textiles, curtains and
any other flammable material at adistance of at
least 1 m from the air outlet.
• Before connecting the appliance to apower socket, check that the rated voltage on its rating label matches the electrical voltage in the power
socket.
• Do not connect the appliance to an extension cord or two way adapter.
• The appliance is designed for use in households, offices and similar types of areas.
• Do not use the appliance in very dusty or humid rooms such as laundries or bathrooms, in areas where chemicals are stored, in industrial
surroundings or outdoors!
• This appliance is not intended to be mounted on awall.
• Do not place the appliance on unstable surfaces such as carpets with very long and thick fibres.
• Free space of at least 100 cm in front of the appliance and 50 cm behind the appliance must be maintained while it is running to ensure sufficient
air circulation.
• Do not subject people or animals to the direct flow of hot or cold air for an extended period of time. This could negatively affect their health.
• Do not insert any objects through the front air outflow grill or the back air inflow grill. This could lead to an electrical short circuit, fire or damage to
the appliance.
• To avoid potential injury by electrical shock do not submerge any part of this appliance in water or any other liquid and do not touch the appliance
with damp or wet hands.
• Always turn off the appliance and disconnect it from the power socket when not using it or before cleaning it.
• Do not leave the appliance in operation while sleeping.
• When cleaning the appliance, do not submerge it in water or wipe it with awet cloth.
• To avoid damaging the power cord, do not excessively bend or twist it.
• Ensure that the power cord does not come into contact with hot surfaces or sharp objects.
• Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the power cord or the power socket.
• Disconnect the cord from the power socket by gently pulling the plug of the power cord.
• Do not use the appliance if it is not working correctly, if it has been damaged or has been submerged in water. To avoid the danger of injury by
electrical shock, do not repair the appliance yourself or make any adjustments to it. Have all repairs or adjustments of the appliance performed at
an authorised service centre. By tampering with the appliance, you risk voiding your legal rights arising from unsatisfactory performance or quality
warranty.
• The manufacturer is not responsible for any damages caused by the incorrect use of this appliance.

- 4 - 04/2023
2023, .
• Thank you for purchasing aSENCOR brand product and we hope that
you will be happy with it.
• Prior to using this appliance, please read the user'smanual
thoroughly, even in cases, when one has already familiarised
themselves with previous use of similar types of appliances. Only use
the appliance in the manner described in this user’smanual. Keep
this user'smanual in asafe place where it can be easily retrieved for
future use.
• We recommend saving the original cardboard box, packaging
material, purchase receipt and responsibility statement of the vendor
or warranty card for at least the duration of the legal liability for
unsatisfactory performance or quality. In the event of transportation,
we recommend that you pack the appliance in the original box from
the manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Control panel
A2 Protective front air outlet grille
A3 Base stand
A4 Handle for easy carrying
A5 Rear protective grille of the air
inlet
A6 Power switch
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE CONTROL PANEL
B1 Display
B2 On/Off button
B3 POWER button for setting the
power level
B4 TIMER button for setting the
timer
B5 SWING button for oscillating
the heater
B6 Button -
B7 Button +
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE REMOTE CONTROL
C1 On/Off button
C2 Button -
C3 Button for oscillating the
heater
C4 Button for set the power
level
C5 Button +
C6 Timer setting button
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE USING
• Before first use, take the appliance and its accessories out of the
packaging material and remove all promotional labels and stickers.
Check that neither the appliance nor any of its parts is damaged.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CONTROLLING THE HEATER
Locating the heater
• Locate the heater on an even and rigid surface at asufficient distance
from the power socket.
• Insert the power plug into apower socket.
• Set the main switch (A6), that is located in the back at the bottom to
the I(On) position. The heater will switch to the stand-by mode. In
the stand-by mode, the ambient temperature will be shown on the
display.
• Press the button to turn on the heater.
Note:
Aslight odour may be felt when the heater is first turned on
or after an extended period where it has not been used. This
will go away after ashort while.
Turning off the heater
• When not using the heater, press the button and the heater will
turn off. Set the main switch to position "0". Disconnect the power plug
from the power socket.
Note:
When the heater is turned off using the button, the fan
will continue to run for approximately 30 seconds in order
to cool down the internal components. Then it will turn off.
This is normal. Before disconnecting the power cord from
the power socket, wait until the fan stops running.
Fan mode
• When the heater is turned on using the button, it will run in the fan
mode. The indicator will light up on the display. Air is not heated
in this mode. The flowing current of air will, therefore, be cold and the
appliance can be used to cool down the room.
Setting the power level
• The POWER button serves to set the power level. Press the POWER
button once to set the low power level. The indicator will light up
on the display.
• Press the POWER button again to set the high power level. The
indicator will light up on the display.
• Press the POWER level button again to stop heating.
Setting the temperature
• The temperature is set using the +/- buttons. Press them repeatedly to
set the temperature in the range from 10 to 35 °C. The set temperature
will be shown on the display.
• When the ambient temperature reaches the set temperature, or is
higher, the heater will stop heating. The indicator will light up on
the display.
• When the ambient temperature fall 2 °C below the set temperature,
the heater will automatically start running at half power; when the
ambient temperature falls by 4 °C below the set temperature, the
heater will automatically start running at full power. The indicator of
the set power level will be lit on the display.
Setting the timer
• To set the timer, use the TIMER button. Press it repeatedly to set the
time after which the heater will turn off. The indicator will light up on
the display. The duration of the timer can be set from 1 to 12 hours. The
set time will appear on the display.
Swing (oscillation) function
• To turn on the side to side oscillation of the heater, press the SWING
button. The indicator will light up on the display. Press the SWING
button to turn off the oscillation.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
REMOTE CONTROL
Inserting batteries into the remote control
1. Pull the battery holder out of the bottom part of the remote control.
2. Insert aCR2025 (3 V) battery into the holder. Ensure correct
polarity. Battery is not provided.
3. Reinsert the holder with the battery into the remote control.
EN Ceramic tower heater
User'smanual

- 5 - 04/2023
2023, .
• If you wish to use the remote control, point it at the heater. The
maximum signal range is 5 m. If the remote control is positioned in
such away that obstacles prevent the transmission of the signal, then
the signal may not be transmitted at all.
Note:
When not using the remote control for an extended period
of time, remove the batteries from the remote control. Never
put the batteries in afire, short circuit them or damage them
in any way. Dispose of them ecologically at the end of their
lifetime. Never throw batteries out with communal waste.
The principle for controlling the heater using the remote control is the
same as described in the chapter "Controlling the heater".
AUTOMATIC SAFETY SHUT-OFF FUNCTION
• The ceramic heater is equipped with asafety mechanism that
automatically turns it off when it is tipped over. This safety mechanism
serves asafety function and prevents dangerous situations from
arising.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OVERHEATING PROTECTION
• In the event that the temperature of the heater is too high due to an
inappropriate environment in which it is used or as aresult of incorrect
use, the power supply to the heater will automatically be shut off and
it will stop working. It is recommended to disconnect the power plug
from of the power socket and allow it to cool down completely. Then
you will be able to use the heater again.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
THERMAL PROTECTION
• The ceramic heater is equipped with double thermal protection –
aresettable and non-resettable thermal fuse. The resettable thermal
fuse will turn the heater off when there is adanger of it overheating or
malfunctioning. When the temperature of the heater falls, you will be
able to use the heater again.
• The non-resettable thermal fuse is installed for the case, where the
resettable thermal fuse fails. In the event of overheating, malfunction
or if the heater stops working for any other reason, the non-resettable
thermal fuse will completely turn off the heater and it will not be
possible to turn it on. In such acase, contact an authorised service
centre.
• The most frequent cause of overheating is the accumulation of dust
or dirty material on the rear grille and on the the front grille. Regularly
remove any dirty material using avacuum cleaner. Always turn off the
heater, disconnect the power plug from the power socket and allow
the heater to cool down completely before cleaning it.
• The heater is not equipped with aprecision temperature control sensor
and, therefore, it cannot be used as an isolation device for storage or
keeping animals or flowers.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MAINTENANCE AND CLEANING
• Ensure that the appliance is turned off and that it has cooled down
before cleaning it.
• Wipe the appliance using asoft dry cloth. Regularly remove any dirty
material from the front and rear grille. Avacuum cleaner can also be
used for removing the dirty material. Nevertheless, always check that
the heater is turned off, the power plug is disconnected for the power
socket and that the heater has cooled down completely.
• Do not use chemicals or abrasive cleaning products for cleaning.
Otherwise the surface of the appliance may be damaged.
Warning:
To prevent the risk of injury by electrical shock, do not
submerge the appliance, power cord or power plug in
water or any another liquid.
Long term storage
• When not using the appliance, store it in adry, clean place out of
children'sreach. Allow the appliance to cool down before storing it.
• Remove the battery from the remote control.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TECHNICAL SPECIFICATIONS
Rated voltage..........................................................................................220–240 V~
Rated frequency...................................................................................................50 Hz
Rated power input.......................................................................................... 2,200 W
Noise level............................................................................................ max. 50 dB (A)
Power settings..............................................................................1300 W/2 200 W
Temperature settings ..............................................................................10 °C–35 °C
Dimensions of the heater.........................................................22 ×22 ×69.3 cm
Weight of the heaters..............................................................................................3 kg
Declared noise emission level of this appliance is max. 50dB(A), which
represents alevel Aof sound power with respect to areference sound
power of 1 pW.
Safety class for electrical shock protection: Class II – Electrical
shock protection is provided by double or heavy-duty insulation.
We reserve the right to change text and technical specifications.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF
USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your
municipality.
DISPOSAL OF USED ELECTRICALAND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that
used electric or electronic products must not be added to
ordinary municipal waste. For proper disposal, renewal and
recycling, hand these appliances over to determined
collection points. Alternatively, in some European Union
states or other European countries you may return your
products to the local retailer when buying an equivalent
new product. Correct disposal of this product helps save
valuable natural resources and prevents potential negative effects on the
environment and human health, which could result from improper waste
disposal. Ask your local authorities or collection facility for more details. In
accordance with national regulations penalties may be imposed for the
incorrect disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electrical or electronic equipment, ask your
retailer or supplier for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this
product, request the necessary information about the correct disposal
method from the local council or from your retailer.
This product meets all the basic requirements of EU
directives related to it.

FAST ČR, a.s.
U Sanitasu 1621
CZ-251 01 Říčany
www.sencor.eu
