Private mobile radio with twin charger SENCOR SMR 60
USER GUIDE
1. LCD Screen
Channel Number. Changes from 1 to  as selected by the user.
CTCSS Code. Changes from 1 to 38 as selected by the
user.
Displays the Battery change level. When the bars are
reduced, the battery needs recharging.
TX Displayed when transmitting a signal.
RX Displayed when receiving a signal.
DCM Displayed when the Dual Watch function is turned ON.
DCS Displayed when the Digital Code System is turned On.
VOX Displayed when the VOX feature is enabled.
SCAN Displays when the PMR is scanning all channels.
Displayed when the Key Lock feature is activated.
Displays the current Speaker volume level.
Displays when the call signal is ON.
Displays when the vibrator function is activated.
Antenna
LCD Screen
- Displays the
current channel
selection and other
radio s
y
mbols.
PTT (PUSH to
TALK) button
–Press and hold to
transmit. CALL button
-Press to send
Ringing tone to
other PMR units.
MENU Button
-Press to change
To switch between
Modes.
S
p
eake
r
Ear/Mic/Charge
j
ack
PW
R
/VOL Switch
–Rotate
clockwise/counter
clockwise to turn the
unit
ON or OFF.
MIC
(
Micro
p
hone
)
UP/DOWN
Buttons –
Press to change
channels, volume,
and to select
settings during
p
ro
g
rammin
g
.

 Installation
2.1 Removing the Belt Clip
D Pull the Belt Clip latch forward
(away from the SMR 60)
E While pulling the Belt Clip
latch, push up the Belt Clip as
shown in Figure1.
2.2 Installing the Belt Clip
a. Slide the Belt Clip into the
slot as shown in Figure2.
A “click” indicates the Belt
Clip is locked into position.
2.3 Installing the Battery pack
Caution: Observe the proper battery polarity orientation when installing batteries. Incorrect
positioning can damage both the batteries and the unit.
a. Slide down the Battery Compartment Cover.
b. Install the rechargeable battery pack by following the orientation as shown in Figure 3 (the
arrow is showing and pointing upward.)
c. Replace the Battery Compartment Cover. See Figure 4.
Important
Read these Safety Warnings before you charge the batteries.
When placing the unit in the charger, use only the power supplies listed in the user
instructions supplied with the SMR 60.
Don’t try to recharge non-rechargeable batteries.
Make sure the battery compartment cover is securely locked in placewhen you are
charging the batteries.
Dispose of used batteries safely and in a way that will not harm the environment-
never try to burn them or put them anywhere, they could get burnt or punctured.
Don’t leave dead batteries in your units.
They might leak if you do.
2.4 Charging the battery batteries
D Insert the small plug on the end of the mains adaptor into the
Power-in Connection Jack at the back of the desktop charger.
E Plug the mains adaptor into a 20V AC, 50Hz main socket with
the switch on the socket set to OFF.
F Switch ON the main socket.
The SMR 60must be charged using the mains adaptor provided. Using any other
adaptor will result in non-compliance with EN62368-1 and will invalidate any approvals
& warranty.
Belt Cli
p
latch
Fi
g
ure 1 Fi
g
ure 2
Fi
g
ure 3 Fi
g
ure 4

d. Place the units in the charge cradle in an upright position.
The Charge LED indicators will light up.
e. It takes about 10 hours to fully recharge the batteries if they are completely run down. New
batteries take up to 14 hours to fully charge.
f. Charging the battery batteries (using adaptor)
Lift the charge socket cover located on
the right side of the handset.
Insert the round connector of the 9.0V DC/300mA
adaptor into the charge jack.
Plug the mains adaptor into a 20V AC, 50Hz
main socket with the switch on the socket set to OFF.
Use only power supplies listed in the user
instruction. AC Adaptor Model – TEE 090P030 .
Then switch ON the main socket.
Battery meter
The battery meter is located in the left corner of the LCD Screen. It appears like a battery
with three bars inside. These indicate the amount of power available. When the battery level
reaches it minimum level in PMR on mode, unit will emit two beep tones and automatically
the unit will power off.
The SMR 60can detect the battery charge in 4 levels;
Battery charge at high level.
Battery charge at medium level.
Battery charge at low level. At this level, the SMR 60will emit a “beep” sound
for every 10 seconds in normal mode.
Important: Charge the unit for 10-14 hours.
Battery charge at very low level. When the battery level reach it minimum level , unit
will emit two beep tone and automatically turn off the power and proceeds to watch
mode.
Important: Charge the unit for 10-14 hours.
CAUTION : Risk of explosion if battery is replaced by an incorrect type. Disposed of used
batteries according to the instructions.
Battery life
The SMR 60has a built in power saver to make the batteries last longer. But when you are not
using the units, turn them OFF to conserve battery power.
3. Operation
Mic/spk jack
Important:
Always turn off the PMR units
when charging. This will
shorten the charging time.
Main socket
Charge jack

3.1 Transmitting range
The talk range depends on the environmental and terrain. It will be reach (up to about
8km) in wide open spaces, without obstructions such as hills or buildings. Don’t try to
use two PMR units which are less than 1.5m (5feet) apart. Otherwise, you may have
experience interference.
Important safety warning
To reduce radio frequency exposure when you are using your SMR , hold the unit
at least 5cm (2 inches) away from your face.
Never use your SMR 60outdoors during a thunderstorm.
Don’t use the SMR  in the rain.
If your SMR  gets wet, turn it off and remove he battery. Dry the battery
compartment
and leave the cover off for a few hours. Don’t use the unit until it is completely dry.
Keep the SMR  out of reach babies and young children.
3.2 Turning the Unit ON/OFF
To Turn ON;
a. Rotate the POWER/VOL button clockwise until the LCD Screen turns ON and
displays the current channel.
To switch OFF;
b. Rotate the POWER/VOL button counter clockwise until the LCD screen turns
blank.
Note: Every time you rotate the Power/Vol button to turn ON, the volume will also open. The
volume level will increase or decrease by rotating the Power/Vol button.
3.3 Changing Channels
The SMR  has  available channels, to communicate with other SMR 
users within a range, you must all have your SMR 60tuned to the same channel.
D Press the MENU button once, the current channel number flashes on the LCD
Screen.
E Press the UP or DOWN button to select the desired channel. The channel
changes from 1 to , or vice versa.
F Press the PTT button to confirm the channel setting.
Note: Refer to the “Channel Table” section of this Owner’s Manual for detailed frequency
listing.
3.3.1 Setting the CTCSS sub-channel
Each channel also has 38 sub-channels to let you set up group of users within the same
channel for more private communication. If you have set the sub-channel, you can only
communicate with other PMR users tuned to the same channel and sub-channel.
To turn the sub-channel function off, simply set the sub- channel
to 0 (zero). You can communicate with any SMR  user set to the same channel who also
turns off the sub-channel operation (or whose have unit does not have the feature).
a.Press the MENU button twice, the current CTCSS sub-channel number flashes
on the LCD Screen.
b.Press the UP or DOWN button to select one of the 38 CTCSS sub-channels.
c.Press the PTT button to confirm the sub-channel setting.

3.3.2 SETTING THE DCS ADVANCED DIGITAL CODE.
Each channel also has 83 digital codes to let you set up group of users for more secured
private communication.
a. Press the MENU button 3 times. DCS code is blinking on the LCD screen.
b. Press the UP or DOWN button to select the desired DCS code.
c. Press the PTT button to confirm the DCS channel setting.
Transmitting and Receiving
The SMR  transmission is “one way-at-a-time.” While you are speaking, you
can not receive a transmission.
The SMR  is an open-license band. Always identify yourself when transmitting
on the same channel.
3.4 Transmitting (sending a speech)
The unit is continuously in the Receive mode when the unit is turned ON and not transmitting.
When a signal is received on the current channel, “RX” icon will be displayed on the LCD
Screen and the receiver LED lights up.
3.5 Transmitting (sending a speech)
a. Press and hold the PTT (push to talk) button to transmit your voice. “TX’ icon will
be displayed on the LCD Screen.
b. Hold the unit in a vertical position with the MIC (Microphone) 5 cm away from the
mouth. While holding the PTT button, speak into the MIC (microphone) in a
normal tone of voice.
c. Release the PTT button when you have finished transmitting.
3.6 Monitor
You can use the Monitor feature to check for weak signals on the current channel.
DPress and hold the MENU and DOWN buttons at the same time. “RX” icon will be
displayed on the LCD Screen. Your SMR  will pick up signals on the current
channel, including background noise.
EPress the MENU button to stop the channel monitoring.
3.7 Setting the VOX (Voice Activated) Sensitivity
In VOX mode, the SMR  will transmit a signal only when it is activated by your voice or
other sounds around you. The unit will transmit further for 2 seconds even if you stop talking.
The level of VOX sensitivity is shown by a number on the LCD Screen. At the highest level,
the units will pickup softer noise (including background noise); at the lowest level, it will pick
up only quite loud noise.
a.Press the MENU button 4 times, “VOX” icon will be displayed and “OFF” flashes
on the LCD Screen.
b.Press the UP button to set the VOX sensitivity into maximum level (the maximum
level is“3 ”.) To deactivate the VOX function, press the DOWN button until “OF”
appears on the LCD Screen.
c.Press the PTT button to confirm your setting. “VOX” will steadily appear on the
LCD Screen as along as the VOX feature is activated.
VOX operation is not recommended if the SMR  will be used in a noisy or
windy environment.

3.8 Activating the Auto Channel Scan
Channel scan perform searches for active signals in an endless loop for all  channels,
38 CTCSS codes and all 83 DCS codes.
a. Press the MENU button 5 times, “SCAN” icon will display on LCD Screen.
b. Press the UP or DOWN button to begin scanning channels when an active
signal is detected, channel scan pauses on the active channel.
c. Press the MENU button six times, CTCSS flashes on the LCD screen press
the UP or DOWN button to begin scanning the CTCSS from 1-38.
d. Press the MENU button seven times, DCS flashes on the LCD screen. Press
the UP or DOWN button to begin scanning DCS code 1-83.
e. Press the PTT button to confirm your setting.
3.9 Vibrator and Call alert
Your unit can alert you to incoming signal by emitting an audible call tone and vibration
signal.
4 Call-Ring tone
You can send a Call-ring tone to other PMR users to give an alert that you want to
communicate with them.
Press the CALL button
Yu will hear a ring tone for about two seconds; “TX” icon appears on the LCD
Screen. Any other units within the transmitting range and tuned to the same
channel and sub-channel (if applicable) will hear the Call-ring tone.
4.1 Selecting a Call- Ring tone
The SMR  is equipped with 15 different types of Call-Ring
tones. a. Press the MENU button 8 times, the “C 1” icon will display and blinking on the
LCD Screen.
b. Press the UP or DOWN button to select the desired Call-ring tone. A respective
Call- Ring tone sound will be played when changing from one tone to another.
c. Press the PTT button to confirm your setting.
4.2 Activating the Vibrator mode
a. Press the MENU button 9 times; “3” flashes on the LCD Screen.
b. Press the UP or DOWN button to activate the vibrator function.
c. Press the PTT button to confirm your setting.
Note: Vibrator and Call tone can be activated at the same.
4.3 Setting the Roger Beep
The Roger Beep is a tone which is automatically transmitted whenever the PTT button is
released. This alerts the receiving party to inform that you have intentionally ended the
transmission, and you are now in receive mode.
a.Press the MENU button 10 times, the “ON” icon is blinking on the LCD Screen.
b.Press the UP or DOWN button to select the Roger beep On/Off.
c.Press the PTT button to confirm your setting.

4.4 Setting the Key Tone ON or OFF
This feature allows the SMR  to emit a confirmation tone after pressing each
button. a.Press the MENU button 11 times, the “ON” icon is blinking on the LCD Screen.
b.Press the UP or DOWN button to select the Key tone On/Off.
c. Press the PTT button to confirm your setting.
4.5 Setting the Dual Watch Mode
Your SMR  is capable of monitoring two channels, the current and another (dual
watch) channel. If the unit detects a signal on either channel, it will stop and receive the
signal.
D Press the MENU button 12 times, “DCM” icon will be displayed while “OF ”
flashes on the LCD Screen.
E Press the UP or DOWN button to select the Dual Watch channel (1-,
exceptthe current channel).
F Continue pressing the MENU button to change the CTCSS code.
G Press the UP or DOWN button to select the desired CTCSS code (1-38)
H Continue pressing the MENU button to change the DCS code.
I Press the UP or DOWN button to select the desired DCS code (1-83)
J Press the PTT button to confirm your setting.
5 Auxiliary Features
5.1 Key Lock
The Key Lock feature allows user to disable the UP, DOWN and MENU buttons
so that the SMR  settings could not be changed accidentally.
a. To activate the Key Lock feature, press and hold the MENU button until key
lock Āāicon appears on the LCD Screen.
b. To deactivate the key Lock feature, press and hold the MENU button until key
lock Āāicon disappears on the LCD Screen.
Note: The PTT, and CALL buttons will remain functional even if the
Key Lock feature is activated.
5.2 LCD Screen Back Light
Every time the Power/Vol button is open (except PTT and CALL button), the LCD
Screen back light will illuminate for 5 seconds.
5.3 Microphone/Earphone/Charge Jack
The SMR  is equipped with an auxiliary microphone, earphone, and
charge jack located at the opposite side of the PTT button.

6. Specifications
Channels Available  Channels
CTCSS Sub-channel 38 for each Channel
Output Power (TX) 0.5 W
Range Up to 8 Km.
Channel Frequency Table
7. Safety CAUTION
Damaged Antenna
Do not use any 605  that has a damaged antenna. If a damaged antenna comes
in contact with the skin, a minor burn may result.
Batteries
All batteries can cause property damage and/or bodily injury such as burns if
conductive material such as jewelry, keys, or beaded chains touches exposed terminals.
The material may complete an electrical circuit (short circuit) and become quite hot.
Exercise care in handling any charged battery, particularly when placing it inside a
pocket, purse, or other container with metal objects.
WARNING
For Vehicles with an Air Bag
Do not place your SMR  in the area over an air bag or in the air bag deployment area. Air
bags inflate with great force. If a SMR  is placed in the air bag deployment area and
the air bag inflates, the SMR  may be propelled with great force and cause serious
injury to the occupants of the vehicle.
Potentially Explosive Atmospheres
Turn your SMR  OFF when in any area with a potentially explosive atmosphere, unless
it is a type especially qualified for such use (for example, Factory Mutual Approved). Sparks
in such areas could cause an explosion or fire resulting in injury or even death.
Batteries
Do not replace or charge batteries in a potentially explosive atmosphere. Contact
sparking may occur while installing or removing batteries and cause an explosion.
Blasting Caps and Areas
To avoid possible interference with blasting operations, turn your SMR  OFF
near electrical blasting caps or in a “blasting area” or in areas posted: “Turn off the two way
radio.” Obey all signs and instructions.
NOTE: Areas with potentially explosive atmospheres are often, but not always clearly marked.
They include fueling areas such as below deck on boats; fuel or chemical transfer or storage
facilities; areas where the air contains chemicals or particles, such as grain, dust, or metal powders;
and any other area where you would normally be advised to turn off your vehicle engine.

8. Cleaning and Care
To clean your SMR , use a soft cloth dampened with water. Do not use cleaners or
solvent, which may cause damage that may not be covered by guarantee.
Hereby Fast CR, a.s. declares that the SMR 601 type of radio equipment complies with
Directive 2014/53 / EU. The full text of the EU Declaration of Conformity is available at the
following Internet address: www.sencor.eu .
EN Disposal of Used Electrical & Electronic Equipment
The meaning of the symbol on the product, its accessory or packaging indicates that this
product shall not be treated as household waste. Please, dispose of this equipment at your
applicable collection point for the recycling of electrical & electronic equipments waste. In
the European Union and Other European countries which there are separate collection
systems for used electrical and electronic product. By ensuring the correct disposal of this
product, you will help prevent potentially hazardous to the environment and to human health,
which could otherwise be caused by unsuitable waste handling of this product. The
recycling of materials will help conserve natural resources. Please do not therefore
dispose of your old electrical and electronic equipment with your household waste. For
more detailed information about recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you purchased the product.
0DQXIDFWXUHU)DVWý5DVU Sanitasu&=ětþDQ\&]HFK5HSXEOLF
