Sengled C01-BR30NA LINK User manual

User Manual
C01-BR30NA LINK
Features
Easy setup and configuration
Enjoy the energy saving from LED and high-quality JBL® stereo audio system
Create up to 7 wireless speaker bulbs system, control and playing
synchronously
Quick connection via a standard 3.5mm AUX cable for audio playing
Compatible with most smart phones, tablets and computers that support
Bluetooth® technology
Indicator lights for power, 3.5mm AUX audio signal, and Bluetooth connection
Sengled Pulse Android/iOS App provides greater functionality and control
Box Contents
One Pulse Link (C01-BR30NA LINK),
Two Pulse Satellite bulbs (C01-BR30)
User Manual
Quick Start Guide
Limited Written Express Warranty
Product Specifications (Pulse Link, per device)
Model Number: C01-BR30NA LINK
Power Supply: 100~240V AC, 50/60Hz, 20mA(Max)
Power Consumption: 1.35W (Rated)
Operating Temperature: -20°C (-4°F) ~ +40°C (+104°F),
Humidity: 10 ~ 90% Non-Condensing
Color: White
Dimensions: 3.78" (L) x 2.21" (W) x 0.95" (H)

Weight: 2.68oz/device (approx.)
Frequency Response: 100 Hz - 20 kHz
System Wireless Point-to-Point Latency < 20ms
Bluetooth Standard: v2.1 + EDR (Class 2), 2.402 - 2.480 GHz
Bluetooth Profiles: A2DP, AVRCP, SPP etc.
Bluetooth Transmission Power: 4dBm, 10 meters (near line of sight, without
any hindrance)
Wireless Connection between Pulse Link and Satellite Bulb: 5GHz wireless
technology
Transmission Power between Pulse Link and Satellite Bulb: 9.74dBm§
§
Actual effective range will vary with network conditions and environmental factors
including volume of network traffic, radio interference, building materials and
construction, and network overhead. A maximum range of 60 to 100 feet is
recommended between the Pulse Link and the Satellite bulb for optimal wireless
transmission and audio quality.
© 2015 Sengled, Incorporated. All rights reserved. Sengled Pulse is a trademark of Sengled,
Incorporated, registered in the United States and other countries. Specifications are subject to
change without notice. Other Trademarks and trade names are the property of their respective
owners.
Pulse Link Introduction
—Standard 3.5mm Line In
—Power button
Power Indicator: [ON] when the device is powered on.
Wireless Connection Indicator:
[ON –blinking] the device is waiting to be connected via Bluetooth.
[ON –not blinking] when the device is connected to the smart device via Bluetooth;
3.5mm Line In Indicator:
[OFF] when a cable is not connected.
[ON –not blinking] when a 3.5mm auxiliary cable is plugged into the device;

INSTALLATION INSTRUCTIONS
WARNING - TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, USE IN DRY
LOCATIONS ONLY AND DO NOT EXPOSE TO RAIN OR LIQUIDS.
WARNING - TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE THE BACK
COVER OR TAKE APART. THERE ARE NO SERVICEABLE PARTS INSIDE.
1. Before installing the Pulse Satellite bulb into a light bulb socket (E26), turn the
light switch to the OFF position. (DO NOT USE WITH EXTERNAL OR OUTSIDE
DIMMERS).
2. Screw the bulb into asocket (E26) and turn the power on. The LED light will turn
on.
NOTICE: The stereo sound effect is affected by the installation position in the
lighting fixture, the distance between Pulse Link and Satellite bulbs, and the
room space etc., to achieve the best stereo sound effect, please make sure the
LED plastic cover is at the same level of the lighting fixtures (in Horizontal), and a
distance around one to three meters between bulbs is recommended.
3. Plug in Pulse Link near Satellite bulbs. Power on Pulse Link, connect it with any
device (e.g. TV, MP3, smartphone, tablet, or computer) which has a 3.5mm aux
output via a 3.5mm Aux cable for audio output through Satellite bulbs. Or go to
step 4 to connect Pulse Link via Bluetooth for wireless audio controlling.
4. On the portable smart device (e.g. smartphone, tablet, or computer), make sure
Bluetooth is turned on. Then via Bluetooth, connect the smart device with the
Pulse Link. The default Pulse Link’s Bluetooth ID is ‘C01-BR30’. Once connected,
user can launch any media App on the smart device to enjoy music via the Pulse
light speakers. Or go to Step 5 to download and install Pulse mobile App for
greater control of the light and speakers.
5. Search for the 'Pulse by Sengled' or 'Sengled pulse' App for corresponding
operating system, download and install it on a portable smart device:
Get App from Google Play Store for Android Devices;
Get App from App Store for Apple iOS Devices. Compatible with iPhone 6s Plus,
iPhone 6s , iPhone 6 Plus, iPhone 6 ,iPhone 5s, iPhone 5c, iPhone 5, iPhone 4s,
iPad Air, iPad mini with Retina display, iPad (4th generation), iPod touch (5th
generation).
Or get more information from www.sengled.com

6. Open the Pulse application, and a 'Welcome' page appears. Select Pulse Link and
the Pulse App will search and connect to the Pulse Link automatically. The wizard
guides you through the steps for connecting your portable smart device to the
Pulse Link. If the application doesn't detect the Pulse Link, restart the application
and setup wizard again.
7. Once the portable device has been successfully connected to the Pulse Link, the
application will display the main control screen. Press the 'Lights' or 'Sounds' tab
to switch between them and achieve different functions, such as Light Brightness
& Settings, Sound Volume & Settings, and Equalizer (EQ) Settings etc.
To add a new Satellite bulb to the Pulse Link
1. Successfully configure Pulse Link (C01-BR30) and the current Satellite bulbs
before installing a new Satellite bulb.
2. On your smart device, turn on Bluetooth and connect to the Pulse Link.
3. Install the new Satellite bulb in the proper light socket.
4. Turn on the new Satellite bulb.
5. Launch the Pulse App on your device
6. Select one of two methods to add the Pulse Satellite bulb to the Pulse Link
network:
i. Select “Scan QR code” to automatically scan the network, or
ii. Manually type the Satellite bulb “AD Code”.
NOTE: The AD code in QR format is labeled in two locations: The bottom side
of the Satellite packaging (near the bar code) and on the Satellite bulb itself.
7. Once the scanning has been successful, select the “Link” option. The Satellite
bulb will connect with the Pulse Link after approximately 30 seconds. Do not
turn off power during the connection.
8. The Satellite bulb should begin to blink, indicating that it has successfully
connected with the Pulse Link. The user can now enjoy a high-quality audio
system, as desired.
To delete a connected Satellite bulb from the Pulse Link
1. Ensure that the Pulse Link and Pulse Satellite bulbs are powered on and
paired with your smart device via Bluetooth.
2. Launch the Pulse App.
3. Simply switch the Main Brightness ON/OFF button to confirm that all Pulse
bulbs are connected under the same Pulse Link.
4. Select the “Devices Management” tab in the Settings menu.
5. Select the Satellite bulb that you want to remove from the Pulse Link Network,
click Delete/Close button.
6. A delete confirmation will appear on the screen, click “OK” to continue.
7. Wait for approximately 30 seconds. Do not power off the devices during this

process
8. Click the “Refresh” tab in the Settings menu to confirm the device has been
removed
IMPORTANT SAFETY INSTRUCTIONS
Read and keep these safety instructions.
Heed all warnings contained within these instructions.
Please follow all user manual instructions when installing the product.
Only clean Sengled product only with a dry towel.
This Product is intended for indoor use only.
Do NOT use this product outdoors.
Do NOT get this product wet and do NOT use near any water source.
The product should not be exposed to dripping or splashing liquids of any kind.
Do not install the product near any heat sources, such as heater, radiators,
stove, heat registers or other apparatus that produce heat.
Ensure that the product is stable and secured in place during installation. If the
product is dropped or falls out of the power socket, it may cause bodily harm.
If the product is dropped or falls out of the power socket, it may be damaged.
Please check the product for any visible damage.
To reduce the risk of electric shock, do NOT remove the back cover or take
apart. There are no serviceable parts inside.
To prevent product failure, the product should only be installed in operating
environments ranging between -4 degrees Fahrenheit and +104 degrees
Fahrenheit (-20degrees Celsius and +40 degrees Celsius).
Never push any objects into the openings or slots on the product. Doing so may
create an electric shock or fire hazard.
Maintain sufficient distance around your product for sufficient ventilation;
For best protection against lightning, unscrew the product from its power
source during a storm.
Only use accessories specifically recommended by the manufacturer.
Refer all servicing to qualified Sengled service technician.
Servicing is required when the product:
1. Has been damaged in any way
2. Liquid has been spilled on the product
3. Objects have fallen into the product
4. The product has been exposed to rain or moisture
5. The product does not operate normally, or has been dropped
Repairs must be performed by a qualified Sengled technician.
The product can be hot and should not be touched without taking care.
CAUTION:
RISK OF ELECTRIC SHOCK –USE IN DRY LOCATION ONLY
REQUIRE EITHER 3.5MM OR RCA VERSION. CONNECTING CABLE NOT INCLUDED
REQUIRED FOR USE: SENGLED PULSE JBL WIRELESS BLUETOOTH SPEAKERS (C01-BR30

BULBS)
FCC
FCC STATEMENT FOR USERS
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
SECTION 15.21
The user’s manual or instruction manual for an intentional or unintentional radiator
shall caution the user that changes or modifications not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment. In cases where the manual is provided only in a form other than paper,
such as on a computer disk or over the Internet, the information required by this
section may be included in the manual in that alternative form, provided the user
can reasonably be expected to have the capability to access information in that
form.
FEDERAL COMMUNICATION COMMISSION INTERFERENCE STATEMENT, SECTION
15.105(b)
This equipment has been tested and found to comply with the limits for a class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
RF RADIATION EXPOSURE WARNING
This equipment must be installed and operated in accordance with provided
instructions and the antenna(s) used for this transmitter must be installed to provide
a separation distance of at least 20 cm from all persons and must not be co-located
or operated in conjunction with any other antenna or transmitter. End-users and

installers must be provided with antenna installation instructions and transmitter
operating conditions to satisfy RF exposure compliance.
IC
DECLARACIÓN DE LA FCC / RSS-GEN DE USUARIOS
Este dispositivo cumple con la parte 15 de las normas de la FCC y exento de licencia
RSSs de Industria de Canadá. La operación está sujeta a las dos condiciones
siguientes:
(1) Este dispositivo no puede causar interferencias perjudiciales y
(2) Este dispositivo debe aceptar cualquier interferencia recibida, incluyendo
interferencias que puedan causar un funcionamiento no deseado.
SECTION 15.21
Le guide d’instruction de l’utilisateur pour un radiateur intentionnel ou non
intentionnel doit prévenir l’utilisateur que les changements ou modifications non
expressément approuvés par la partie responsable de la conformité pourraient
annuler l’autorité de l’utilisateur à utiliser l’appareil. Dans les cas où le guide est
disponible uniquement sous une forme autre que le papier, comme sur un disque
d’ordinateur ou sur Internet, les informations requises par cette section peut être
inclus dans le guide sous une forme différente, à condition que l’utilisateur puisse
raisonnablement avoir la capacité à accéder à l'information sous cette forme.
Le dispositif de l'opération dans la bande 5150-5250 MHz est réservé à une
utilisation en intérieur afin de réduire les risques d'interférences nuisibles à la
co-canal avec les systèmes mobiles par satellite.
COMMISSION FÉDÉRALE DES COMMUNICATIONS, DÉCLARATION
D’INTERFÉRENCE, SECTION 15.105 (b)
Cet équipement a été testé et s’'est avéré être conforme aux limites d’un appareil
numérique de classe B, conformément à la partie no 15 des règles de la FCC. Ces
limites sont conçues pour fournir une protection raisonnable contre les interférences
nuisibles dans une installation résidentielle. Cet équipement génère, utilise et peut
émettre de l’énergie de fréquence radio, et s’il n’est pas installé et utilisé
conformément aux instructions, il peut provoquer des interférences nuisibles aux
communications radio. Cependant, il n’existe aucune garantie que des interférences
ne se produiront pas dans une installation particulière. Si cet équipement provoque
des interférences nuisibles à la réception radio ou télévision, ce qui peut être
déterminé en mettant l'équipement hors et sous tension, l’utilisateur est encouragé

à essayer de corriger l’interférence par une ou plusieurs des mesures suivantes :
• Réorientez ou déplacez l’antenne de réception.
• Augmentez la distance entre l’équipement et le récepteur.
• Connectez l’équipement à une sortie sur un circuit différent de celui sur lequel le
récepteur est branché.
• Consulter le revendeur ou un technicien radio / TV expérimenté.
ADVERTENCIA DE EXPOSICIÓ N A LA RADIACIÓ N DE RADIOFRECUENCIA
Este equipo tiene que ser instalado y funcionar según las instrucciones
proporcionadas y la(s) antena(s) utilizada(s) para este transmisor tiene(n) que ser
instalada(s) para proporcionar una distancia de separación de por lo menos 20 cm
lejos de todas las personas y no deben estar colocadas o funcionar junto con alguna
otra antena o transmisor. Los usuarios finales y los instaladores tienen que obtener
las instrucciones de instalación de la antena y las condiciones de funcionamiento del
transmisor para cumplir con la exposición a la radiofrecuencia.
