Sensor Access X-PIN User manual

X‐PIN&X‐PROX
InstallGuide
www.sensoraccess.co.uk
 X‐PINX‐PROX

InputVoltage
VDC12vDC‐24vDC12vDC‐24vDC
VAC12vDC‐24vAC16vDC‐24vAC
Maximum
InputCurrent
(12vDC)
HeaterOn130mA145mA
HeaterOff610mA625mA
StandbyIn‐
putCurrent
(12vDC)
HeaterOn70mA85mA
HeaterOff550mA365mA
MaximumRelayCurrent2A2A
REXInputNormallyOpenNormallyOpen
AuxInputNormallyOpenNormallyOpen
MaxProximityRead
RangeN/A65mm
ProximityCardCompati‐
bilityN/ASP‐SHL,SP‐ISO, SP‐KEY,SP‐DISC
LEDIndicatorsTwo3Coloured
LED
Two3Coloured
LED
OperatingTemperatures‐20°Cto60°C‐20°Cto60°C
OutdoorUsageMeetsIP64MeetsIP64
Dimensions120mm(H)x76mm(W)x22mm(D)
Weight521g
TheX‐PINisasingledoorcontrollerwhichusesPINonly.TheX‐PROXisasingle
doorcontrollerthatusesPINandproximitytechnology.Allelectronicsarewithin
thehousingofthereader.TheX‐PINandX‐PROXcanbeconnectedtoadoorcon‐
tactandrequesttoexitbuttontoallowthesystemtosendasignaltoasounderin
casethedoorhasbeenforcedorleftopen.

X‐PIN&X‐PROX
InstallGuide
www.sensoraccess.co.uk
MODESOFOPERATION

NormalMode(Default)
•Modeindicatorisgreen.
Innormalmode,thedoorislockeduntilavalidprimarycodeispresentedtothecontroller.Thecontrollercan
onlybeprogrammedinnormalmode.
SecureMode
•Modeindicatorisred.
Onlysecureandmasteruserscanaccessthepremisesinsecuremode.
USERLEVELS

TheX‐PIN&X‐PROXAccessControlunitsacceptupto500usersandprovideentryviatheuseofcodesorcards.
NormalUser‐Anormaluseronlyhasaprimarycodeandisgrantedaccessonlywhenthecontrollerisinitsnor‐
malorbypassmode
SecureUser‐Asecureusermusthaveaprimaryandsecondarycodeassigned,andthetwocodesmustnotbe
thesame.(pleaseseeUserManualformoreinformation)
ColourDescription
RedVInput
BlackGround
GreenREX/BL
WhiteIn/Monitor
PurpleLock:Com
GreyLock:N.O.
BrownLock:N.C.
BlueAux:Com
YellowAux:N.O.
OrangeAux:N.C.

X‐PIN&X‐PROX
InstallGuide
www.sensoraccess.co.uk
SWITCHINGOPERATONALMODES

FromNormaltoSecureMode/FromSecureModetoNormal
Thedefaultfactorysettingforthenormal/securecodeis3838

1)Enterthenormal/securecode
•Modeindicatorwillflashred(normaltoSecure)orflashGreen(Secure
toNormal)

2)Depressthe#keytoconfirmtheModechange
•ModeindicatorisredtoconfirminSecuremode/orgreentoconfirm
NormalMode
STANDARDMETHODFORENROLLING

1)Entertheprogrammingmode.

2)Depress7toenterMenu7.
• TheDoorindicatorwillturnorange.

3)Enterthe3‐digituserslotnumberintothememory(from001to500)soastoenroll
aprimaryorsecondarycode.
• Forexample,theuserslot003representsuserno.3.

4)Atthistimethreepossibilitiesexist:
a.Iftheselectedslothasnoprimarycode,theModeindicatorwillflashgreen,
indicatingthatthecontrollerisreadytoacceptaprimarycode.

b.Iftheselectedslotalreadyhasaprimarycode,butnosecondarycode,theMode
indicatorwillflashred,indicatingthatthecontrollerisreadytoacceptasecond‐
arycode.

c. Iftheselectedslotalreadyhasaprimaryandsecondarycode,alongbeepwillbeheardandthecontroller
willreturntoitsnormalmode.

5)Enterthecodetobeassignedastheprimaryorsecondarycodeforthisslotnumber.Ifthecodethatisen‐
teredisvalid,theModeindicatorwillceaseflashingandthecontrollerisreadyforthenext3‐digitslotnumber
(step3)ordepressthe#keytomovetothenextslotnumber(step4).Ifyoudonotwishtocontinueenrolling
codes,depressthe#keytwiceandthecontrollerwillreturntoitsnormalmode.

X‐PIN&X‐PROX
InstallGuide
www.sensoraccess.co.uk
DELETINGCODES
Whendeletingauserslot,boththeprimarycodeandthesecondarycodeareerased.

1)Entertheprogrammingmode.

2)Depress8toenterMenu8.
• TheModeindicatorwillturnred.

3)Enterthe3‐digituserslotcodetobedeleted.

•TheModeindicatorwillflashred,indicatingthecontrolleriswaitingforaprogrammingcode
toconfirmthedeletion.
Iftheuserslotisempty,alongbeepwillbeheardandthecontrollerwillreturntoits
normalmode.

4)Enteryourprogrammingcodetoconfirmthedeletion.Iftheprogrammingcodeisvalid,threebeepswillbe
heard
andthecontrollerwillreturntoitsnormalmode.
Iftheprogrammingcodeisinvalid,alongbeepwillbeheardandthecontrollerwillreturntoitsnormalmode.
SensorAccessTechnologyLtd
SensorHouse
10‐11LewesRoad
Brighton
EastSussex
BN24JZ
Tel:01273242355
Fax:01273235030
[email protected]
ForthefullUserManualpleasegoto:
public.sensoraccess.co.uk
