Dnake C112 User manual

User Manual
———
DNAKE C112

REMARK
Please follow the user manual for correct installation and testing. If there is any
doubt please call our tech-supporting and customer center.
Our company applies ourselves to reformation and innovation of our products. No
extra notice for any change. The illustration shown here is only for reference. If
there is any difference, please take the actual product as the standard.
The product and batteries must be handled separately from household waste.
When the product reaches the end of service life and needs to be discarded,
please contact the local administrative department and put it in the designated
collection points in order to avoid the damage to the environment and human
health caused by any disposal. We encourage recycling and reusing the material
resources.

CATALOG
PRODUCT FEATURE ............................................. 1
TECHNICAL PARAMETER ..................................... 1
PACKAGE CONTENT ............................................. 2
OVERVIEW.............................................................. 3
BASIC OPERATION ................................................ 4
WEB SETTING ........................................................ 5
SYSTEM DIAGRAM .............................................. 18
DEVICE WIRING ................................................... 19
INSTALLATION...................................................... 21
TROUBLESHOOTING........................................... 28
SAFETY INSTRUCTION ....................................... 29

1
PRODUCT FEATURE
1. Compact Design
2. 2MP, 1080P HD Camera, WDR
3. H.265 Video Codec
4. Motion Detection
5. Tamper Alarm
6. Optional WIFI and Bluetooth
TECHNICAL PARAMETER
Power Supply: PoE (802.3af) or DC 12V/2A
Resolution: 1920 x 1080
Working Temperature: -40℃to +55℃
Storage Temperature: -40℃to +70℃
Working Humidity: 10% to 90% (non-condensing)

2
PACKAGE CONTENT
MODEL: C112
C112
Screw Fixing Seat
(3 pcs)
PA4×25 (3 pcs) Rear Cover Rain Hood
Sealing Plug of
Wiring Port
Junction Pressing PM2×6 (2 pcs) FM3×6 (1 pcs) FM3×6 (1 pcs)
Wrench Screw
(T10)
Quick Start Guide

3
OVERVIEW
Note:
Calling indicator light: The 1st indicator light will activate if the call button is
pressed.
Talking indicator light: The 2nd indicator light will activate if the call is picked up
or the Door Station is being actively monitored.
Unlocking indicator light: The 3rd indicator light activates for 3 seconds when
the door is unlocked.
Relay Outputs: Supports 1 relay output.

4
BASIC OPERATION
1. Call and Monitor
1.1. Call Indoor Monitor
In standby mode, press button on Villa Station to call Indoor Monitor. During the
call, press button on Villa Station again to end the call. If the call fails or Indoor
Monitor is busy, Villa Station will make a beep sound.
1.2. Monitor Villa Station
Click Doors icon on Indoor Monitor’s homepage to monitor Villa Station.
2. Add Cards by Admin Card
2.1. Add other cards
Step 1: Tap the admin card once;
Step 2: And then tap other cards immediately. Other cards you have tapped can
be used to open the door;
Step 3: Tap the admin card again to finish.
2.2. Delete other cards one by one
Step 1: Tap the admin card twice;
Step 2: And then tap other cards immediately. Other cards you have tapped will
be deleted;
Step 3: Tap the admin card again to finish.
2.3. Delete all other cards
Tap the admin card five times. All the other cards will be deleted.
Tips: The admin card can only be used to manage cards. It cannot be used
to open the door.

5
WEB SETTING
Connect Door Station and PC to a network switch in the same LAN. You can
enter the IP address of Door Station in the web browser search bar and log in
with the default account (admin) and password (123456). This is where you can
configure the device.
To get the IP address, you can search by DNAKE Remote Upgrade Tool installed
in the same LAN with the devices.
1. General
1.1. General > Information
When you first log in to the web interface, you can find basic information
displayed in this dashboard.

6
Model:
Model of the device;
Firmware Version:
Firmware version of the device;
MAC Address:
MAC address of the device;
Framework:
Framework of the device;
UI:
UI of the device;
MCU:
MCU of the device;
DHCP:
Status of DHCP;
IP Address:
Current IP address of the device;
Mask:
Subnet mask of the device;
Gateway:
Gateway of the device;
DNS:
Domain Name Server of the device;
Account:
SIP account of the device;
Status:
Status of SIP registration of the device;
CMS IP:
IP address of CMS;
Status:
Status of CMS registration;
1.2. General > Basic
Language, resolution and volume of the device can be configured in this column.
