Sentera Controls RSTHX-2 Service manual

Mounting and operating instructions
RSTHX-2 COMBINED TEMPERATURE AND
RELATIVE HUMIDITY ROOM
TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 2 - 9
Table of contents
SAFETY AND PRECAUTIONS 3
PRODUCT DESCRIPTION 4
ARTICLE CODES 4
INTENDED AREA OF USE 4
TECHNICAL DATA 4
STANDARDS 4
OPERATIONAL DIAGRAMS 5
WIRING AND CONNECTIONS 5
MOUNTING INSTRUCTIONS IN STEPS 6
OPERATING INSTRUCTIONS 8
VERIFICATION OF INSTALLATION INSTRUCTIONS 9
TRANSPORT AND STORAGE 9
WARRANTY AND RESTRICTIONS 9
MAINTENANCE 9
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 3 - 9
back to the table of contents
SAFETY AND PRECAUTIONS
Read all the information, the datasheet, mounting and operating instructions and
study the wiring and connection diagram before working with the product. For
personal and equipment safety, and for optimum product performance, make sure you
entirely understand the contents before installing, using, or maintaining this product.
For safety and licensing (CE) reasons, unauthorised conversion and/ or modifications
of the product are inadmissible.
e product should not be exposed to abnormal conditions, such as extreme
temperatures, direct sunlight or vibrations. Long-term exposure to chemical
vapours in high concentration can affect the product performance. Make sure the
work environment is as dry as possible; avoid condensation.
All installations shall comply with local health and safety regulations and local
electrical standards and approved codes. is product can only be installed by an
engineer or a technician who has expert knowledge of the product and safety
precautions.
Avoid contacts with energised electrical parts. Always disconnect the power
supply before connecting, servicing or repairing the product.
Always verify that you apply appropriate power supply to the product and use
appropriate wire size and characteristics. Make sure that all the screws and nuts
are well tightened and fuses (if any) are fitted well.
Recycling of equipment and packaging should be taken into consideration
and these should be disposed of in accordance with local and national
legislation/regulations.
In case there are any questions that are not answered, please contact your
technical support or consult a professional.
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 4 - 9
back to the table of contents
PRODUCT DESCRIPTION
e RSTHX-2 series are room sensors which measure temperature, relative humidity
and ambient light. ey feature a wide range of low voltage power supply and two
analogue / modulating outputs. All parameters are accessible via Modbus RTU.
ARTICLE CODES
Article code Supply Maximum power
consumption
Nominal power
consumption Imax
RSTHF-2 18—34 VDC 1,728 W 1,3 W 72 mA
RSTHG-2 18—34 VDC / 15—24 VAC
±10 % 1,8 W 1,35 W 75 mA
INTENDED AREA OF USE
■Monitoring indoor temperature and relative humidity in HVAC applications
■Suitable for residential and commercial buildings
■For indoor use only
TECHNICAL DATA
■2 analogue/ modulating outputs:
►0—10 VDCmode: RL≥ 50 kΩ
►0—20 mA: RL≤ 500 Ω
►PWM (open-collector type): PWM Frequency: 1 kHz, RL≥ 50 kΩ; PWM voltage
level 3,3 or 12 VDC
■Selectable temperature range: 0—50 °C
■Selectable relative humidity range: 0—100 %
■Ambient light sensor with adjustable ‘active’ and ‘standby’ level
■3 LEDs for status indication with adjustable light intensity
■Accuracy: ±0,4 °C (range 0—50 °C); ±3 % rH (range 0—95 % rH)
■Enclosure:
►rear plate: plastic ABS, black (RAL 9004)
►front cover: ASA, ivory (RAL 9010)
■Protection standard: IP30 (according to EN 60529)
■Typical range of use:
►temperature: 0—50 °C
►rel. humidity: 0—95 % rH, (non-condensing)
■Storage temperature: -10—60 °C
STANDARDS
■Low Voltage Directive 2014/35/EC
►EN 60529:1991 Degrees of protection provided by enclosures (IP Code)
Amendment AC:1993 to EN 60529
►EN 60730-1:2011 Automatic electrical controls for household and similar use
- Part 1: General requirements
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 5 - 9
back to the table of contents
■EMC directive 2014/30/EU:
►EN 60730-1:2011 Automatic electrical controls for household and similar use
- Part 1: General requirements
►EN 61000-6-1:2007 Electromagnetic compatibility (EMC) - Part 6-1: Generic
standards - Immunity for residential, commercial and light-industrial
environments
►EN 61000-6-3:2007 Electromagnetic compatibility (EMC) - Part 6-3: Generic
standards - Emission standard for residential, commercial and light-industrial
environments Amendments A1:2011 and AC:2012 to EN 61000-6-3
►EN 61326-1:2013 Electrical equipment for measurement, control and
laboratory use - EMC requirements - Part 1: General requirements
►EN 61326-2-3:2013 Electrical equipment for measurement, control and
laboratory use - EMC requirements - Part 2-3: Particular requirements. Test
configuration, operational conditions and performance criteria for transducers
with integrated or remote signal conditioning
■WEEE 2012/19/ EC
■RoHs Directive 2011/65/EC
OPERATIONAL DIAGRAMS
10
0
50
20
30
40
50
60
70
80
90
100
Minimum
range
Minimum
alert
Maximum
alert
Analogue /
modulating
outputs [%]
T [°C] / rH [%]
Maximum
range
Out of
range
Within
range
Alert
range
Alert
range
Out of
range
* LED indicaon - T (default) and rH
WIRING AND CONNECTIONS
Article type RSTHF-2 RSTHG-2
VIN 18—34 VDC 18—34 VDC 15—24 VAC ±10%
GND Ground Common ground AC ~
AModbus RTU (RS485), signal A Modbus RTU (RS485), signal A
/B Modbus RTU (RS485), signal /B Modbus RTU (RS485), signal /B
AO1 Analogue / modulating output 1 for temperature
measurement (0—10 VDC / 0—20 mA / PWM)
Analogue / modulating output 1 for temperature
measurement (0—10 VDC / 0—20 mA / PWM)
GND Ground AO1 Common ground
AO2 Analogue / modulating output 2 for relative humidity
measurement (0—10 VDC / 0—20 mA / PWM)
Analogue / modulating output 2 for relative humidity
measurement (0—10 VDC / 0—20 mA / PWM)
GND Ground AO2 Common ground
Connections Spring contact terminal blocks, cable cross section: 1,5 mm2
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 6 - 9
back to the table of contents
ATTENTION e -F version of the product is not suited for 3-wire connection. It has separate
grounds for power supply and analogue output. Connecting both grounds together
might result in incorrect measurements. Minimum 4 wires are required to connect
-F type sensors.
e -G version is intended for 3-wire connection and features a ‘common ground’.
is means that the ground of the analogue output is internally connected with
the ground of the power supply. For this reason, -G and -F types cannot be used
together on the same network. Never connect the common ground of -G type
articles to other devices powered by a DC voltage. Doing so might cause permanent
damage to the connected devices.
MOUNTING INSTRUCTIONS IN STEPS
Before you start mounting the unit, read carefully “Safety and Precautions”.
Choose a smooth surface for installation (a wall, panel and etc.).
Follow these steps:
1. Using a flat screwdriver, remove the front white cover by releasing the snap-fits
on its both sides (see Fig. 1 Snap-fits release).
2. Insert the cables through the opening on the rear plate (See Fig. 2 Mounting
dimensions.)
3. Using suitable fastening materials (not supplied), position the room sensor at
least 1,5 m from the floor. When planning the installation, allow enough clearance
for maintenance and service. Mount the sensor in a well-ventilated area. Mind
the correct mounting position and unit dimensions. See Fig. 2 and Fig. 3.
Fig. 1 Snap-fits release Fig. 2 Mounting dimensions
Push here to
release
2x Ø 6
59,8
9,8
74,5
104,5
20
104,5
25,6
70,5
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 7 - 9
back to the table of contents
Fig. 3 Mounting position
Correct Incorrect
Position at min. 1,5 m
from the floor
4. Do the wiring according to the wiring diagram (see Fig.4).
Fig. 4 Wiring and connections
Analogue / modulating
output 1 - T
Analogue / modulating output
2 - rH
Supply voltage
RSTHF-2: 18—34 VDC
RSTHG-2: 18—34 VDC /
15—24 VAC ±10 %
Modbus
RTU
A
/B
5. Put back the cover snap it in.
6. Switch on the mains supply.
7. Customise the factory settings to the desired ones via the 3SModbus software
or Sensistant (if necessary). For the default factory setting refer to the product
Modbus register map.
For the complete Modbus register data, refer to the product Modbus Register
Map, which is a separate document attached to the article code on the website
and contains the registers list. Products with earlier firmware versions may not be
compatible with this list.
NOTE
5.
Optional settings
To assure correct communication, the NBT needs to be activated in only two devices
on the Modbus RTU network. If necessary, enable the NBT resistor via 3SModbus or
Sensistant (Holding register 9).
Example 1 Example 2
RX
ТX
NBT
NBT
NBT
Slave 2
Master
Slave n
Slave 1
Slave 2
Slave 1
RX
ТX
NBT
NBT
Master
Slave n
NOTE On a Modbus RTU network, two bus terminators (NBTs) need to be activated.
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 8 - 9
back to the table of contents
ATTENTION
t
Do not expose to direct sunlight!
OPERATING INSTRUCTIONS
Calibration procedure
All sensor elements are calibrated and tested in our factory. Recalibration is not
necessary.
Bootloader
anks to the bootloader functionality, the unit firmware can be updated via Modbus
RTU communication. With 3SM boot Application (part of 3SM center software
suite), ‘boot mode’ is automatically activated and the firmware can be updated.
NOTE Make sure the power supply does not get interrupted during “bootload” procedure,
otherwise you risk losing unsaved data.
LED indications
1. When the green LED is on, the measured value (temperature or relative humidity)
is between the minimum and maximum alert range values (Fig. 5 - 1).
2. When the yellow LED is on, the measured value (temperature or relative humidity)
is in the alert range (Fig. 5 - 2).
3. When the red LED is on, the measured value (temperature or relative humidity)
is below the minimum measurement range value or above the maximum value.
Blinking red LED indicates loss of communication with a sensor (Fig. 5 - 3).
Fig. 5 LED indications
3
2
1
By default, the LED indication refers to temperature measurements. is can be
changed to relative humidity values via Modbus Holding Register 79 (see Table
Holding registers in the product Modbus Register Map).
NOTE
NOTE Green LED intensity can be adjusted between 0 and 100 % with a step of 10 %
according to the value set in Holding register 80.
Ambient light sensor
e measured light intensity in lux is available in Input Register 41. Additionally,
an active and standby level can be defined in Holding registers 35 and 36. Input
Register 42 indicates if the measured value is below standby level, above active
level or in between both levels:
■Ambient light level < standby level: Input Register 42 indicates “Standby”.
■Ambient light level > active level: Input Register 42 indicates “Active”.
■Standby level < Ambient light level < Active level: Input Register 42 indicates “Low
intensity”.
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER

www.sentera.eu
MIW-RSTHX-2-EN-000 - 06 / 11 / 2019 9 - 9
back to the table of contents
VERIFICATION OF INSTALLATION INSTRUCTIONS
After switching on the power supply one of the LEDs lights up according to the
status of the measured variable. If this is not the case, check the connections.
TRANSPORT AND STORAGE
Avoid shocks and extreme conditions; stock in original packing.
WARRANTY AND RESTRICTIONS
Two years from the delivery date against defects in manufacturing. Any modifications
or alterations to the product after the date of publication relieve the manufacturer
of any responsibilities. e manufacturer bears no responsibility for any misprints or
mistakes in this data.
MAINTENANCE
In normal conditions this product is maintenance-free. If soiled, clean with a dry or
damp cloth. In case of heavy pollution, clean with a non-aggressive product. In these
circumstances the unit should be disconnected from the supply. Pay attention that
no fluids enter the unit. Only reconnect it to the supply when it is completelydry.
RSTHX-2 COMBINED TEMPERATURE AND RELATIVE
HUMIDITY ROOM TRANSMITTER
