SEON CA Series User manual

Wedge Camera CA Series
Quick Installation Guide
© Seon Design Inc. | September 2011 | All rights reserved.
www.seon.com Part Number: 700-0141 R003
Installation Kit Contents
• 1 CA Series wedge camera
• 3 #10 3/4” Phillips screws
• 1 security key
• 1 Quick Installation Guide
• 1 Drilling guide template
1. Choose Camera Location
1. Determine the location for mounting the camera. Select a flat
location to minimize possible moisture leakage into the vehicle.
Cameras must be installed with the cabling running inside the wall
panels.
2. Use the supplied drilling guide template to mark the cable (11/16”)
and screw (5/32”) holes on the panel.
3. Use a step-bit to drill the cable hole, and regular bits for the screw
holes.
2. Connect the Camera
1. Connect the camera cable to the extension cable through the
panel cable hole. See Figure 1.
2. Connect the extension cable’s 2×3 Micro-Fit connector into a
digital video recorder (DVR).
3. Open the Camera
1. Using the security key supplied with the camera, loosen the four
captive screws on the housing. See Figure 2.
2. Lift the housing off of the base.
4. Install the Camera
Use the three #10×3/4" mounting screws supplied with the camera to
attach the camera to a wall or ceiling. See Figure 3.
The mounting gaskets on the camera base seal the screw and cable
holes when mounted on a flat surface.
5. Connect Local Video Out
1. Connect an RCA cable to the Local Video Out RCA jack, shown in
Figure 2.
2. Connect the RCA cable to a video monitor to see the camera’s line
of view while adjusting the camera’s rotation, pan, and tilt
positions.
CAUTION: Vehicle Leakage Risk
For outdoor installations, if a flat surface is not available,
carefully seal the vehicle’s mounting holes under the base of
the camera after installation. Do NOT apply silicone or other
sealants around the base of the camera.
(Version with
optional IR board
shown)
Figure 1
CAUTION: Ventilation Blockage Risk
The camera is designed to vent for proper operation. Do
NOT apply silicone or other sealants around the base of the
camera.
Figure 2
Camera housing
Captive housing
screws
Camera lens
Local Video Out
Base
Figure 3
Mounting gaskets
Base
(Do not
apply
sealant
around
base)
#10x3/4”
mounting
screws
*700-0141*

6. Aim the Camera
To get the required video image, adjust the camera‘s rotation, pan, and
tilt settings using the adjustment controls shown in Figure 4 and
described in the following steps:
1. Rotation: depending on how the camera is mounted, turn the
camera lens until the silver triangle on the lens face is pointed
straight up to ensure the camera shows a level view.
2. Pan: grip the camera pan adjustment U-Bracket sides and twist it
to find the required view.
3. Tilt: loosen the tilt adjustment screws on the U Bracket until the
camera can tilt. Tighten the tilt screws after adjustments are
complete. Do not adjust tilt after tightening screws.
Do not adjust any other screws.
7. Configuration Settings
For configuration switch locations, see Figure 5.
8. Replace Camera Housing
1. Fit the housing onto the base. See Figure 6.
2. Use the security key to tighten the four captive locking screws.
Specifications
Routine Maintenance
Most liquid cleaners or graffiti gel can be used to clean your camera enclosure. Do
not use abrasive cleaners that can scratch the window and reduce visibility of the
camera.
Replacing Damaged Housing
If the camera housing and window is damaged or scratched, order a replacement
housing from your camera distributor.
To remove and replace the housing, follow the steps in section 3 Open the
Camera and section 8 Replace Camera Housing.
Service and Warranty
If your CA Series Wedge Camera is to be returned to Seon Design for service,
please call toll free 1-877-630-7366, or 604-941-0880, and provide the model and/
or serial number of your unit. Ask for a Return Authorization (RA) number. An RA
number allows the Service Technicians to better track your product when it comes
in for service. Please show the RA number on the outside of the package.
ANY PRODUCT SENT TO SEON DESIGN WITHOUT AN RA
NUMBER MAY BE REFUSED.
Please refer to the Warranty form provided with your product to review the terms
of warranty service, contact and shipping information, as well as other important
issues regarding the service and operation of your product.
Information in this guide is subject to change without notice.
Backlight
Compensation
(BLC)
• BLC OFF: (default) shutter speed is based on
the light level of the entire image.
• BLC ON: shutter speed is based on the light
levels near the center of the image. This can
improve image quality when backlight is strong.
Infrared (IR)
Levels • High IR: (default) use for cameras set up to view long range. For example: aisle camera.
• Low IR: use for cameras set up to view close
range. For example: doorway camera.
• Off: IR is disabled. Use in product configurations
where IR is not required.
Camera Rotate Adjustment Directions
Figure 4
Silver Rotation Triangle
Camera Pan Adjustment Directions Camera Tilt Adjustment Directions
Tilt
adjustment
screws (2nd
not shown)
O L H
ON OFF
Figure 5
BLC Switch IR Switch Camera (rear)
Power Consumption 7 W max. @ 12 VDC
Operating Voltage Range 10 to 17 VDC (powered by DVR)
Operating Temperature Range -40 to 140°F (-40 to 60°C)
Horizontal resolution 650 TV Lines
Infrared LED Lamps Optional, 18 high efficiency LEDs
Minimum Illumination 0.1 lux at F1.2 (B&W, D/N),
0 lux (IR on)
Enclosure Size, LxWxH 5.16" (131 mm) x 3.45" (88 mm) x 3"
(77 mm)
Enclosure Material Solid aluminum alloy, powder coated
Window Impact-resistant polycarbonate,
scratch-resistant, UV protected
Connector Cable Length 12" (30 cm)
Weight 19.4 oz (550 g)
Figure 6
Camera housing
Captive housing
screws
Camera sealing
gasket
Base
(Do not apply
sealant around
base)
