SEON CQ Series User manual

Dome Camera CQ/CJ
Series
Quick Installation Guide
© April 2014 | Seon Design Inc. | All rights reserved.
www.seon.com Part Number: 700-0125 R010
Installation Kit Contents
The CQ camera with IR is ideal for interior facing locations. The CJ
camera without IR is ideal for forward windshield facing locations.
• 1 CQ or CJ Series camera, including dome, gasket, connector cable
• 1 Local Video Connector cable (1/8” plug to RCA jack)
• 2 #10 1.25” screws with washers
• 1 Security key
• 1 Quick Installation Guide
• 1 Mounting template
1. Choose Camera Location
Determine the location for mounting the camera.
• choose a solid surface to minimize vibration
• choose a location away from access panels, hatches, or doors
which may block the camera view
• choose a location away from heat sources
Cameras are usually installed with the cabling running inside the wall
panels.
2. Connect the Camera
1. Connect the camera cable to the extension cable. See Figure 1.
2. Connect the extension cable’s 2×3 Micro-Fit connector into a
digital video recorder (DVR).
3. Open the Camera
1. Using the security key supplied with the camera, remove the
locking screw from the bezel. See Figure 2.
2. Turn the bezel and dome counter-clockwise to release it from the
base.
3. Pull the bezel and dome up and away from the base.
4. Install the Camera
Use the two #10×1.25" mounting screws and the two rubber washers
supplied with the camera to attach the camera to a wall or ceiling.
See Figure 3.
5. Connect Local Video Out
1. Connect the supplied 1/8” plug to RCA jack cable to the Local
Video Out socket, shown in Figure 3.
2. Connect the cable to a video monitor to see the camera’s line of
view while aiming the camera’s pan tilt and rotate positions.
(CQ only) The infrared LEDs have a five second lag when turning
on or off.
(CQ Camera shown,
CJ camera has no
IR lamps)
Figure 1
CAUTION: Camera Damage Risk
While installing the camera, do not impact the printed circuit
board inside the camera with screws or screwdriver bits.
Damage to the camera can occur.
Figure 2
(CQ Camera shown,
CJ camera has no
IR lamps)
Figure 3 (CQ Camera shown, CJ camera has no IR lamps)
Rubber Washers
Mounting gasket Base Local Video Out
#10x1.25” mounting screws
*700-0125*

6. Aim the Camera
1. Before adjusting the camera, first loosen the camera‘s pan, tilt, and
rotate adjustment screws.
2. Then adjust the settings to get the required video image using the
adjustment controls shown in Figure 4.
3. Tighten all screws after adjustments are complete. Do not adjust
after tightening screws.
7. Configuration Settings
For configuration switch locations, see Figure 5.
8. Replace Camera Dome
1. Fit the bezel and dome onto the base.
2. Turn the bezel clockwise until it snaps into place.
3. Ensure the rubber IR boot around the camera lens is firmly
pressed against the inside of the dome.
4. Use the security key to tighten the locking screw.
Specifications
Routine Maintenance
Most liquid cleaners or graffiti gel can be used to clean your camera
enclosure. Do not use abrasive cleaners that can scratch the window
and reduce visibility of the camera.
If the window in your camera is damaged or scratched beyond use,
order a replacement window from your camera distributor.
Replacing a Damaged Dome
1. If the camera dome is damaged or scratched, order a replacement
bezel and dome assembly from your camera distributor.
2. To remove and replace the bezel and dome, follow the steps in 3
Open the Camera and 8 Replace Camera Dome.
Service and Warranty
For full warranty information, go to www.seon.com
Seon Design Inc. (Seon) warrants the cameras and components listed
below against defects in workmanship and materials provided that such
defects appear or are discovered within the respective periods specified
below and provided further that the purchaser of such products notifies
Seon of such defects within thirty (30) days of the appearance or
discovery of such defects:
• Three (3) years from date of purchase, parts and labor on all
Cameras
• Three (3) years from date of purchase, parts and labor on the
Explorer® Premier, DX, TX, EX, MX, and Trooper® TL series
mobile DVR Systems
• One (1) year from date of purchase, parts and labor on the
Smart Reach® Wireless systems and other Wireless products
• One (1) year from date of purchase, parts and labor on the
VML Controller and other vMax Live Plus hardware products
• One (1) year from date of purchase, parts and labor on all
other products and accessories
All service/replacement parts and repairs are warranted for a period of
90 days.
If your CQ Series Dome Camera is to be returned to Seon Design for
service, please call toll free 1-877-630-7366, or 604-941-0880, and
provide the model and/or serial number of your unit. Ask for a Return
Authorization (RA) number. An RA number allows the Service
Technicians to better track your product when it comes in for service.
Please show the RA number on the outside of the package.
ANY PRODUCT SENT TO SEON DESIGN WITHOUT AN RA
NUMBER MAY BE REFUSED.
Customer Service Contact Information
Audio Level
(Adjust only if
necessary)
• Clockwise: decrease volume level.
• Counter clockwise: increase volume level.
IR Levels
(CQ Camera
only)
• High IR: (default) use for cameras set up to view
long range. For example: aisle camera.
• Low IR: use for cameras set up to view close
range. For example: doorway camera.
Mirror Image
Setting • Mirror OFF: (default) camera image appears as normal.
• Mirror ON: camera image displays as seen
through a mirror.
Backlight
Compensation • BLC OFF: (default) shutter speed is based on the light level of the entire image.
• BLC ON: shutter speed is based on the light
levels near the center of the image. This can
improve image quality when backlight is strong.
Microphone
Camera Pan Adjustment
screw (not shown) at the
base of the U-bracket.
U Bracket
Camera Tilt Adjustment
Screws (2nd not shown).
Camera Rotate
Adjustment Grips
IR Boot
(CQ Camera shown, CJ
camera has no IR lamps)
Figure 4
Figure 5
Audio Level Control
IR LED Lamps
IR Switch
Mirror Switch
BLC Switch
Local Video Out
(CQ Camera shown,
CJ camera has no IR
lamps)
Power Consumption 1.3 W (IR off); 2.7 W (IR on, CQ only)
Operating Voltage Range 11 to 17 VDC (powered by DVR)
Operating Temperature Range -4 to 140°F (-20 to 60°C)
Horizontal resolution 600 TV Lines
Infrared LED Lamps (CQ only) 14 high efficiency LEDs
Minimum Illumination
(CQ only) 0.1 lux at F1.2 (B&W, D/N),
0 lux (IR on)
Enclosure Size Diameter: 3.75” (95 mm)
Height: 3.4" (86 mm)
Enclosure Material Solid aluminum alloy
Dome Impact-resistant polycarbonate,
anti-glare, scratch-resistant hard
coating, UV protected
Connector Cable Length 9.5” (24 cm)
Local Video Out Cable 1/8” (3.5mm) plug to RCA jack
Weight 0.9 lbs (0.4 kg)
