DeLonghi TRV Series User manual

TRV Series
OIL FILLED RADIATOR
Instructions for use

23
1
EF
A
B
D
C

3
IMPORTANT WARNINGS
Read all the Instruction for Use carefully before using
the appliance. Keep this Instructions for Use.
Danger!
Failure to observe the warning may result in life threatening
injury by electric shock.
- Do not use the heater in the vicinity of
bathtubs, wash basins, showers, sinks
and swimming pools.
- Never use the heater to dry laundry.
- If the power cable has been damaged,
it must be replaced by the manufac-
turer or the technical service centre or
by a qualied person so as to avoid all
risks.
Important!
Failure to observe the warning could result in injury or dam-
age to the appliance.
-This appliance can be used by children
aged from 8 years and above and per-
sons with reduced physical, sensory
or mental capabilities or lack of ex-
perience and knowledge if they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved.
Children shall not play with the appli-
ance. Cleaning and user maintenance
shall not be made by children without
supervision.
- Children of less than 3 years should be
kept away unless continuously super-
vised.
- Children aged from 3 years and less
than 8 years shall only switch on/o
the appliance provided that it has been
placed or installed in its intended nor-
mal operating position and they have
been given supervision or instruction
concerning use of the appliance in a
safe way and understand the hazards
involved. Children aged from 3 years
and less than 8 years shall not plug
in, regulate and clean the appliance or
perform user maintenance.
CAUTION — Some parts of this
product can become very hot and
cause burns. Particular attention
has to be given where children
and vulnerable people are pres-
ent.
- WARNING: Do not use this heater in
small rooms when they are occupied
by persons not capable of leaving the
room on their own, unless constant
supervision is provided.
- The body of this radiator is lled with
a precise quantity of special oil, so that
repairs requiring the opening of the oil
body must only be made by the service
agent. Any oil leakage must be report-
ed to the Customer Experience, see en-
closed guarantee for details.
- When scrapping the heater, follow the
regulations concerning the disposal of
oil.
- The appliance must not be located im-
mediately below a xed socket-outlet.
- CAUTION: in order to avoid any dan-
ger caused by an accidental resetting
of the safety system, this appliance
must not be powered through an ex-
ternal timer.
- Do not obstruct the air intake and out-
let area (danger of overheating).
Danger of burns!!
Failure to observe the warning could result in burns or scalds.
- WARNING: In order to avoid
overheating, never under any

45
circumstances cover the appliances
during operation, as this would lead
to dangerous overheating.
- The use of an extension lead is not
recommended, as overheating of the
extension lead may occur during the
operation of the heater.
- Never place the power cable on top of
the heater while it is hot.
- Do not rest anything on the appliance.
- WARNING: To reduce the risk of re,
keep textiles, curtains, or any other
ammable material a minimum dis-
tance of 1 m from the air outlet.
Please note:
This symbol indicates recommendations and important infor-
mation for the user.
- We recommend that you not place the
heater in a draught, because strong
draughts of air may adversely aect
the equipment’s operational ecien-
cy.
- Only use this heater on a horizontal
and stable surface.
- Always use the appliance in an upright
position.
- Do not use this heater if it has been
dropped.
- Do not use if there are visible signs of
damage to the heater.
- In order to eliminate the radiator's
“new”smell , set it to maximum power
for at least two hours when used for the
rst time. During this operation, the
room in which the radiator is located
must be ventilated. A little smoke due
to the protective substances applied to
the heating element before transport
may be given o.
- Position the appliance so that the plug
and the outlet can be easily reached.
- Do not use the appliance in rooms less
than 4 m2in area.
- The appliance is tted with a safety
device which will switch o it in case
of accidental overheating.
To reset, please contact Customer Ex-
perience, see enclosed guarantee.
- Before putting the appliance away,
make sure it is completely cooled and
unplugged from the mains socket.
Do not store in dusty atmospheres.
- The appliance must not be hung.
Fundamental safety warnings
Dear customer - the plug on the
appliance heats up during use. This is
completely normal. This HIGH POWER
HEATING APPLIANCE complies with our
usual high standards. You should,
however, make sure that your power
socket is in good condition and that the
plug on the appliance is plugged into the
socket correctly to avoid accidental
overheating. If the appliance is used for
long periods of time, we recommend
checking the plug and mains socket
regularly. If in doubt, consult an
electrician.
For non-EU countries only:
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or in-
struction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.

5
DESCRIPTION
A Thermostat pointer
B Indicator light
C Power selector
DTimer
E Cord holder
F Wheel
USE
“Easy wheel” system
Turn the radiator upside down and rest it on a piece of cloth or
other soft surface to avoid damaging the paint.
Open the wheels completely by rotating them outwards (g.
1). Turn the radiator upright.
Important
When in use, the radiator should always be kept vertical
(wheels at the bottom, controls at the top). Any other
position could be dangerous!
Connection
- Before using the appliance check that your supply
voltage is the same of that shown on the rating label
of the unit and that the power socket and power supply
line correspond to the load specied.
- Check also the current capacity of your fuses. CONNECT
YOUR HEATER TO EARTH PROVIDED SOCKET ONLY.
The radiator must be connected to a perfectly functioning
230-240 V AC socket with correct poles. Avoid contact
between clothing, household linen, furniture, inammable
material and the socket providing power to the radiator.
TURNING ON
Plug into the mains, turn the thermostat pointer as far as it
will go to maximum and turn the radiator on using the power
selector as described below:
• Turn the power selector to 1 (minimum power) (the
light comes on).
• Turn the power selector to 2 (medium power) (the light
comes on).
• Turn the power selector to 3 (maximum power) (the
light comes on).
Please note: For economic operation, once the
appliance has reached working temperature, you can use
minimum or medium power (1 or 2).
Adjusting the thermostat
When the room has reached the required temperature, turn
the thermostat slowly clockwise until a "click" is heard and
no further. The thermostat will automatically regulate the
temperature set and keep it constant. If your model has three
power levels, in the spring or autumn or on mild days, you can
further save energy by using minimum power.
Frost protection function
Turn the thermostat dial to the and select the maximum
power, the appliance maintains room temperature at about
5°C, preventing freezing with minimal energy consumption.
Please note: To turn the appliance o completely, turn
the power selector to "0".
THE TIMER
As with all clocks, the timer must be set to the exact time.
For example, if it is 9.30 in the morning, turn the dial of the
timer clockwise (in the direction of the arrow) until 9.30 is
lined up with the pointer
IMPORTANT: DO NOT TURN THE DIAL OF THE TIMER
ANTICLOCKWISE.
The timer is an electric clock and works only if plugged into
a socket. If disconnected, the timer stops and must be reset.
See gure below:
Period of
operation Tooth
Pointer
Selector (some models only)
Manual mode
Programme mode
Appliance o

67
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
The appliance doesn't work Be sure it is plugged in and that the
electrical outlet is working.
Check for any obstruction.
The temperature may be set too low.
Plug into the power outlet.
Remove the obstruction and let the
appliance cool down. If the appliance
doesn't work please contact the nearest
De'Longhi Customer Service.
Set the temperature to a higher position.
IMPORTANT: the timer consists of 96 teeth, each representing
a 15-minute period. The appliance can be programmed to
come on and go o at set times. With the timer, the appliance
is programmed to within 15 minute intervals and you can
programme up to 48 cycles (each cycle consists of a coming
on and a going o time) during a 24 hour period). The teeth
can be pushed or pulled with your ngers. When a tooth is
pushed towards the centre of the dial, the radiator remains in
operation for those 15 minutes. If the tooth is pulled out, the
radiator is o during that period.
Using the timer
A) Plug into the mains socket.
B) Turn the dial clockwise to set the current time (see
SETTING THE CLOCK).
C) Push the teeth corresponding to the period you do not
want the radiator to operate towards the outside. For
example, the radiator in the gure will be on from 2.00
to 5.00.
D) Turn the power selector to the required position (1, 2 or
3).
E) Once the teeth have been set for the desired periods of
heating, the radiator will come on and go o as set.
F) While the radiator remains plugged into the socket, the
timer retains the correct time.
OPERATION WHITOUT TIMER
To operate whitout timer, place the selector in the I position
(see gure).
To go back to programmed operation, place the selector in
the position.
Please note: when the selector is in the 0 position, the
appliance is o. In the I and 0 positions, the timer is still set
to the current time.
Safety device
A safety device shuts the radiator down in the case of
overheating. To start the radiator up again, call the nearest
service centre.
MAINTENANCE AND SERVICE
Before performing any operations on the appliance, always
unplug from the mains socket and leave to cool.
Dust the radiator with a soft damp cloth without using
detergents or abrasives.
If the radiator is not used for a long period of time, wrap
the cable around the cable tidy and store the appliance in a
dry place. This appliance has been made to last many years
without problems.
In the event of malfunction or doubt, do not try and repair on
your own.There would be the danger of re or electric shock.
Call the nearest service centre (see list of service centres).
TECHNICAL CHARACTERISTICS
Power supply See rating plate
Absorbed power “

7
5710910471_01_1219
De’Longhi Appliances via Seitz, 47 31100 Treviso Italia www.delonghi.com
Proudly distributed by
De’Longhi Australia Pty Limited
P.O. BOX 4540
CASULA MALL NSW 2170
Customer Service Ph: 1800 126 659
Fax: [phone]
www.delonghi.com.au
e-mail: info[email protected]
De’Longhi New Zealand Limited
99 Khyber Pass Road
Grafton 1023
Auckland, New Zealand
P.O. Box 58-056 Botany
MANUKAU 2163
Customer Service Ph: 0508 200 300
Fax: [phone]
www.delonghi.co.nz
e-mail: info[email protected]
