SEWOO LK-P12 Release note

LK-P12
SEWOO TECH 1 Rev. 1.00
Mobile Printer
Rev. 1.00
Windows CE Printer Driver Manual
LK
-
P
1
2

LK-P12
SEWOO TECH 2 Rev. 1.00
TABLE of CONTENTS
1. Instruction.
2. Supported processor family.
3. How to install the Windows CE Printer Dri er.
4. How to setup the Windows CE Printer Dri er.
5. How to setup the printing dialog box with Windows CE Printer Dri er.
6. How to print with Windows CE Printer Dri er.

LK-P12
SEWOO TECH 3 Rev. 1.00
1. Instrution.
This Windows CE Printer Driver Manual explains how to install, how to setup and
how to use mobile printer driver on OS like Microsoft Windows CE.
The installation manual is written based on the LK-P11.
The installation program is different. But, the installation procedure is
same.
Please note.
2. Supported processor family.
ARM, MIPS, SH, x86

LK-P12
SEWOO TECH 4 Rev. 1.00
3. How to install the Windows CE Printer Dri er.
2.1. Double-click the Dri er installation file (LUKHANLK-P11WindowsCEPrinterDri er-xxx.exe).
2.2. Click the “Next>” button.
2.3. Click the “Next>” button.

LK-P12
SEWOO TECH 5 Rev. 1.00
2.4. After confirming the license click the “Finish” button.
2.5. Choose the location to install and click the “Install” button.

LK-P12
SEWOO TECH 6 Rev. 1.00
2.6. You can see the progress of driver installation in PDA.
2.7. You can see the below message on PDA when the driver is successfully installed
on your device. After seeing this message click the “ok” button.

LK-P12
SEWOO TECH 7 Rev. 1.00
4. How to setup the Windows CE Printer Dri er.
- Start  Program  Execute LK-P11 ARMV4(i) Setup.exe.
The “Printer Commands” and “NV Upload” button are not available on below
photo, because its basic emulation is CPCL.
Click the “Port Settings” button.
- Input the port name what you want to use.
Port Name : “COM5:” or “COM5:115200” or “LPT1” or “Wi-Fi Address”
“Wi-Fi Address”“192.168.0.193” or “192.168.10.200”, and so on.
(ex) Input COM5:115200.

LK-P12
SEWOO TECH 8 Rev. 1.00
- Click the “Add Port” button.
You can see the added port in “Port Lists in Device”.
- Choose the port and click the “Select Port” button.
COM
5
:115200

LK-P12
SEWOO TECH 9 Rev. 1.00
- Click the “Paper Settings” button at Start Menu.
- Choose the paper you want to use.
When the user does not choose the paper, the default paper set will be selected.

LK-P12
SEWOO TECH 10 Rev. 1.0
0
- Choose the emulation according to your need.
Value Description
ESC/POS Receipt Printing.
CPCL With Gap Label printing with gap.
CPCL With Mark Label printing with Black Mark.
CPCL Continuous Continuous label printing.
- When you choose ESC/POS emulation, you can use additional functions by
clicking “Printer Commands” button.

LK-P12
SEWOO TECH 11 Rev. 1.0
0
- With this driver, you can print image and text which are stored in Flash of the
printer. You only need to do input the number of stored logo.
- Click the “NV Upload” button to save the images to flash memory.

LK-P12
SEWOO TECH 12 Rev. 1.0
0
- After connecting printer you can store data into the Flash of the printer and you
can print and cancel it by adding files like below photo.
- When you finish the setting of printer driver, pleas click the “Save” button.

LK-P12
SEWOO TECH 13 Rev. 1.0
0
- When you click “OK” button the program is closed.
- Restart the program and check it by using “Test Page Print”.

LK-P12
SEWOO TECH 14 Rev. 1.0
0
5. How to setup printing dialog box with Windows CE printer dri er.
- When you choose printing function in Windows CE printer driver, you can see
the below printing dialog box.
When you set up it like below picture and click “ ok” button, the printer starts
printing.
6. How to print with Windows CE printer dri er.
When you want to get more information about printing with printer dri er, please refer to the
attached sample program.
