SEWOO LK-P43B User manual

All specifications are subject to change without notice
USER’S MANUAL
MODEL : LK-P43B (Peeler)
SEWOO TECH CO.,LTD.
374-2, Gajang-dong, Osan-si, Gyeonggi-do, 447-210, Korea
TEL : [phone] FAX : [phone]
www.miniprinter.com
P43B(Peeler) Rev. D 10/14

1
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTION
“Made for iPod,” “Made for iPhone,” and “Made for iPad” mean that an electronic
accessory has been designed to connect specically to iPod, iPhone, or iPad, respectively,
and has been certied by the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its compliance with safety and
regulatory standards. Please note that the use of this accessory with iPod, iPhonem or
iPad may affect wireless performance.

233
Table of Contents
1. Safety Caution 4
2. Unpacking 6
3. Product Overview 7
4. Installation & Usage 8
4-1. Display 8
4-2. Installing the Battery 9
4-3. Removing the Battery 10
4-4. Charging the Battery 11
4-5. Battery charger usage 12
4-6. Usage of Cigar Jack Charger 13
4-7. Installing Belt Clip 14
4-8. Interface Cap Installation 15
4-9. Roll Paper Installation 16
4-10. Install / Uninstall the External Paper Guides 18
4-11. Peel Mode 20
4-12. Shoulder Strap Installation 22
4-13. Diagnostic Test 23
5. Peripherals Connection 25
5-1. Bluetooth Connection 25
5-2. Interface Cable Connection 26
6. Printer Cleaning 27
6-1. Print-Head Cleaning 27
6-2. Platen Roller Cleaning 28
7. Pritner Specication 29
7-1. Specication 29
8. CPCL Command Compatibilit y 31
9. ESC/POS Command Compatibilit y 34
10. ZPL Command Compatibilit y 36

45
WARNING
Failure to follow these instructions could result in re, electric shock,
or other injuries, or property damage
Failure to follow these instructions could result in re, electric shock,
or other injuries, or property damage
(Turn off the power at installation,
transportation, wiring and inspection.)
(You may get hurt and it can be broken
when it falls)
(Potential risk of re or unit malfunction)
(Potential risk of re or unit malfunction)
(Potential risk of discoloration or
electric shock)
(Potential risk unit malfunction, electric
shock or re. When the product needs
to be repaired, please contact in place
where you ordered.inspection.)
Dealer
Do not pull out the power plug to turn off
the product.
Do not install the product in uneven or
inclined surface.
If the product that needs to be repaired,
please contact in place where you ordered.
Please do not give excessive shock.
Keep product away from the water and
other material.
Do not disassemble, repair or modify the
product.
CAUTION
For higher reliability and safety, consider the following precautionary measures.
Read and follow the instructions carefully before running of the product.
1. Safety Caution
WARNING
Failure to follow these instructions could result in re, electric shock,
or other injuries, or property damage
Indication
Prohibition
(Potential risk of electric shock or re)
(Potential risk of electric shock or re) (Potential risk of electric shock or re)
(Potential risk of electric shock or re)
Must follow
Do not disassemble Unplug the power from the
outlet
Grounding to prevent electric
shock
Do not handle the product
with wet hands
Do not pull or touch the power plug with
wet hands.
Do not bend the wire and do not allow the
wire to be pressed by heavy object.
If a power plug is broken or a plug is cut or
worn, do not use it.
Do not overload the power plug into one
outlet.

67
SHOULDER
STRAP RING
3. Product Overview
CHARGER
CONNECTOR
COVER OPEN
BUTTON
Front
Bottom
PEELER BODY
PEELER WING
BATTERY
BELT CLIP
CONNECTOR
SERIAL
USB
DISPLAY
2. Unpacking
Printer Battery Belt Clip
AC cord
Optional
Standard
CD
USB Cable
Quick Reference
Adaptor
Paper
Shoulder Strap
Serial Cable
Battery Cradle
Cigar Jack

89
4-2. Installing the Battery
NOTE
Remove the battery. Insert the battery as shown.
Replace the battery.
You must fully charge the battery when you receive the printer.
Batteries can be charged in the printer or in an optional external cradle.
4-1. Display
4. Setting Up the Product
Button Name
F unction
Paper Feed /
Down Button
Advances the supply. Clears error message.
Moves down through menu options.
1. Refer to 4-9 for Diagnostic Test information.
2. Refer to the service manual regarding Hexadecimal
Dumping.
Enter Button Selects the highlighted menu option.
Up Button Moves up through menu options.
Power Button
Turns the printer on and off. Press to turn
power on. Press for three seconds to turn power off.
Wakes the printer from sleep mode.
NOTE
1. The battery status LEDs indicate amount of power remaining.
Actual run-time remaining depends on factors such as the contents of output,
distance to computer, etc.
2. When the battery level is very low, high density printing can result in the printer
switching off during printing resulting in possible loss of data.

10 11
4-4. Charging the Battery
1. Be sure that the printer is turned off
2. After open the DC JACK cover, insert DC JACK into the printer.
3. Plug the power code to electrical outlet.
4-4-1 The status of lamp in charging
Status Charging Charging Completed
Charging Lamp
Red
Green
If there is trouble while charging the battery, the charge indicator LED blinks green.
Try unplugging and reconnecting charger, charging should resume.
Charging is complete when the LED changes to solid green.
NOTE
4-3. Removing the Battery
Remove the battery. Lift out the battery.

12 13
4-5-1 The status of lamp in charging
Status charging charging complete
Charging Lamp
Red
Green
NOTE
4-5 Battery charger usage
DC Jack
1. Insert the battery into the battery holder as shown above
2. Connect the DC JACK to the power electrical outlet.
3. Plug the power code into the electrical outlet.
4. Once the charging is completed, remove the battery from the holder.
Optional
Lamp
In the case the battery is not xed properly in the holder, the red lamp will be blinking,
Then, extract and reinsert the battery.
Connect the vehicle charger to the printer.
4-6. Usage of Cigar Jack Charger
Printer
Optional
Input 12V ~ 24V
9.5V / 3A
Output
Connect the vehicle charger to the printer.
NOTE

14 15
The belt clip is included with the printer but is not required to be used or installed!
4-7. Belt Clip Usage
Insert screw into belt clip.
Tighten the screw with driver as shown.
1
2
NOTE
4-8. Interface Cap Installation
1 2
34
When Interface Cap separated from
the printer, try to array the Cap Hook in
horizontal direction as shown in the image.
Using a sharp tool, insert the Cap Hook
to the hole which is located in the right
side of Interface Cap.
When Cap Hook inserted, install the Cap
Cover in direction of an arrow as shown
in the image.
Close the Interface Cap cover.

16 17
NOTE
If the users close the cover with one hand,
it would not be closed completely.
Please use both hands to close.
4-9. Roll Paper Installation
1 2
34
Put the stock in so it unrolls from the
bottom. Remove the stock core when it
is empty. Pull a short length of stock out
of the printer.
Open the Paper cover by pressing the
Open button and set the width of paper
guide by turning the knob with nger.
After inserting the paper, adjust the
paper guide to little wider than paper size.
Then pull the paper out and close the
paper cover.
Close the Paper cover with both hands
and run the paper line up by pressing
the Feed button.
Be cautious to handle the product when Printer Cover is an open position.
You may have a potential risk of injury when Paper Cover closes
CAUTION

18 19
Using sharp tool, push External Paper
Guides in order to detach from the
printer. Press circle on the middle of
external paper guide with tool.
Assemble two (inner & outer) External
Paper Guides as shown in gure and
press three points to x rmly inner
guide with outer guide.
The outer cover of External Paper Guides
will be separated.
Two external paper guides will be
installed to printer.
External Paper
Guides
4-10. Install / Uninstall the External Paper Guides
Uninstall the External Paper Guides
Install the External Paper Guides
1 2
1 2
When install the external paper, set the printer 20mm above from the
ground. Then insert the paper in right direction to the backside of the printer
paper slot and adjust the paper guide to t the paper properly.
Please set apart the printer and paper at
least twice of the paper length.
Recommendation
300mm이상
20mm이상
300mm이상
20mm이상
CAUTION
20mm or more
300mm or more

20 21
4-11. Peel Mode
1 2
1 2
With a roll of stock installed, slide the
peeler body towards the back of the
printer.
Press the Feed button.
Peel Mode
Non-Peel Mode
Push the peeler body until you see
two complete triangles.
Press the Feed button.
Pull down the Peeler Wing while pressing
the Cover open button slightly.
Paper (1)
Label Paper
Engraved Line
Paper (2)
Label Paper
When users operates the peeler like the image below that has slits
on the label(1) and the perforated label(2), there might be an error
in the peeler function
CAUTION

22 23
Insert the strap into the hook of the printer.
Place the end of the strap into the hook
of shoulder strap.
After pulling out the end of the strap tightly,
put it into the clip to be fastened.
Optional
1
32
4-12. Shoulder Strap Installation 4-13. Diagnostic Test
1 2
3
NOTE
Turn off the printer.
The information label prints.
Press and hold the Feed button
and Power button.
1. For Hex Dump mode, do steps 1-2 then
press the Feed button.
2. After printing ASCII pattern, the diagnostic
test is complete.
3. If the Feed button is not pressed to go to
Hex Dump mode, the printer exits
diagnostics after three seconds.

24 25
The Sample of Self-test Printout
Upon initial installation or for troubleshooting, you can run the diagnostic test to
get information about:
Firmware version, emulation, codepage, sensor settings, interface settings, etc.
If no issues are found with diagnostic test, examine other devices and software.
The diagnostic test is working independent of devices and software.
● Do Not Overheat the Motor
To prevent the motor from overheating, stop the printer for at least 30 seconds after
continuously printing 1.5 meters.
5. Peripherals Connection
1. Printer can be connected to the PDA and PC which can do wireless communication.
2. By using Bluetooth function supported in PC, printer can be connected.
NOTE
Refer to the System Administrator Guide for more information.
This printer can communicate with peripherals device via Bluetooth and Cables.
5-1 Bluetooth Connection

26 27
5-2. Interface Cable Connection
1. Connect the USB or Serial cable to the cable connector on the printer.
2. Connect the interface cable into the USB or Serial port of the device
(PDA, PC, etc.)
NOTE
Use cable only offered by the printer manufacturer.
Serial
USB
6-1. Print-Head Cleaning
6. Printer Cleaning
If the interior of the printer is dusty, printing quality can be lowered.
In this case, follow the instructions below to clean the printer.
NOTE
1. Make sure to turn the printer power off prior to cleaning.
2. The print-head can become very hot during printing;
allow the printer approximately10 minutes to cool before cleaning.
3. Do not touch the print-head, it can be damaged by static electricity.
4. Take care not to allow the print head to become scratched and /or damaged
in any way.
1. Use an applicator swab moistened with an isopropyl alcohol to clean the
print-head and remove any dust.
2. Once cleaning is complete, allow the printer to dry then install the stock
and close the cover.
Print-Head

28 29
6-2. Platen Roller Cleaning
1.Clean the platen roller with a clean soft cloth moistened with isopropyl
alcohol or a cleaning pen.
2. Turn the platen roller with your nger to clean the
Platen Roller
Printing Method Direct Thermal
Printing Speed 80mm/sec
Resolution 203 DPI X 203 DPI
Character ALPHA NUMERIC Character, Extension Character
Barcode One-Dimensional
Barcodes
UPCA +2/+5, UPCE +2/+5, EAN8 +2/+5,
EAN13 +2/+5, EAN 128, Interleaved 2 of 5,
Extended Code 39, Codabar (NW7), Code 128,
Code 93, PostNet
Two-Dimensional
Barcodes
PDF417, MaxiCode, Aztec, QR Code (Quick Response),
Datamatrix
Stacked One-
Dimensional
Barcodes
GS1 Databar (RSS or Composite Code)
Emulation ESC/POS, ZPL, CPCL Command compatible
Driver Windows (2000, XP, Vista, 7, 8), Symbian OS
Windows mobile(Pocket PC, 2003, 6x), Android,
Windows CE 4.2/5.0/6.0, Linux, Blackberry
Sensor Black-Mark Upper/Lower, Gap, Cover open,
Peeler Detect, Peeler S/W, Media-Width Detect
Paper Paper Type Thermal Paper
Width 50~112mm
Thickness Roll : 0.06 ~ 0.165 mm / Fanfold : 0.06~0.15 mm
External Diameter Max. Φ 58mm
Internal Diameter 12.5mm±0.5mm
Reliability TPH 50km
Battery Continuous Printing 62min
Standby for 60hours
Printing Length: 140M
MEMORY Up to Flash 32MB
Communications standard Serial(RS-232C), USB
Optional Bluetooth Class2
7-1. Specication
7. Printer Specication

30 31
Display TFT-LCD (RGB) 240X400
Adaptor Input AC 100 ~240V 50/60Hz
Output 9.0V, 4.0A
Battery Battery Type Li-ion
Output STANDARD : 7.4V, 2600 mAh/19.24Wh
OPTION : 7.4V, 5200 mAh/38.48Wh
Charging Time 3.3 Hrs Charging
Size WXDXH(mm) 166X 174 X 80
WXDXH” 6.5 X 6.8 X 3.1
Weight 1Kg (With battery)
Environment Sealing IP54
Temperature Operation -21~ 55℃
Storage -30 ~ 65℃
Humidity Operation 10 ~ 90%
Storage 10 ~ 90%
Printer Commands Compatibility
PRINT
○
FORM
○
JOURNAL
○
UNITS
○
USING COMMENTS
○
TEXT Compatibility
TEXT
○
FONT-GROUP(FG)
○
TEXT CONCATENATION
○
MULTILINE(ML)
○
COUNT
○
SETMAG
○
SCALABLE TEXT Compatibility
SCALE-TEXT
○
SCALABLE CONCATENATION
○
LINEAR BARCODES Compatibility
BARCODE
○
BARCODE-TEXT
○
COUNT
○
Two-Dimensional Bar Codes Compatibility
PDF417 (PORTABLE DATA FILE)
○
MICROPDF-417
●
MAXICODE
○
QRCODE
○
NOTE
Compatible Partially
Compatible Not Compatible
○●△x
Compatible with only
commanders provided by
the manufacturer.
8. CPCL Command Compatibility

32 33
DATAMATRIX
●
GS1(RSS-14)
○
AZTEC
○
GRAPHICS Compatibility
BOX
○
LINE
○
INVERSE-LINE
○
PATTERN
○
GRAPHICS
○
PCX
○
Advanced Commands Compatibility
CONTRAST
○
TONE
○
JUSTIFICATION
○
PAGE-WIDTH
○
PACE
○
NO-PACE
○
WAIT
○
SPEED
○
SETSP
○
ON-FEED
○
PREFEED
○
POSTFEED
○
COUNTRY/CODE PAGE
○
FORMAT FILES
○
BEEP
○
Line Print Mode Compatibility
SETLP
○
SETLF
○
Moving With X and Y Coordinates
○
LMARGIN
○
SETBOLD
○
SETSP
○
Special ASCII Characters
○
SETFF
○
SET-TOF
○
SETLP-TIMEOUT
○
ADVANCED UTILITIES Compatibility
VERSION
○
CHECKSUM
○
DEL
○
DIR
○
DEFINE-FILE
○
TYPE
○
BAUD
○
COUNTRY / CODE-PAGE
○
TIMEOUT
○
BEED
○
ON-LOW-BATTERY
○
LT
○
SET-TIME
○
GET-TIME
○
SET-DATE
○
GET-DATE
○
PRINTING A TIME STAMP
○
PRINTING A DATE STAMP
○
PAPER-JAM
○
PRINTER ESCAPE Compatibility
SET AND READ CODE
△
STATUS / INFROMATION
○
USER LABEL COUNT
○
POWER OFF
○

34 35
9. ESC / POS Command Compatibility
Command Function Compatibility
HT Horizontal tab
○
LF Print and line feed
○
CR Print and carriage return
○
FF Print end position label to start printing
○
CAN Cancel print data in page mode
○
DLE EOT Real-time status transmission
○
DLE ENQ Real-time request to printer
○
ESC FF Print data in page mode
○
ESC SP Set character right-side spacing
○
ESC ! Set print mode
○
ESC $ Set absolute print position
○
ESC % Select/cancel user-defined character set
○
ESC & Define user-defined characters
○
ESC * Set bit image mode
○
ESC - Turn underline mode on/off
○
ESC 2 Set 1/6 inch line spacing
○
ESC 3 Set line spacing using minimum units
○
ESC ? Cancel user-defined characters
○
ESC @ Initialize printer
○
ESC D Set horizontal tab positions
○
ESC E Select emphasized mode
○
ESC G Select double-strike mode
○
ESC J Print end feed paper using minimum units
○
ESC L Select page mode
○
ESC M Select character font
○
ESC R Select international character set
○
ESC S Select standard mode
○
ESC T Select print direction in page mode
○
ESC V Set/cancel 90˚cw rotated character
○
ESC W Set printing area in page mode
○
Command Function Compatibility
ESC＼Set relative position
○
ESC a Align position
○
ESC d Print and feed paper n lines
○
ESC t Select character code table
○
ESC { Set/cancel upside-down character printing
○
FS p Print NV bit image
○
FS q Define NV bit image
○
GS ! Select character size
○
GS $ Set absolute vertical print position in page mode
○
GS * Define downloaded bit image
○
GS / Print down-loaded bit image
○
GS B Turn white/black reverse printing mode on/off
○
GS H Select printing position of HRI characters
○
GS I Transmit printer ID
○
GS L Set left margin
○
GS W Set printing area width
○
GS＼Set relative vertical print position in page mode
○
GS a Enable/disable Automatic Status Back(ASB)
○
GS f Select font for HRI characters
○
GS h Set bar code height
○
GS k Print bar code
○
GS r Transmit status
○
GS v 0 Print raster bit image
○
GS w Set bar code width
○
GS S C Set Serial Baudrate
○
DLE EOT n Selects card read mode / Cancel card read mode
○
GS S P Power Save Mode
○

36 37
10. ZPL Command Compatibility
Command Compatibility
^A
○
^B0
○
^B1
○
^B2
○
^B3
○
^B4
○
^B5
○
^B6
○
^B7
○
^B8
○
^B9
○
^BA
○
^BB
○
^BC
○
^BD
○
^BE
○
^BF
○
^BI
○
^BJ
○
^BK
○
^BL
○
^BM
○
^BO
○
^BP
○
^BQ
○
^BR
○
^BS
○
^BT
○
^BU
○
Command Compatibility
^BX
○
^BY
○
^BZ
○
^CC ~CC
○
^CD
○
^CF
○
^CI
○
^CT ~CT
○
~DF
○
~DG
○
^FB
○
^FC
○
^FD
○
^FH
○
^FN
○
^FO
○
^FP
○
^FR
○
^FS
○
^FT
○
^FV
○
^FW
○
^FX
○
^GB
○
^GC
○
^GD
○
^GE
○
^GF
○
^GS
○
