SGM SP-6 SIXPACK User manual

SP∙6
SIXPACK

2
SP-6 SixPack dimensions
SP-6 SIXPACK
USER MANUAL REV. 4C
All dimensions in mm.
Drawing not to scale.

3
SP-6 SIXPACK
USER MANUAL REV. 4C
© 2013 SGMTM. Information subject to change without notice. SGM and all afliated com-
panies disclaim liability for any injury, damage, direct or indirect loss, consequential or
economic loss or any other loss occasioned by the use of, inability to use or reliance on
the information contained in this manual. The SGM logo, the SGM name and all other
trademarks in this document pertaining to services or products by SGM or its afliates and
subsidiaries are trademarks owned or licensed by SGM or its afliates or subsidiaries.
English edition

4

5
Contents
Safety information.................................................................................................... 6
Overview.................................................................................................................. 8
Preparing for installation.......................................................................................... 9
Installing the SP-6 SixPack .................................................................................. .10
Installing xtures at elevation in an array ...............................................................11
Connecting AC power............................................................................................ 16
Connecting to control data..................................................................................... 17
Conguring the device .......................................................................................... 18
Service................................................................................................................... 23
DMX protocols....................................................................................................... 24
Control menu......................................................................................................... 31
Specications ........................................................................................................ 34
User’s notes .......................................................................................................... 37
