Shark BG-2527 Service manual

MODEL: BG
OPERATING INSTRUCTION
AND PARTS MANUAL
For technical assistance or the SHARK dealer nearest you,
visit our website at www.shark-pw.com or call 360-833-1600
■BG-2527 ■BG-2820 ■BG-3030
■BG-3532 ■BG-3735 ■BG-3040
97-707

3
CONTENTS
ModelNumber______________________________
Serial Number ______________________________
Date of Purchase ___________________________
The model and serial numbers will be found on a decal attached to
the pressure washer.You should record both serial number and
date of purchase and keep in a safe place for future reference.
97-705, 97-707 • REV. 9/05
Introduction & Important Safety Information ......................................... 4-5
ComponentIdentification......................................................................... 6
Assembly Instructions............................................................................. 7
OperatingInstructions .......................................................................... 8-9
Detergents&CleaningTechniques ........................................................ 10
ShutDownandClean-Up ...................................................................... 11
Storage ................................................................................................. 11
Troubleshooting ................................................................................ 12-13
PreventativeMaintenance ..................................................................... 14
OilChange Record ................................................................................ 14
Models2527,2820ExplodedView ........................................................ 15
Models 2527, 2820 ExplodedView Parts List ................................... 16-17
Models3030,3532,3735 ExplodedView .............................................. 18
Models 3030, 3532, 3735 ExplodedView Parts List ......................... 19-20
Hose and Spray Gun Assembly ............................................................ 21
Specifications .................................................................................. 22-23
Warranty

97-705, 97-707 • REV. 9/05
OPERATOR’S MANUAL PRESSURE WASHER
4
Thankyouforpurchasingthis pressure washer.
All information in this manual is based on the latest
product information available at the time of printing.
Wereservethe right to makechangesatany time with-
outincurringanyobligation.
Owner/User Responsibility:
Theownerand/orusermusthaveanunderstandingof
themanufacturer’soperatinginstructionsand warnings
beforeusingthis pressurewasher.Warning information
shouldbeemphasizedandunderstood.Iftheoperator
is not fluent in English, the manufacturer’s instructions
and warnings shall be read to and discussed with the
operator in the operator’s native language by the pur-
chaser/owner, making sure that the operator compre-
hends its contents.
Owner and/or user must study and maintain for future
referencethemanufacturers’instructions.
The operator must know how to stop the machine
quickly and understand the operation of all controls.
Never permit anyone to operate the engine without
properinstructions.
This manual should be considered a permanent
part of the machine and should remain with it if
machine is resold.
When ordering parts, please specify model and
serial number.
MACHINE SAFETY
CAUTION:To reduce the risk of
injury, read operating instruc-
tions carefully before using.
1. Readtheowner'smanualthor-
oughly. Failure to follow in-
structions could cause mal-
function of the machine and
resultindeath,seriousbodily
injuryand/orpropertydamage.
2. Allinstallations must complywithlocal codes. Con-
tact your electrician, plumber, utility company or
the selling distributor for specific details.
WARNING:Risk of asphyxiation
—Use thisproduct onlyin a well
ventilatedarea.
3. Avoid installing machines in
small areas or near exhaust
fans. Exhaust contains poi-
sonouscarbonmonoxidegas;
exposure may cause loss of
consciousnessandmaylead
to death. It also contains
chemicals known, in certain quantities, to cause
cancer, birth defects or other reproductive harm.
WARNING: Flammable liquids
can create fumes which can ig-
nitecausing propertydamage or
severe injury.
WARNING:Risk of fire — Do not
add fuel when the product is
operating.
WARNING:Risk of explosion —
Do not spray flammable liquids.
4. Do not place machine near flammable objects as
the engine is hot.
5. Allowengineto cool for 2 minutesbeforerefueling.
If any fuel is spilled, make sure the area is dry
before testingthespark plugorstarting the engine.
(Fireand/or explosionmayoccurifthis isnotdone.)
Refuel gasoline engines on mobile or portable
equipment:
a. outdoors;
b. with the engine on the equipment stopped;
c. with no source of ignition within 10 feet of the
dispensingpoint; and
d. with an allowance made for expansion of the
fuel should the equipment be exposed to a
higher ambient temperature.
Inan overfilling situation,additionalprecautions are
necessary to ensure that the situation is handled
in a safe manner.
WARNING:High pressure stream
ofwater that thisequipment can
produce can pierce skin and its
underlying tissues, leading to
serious injury and possible am-
putation.
WARNING
HIGH PRESSURE
SPRAY CAN PIERCE
SKIN ANDTISSUES.
WARNING
RISK OF FIRE.
DO NOT ADD FUEL
WHENOPERATING
MACHINE.
WARNING
RISK OF
ASPHYXIATION.
USE ONLY IN AWELL
VENTILATEDAREA.
WARNING
READOPERATOR’S
MANUAL
THOROUGHLY
PRIORTO USE.
CAUTION
INTRODUCTION & SAFETY INFORMATION

97-705, 97-707 • REV. 9/05 5
PRESSURE WASHER OPERATOR’S MANUAL
WARNING:High pressure spray
can cause paint chips or other
particlestobecomeairborne and
fly at high speeds.To avoid per-
sonal injury, eye safety devices
must be worn.
6. Eye safety devices and foot
protectionmustbewornwhen
usingthisequipment.
7. High pressure developed by these machines will
cause personal injury or equipment damage. Use
caution when operating. Do not direct discharge
stream at people, or severe injury or death will re-
sult.
8. Never make adjustments on machine while in op-
eration.
WARNING
PROTECTIVE
EYEWEAR AND
CLOTHING MUST
BEWORN.
WARNING
KEEPWATER
SPRAY AWAYFROM
ELECTRICALWIRING.
SAFETY INFORMATION CONT.
9. Donotoperate with spray gun intheoffpositionfor
extensive periods of time as this may cause dam-
age to the pump.
10. The best insurance against an accident is precau-
tionandknowledgeof the machine.
11. Manufacturer will not be liable for any changes
made to our standard machines, or any compo-
nents not purchased from us.
12. Read engine safety instructions provided.
WARNING: Keep water spray
awayfrom electricalwiring orfa-
tal electric shock may result.
13. Never run pump dry or leave
spray gun closed longer than
5 minutes.
14. Do not allow children to oper-
atethepressurewasheratany
time.
15. Inletwatersupplymustbecold
andcleanfreshwater.

97-705, 97-707 • REV. 9/05
OPERATOR’S MANUAL PRESSURE WASHER
6
COMPONENT IDENTIFICATION
Pump — Develops high pressure.
Starter Grip— Used for starting the engine manually.
Spray Gun — Controls the application of water and
detergentontocleaningsurfacewith triggerdevice.In-
cludes safety latch.
Detergent Injector — Allows you to siphon and mix
detergents.
Wand — Must be connected to the spray gun.
High Pressure Hose — Connect one end to water
pumpdischargenippleandtheother end to spraygun.
Note:If trigger on spray gun is released for more
than 2 minutes, water may leak from valve. Warm
water will discharge from pump protector onto
floor. This system prevents internal pump dam-
age.
Starter Grip
Trigger
Spray Gun
High Pressure
Hose
Pump
Straight
Through
Wand
Pressure
Nozzle
Garden Hose
(not included)
Inlet
Screen
Unloader
Detergent
Bucket
(not included)
Detergent Injector

97-705, 97-707 • REV. 9/05 7
PRESSURE WASHER OPERATOR’S MANUAL
STEP 1: Attach the handle to the
frameof the pressurewasher. Note:
It may be necessary to move the
handle supports from side to side in
ordertoalignthehandlesoitwillslide
over the frame supports.
STEP 2: Insert the carriage bolt
through the holes from the outside
of the unit and attach a nut from the
inside of the machine.Tighten nuts.
STEP 3: Attach the spray gun/hose
storage handle, and bracket to
handle.Tighten nuts.
STEP 4: Attach the high pressure
hose to the spray gun using teflon
tapeonhosethreads.
STEP 6: Release the coupler collar
and push the nozzle until the collar
clicks. Pull the nozzle to make sure
it is seated properly.
STEP7: Connecthighpressurehose
topumpsdischargenipple. Pushcou-
plercollarforward until secure.
STEP 5: Pull the spring-loaded col-
lar of the wand coupler back to in-
sert yourchoice of pressure nozzle.
STEP8: Connectgardenhosetothe
coldwatersource.
ASSEMBLY INSTRUCTIONS
STEP 9: Connect the garden hose to pump water inlet.
Inspect inlets. CAUTION: Do not run the pump with-
out water or pump damage will result.
Alignment
Holes
Handle
Frame
Assy.
Carriage
Bolt
Nut
Studs
Nut
Hose/Spray Gun
Storage Bracket
Safety
Latch
Spray
Gun
High Pressure
Hose
Wand
Coupler
Pressure
Nozzle
Pressure
Nozzle Wand Coupler
Wand
Collar
Discharge
Nipple
High Pressure Hose Cold
Water
Source
Garden
Hose
Pump
Water Inlet
Garden
Hose
Coupler
Collar
Bolts
Washer

97-705, 97-707 • REV. 9/05
OPERATOR’S MANUAL PRESSURE WASHER
8
STEP 1: Checkengineoillevel. Oil level should be level with the bottom of
the oil filler neck. Be sure the machine is level when checking the oil level.
(Refertothe engine'soperatingmanualincludedwithmachine.)We recom-
mendthattheoil be changed after the first 5 hours of use, then onceevery
50 hours. Note: Improper oil levels will cause low oil sensor to shut off
engine.IMPORTANT! Do not run engine with high or low oil levels as
this will cause engine damage.
STEP 2: Remove shipping cap and
install oil dipstick. Check pump oil
levelbyusingdipstickorobserveoil
levelin oil window (ifequipped).Use
30wt.nondetergentoil.
STEP4: Connectgardenhosetothe
coldwatersourceand turn water on
completely.Never use hot water.
STEP 6: Rotate the fuel shut-off valve to the "On" posi-
tion.Slidethe fuelvalvelevertothe "ON" position.When
theengine is notinuse, leavethefuelvalve inthe"OFF"
position.
STEP 5: Trigger the spray gun to
eliminate trapped air then wait for
a steady flow of water to emerge
from the spray nozzle.
OPERATING INSTRUCTIONS
STEP 3: Fillgastankwith unleaded
gasoline. Do not use leaded gaso-
line.
STEP 7: Move the choke lever to the "Choke" position
(on a warm engine, leave the choke lever in the run
position).Move the chokelevertothe "Closed" position.
To restart a warm engine, leave the choke lever in the
"Open"position.
Engine Oil
Dipstick
Pump Oil
Dipstick
Oil Window
Gas
Tank
Cold
Water
Source
Garden
Hose
Choke
Lever
Fuel
Valve
Choke
Fuel
Valve

97-705, 97-707 • REV. 9/05 9
PRESSURE WASHER OPERATOR’S MANUAL
STEP 8:Turn the engine switch to "On" position.
On Briggs engines, move the throttle lever to "Fast"
position, shown on engine as a rabbit.
STEP 9: Pull the starter grip. If the engine fails to start
after 2 pulls, squeeze the trigger gun to release pres-
sure and repeat step. Return starter gently. After the
engine warms up enough to run smoothly, move choke
to run position and throttle to fast position.
CAUTION:Small enginesmaykick back.Do nothold
pull starter grip tightly in hand.
OPERATING INSTRUCTIONS (CONT.)
WARNING! Never replace
nozzles without engaging the
safety latch on the spray gun trig-
ger.
The five color-coded quick connect nozzles provide a wide array of spray
widths from 0° to 45° and are easily accessible when placed in the conve-
nient rubber nozzle holder, which is provided on the front of the machine.
NOTE: Foramoregentle rinse,select thewhite40° or green25° nozzle. To
scourthesurface, select the yellow 15° or red 0° nozzle.To applydetergent
select the black nozzle.
NOZZLES
Safety
Latch
On-Off
Switch

97-705, 97-707 • REV. 9/05
OPERATOR’S MANUAL PRESSURE WASHER
10
WARNING:Somedetergentsmay
beharmfulif inhaled oringested,
causingsevere nausea, fainting
or poisoning. The harmful ele-
mentsmay causeproperty dam-
age or severe injury.
STEP 1: Connectdetergentinjectorto dischargenipple
onmachine.Connecthighpressurehosetoinjectorwith
quick coupler. (Check to make sure locking coupler
sleeves are in proper position before applying water
pressure).
STEP2: Usedetergent designed
specificallyforpressurewashers.
Householddetergentscoulddam-
agethepump.Prepare detergent
solutionasrequiredby themanu-
facturer.Filla containerwith pres-
surewasher detergent.Placethe
filterendofdetergentsuctiontube
intothedetergentcontainer.
STEP 3: With safety latch on spray gun engaged, se-
cure black detergent nozzle into quick coupler.
NOTE: Detergent cannot be applied using red, yellow,
greenorwhitenozzles.
STEP4:Withtheengine running,
pull trigger to operate machine.
Liquiddetergent is drawnintothe
machine and mixed with water.
Applydetergentto work area. Do
notallowdetergentto dry on sur-
face.
IMPORTANT:You must flush the detergent injection
system after each use by placing the suction tube
into a bucket of clean water,then run the pressure
washer in low pressure for 1-2 minutes.
THERMAL PUMP PROTECTION
If you run the engine on your pressure washer for 3-5
minutes without pressing the trigger on the spray gun,
circulatingwaterin the pump can reach high tempera-
tures. When the water reaches this temperature, the
pump protector engages and cools the pump by dis-
chargingthewarmwaterontotheground.Thisthermal
devicepreventsinternal damage to the pump.
CLEANINGTIPS
Pre-rinse cleaning surface with fresh water.Place deter-
gentsuctiontubedirectlyintocleaningsolutionandapply
tosurfaceatlowpressure(forbestresults,limityourwork
areatosectionsapproximately6feetsquareandalways
apply detergent from bottom to top). Allow detergent to
remainonsurface1-3minutes.Donotallowdetergentto
dry on surface. If surface appears to be drying, simply
wet down surface with fresh water.If needed, use brush
to remove stubborn dirt.Rinse at high pressure from top
tobottominanevensweepingmotionkeepingthespray
nozzle approximately 1 foot from cleaning surface. Use
overlapping strokes as you clean and rinse any surface.
For best surface cleaning action spray at a slight angle.
Recommendations:
• Beforecleaninganysurface,aninconspicuousarea
should be cleaned to test spray pattern and dis-
tance for maximum cleaning results.
• Ifpaintedsurfaces are peeling orchipping,useex-
tremecaution aspressurewasher mayremovethe
loose paint from the surface.
• Keepthespraynozzle asafedistance fromthe sur-
face you plan to clean. High pressure wash a small
area,thencheckthesurfacefordamage.Ifno dam-
ageisfound,continuepressurewashing.
CAUTION - Never use:
• Bleach,chlorine and other corrosive chemicals
• Liquidscontainingsolvents(i.e.,paintthinner,gaso-
line, oils)
• Tri-sodiumphosphate products
• Ammoniaproducts
• Acid-basedproducts
These chemicals will harm the machine and will dam-
agethesurfacebeingcleaned.
RINSING
It will take a few seconds for the detergent to clear.
Apply safety latch to spray gun. Remove black soap
nozzle from the quick coupler. Select and install the
desiredhigh pressure nozzle.NOTE:Youcanalso stop
detergent from flowing by simply removing the deter-
gent siphon tube from bottle.
WARNING
DETERGENTS & GENERAL CLEANINGTECHNIQUES
Detergent
Injector
Discharge
Nipple
High
Pressure
Hose
