Sharp XE-A203A User manual

ELECTRONIC CASH REGISTER
CAISSE ENREGISTREUSE ELECTRONIQUE
INSTRUCTION MANUAL MANUEL D’INSTRUCTIONS
XE-A203A
MODEL
MODELE

CAUTION
The socket-outlet shall be installed near the equipment and shall be
easily accessible.
ATTENTION
La prise de courant murale devra être installée à proximité de
l’équipement et être facilement accessible.

1
English
English
INTRODUCTION
Thank you very much for your purchase of the SHARP Electronic Cash Register, Model XE-A203A.
Please read this manual carefully before operating your machine in order to gain full understanding of
functions and features.
Please keep this manual for future reference. It will help you if you encounter any operational problems.
Never install the batteries into the cash register before initializing it. Before you start operating the cash
register, you must first initialize it, then install three new alkaline batteries LR6 (“AA” size) on the register.
Otherwise, distorted memory contents and malfunction of the cash register will occur. For this procedure,
please refer to page 7.
IMPORTANT
• On the printer, a cutter to cut the paper roll is mounted. Always be careful not to cut yourself by the
cutter.
• Install your register in a location that is not subject to direct radiation, unusual temperature changes,
high humidity or exposed to water sources.
Installation in such locations could cause damage to the cabinet and the electronic components.
• Never operate the register with wet hands.
The water could seep into the interior of the register and cause component failure.
• When cleaning your register, use a dry, soft cloth. Never use solvents, such as benzine and/or
thinner.
The use of such chemicals will lead to discoloration or deterioration of the cabinet.
• The register plugs into any standard wall outlet (120V AC ±10%).
Other electrical devices on the same electrical circuit could cause the register to malfunction.
• For protection against data loss, please install three alkaline batteries LR6 (“AA” size) after
initializing the cash register. When handling the batteries, never fail to observe the followings:
Incorrectly using batteries can cause them to burst or leak, possibly damaging the interior of the
cash register.
• Be sure that the the positive (+) and negative (-) poles of each battery are facing in the proper
direction for installation.
• Never mix batteries of different types.
• Never mix old batteries and new ones.
• Never leave dead batteries in the battery compartment.
• Remove the batteries if you do not plan to use the cash register for long periods.
• Should a battery leak, clean out the battery compartment immediately, taking care to avoid letting
the battery fluid come into direct contact with your skin.
• For battery disposal, follow the corresponding law in your country.
• If the register malfunctions, call 905-568-7140 for service - do not try to repair the register yourself.
•For a complete electrical disconnection, disconnect the main plug.
SD logo is a trademark of the SD Card Association.
CAUTION!
Customer Service Hotline
905-568-7140
For Easy Set-up, see
“GETTING STARTED” (page 7).
A203(SECL)(E)_1 06.5.24 8:05 AM Page 1

CONTENTS
INTRODUCTION............................................................................................................................................1
IMPORTANT ..................................................................................................................................................1
CONTENTS....................................................................................................................................................2
PARTS AND THEIR FUNCTIONS.................................................................................................................4
1External View..................................................................................................................................................4
2Printer .............................................................................................................................................................4
3Mode Switch and Mode Keys .........................................................................................................................5
4Keyboard.........................................................................................................................................................5
5Displays ..........................................................................................................................................................6
6Drawer Lock Key.............................................................................................................................................6
GETTING STARTED......................................................................................................................................7
OVERVIEW OF FLOW OF DAILY SALES ENTRIES .................................................................................11
BASIC SALES ENTRY ................................................................................................................................12
1Basic Sales Entry Example...........................................................................................................................12
2Error Warning................................................................................................................................................13
3Item Entries...................................................................................................................................................14
Single item entries .................................................................................................................................14
Repeat entries .......................................................................................................................................15
Multiplication entries ..............................................................................................................................15
Split pricing entries ................................................................................................................................16
Single item cash sale (SICS) entry........................................................................................................17
4Displaying Subtotal .......................................................................................................................................17
5Finalization of Transaction............................................................................................................................17
Cash or check tendering........................................................................................................................17
Cash or check sale that does not require tender entry..........................................................................18
Charge (credit) sale ...............................................................................................................................18
Mixed-tender sale ..................................................................................................................................18
6Tax Calculation .............................................................................................................................................19
Automatic tax.........................................................................................................................................19
Manual tax .............................................................................................................................................19
Tax delete..............................................................................................................................................19
Tax status shift.......................................................................................................................................20
OPTIONAL FEATURES...............................................................................................................................21
1Auxiliary Entries ............................................................................................................................................21
Discount and premium entries using the percent key............................................................................21
Discount and premium entries using the discount key ..........................................................................21
Refund entries .......................................................................................................................................22
Non-add code number entries and printing ...........................................................................................22
2Auxiliary Payment Treatment........................................................................................................................23
Currency conversion..............................................................................................................................23
Received-on Account and Paid-out Entries...........................................................................................24
No sale (exchange)................................................................................................................................24
3 Automatic Sequence Key (a
key) Entries..................................................................................................24
CORRECTION .............................................................................................................................................25
1Correction of the Last Entry (direct void) ......................................................................................................25
2Correction of the Next-to-last or Earlier Entry (indirect void) ........................................................................25
3Subtotal Void.................................................................................................................................................26
4Correction of Incorrect Entries not Handled by the Direct or Indirect Void Function.....................................26
PRIOR TO PROGRAMMING ......................................................................................................................27
BASIC FUNCTION PROGRAMMING (For Quick Start) ............................................................................27
1Date and Time Programming........................................................................................................................27
2Tax Programming for Automatic Tax Calculation Function...........................................................................28
Tax programming using a tax rate.........................................................................................................28
FOR THE MANAGER
FOR THE OPERATOR
2
A203(SECL)(E)_1 06.5.24 8:05 AM Page 2

The tax table (applicable to the add-on tax) ..........................................................................................29
Quantity for doughnut tax exempt (for Canadian tax system) ...............................................................31
AUXILIARY FUNCTION PROGRAMMING .................................................................................................32
1Department Programming.............................................................................................................................32
2PLU (Price Look-Up) and Sub-department Programming ............................................................................33
3Miscellaneous Key Programming .................................................................................................................35
Rate for %, &
and V......................................................................................................................35
Amount for -......................................................................................................................................36
Percent rate limitation for % and &..................................................................................................36
Function parameters for %, &
and -.............................................................................................36
Function parameters for V..................................................................................................................37
Entry digit limit for r, R
and t....................................................................................................38
Function parameters for C, c and A (when using as CA key).................................................38
4Text programming.........................................................................................................................................39
ADVANCED PROGRAMMING....................................................................................................................44
1Register Number and Consecutive Number Programming...........................................................................44
2Electronic Journal (EJ) Programming ...........................................................................................................45
3Various Function Selection Programming 1..................................................................................................47
Function selection for miscellaneous keys ............................................................................................47
Print format ............................................................................................................................................48
Receipt print format ...............................................................................................................................48
Function selection for tax.......................................................................................................................48
Other programming................................................................................................................................49
4Various Function Selection Programming 2..................................................................................................51
Power save mode..................................................................................................................................51
Logo message print format....................................................................................................................51
Online time out setting...........................................................................................................................52
Thermal printer density..........................................................................................................................52
Language selection................................................................................................................................53
Training clerk specification for training mode ........................................................................................53
AUTO key programming........................................................................................................................54
5Reading Stored Program ..............................................................................................................................54
TRAINING MODE ..................................................................................................................................................56
READING (X) AND RESETTING (Z) OF SALES TOTALS ........................................................................57
EJ REPORT READING AND RESETTING .................................................................................................60
OVERRIDE ENTRIES ..................................................................................................................................61
CORRECTION AFTER FINALIZING A TRANSACTION (Void mode).......................................................61
HOW TO USE AN SD MEMORY CARD......................................................................................................62
1What You Can Do with an SD Memory Card................................................................................................62
2In Case of SD Error.......................................................................................................................................63
3Inserting and Removing an SD Memory Card ..............................................................................................64
4Formatting an SD Memory Card...................................................................................................................64
5Saving and Restoring All the Data................................................................................................................65
6Writing and Reading of Programming Data ..................................................................................................65
7Writing of Sales Data ....................................................................................................................................66
8Writing and Printing of Electronic Journal.....................................................................................................67
OPERATOR MAINTENANCE......................................................................................................................68
1In Case of a Power Failure ...........................................................................................................................68
2In Case of Printer Error.................................................................................................................................68
3Cautions in Handling the Printer and Recording Paper ................................................................................68
4Replacing the Batteries.................................................................................................................................69
5Replacing the Paper Roll ..............................................................................................................................69
6Removing a Paper Jam ................................................................................................................................72
7Cleaning the Printer (Print Head / Sensor / Roller).......................................................................................72
8Removing the Till and the Drawer.................................................................................................................72
9Opening the Drawer by Hand .......................................................................................................................72
10 Before calling for service...............................................................................................................................73
Error code table .....................................................................................................................................73
SPECIFICATIONS .......................................................................................................................................74
3
A203(SECL)(E)_1 06.5.24 8:05 AM Page 3

4
PARTS AND THEIR FUNCTIONS
Front view Rear view
External View
1
The printer is a one station type thermal printer, therefore it does not require any
type of ink ribbon or cartridge.
Lift the rear of the printer cover to remove. To re-install, hook the pawls on the
cabinet and close.
Caution: The paper cutter is mounted on the printer cover. Be careful not to
cut yourself.
Printer
2
USB portSD card slot
(Refer to page 64.)
Operator display
Receipt paper
Keyboard
Drawer lock
Drawer
Printer cover
Customer display
(Pop-up type)
Mode switch
Power cord
Take-up spool
Print roller
release lever
Print roller arm
Inner cover
Paper roll cradle
Paper positioning guides
Do not attempt to remove the paper roll
with the print roller arm locked. This may
result in damage to the printer and print
head.
Use only the USB cable (manufactured by SHARP) supplied with the XE-A203A for the connection
with a PC. Never use other cables.
A203(SECL)(E)_1 06.5.24 8:05 AM Page 4

5
The mode switch can be operated by inserting one of the two supplied mode keys - manager (MA) and operator
(OP) keys. These keys can be inserted or removed only in the “REG” or “OFF” position.
The mode switch has these settings:
OFF: This mode locks all register operations. (AC power turns off.)
No change occurs to register data.
OP X/Z: To take individual clerk X or Z reports, and to take flash reports.
It can be used to toggle receipt state “ON” and “OFF” by pressing
the Rkey.
REG: For entering sales.
PGM: To program various items.
VOID:Enters into the void mode. This mode allows correction after
finalizing a transaction.
MGR: For manager’s entries. The manager can use this mode for an
override entry.
X1/Z1: To take the X/Z report for various daily totals
X2/Z2: To take the X/Z report for periodic (weekly or monthly)
consolidation
Keyboard layout
The small characters on the bottom or lower right in each key indicates functions or characters
which can be used for character entries for text programming. For details, refer to page 39.
Key names
Keyboard
4
PGM
VOID
OFF
OPX/Z
REG
MGR
X1/Z1
X2/Z2
OP
MA
Manager key (MA)
Operator key (OP)
OPMA
Mode Switch and Mode Keys
3
123
456
789
CL
•
00
0
DEPT
SHIFT
CLK #
CONV
%1RA
VOID RFND
–
%2
NUMBER
SHIFT
SPACE
DC
ESC
BS
RCPT
/PO
@/ FOR
PLU
/SUB DEPT #
B
A
20
4
C
19
3
D
18
2
E
17
1
G
F
24
8
H
23
7
I
22
6
J
21
5
L
K
28
12
M
27
11
N
26
10
O
25
9
Q
32
P
16
R
31
15
S
30
14
T
29
13
AUTO
TAX
TAX2
SHIFT
TAX1
SHIFT
MDSE
SBTL
#/TM
SBTL
CHK CH
Y
X
Z
V
U
W
CA/AT/NS
RA
ESC
RCPT
/PO
CA/AT/NS
Paper feed key
Received-on account key
Receipt print/Paid-out key
Void key
Conversion key
Escape key
Multiplication key
Decimal point key
Clear key
Department code entry key
PLU/Sub-department key
Department shift key
Clerk code entry key
Department keys
~
Total/Amount tender
/No sale key
~Numeric keys
9
00 0
VOID
@/ FOR
CL
•
CONV
RFND
Refund key
%1 %2 Percent 1 and 2 keys
Discount key
PLU
/SUB
DEPT
#
DEPT
SHIFT
TAX1
SHIFT
Merchandise subtotal key
MDSE
SBTL
Non-add code/Time display
/Subtotal key
#/TM
SBTL
CLK #
Tax key
TAX
Check key
CHK
Automatic sequence key
AUTO
Charge key
CH
17
1
32
16
TAX2
SHIFT Tax 1 and 2 shift keys
A203(SECL)(E)_1 06.5.24 8:05 AM Page 5

6
This key locks and unlocks the drawer. To lock it, turn 90
degrees counterclockwise. To unlock it, turn 90 degrees
clockwise.
Drawer Lock Key
6
Operator display Customer display (Pop-up type)
Amount: Appears in the far-right eight (max.) positions. When the amount is negative, the minus symbol “-”
appears before the amount.
Number of repeats for repetitive registrations:
The number of repeats is displayed, starting at “2” and incremental with each repeat. When you
have registered ten times, the display will show “0.”(2 →3 ..... 9 →0 →1 →2 ... )
Receipt function status:
The indicator “_” appears in the RCPT OFF position when the receipt function is in the OFF
status.
Time: Appears in the far-right six positions (hour-minute -“ ” or hour-minute -“ ”) in the OP X/Z, REG,
or MGR mode. “ ” is displayed in the morning (AM), and “ ” in the afternoon (PM). In the REG
or MGR mode, press the skey to display the time.
Machine state symbols
: Appears during programming.
: Appears when an error is detected.
: Appears when the subtotal is displayed or when the amount tendered is smaller than the sales amount.
: Appears when the Vkey is pressed to calculate a subtotal in foreign currency.
: Appears when a transaction is finalized by pressing the A, Cor ckey.
: Appears when the change due amount is displayed.
: May appear in the far-left three positions at the timing of key entry when the electronic journal (EJ)
memory is full. (Depending on programming.)
: Appears when the voltage of the installed batteries is under the required level. You must replace with
new ones within two days. Refer to page 69 for details.
: Appears when the batteries are not installed, or the installed batteries are dead. You must replace with
new ones immediately. Refer to page 69 for details.
: May appear right below the eighth and ninth places at the timing of finalization of a transaction when the
electronic journal (EJ) memory is nearly full.
Also appears right below the tenth place when power save mode is effective.
: Appears when the print roller arm is not locked.
: Appears when the paper is not set or has run out.
PLU/SUB
DEPT REPEAT
RCPT
OFF
NUMBERSHIFT DC
Clerk code
Displays
5
SK1-1
A203(SECL)(E)_1 06.5.24 8:05 AM Page 6

7
GETTING STARTED
Please follow the procedure shown below. The batteries are not installed and the power is OFF.
Three new alkaline batteries LR6 (“AA” size) must be installed in the cash register to prevent the data
and user-programmed settings from being erased from the memory, when the AC cord is accidentally
disconnected or in case of power failure. Once installed, the batteries will last approximately one year before
needing replacement. At this time, the “ ” symbol will appear on the display to indicate the batteries are low
and must be replaced within two days. If the no battery symbol “ ” appears, you must install the batteries at
once.
Install three new alkaline batteries LR6 (“AA” size) according to the procedure shown below with the AC cord
connected and the mode switch set to the REG position:
1. Push the printer cover forward and detach it.
Be careful with the paper cutter, so as not to cut yourself.
2. Open the battery compartment cover next to the paper roll cradle.
Initializing the cash register
In order for your cash register to operate properly, you must initialize it before programming for the first
time. Follow this procedure.
1. Insert the manager (MA) key into the mode switch and turn it to the REG
position.
2. Insert the plug into the AC outlet. The buzzer will sound three times.
IMPORTANT: This operation must be performed without batteries installed.
3. The cash register has now been initialized. The register display will show “0.00”
with “ ”.
If the buzzer does not sound when the plug is inserted, the initialization has not been done
successfully. (This will occur when the voltage is still high because you operated the cash register
just before starting initialization.) In this case, wait at least one minute after pulling out the plug,
and insert the plug again.
Find a stable surface where the cash register is not subject to water sources or direct sunlight near an
AC outlet.
Unpack the cash register and make sure all accessories are included. For details of accessories, please refer to
“Specifications” section.
REG
OPX/Z MGR
PGM
X1/Z1
X2/Z2
OFF
VOID
2
Installing the cash register
1
Installing batteries
3
A203(SECL)(E)_1 06.5.24 8:05 AM Page 7

8
3. Insert three new alkaline batteries LR6 (“AA” size) as illustrated at the right.
When the batteries are properly installed “ ” on the display will disappear.
4. Close the battery compartment cover.
Be sure to observe precautions shown on page 1 when handling
batteries.
Precaution: The paper cutter is mounted on the printer cover. Take caution when removing and
installing the cover.
The register can print receipts or journals. For the printer, you must install the paper roll provided with the
register, even when you program the register for not printing receipts or journals.
Install the paper roll according to the procedure shown below with the AC cord connected and the mode switch
set to the REG position:
1. Lift up the print roller release lever to unlock and open the
print roller arm.
2. Set a paper roll in the paper roll cradle as illustrated at the
right.
When setting a new paper roll in the paper roll
cradle, be sure to cut the paper end behind the
taped (or pasted) point in advance.
3. Feed the end of the paper along with
the paper positioning guides as
illustrated at the right.
Installing a paper roll
4
To the printer
Incorrect
To the printer
Correct
Print roller
release lever
Print roller arm
Paper positioning guides
A203(SECL)(E)_1 06.5.24 8:05 AM Page 8

9
4. While holding down the paper, slowly close the print roller arm, and
push down the arm until you hear a click locking the arm. Make
sure securely you push down the center of the wing part of the arm
as illustrated at the right. The paper will be fed automatically.
If the print roller arm is not securely locked, the unit will
not print correctly. If this problem occurs, open the arm,
and close the arm as instructed above.
5. When not using the take-up spool (using as receipt paper):
• Cut off the excess paper using the edge of the inner cover, and
replace the printer cover. Press the Fkey to make sure the
paper end comes out of the printer cover and clean paper
appears.
If the paper end does not come out, open the printer
cover, and pass the paper end between the paper cutter
and the paper guide of the printer cover, and replace the
cover.
When using the take-up spool (using as journal paper):
• Insert the end of the paper into the slit in the spool. (Press the F
key to feed more paper if required.)
• Wind the paper two or three turns around the spool shaft.
• Set the spool on the bearing, and press the Fkey to take up
excess slack in the paper.
• Replace the printer cover.
When using a paper roll as journal paper, you must change
the printing style. Refer to “Print Format” in “Various
Function Selection Programming 1” section (Job code 6)
for changing the printing style.
The cash register provides text languages of English, French and Spanish. It is preset to English.
If you want to change the language, you must change it before programming. Refer to “Language
selection” in “Various Function Selection Programming 2” section for changing the language.
Before you can proceed with registration of sales, you must program:
•date
•time
•tax
Please refer to the BASIC FUNCTION PROGRAMMING section for details (page 27).
Programming date, time and tax
5
A203(SECL)(E)_1 06.5.24 8:05 AM Page 9

10
Now you are ready for sales registration.
Starting sales entries
7
While the cash register is pre-programmed so it can be used with minimal setup, it does provide you
with optional functions. Before you start programming, please read through the sales operations section to
understand optional functions. The main optional functions are listed below.
• PLU (price lookup)
• Consecutive number
• Machine number
• Receipt or journal printing selection (factory setting: receipt printing)
• Power save mode (factory setting: goes into power save mode in 30 minutes)
• Electronic journal (EJ) memory size (factory setting: 2000 lines are storable. Up to 3000 lines)
The memory for electronic journal is commonly used for PLU. If you change the setting, the
maximum number of PLU code will decrease from 1200 to 200.
• Text programming for clerk name, department items, PLU/sub-department items, logo messages printed on
the top or bottom of receipts, function texts and foreign currency symbol
• Split pricing entry
This is not factory preset. You must enable this function.
• Foreign currency conversion rate
You must set a conversion rate to use Vkey.
• Preset unit price for departments and PLUs
• Preset amount for -
• Preset rates for %&
You do not have to program these preset prices/amount/rates because you can enter during
registration. It might be convenient to preset so you do not have to re-enter every time.
• Amount entry digit limit for PO amount, RA amount, Manual tax amount
The factory setting makes the maximum amount you can enter. You can program to limit the amount.
• Key sequence for AUTO key
• Online time out setting
• Specification of clerk to be trained
Department programming:
The cash register is pre-programmed for departments as follows:
Department: Allow open price entry, taxable status- taxable 1 for department 1 to 10, and non taxable
for department 11 to 99
When you use department 11 or above, and/or you apply taxable status other than taxable 1 for department 1 to
10, you must change department settings. Please refer to the department programming section for
programming details.
Programming other necessary items
6
A203(SECL)(E)_1 06.5.24 8:05 AM Page 10

11
OVERVIEW OF FLOW OF DAILY SALES ENTRIES
Things to do before you start sales entries:
• Make sure the power cord is securely inserted into the AC outlet.
• Turn the mode switch to OP X/Z position, and check if time is correctly set.
• Replace the drawer, if removed for safety.
• Check if there is enough paper on roll.
• Select receipt ON/OFF function.
• Make any necessary programming for the day in PGM mode.
For details, refer to BASIC SALES ENTRY, page 12. For drawer and paper roll, refer to OPERATOR
MAINTENANCE, page 68 and for programming, refer to programming sections.
Things you can do for sales entries:
• Item entries
• Item repeat entries
• Item multiplication entries
• Single item cash sale (SICS), if programmed.
• Split pricing entries, if programmed.
• Displaying subtotals
• Cash/Check/Charge sale
• Cash tendering in a foreign currency, if the currency conversion rate is programmed.
• Manual tax entry
• Discount or premium using %&and -key
• Refund entry
• No sale
• Paid-out entries
• Received on account entries
• Printing non-add code number
• Making corrections
• Checking sales report
For details of sales entry method, refer to BASIC SALES ENTRY (page 12) and OPTIONAL FEATURES
(page 21). For details of correcting sales entries, refer to CORRECTION (page 25). For details on reading
sales information, refer to READING (X) AND RESETTING (Z) OF SALES TOTAL (page 57).
Things to do after you close your store:
• Print sales reports, and clear sales data for the day.
• Print Electronic Journal (EJ) reports, and clear Electronic Journal (EJ) data, if necessary.
• Account money - comparing it with the amount in cash in drawer printed on the general report.
• Remove the drawer for safety.
• Turn the mode switch to OFF position.
For details of reading sales information, refer to READING (X) AND RESETTING (Z) OF SALES TOTAL (page
57) and EJ REPORT READING AND RESETTING (page 60). For details of removing the drawer and
maintenance details, refer to OPERATOR MAINTENANCE (page 68).
FOR THE OPERATOR
A203(SECL)(E)_2 06.5.24 8:05 AM Page 11

12
BASIC SALES ENTRY
Listed below is a basic sales entry example when selling department items by cash. For operation details,
please refer to each section.
Mode switch setting
1. Turn the mode switch to the REG position.
Clerk assignment
2. Enter your clerk code. (For example, clerk code is 1. Press the 1and Lkey in
this order.) The clerk code 1 is automatically selected just after initialization of the
cash register.
Item entries
3. Enter the price for the first department item. (For example, for 15.00, enter 15:, and press the
appropriate department key.)
For department 17 to department 32, press the Dkey first before pressing the department key.
For department 33 and above, enter the department code using numeric keys, and press the dkey,
then enter the price and press the dkey again.
4. Repeat step 3 for all the department items.
Displaying subtotals
5. Press the skey to display the amount due.
Finalizing the transaction
6. Enter the amount received from the customer. (You can omit this step if the amount tendered is the same as
the subtotal.)
7. Press the Akey, and the change due is displayed (when the amount received was not entered, the total
amount is displayed) and the drawer is opened.
8. Tear off the receipt and give it to the customer with his or her change.
9. Close the drawer.
PrintKey operation example
Basic Sales Entry Example
1
REG
OPX/Z MGR
PGM
X1/Z1
X2/Z2
OFF
VOID
Graphic logo
Date/Time/Clerk code number
Register number
/Consecutive number/Clerk name
Items
Tax status (T1: taxable 1)
Price
Merchandise
subtotal
Not printed when
non-taxable items
only are sold.
Tax amount
Total amount
Cash tendering/amount received
Change
Total quantity
1 L
1500 !
2300 "
s
5000
A
Item
entries
Clerk
assignment
Displaying
subtotal
Finalizing
the transaction
(In this example, the tax rate is set to 6.25%.)
A203(SECL)(E)_2 06.5.24 8:05 AM Page 12

13
Clerk assignment
Prior to any item entries, clerks must enter their clerk codes into the register. However, the code entry may not
be necessary when the same clerk handles the next transaction.
Receipt ON/OFF function
When you use the printer to issue receipts, you can disable receipt printing in the REG mode to save paper
using the receipt ON/OFF function. To disable receipt printing, press the Rkey in the OP X/Z position. This
key toggles the receipt printing status ON and OFF.
To check the receipt printing status, turn the mode switch to the OP X/Z position or press the lkey in the REG
mode. When the function is in the OFF status, the receipt off indicator “_” is illuminated. Your register will print
reports regardless of the receipt state, so the paper roll must be installed even when the receipt state is “OFF”.
To issue a receipt when receipt ON/OFF function is set to OFF:
If your customer wants a receipt after you finalized a transaction with the receipt ON/OFF function being OFF
status, press the Rkey. This will produce a receipt. However, if more than 30 items were entered, the
receipt will be issued in the format of summary receipt print.
Power Save Mode
The register will enter into power save mode when no entries are performed based on the pre-programmed time
limit (by default, 30 minutes).
When your register goes to the power save mode, all the display lights will turn off except the decimal point at
the left-most position. Your register will return to the normal operation mode when any key is pressed or a mode
is changed with the mode key. Please note when your register is recovered by a key entry, its key entry is
invalid. After the recovery, start the key entry from the beginning.
L
Clerk code 1 to 25
To display the signed-on clerk code
LL
■Sign-on (in REG, MGR, VOID mode) ■Sign-off (in REG, MGR, VOID mode)
In the following examples, your register will go into an error state accompanied with a warning beep and the
error symbol “ ” on the display. Clear the error state by pressing the lkey and take proper action.
Please refer to the error code table on page 73.
• You enter over a 32-digit number (entry limit overflow): Cancel the entry and re-enter the correct number.
• You make an error in key operation: Clear the error and continue operation.
• You make an entry beyond a programmed amount entry limit: Check to see if the entered amount is correct. If
it is correct, it can be rung up in the MGR mode. Contact your manager.
• An including-tax subtotal exceeds eight digits: Delete the subtotal by pressing the lkey and press the A,
Cor ckey to finalize the transaction.
Error escape function
When you want to quit a transaction due to an error or an unforeseen event, use the error escape function as
shown below:
The transaction is voided (treated as a subtotal void) and the receipt is issued by this function. If you have
already entered a tendered amount, the operation is finalized as a cash sale.
l
Transaction
To clear the error state
EE
Error Warning
2
A203(SECL)(E)_2 06.5.24 8:05 AM Page 13

14
Single item entries
Department entries
The cash register provides a maximum of 99 departments for a merchandise classification. Group attributes,
such as taxable status, are applied on items when they are entered to the departments.
• When using the department keys (for department 1 to 32)
For department 1 to 16, enter a unit price and press a department key. If you use a programmed unit price,
press a department key only.
For department 17 to 32, enter a unit price, press the Dkey and press a department key. If you use a
programmed unit price, press the Dkey and press a department key.
*1Less than the programmed upper limit amounts
When zero is entered, only the sales quantity is
added.
*2 For the optional departments 17 through 32,
press the Dkey.
• When using the department code entry key
Enter a department(dept.) code and press the dkey, then enter a unit price and press the dkey again. If
the dept. code is programmed to preset price entry style and a unit price is preset, your cash register will finish
its registration operation.
*1Less than the programmed upper limit
amounts
When zero is entered, only the sales
quantity is added.
PLU/sub-department entries
For another merchandise classification, the cash register provides a maximum of 1200 PLUs/sub-departments.
PLUs are used to call up preset prices by a code entry. Sub-departments are used to classify merchandise into
smaller groups under the departments. Every PLU and sub-department has a code from 1 to 1200, and should
belong to a department to obtain attributes of that department.
The cash register is pre-programmed to PLU mode and zero for unit price. To use PLU entries, their preset unit
prices should be previously programmed. (Refer to page 33.)
To use sub-department entries, change to sub-department mode for the PLU codes.
• PLU entries
• Sub-department (open PLU) entries
* Less than the programmed upper limit
amounts
When zero is entered, only the sales
quantity is added.
PLU code
(1 to 1200) pUnit price * (max. 7 digits) p
PLU code
(1 to 1200) p
Dept. code
(1 to 99)
Unit price *1
(max. 7 digits)
When using a programmed unit price
(In case only preset price entry is allowed.)
dd
Department keyUnit price *1
(max. 7 digits)
When using a programmed unit price
D
*2
Item Entries
3
A203(SECL)(E)_2 06.5.24 8:05 AM Page 14

15
Repeat entries
You can use this function for entering a sale of two or more of the same items. Repeat pressing a department
key, dkey or pkey as shown on key operation example.
Multiplication entries
When you sell a large quantity of items, it is convenient to use the multiplication entry method. Enter quantity
using numeric keys and press the @key before starting item entry as shown in the example below.
When programmed to allow fractional quantity entries, you can enter up to four integers and three
digit decimal, though the quantity is counted as one for sales reports. To enter a fractional quantity,
use the decimal point key between integer and decimal, as 7P5 for entering 7.5.
1200 ((
500 D!!
))
D""
50 d1500 dd
33 dd
2 pp
11 p1200 pp
A
Sub-department
entry
PLU entry
Department entry
PrintKey operation example
Sub-department
entry
PLU entry
Department entry
1200 (
500 D!
)
D"
50 d1500 d
33 d
2 p
11p1200p
A
PrintKey operation example
A203(SECL)(E)_2 06.5.24 8:05 AM Page 15

16
Split pricing entries
This function is practical when the customer wants to purchase items normally sold in bulk.
To utilize this function, you must change the pre-programmed or default programmed setting. Refer to “Various
Function Selection Programming 1” (job code 70) for programming details.
To make split pricing entries, follow the procedure below:
Department entry
PLU entry
7 @10 @
600 *
8 @12 @
35 p
A
PrintKey operation example
Selling q'ty
(Up to 4 digits)
Base q'ty
(Up to 2 digits)
Unit price
per base q'ty
When using a programmed unit price
@ @ Department key
D
Dept. code d
PLU code p
PLU code Unit price
per base q'ty
p p
Unit price
per base q'ty d
(Only preset entry is allowed.)
Sub-department
entry
PLU entry
Department entry
3 @1200 (
5 @500 D!
3 @)
5 @D"
3 @50 d1500 d
5 @33 d
3 @2 p
5@11p1200p
A
PrintKey operation example
A203(SECL)(E)_2 06.5.24 8:06 AM Page 16

17
Single item cash sale (SICS) entry
• This function is useful when a sale is for only one item and is for cash. This function is applicable only to those
departments that have been set for SICS or to their associated PLUs or sub-departments.
• The transaction is complete and the drawer opens as soon as you press the department key, dkey or
pkey.
If an entry to a department or PLU/sub-department set for SICS follows the ones to departments or
PLUs/sub-departments not set for SICS, it does not finalize and results in a normal sale.
For finishing
the transaction
250
,
PrintKey operation example
The register provides three types of subtotals:
Merchandise subtotal
Press the mkey at any point during a transaction. The net sale subtotal - not including tax - will appear in
the display.
Taxable subtotal
Taxable 1 subtotal
Press the Tand skeys in this order at any point during a transaction. The sale subtotal of
taxable 1 items will appear in the display.
Taxable 2 subtotal
Press the Uand skeys in this order at any point during a transaction. The sale subtotal of
taxable 2 items will appear in the display.
Including-tax subtotal (full subtotal)
Press the skey at any point during a transaction. The sale subtotal including tax and the symbol “ ” will
appear in the display.
Cash or check tendering
Press the skey to get an including tax subtotal, enter the amount tendered by your customer, then press
the Akey if it is a cash tender or press the Ckey if it is a check tender. When the amount tendered is
greater than the amount of the sale, your register will show the change due amount and the symbol “ ” will light
up. Otherwise the register will show a deficit and the symbol “ ” will light up. You now must make a correct
tender entry.
Cash tendering
s
1000 A
PrintKey operation example
Finalization of Transaction
5
Displaying Subtotals
4
A203(SECL)(E)_2 06.5.24 8:06 AM Page 17

18
Check tendering
Cash or check sale that does not require entry
Enter items and press the Akey if it is a cash sale or press the Cif it is a check sale. Your register will
display the total sale amount.
Charge (credit) sale
Enter items and press the charge key (c).
Mixed-tender sale
You can perform mixed-tendering of check and cash, cash and charge, and check and charge.
Example: Your customer pays $9.50 in cash and $40.00 by charge for an including-tax subtotal of $49.50.
s
950 A
c
PrintKey operation example
2500 +
3250 *
c
PrintKey operation example
In the case of check sale
300 +
10 p
A
PrintKey operation example
s
1000 C
PrintKey operation example
A203(SECL)(E)_2 06.5.24 8:06 AM Page 18
