Sharp SD-AT100W User manual

SD-AT100W
OPERATION MANUAL
MODE D’EMPLOI
1-BIT DIGITAL HOME THEATER WITH DVD
ENSEMBLE HOME THEATER 1-BIT AVEC DVD
Se reporter aux
pages F-1 à F-70.
FRANÇAIS
Consulte las
páginas S-1 a S-70.
ESPAÑOL
Please refer to
pages E-1 to E-70.
ENGLISH
MODEL MODELO
MODÈLE
SISTEMA 1-BIT PARA HOME THEATER CON DVD
MANUAL DE MANEJO
SDAT100W(X)_FRONT 02.2.27, 6:54 PM1
Downloaded from: http://www.usersmanualguide.com/

E-1
02/2/27 SD-AT100W(X)E1.fm
SD-AT100W
ENGLISH
ENGLISH
Important Instruction
- Introduction / Special notes -
Introduction
Special notes
Warning:
!When the ON/STAND-BY button is set at STAND-BY position, mains voltage is
still present inside the unit. When the ON/STAND-BY button is set at STAND-BY
position, the unit may be brought into operation by the timer mode or remote con-
trol.
!This unit contains no user serviceable parts. Never remove covers unless qualified
to do so. This unit contains dangerous voltages, always remove mains plug from
the socket before any service operation and when not in use for a long period.
!To prevent fire or shock hazard, do not expose this appliance to dripping or
splashing. No objects filled with liquids, such as vases, should be placed on the
apparatus.
CAUTION
Note:
!Audio-visual material may consist of copyrighted works which must not be
recorded without the authority of the owner of the copyright. Please refer to the rel-
evant laws in your country.
!Manufactured under license from Dolby Laboratories. "Dolby", "Pro Logic" and the
double-D symbol are trademarks of Dolby Laboratories. Confidential unpublished
works. 1992- 1997 Dolby Laboratories. All rights reserved.
!Manufactured under license from Digital Theater Systems, Inc. US Pat.
No.5,451,942 and other world-wide patents issued and pending. "DTS" and "DTS
Digital Surround" are trademarks of Digital Theater Systems, Inc. 1996 Digital
Theater Systems, Inc. All rights reserved.
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
SD-AT100W 1-Bit Digital Home Cinema with DVD consisting of SD-AT100W (main
unit), CP-AT100WF (front speakers), CP-AT100WC (centre speaker), CP-AT100WR
(surround speakers) and CP-AT100WSW (subwoofer).
!This product is classified as a CLASS 1 LASER product.
!Use of controls, adjustments or performance of procedures other than those spec-
ified herein may result in hazardous radiation exposure.
As the laser beam used in this compact disc player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel only.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
Downloaded from: http://www.usersmanualguide.com/

4
E-2
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Accessories -
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Remote control 1 "AAA" size battery (UM-4, R03, HP-16
or similar) 2
AM loop aerial 1 FM aerial 1
AC power lead 1 Video cable 1
Speaker connection lead 6
White
approx. 15m approx. 15m approx. 5m
approx. 5m approx. 5m approx. 5m
Red Green
Blue Grey Purple
Types of playable discs
Types of unplayable discs
!DVDs without the region number on
the back of the unit or "ALL". !CDG
!Photo CD
!DVDs with SECAM system !CD-ROM
!DVD-ROM !SACD
!DVD-RAM !Discs recorded in special formats,
etc.
!DVD-Audio
(As for the details, see pages 5, 6.)
Icons used in this operation manual
Some functions may not be available depending on discs. The following icons indi-
cate the discs that can be used in the section.
... Indicates DVDs.
... Indicates video CDs.
... Indicates audio CDs.
!Some operations may not be performed depending on discs even if they are de-
scribed in this manual.
!During operation, " " may be displayed on the screen. This means that the oper-
ations described in this manual are prohibited by the disc.
Downloaded from: http://www.usersmanualguide.com/

E-3
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Contents -
Contents
Page
"General Information
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5, 6
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 12
"Preparation for Use
Speaker connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
Aerial connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
TV connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 17
Turning the power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing the initial setting of DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 - 25
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
"Basic Operation
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Listening to the memorised station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29, 30
"Advanced Disc Features
Basic operation
To locate the beginning of a chapter (track) (skip) . . . . . . . . . . . . . . . . . . . . . . 31
Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . 33, 34
To resume playback after stopping (sequential playback) . . . . . . . . . . . . . . . . 34
Useful features
To play in the desired order (programmed playback) . . . . . . . . . . . . . . . . . 35, 36
To play in random order (random play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
To play the contents between the specified points repeatedly (A-B repeat) . 38
To select a title from the top menu of the disc . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Page
Various settings
To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
To hide the subtitle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
To change the audio language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
To brighten an image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
To improve the image quality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
To zoom in on an image (zoom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
To change the display on TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
To change the display on the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
DVD mode operation indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
To change the setting on the playback control screen . . . . . . . . . . . . . . . . . . . 45
To set on the disc menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
"Advanced Features
Enjoy the surround sound (sound mode) . . . . . . . . . . . . . . . . . . . . . . . . . 47 - 49
Speaker settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 - 52
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 - 55
Connecting other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56 - 59
Operating other equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Changing the registration in the remote control . . . . . . . . . . . . . . . . . . . . . 61, 62
"References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63 - 65
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67, 68
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Language code list for disc language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Copyright Information:
!Unauthorised copying, broadcast, public display, transmission, public perfor-
mance and rental (regardless of whether or not such activities are for profit) of disc
contents are prohibited by law.
!This device is equipped with copy protection technology that causes substantial
degradation of images when the contents of a disc are copied to video tape.
!This device is protected by U. S. patents and other intellectual property rights, the
copyright for which belongs to Macrovision Corporation. The use of Macrovision's
copy protection technology in the device is authorised by Macrovision and is
intended for home use only, unless otherwise authorised in writing by Macrovision.
Reverse engineering or disassembly is prohibited.
Downloaded from: http://www.usersmanualguide.com/

4
E-4
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Precautions -
Precautions
"General
!Please ensure that the equipment is positioned in a well ventilated area and that
there is at least 10 cm (4") of free space along the sides and back. There must
also be a minimum of 15 cm (6") of free space on the top of the unit.
!Use the unit on a firm, level surface free from vibration.
!Keep the unit away from direct sunlight, strong magnetic fields, excessive dust,
humidity and electronic/electrical equipment (home computers, facsimiles, etc.)
which generates electrical noise.
!Do not place anything on top of the unit.
!Do not expose the unit to moisture, to temperatures higher than 60°C (140°F) or to
extremely low temperatures.
!If your system does not work properly, disconnect the AC power lead from the wall
socket. Plug the AC power lead back in, and then turn on your system.
!In case of an electrical storm, unplug the unit for safety.
!Hold the AC power plug by the head when removing it from the wall socket, as
pulling the lead can damage internal wires.
!Do not remove the outer cover, as this may result in electric shock. Refer
internal service to your local SHARP service facility.
!The ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, tablecloths, curtains, etc.
!No naked flame sources, such as lighted candles, should be placed on the appa-
ratus.
!Attention should be drawn to the environmental aspects of battery disposal.
!This unit should only be used within the range of 5°C - 35°C (41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit. Using this product
with a higher voltage other than that which is specified is dangerous and may result
in a fire or other type of accident causing damage. SHARP will not be held responsi-
ble for any damage resulting from use of this unit with a voltage other than that which
is specified.
Caution:
!During use the unit will get warm, do not touch warm areas of the unit for pro-
longed periods to avoid damage to you or the unit.
!This product is equipped with special function which protects amplifier circuit from
damages. When it is activated, sound switch is turned off. In this case, set the unit
to the stand-by mode and turn it on again.
"Volume control
The sound level at a given volume setting depends on speaker efficiency, location,
and various other factors. It is advisable to avoid exposure to high volume levels, to
avoid this do not turn the volume on to full at switch on and listen to music at moder-
ate levels.
"Care of DVD/CD discs
DVD/CD discs are fairly resistant to damage, however mistracking can occur due to
an accumulation of dirt on the disc surface. Follow the guidelines below for maximum
enjoyment from your DVD/CD collection and player.
!Do not write on either side of the disc, particularly the non-label side from which
signals are read. Do not mark this surface.
!Keep your discs away from direct sunlight, heat, and excessive moisture.
!Always hold the DVD/CDs by the edges. Fingerprints, dirt, or water on the DVD/
CDs can cause noise or mistracking. If a DVD/CD is dirty or does not play prop-
erly, clean it with a soft, dry cloth, wiping straight out from the centre, along the
radius.
10 cm (4") 10 cm (4") 15 cm (6")
10 cm (4")
!This unit is fitted with a cooling fan at the rear for im-
proved cooling. It begins to run automatically when
the unit is turned on. Do not cover the opening in this
section with any obstacles.
Cooling fan
NO YES
Correct
Downloaded from: http://www.usersmanualguide.com/

E-5
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Description of discs -
Description of discs
"Types of playable discs
The unit can play back discs bearing any of the following marks:
"Discs that cannot be played
!You need the PAL-compliant TV to watch DVD/Video CDs recorded in PAL sys-
tem.
!The discs above cannot be played at all, or no sound is heard although images
appear on the screen or vice versa.
!Faulty playback may damage the speakers and can have an adverse effect on
your hearing when played at high volume settings.
!You cannot play illegally produced discs.
Notes:
!A disc that has scratches or fingerprints on it may not play properly. Refer to "Care
of DVD/CD discs (page 4)" and clean the disc.
!Do not play the discs of special shapes (heart or octagon shaped) as they can be
ejected from the machine whilst rotating and cause injury.
"Title, chapter and track
DVDs are divided into "titles" and "chapters". If the disc has more than one movie on
it, each movie is a separate "title". "Chapters" are subdivisions of titles.
The video and audio CDs consist of "tracks".
A "track" is each tune on an audio CD.
Note:
Title, chapter, or track numbers may not be recorded on some discs.
Disc type Disc contents Disc size
DVD Video Disc Audio and video (movies) 12 cm (5")
8 cm (3")
Or DVD-R/DVD-RW record-
ed in video mode (*1)
Video CD Audio and video (movies) 12 cm (5")
8 cm (3")
Audio CD Audio 12 cm (5")
8 cm (3")
Or CDV (*2)
Audio CD-R/CD-RW (*3) Audio 12 cm (5")
8 cm (3")
Or CD-R/CD-RW recorded
in MP3 format (*4)
(*1): The DVD-R/DVD-RW may not be played back due to properties and scratch-
es of the disc, dirty optical pickup lens, etc.
(*2): Only the audio on the CDV can be played.
(*3): The CD-R/CD-RW may not be played back properly depending on the record-
ing equipment or the disc.
(*4): Only discs in MP3 format can be played (MPEG 1 Audio Layer 3, 44.1kHz or
48kHz). However, some of them may not be played depending on their con-
ditions or format.
MP3 multi-session disc is not supported by this system.
!DVDs without the region number on
the back of the unit or "ALL". !CDG
!Photo CD
!DVDs with SECAM system !CD-ROM
!DVD-ROM !SACD
!DVD-RAM !Discs recorded in special formats, etc.
!DVD-Audio
Chapter 1
Title 1 Title 2
Chapter 2 Chapter 3 Chapter 1 Chapter 2
Track 1 Track 2 Track 3 Track 4 Track 5
Downloaded from: http://www.usersmanualguide.com/

4
E-6
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Description of discs -
!Icons used on DVD discs
Check the icons of the DVD case before playing your discs.
Types of playable DVD discs vary depending on the region. This unit can play back
only DVDs with the same region number are written on the back of the unit or with
"ALL".
Display Description
Region number (playable area number) DVD discs are programed with region
numbers indicating countries in which
they can be played.This system canplay
discs with region number on the back of
the unit or "ALL".
Format recorded on the DVD To adopt the video format to the connect-
ed TVs ("wide-screen TV" or "4:3 size
TV").
Recorded in 4:3.
You can enjoy wide images on a wide-screen TV, and letterbox size
images on the 4:3 size TV.
You can enjoy wide images on a wide-screen TV, and sides-cut 4:3
images on the 4:3 size TV.
Type of subtitles recorded
Example: Recorded subtitle language.
1: English A desired language can be selected with
the SUBTITLE button.
2: Japanese
Number of camera angles Number of angles recorded on the DVD.
A desired angle can be selected with the
ANGLE button.
Number of audio track and audio
recording system The number of audio tracks and audio re-
cording system are indicated.
Example:
1: Original <English>
(DTS 5.1 Surround)
"The audio recorded on the DVD can
be switched by using the SOUND
button.
"Audio and recording system vary de-
pending on the DVD. Check them in
the DVD's manual.
2: Japanese (Dolby Digi-
tal 5.1 Surround)
2 3 4
ALL
2
2
2 3 4 and
ALL
Downloaded from: http://www.usersmanualguide.com/

E-7
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Controls and indicators -
Controls and indicators
!Front panel Reference page
1.Disc Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
2.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.Disc Cover Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.Sound Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48, 49
5.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6.Disc Play or Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29, 30
7.Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
8.DVD Chapter Skip, VCD/CD Track Down or
Tuning Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27, 31
Reference page
9.DVD Chapter Skip, VCD/CD Track Up or
Tuning Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27, 31
10.Power Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
11.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .54
12.Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
13.Tuner Band, Digital Input Button . . . . . . . . . . . . . . . . . . . . . . . .27, 60
14.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
15.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .58
11 12 13 14 15
1 2 3 654 7 8 9 10
Downloaded from: http://www.usersmanualguide.com/

4
E-8
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Controls and indicators -
!Display
1.Timer Play Indicator
2.Sleep Indicator
3.Playback Control Indicator
4.Audio Signal Indicators/Speaker Indicators
5.Programme indicator
6.Disc Indicator
7.VCD/CD Random Play Indicator
8.FM Stereo Receiving Indicator
9.VCD/CD Track Name Indicator
10.DVD Title Indicator
11.VCD/CD Total Indicator
12.DVD Chapter Indicator
13.DVD Angle Indicator
14.FM Stereo Mode Indicator
15.VCD/CD Repeat or Disc A - B Repeat Indicator
11 12 13 1510 14
9
7
8
6
5
123
(11)
(13)
(8)
4
(9) (10)
(12)
(7)
(1) (2) (3)
(4)
(5) (6)
(1) Front Left Signal Indicator (8) Left Front Speaker Indicator
(2) Centre Signal Indicator (9) Centre Speaker Indicator
(3) Front Right Signal Indicator (10)Right Front Speaker Indicator
(4) Low Frequency Effect Indicator (11)Subwoofer Indicator
(5) Surround Left Signal Indicator (12)Left Surround Speaker Indicator
(6) Surround Monaural Signal
Indicator (13)Right Surround Speaker Indicator
(7) Surround Right Signal Indicator
Downloaded from: http://www.usersmanualguide.com/

E-9
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Controls and indicators -
Controls and indicators (continued)
!Rear panel Reference page
1.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
2.Video Output Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16
3.Monitor Output Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.Audio Digital Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
5.Audio Digital Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
6.AV 1 (TV) Input socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7.FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8.Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
9.AM Loop Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Reference page
10.AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
11.Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
12.Mounting Holes for Wall Bracket (Optionally available) . . . . . . . .68
13.Component Video Output sockets . . . . . . . . . . . . . . . . . . . . . . . . . .16
14.Video and Audio Input sokets (AV 2) . . . . . . . . . . . . . . . . . . . . . . . .56
15.Video and Audio Input sockets (AV 3) . . . . . . . . . . . . . . . . . . . . . . .57
16.Video and Audio Output sockets (AV 2) . . . . . . . . . . . . . . . . . . . . .56
17.Subwoofer Pre Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . .59
12
2
139
5
478
10
6
11
161514 17 13
Downloaded from: http://www.usersmanualguide.com/

4
E-10
SD-AT100W(X)E1.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Controls and indicators -
!Front speaker 2 (magnetically shielded)
1.Tweeter
2.Woofer
3.Mounting Holes for Stand or Bracket (Optionally available)
4.Speaker Terminals
!Centre speaker 1 (magnetically shielded)
1.Woofer
2.Tweeter
3.Mounting Holes for Stand or Bracket (Optionally available)
4.Speaker Terminals
!Surround speaker 2
1.Woofer
2.Mounting Holes for Stand or Bracket (Optionally available)
3.Speaker Terminals
!Subwoofer 1
1.Bass Reflex Duct
2.Woofer
3.Speaker Terminals
Front Back
1
23
4
124
3
Front Back
Front Back
12
3
21 3
Front Side Back
Downloaded from: http://www.usersmanualguide.com/

E-11
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
General Information
- Controls and indicators -
Controls and indicators (continued)
[Front] !Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
2.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
3.VCD/CD Play Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . .37
4.TV On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
5.TV Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . .60
6.TV Input Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
7.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
8.Function Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
9.Disc Fast Reverse, Tuner Preset Down Button . . . . . . . . . . . . . . .28, 31
10.DVD Chapter Skip, VCD/CD Track Down Button . . . . . . . . . . . . . . . .31
11.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38, 46
12.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
13.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
14.DVD Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
15.TV Display Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
16.Disc Cover Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
17.Sound Mode Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
18.Dynamic Sound Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
19.Main Unit Display Select Button . . . . . . . . . . . . . . . . . . . . . . . . .18, 43
20.TV Channel Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .60
21.Disc Play or Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29, 30
22.Disc Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
23.Disc Fast Forward, Tuner Preset Up Button . . . . . . . . . . . . . . . . .28, 31
24.DVD Chapter Skip, VCD/CD Track Up Button . . . . . . . . . . . . . . . . . . .31
25.Cursor Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38, 42, 46
26.Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
27.DVD Top Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
28.DVD Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
12
11
1
2
3
4
5
6
8
7
9
10
13
14
15
16
17
20
19
21
22
23
26
27
28
24
25
18
Buttons with " " mark in the illustration can be operated on the remote control
only.
Downloaded from: http://www.usersmanualguide.com/

E-12
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
4
General Information
- Controls and indicators -
[Back] !Remote control Reference page
1.DVD Subtitle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
2.Playback Control Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
3.Disc A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
4.DVD/VCD Digital Gamma Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.DVD/VCD Frame Advance Button . . . . . . . . . . . . . . . . . . . . . . . . . . 32
6.Direct Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33, 34
7.Programme Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35, 36
8.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35, 36
9.DVD Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
10.Amplifier Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . . . 50 - 52
11.Timer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53 - 55
12.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
13.VCR On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
14.VCR Channel Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
15.DVD Angle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
16.DVD Sound Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
17.DVD/VCD Super Picture Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
18.Disc Play or Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29, 30
19.DVD/VCD Slow Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
20.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35, 36
21.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
22.Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21, 45
23.VCR Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
24.VCR Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
25.VCR Fast Forward Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
26.VCR Rewind Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
27.Sliding Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11
10
1
2
3
4
5
6
7
8
9
12
13
14
15
16
17
18
19
20
22
23
24
25
26
27
21
Buttons with" "markin theillustration canbeoperatedon thebackoftheremote
control. Other buttons can be operated on both sides of the remote control only.
Downloaded from: http://www.usersmanualguide.com/

E-13
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
Preparation for Use
- Speaker connection -
Speaker connection
Front speaker
(right) Front speaker (left)
Surround speaker
(right)
Black
Blue
Blue
Red
Black
White
White
Red
Black
Red
Black
Red
Red
Red
Green
Green
Purple
Grey
Grey
Surround speaker
(left)
Centre
speaker
Subwoofer
You can connect
separately available
woofer to enjoy more
of the bass sound.
(see page 59 .)
Black Red
Purple
Black
Red
Downloaded from: http://www.usersmanualguide.com/

E-14
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
4
Preparation for Use
- Speaker connection / Aerial connection -
The speaker terminals on the main unit, the tube and plugs of the speaker lead, and
speaker labels are distinguished by colours.
Connect the speaker and the unit by matching the colours.
Connect the speaker wires to the speakers first, then to the unit.
Speaker
Main unit
Caution:
"Make sure to connect the speakers after unplugging the unit.
"Do not mistake the and , and right and left terminals of the speaker leads. (The
right speaker is placed on the right when you face the unit.)
"Only the supplied speakers should be used with this product.
"Do not stand or sit on the speakers. You may be injured.
"Insert the speaker plug fully with the rising side facing up.
"Hold the speaker plug when removing it from the main unit. Pulling the lead may
cause malfunction to the unit.
Aerial connection
Notes:
"Placing the aerial on the unit or near the AC power lead may cause noise pickup.
Place the aerial away from the unit for better reception.
"When static is still heard even after adjusting the position of the AM loop aerial, try
reversing the wire connections.
Installing the AM loop aerial:
External FM or AM aerial:
Use an external FM or AM aerial if you require better reception. Consult your dealer.
Note:
When using an external AM aerial, be sure to keep the wire of the AM loop aerial
connected.
"Never short-circuit the speaker leads. If the
speaker leads are short-circuited, the protec-
tion circuit is activatedand the power is turned
off. In such a case, check that the leads are
properly connected before turning the power
on again.
Tube
Red
Black
Label
Speaker terminals
Label Speaker Plug Plug in with the rising
side facing up.
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS
socket and position the FM aerial wire in the di-
rection where the strongest signal can be re-
ceived.
Supplied AM loop aerial:
Connect the AM loop aerial wire to the AM and
GND terminals. Position the AM loop aerial for
optimum reception. Place the AM loop aerial on
a shelf, etc., or attach it to a stand or a wall with
screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
White
Black
External
FM aerial External AM aerial
15 m (49 feet)
7.5 m (25 feet)
AM loop aerial
Earth rod
Downloaded from: http://www.usersmanualguide.com/

E-15
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
Preparation for Use
- TV connection -
TV connection
Caution:
Before connecting the TV, turn off all the equipment.
!Connecting to TV with video cable
Move the VIDEO OUT SELECTOR switch to S-VIDEO/VIDEO.
Notes:
"Change the TV input in accordance with the connected socket.
"Do not connect other equipment between the TV and this unit. If they are con-
nected via a VCR, pictures may be distorted.
"You need the PAL-compliant TV to watch DVD/Video CDs recorded in PAL sys-
tem.
This unit has two sokets to output images in addition to the MONITOR OUT
(VIDEO)socket. To enjoy clearer DVD images, connect your TV to these
sokets.
MONITOR OUT (S-VIDEO)
socket: Transmits the image signal by dividing it into the lu- minance signal (Y) and the color signal (C) to real-
ize clearer images than the video output socket.
COMPONENT VIDEO OUT
socket: Directly transmits the image information, which is composed of the luminance signal (Y) and the com-
ponent signal (PB, PR) to ensure the fidelity of co-
lour compared with the S1 video output coket.
Connecting toTV with video cable:
TV
TV
TV
Video cable (supplied)
(See page 16.)
(See page 16.)
S-video cable (not supplied)
Component video cable (not supplied)
Connecting toTV with S-video cable:
Connecting toTV with Component video cable:
TV
Video cable
(supplied)
To video output socket
To video input
socket
Downloaded from: http://www.usersmanualguide.com/

E-16
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
4
Preparation for Use
- TV connection -
!Connecting to TV with S-video cable
Move the VIDEO OUT SELECTOR switch to S-VIDEO/VIDEO.
Note:
When the video and S-video cables are both connected, the images from the S-video
input socket appears on your TV.
!Connecting to TV with Component video
cable
Move the VIDEO OUT SELECTOR switch to COMPONENT.
Notes:
"If your TV has different indications for the component video inputs (Y, CB and CR
or Y, B-Y and P-Y), connect sockets with its matching colour.
"Do not connect to a component video input socket designed for the high-vision
system, which is not DVD-compatible (the images may be distorted or not
appear).
TV
S-video cable
(not supplied)
To S-video
output socket
To S-video input
socket
TV
Component video cable (not supplied)
To Component video
input sockets
To Component video
output sockets
Downloaded from: http://www.usersmanualguide.com/

E-17
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
Preparation for Use
- TV connection / Turning the power on -
TV connection (continued) Turning the power on
After checking all the connections have been made correctly, connect the AC power
lead to the AC power input socket, then plug the AC power lead of this unit into the
wall socket.
Notes:
"Never use a power lead other than the one supplied. Otherwise, a malfunction or
an accident may occur.
"Unplug the unit if it is not to be used for a prolonged period of time.
!To turn the power on
Press the ON/STAND-BY button to turn the power on.
To set the unit to stand-by mode:
Press the ON/STAND-BY button again.
To listen to the TV sound via the speakers of this unit:
Using the audio cable, you can listen to the TV sound with this unit.
(The audio cable is not supplied. Purchase a commercially available cable.)
Note:
For TV sound operations, refer to page 60.
Audio cable
(not supplied )
TV Red White
Red White
To audio
output sockets
To audio
input sockets
Power indicator
Downloaded from: http://www.usersmanualguide.com/

E-18
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
4
Preparation for Use
- General control -
General control
[Front]
!Volume control
Press the VOLUME button to increase the volume and the VOLUME button for
decreasing.
!Bass control
When the X-BASS button is pressed, the current mode setting will be displayed. To
change to a different mode, press the X-BASS button.
This function is enabled only when the sound mode is set to "STEREO" or "VIR-
TUAL" (page 49).
!To change the display brightness (2 levels)
You can switch the display brightness by holding down the DISPLAY button on the
remote control for 2 seconds or more.
Bass frequencies are
emphasised. The sound is not modified.
Dimmed Brightened
012 39 40
.....
Downloaded from: http://www.usersmanualguide.com/

E-19
SD-AT100W(X)E2.fm02/2/27
SD-AT100W
ENGLISH
Preparation for Use
- System installation -
System installation
!Placing the speaker system
The best surround effect will be achieved by placing each speaker at the same dis-
tance from the listening position.
It is recommended to arrange the speakers as shown below.
Notes:
"Place the TV halfway between the front speakers.
"It is recommended that the centre speaker be placed near the television.
"Keep the free space of at least 10 cm (4") along the left side of the subwoofer.
"Place the surround speakers at a position just above the height of your ears.
"The speaker grille is not removable.
The speaker stands and brackets are optionally available. Refer to their manuals for
assembly.
The front and centre speakers may be placed beside or near the TV as they are mag-
netically shielded. However, colour variation may occur, depending on the type of the
TV.
If colour variation occurs...
Turn off the TV (from the power switch).
After 15 - 30 minutes, turn the TV on again.
If the colour variation is still present...
Move the speakers further away from the TV.
Refer to the user's manual of the TV for details.
Caution:
Do not place the surround speakers and the subwoofer near the TV as they are
not magnetically shielded.
Subwoofer
Subwoofer
10 cm (4")
Front
speaker (left) Front
speaker (right)
Surround
speaker (left) Surround
speaker (right)
Centre
speaker
Front speaker (left)
Same distance
Front speaker (right)
Centre speaker
Same distance
Downloaded from: http://www.usersmanualguide.com/
