Sharp HT-X1H User manual

HT-X1H(H)_FR.fm TINSZA030SJZZ
04/10/12
MODELL
MODÈLE
MODELO
MODELL
MODELLO
MODEL
MODELO
MODEL
HT-X1H
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE MANEJO
BRUKSANVISNING
MANUALE DI ISTRUZIONI
GEBRUIKSAANWIJZING
MANUAL DE OPERAÇÃO
OPERATION MANUAL
DEUTSCH
FRANÇAIS
ESPAÑOL
SVENSKA
ITALIANO
NEDERLANDS
PORTUGUÊS
ENGLISH
Siehe Seiten i
bis vi und D-1
bis D-68.
Se reporter aux
pages i à vi et
F-1 à F-68.
Consulte las
páginas i a vi y
S-1 a S-68.
Hänvisa till
sidorna i till vi
och V-1 till V-68.
Leggere le
pagine i a vi e
I-1 a I-68.
Raadpleeg de
bladzijden i t/m
vi en N-1 t/m N-68.
Favor consultar
as páginas i a vi
e P-1 a P-68.
Please refer to
pages i to vi
and E-1 to E-68.
HEIMKINO MIT DVD
HOME CINEMA AVEC DVD
HOME CINEMA CON DVD
HEMBIOGRAF MED DVD
HOME CINEMA CON DVD
THUIS-BIOSCOOP MET DVD
CINEMA DOMÉSTICO COM DVD
HOME CINEMA WITH DVD
8
1
2
3
4
5
6
7

i
HT-X1H
04/10/12 HT-X1H(H)_com.fm TINSZA030SJZZ
BESONDERE ANMERKUNGEN
REMARQUES SPÉCIALES
NOTAS ESPECIALES
SÄRSKILDA ANMÄRKNINGAR
NOTE PARTICOLARI
BIJZONDERE OPMERKINGEN
NOTAS ESPECIAIS
SPECIAL NOTES
0408_A5
●Dette udstyr overholder kravene i direktiv nr. 89/336/EEC og
73/23/EEC med tillaeg nr. 93/68/EEC.
●Dette produktet oppfyller betingelsene i direktivene 89/336/
EEC og 73/23/EEC i endringen 93/68/EEC.
●Tämä laite täyttää direktiivien 89/336/EEC ja 73/23/EEC
vaatimukset, joita on muutettu direktiivillä 93/68/EEC.
●
●Bei Einstellung der ON/STAND-BY-Taste auf STAND-BY ist
die Netzspannung immer noch im Gerät vorhanden.
Wenn die ON/STAND-BY-Taste auf STAND-BY eingestellt
wird, kann das Gerät unter Verwendung der Fernbedienung
in Betrieb gesetzt werden.
Warnung:
In diesem Gerät sind keine vom Benutzer wartbaren Teile
vorhanden. NiemalsAbdeckungen entfernen, außer wenn Sie
dafür qualifiziert sind. In diesem Gerät sind gefährliche
Spannungen vorhanden. Vor Ausführung von irgendwelchen
Kundendienstarbeitenoderbei längerer Nichtverwendungdes
Gerätes stets den Netzstecker aus der Netzsteckdose ziehen.
●Lorsque la touche ON/STAND-BY est mise en STAND-BY,
l’appareil est toujours sous tension.
Lorsque la touche ON/STAND-BY se trouve sur la position
STAND-BY, l’appareil est prêt à fonctionner par la
télécommande.
Avertissement:
Cet appareil contient des pièces non réparables par
l’utilisateur. Personne non qualifiée n’enlèvera jamais les
couvercles. L’appareil contenant des organes portés à haute
tension, débrancher l’appareil avant toute réparation ou en
période de non-utilisation.
●DiesesGerätentspricht denAnforderungen derEG-Richtlinien
89/336/EWG und 73/23/EWG mit Änderung 93/68/EWG.
●Ce matériel répond aux exigences contenues dans les direc-
tives 89/336/CEE et 73/23/CEE modifiées par la directive 93/
68/CEE.
●Este aparato satisface las exigencias de las Directivas
89/336/CEE y 73/23/CEE, modificadas por medio de la 93/
68/CEE.
●Denna utrustning uppfyller kraven enligt riktlinjerna 89/336/
EEC och 73/23/EEC så som kompletteras av 93/68/EEC.
●Quest’apparecchio è conforme ai requisiti delle direttive 89/
336/EEC e 73/23/EEC, come emendata dalla direttiva 93/68/
EEC.
●Dichiarazione di conformità
La società SHARP ELECTRONICS EUROPE GmbH dichiara
che il prodotto SHARP MINI SISTEMI CD-XP300H è costruito
in conformità alle prescrizioni del D.M.n˚548 del 28/8/95,
pubblicato sulla G.U.n˚301 del 28/12/95 ed in particolare è
conforme a quanto indicato nell’art. 2, comma 1 dello stesso
decreto.
●Dit apparaat voldoet aan de eisen van de richtlijnen 89/336/
EEG en 73/23/EEG, gewijzigd door 93/68/EEG.
●Este equipamento obedece às exigências das directivas 89/
336/CEE e 73/23/CEE, na sua versão corrigida pela directiva
93/68/CEE.
●This equipment complies with the requirements of Direc-
tives 89/336/EEC and 73/23/EEC as amended by 93/68/
EEC.
HOME CINEMA CON DVD HT-X1H

ii
HT-X1H
04/10/12 HT-X1H(H)_com.fm TINSZA030SJZZ
0408_A5
●Cuando el botón ON/STAND-BY estápuesto en la posición
STAND-BY, todavía hay tensión dentro del aparato.
Cuando el botón ON/STAND-BY estápuesto en la posición
STAND-BY, el aparato puede ponerse en funcionamiento
utilizando el controlador remoto.
Advertencia:
Tenga en cuenta que dentro de este aparato no hay piezas
que pueda reparar. No quite nunca las tapas a menos que se
estécualificado para hacerlo. Este aparato tiene en su inte-
rior tensiones peligrosas.
Desenchufe siempre la clavija de la red del tomacorriente
antes de realizar cualquier servicio de mantenimiento y
cuando no se use el aparato durante un largo período de
tiempo.
●När ON/STAND-BY knappen är i läge STAND-BY, finns
nätspänning i apparaten.
MedON/STAND-BYknappen i lägeSTAND-BYkan apparaten
startas med fjärrkontrollen.
Varning:
Apparaten innehåller inga delar som kan åtgärdas av kunden.
Höljet får endast öppnas av kvalificerad personal. Apparaten
innehåller farliga spänningar.
Stickkontakten ska därför dras ut från nätuttaget före
reparationsarbeten och bör dras ut om apparaten inte ska
användas påmycket länge.
●Quando il tasto ON/STAND-BY si trova in posizione STAND-
BY, all’interno dell’apparecchio c’è ancora la corrente.
Se il tasto ON/STAND-BY si trova nella posizione STAND-
BY, l’unitàpuòessere accesa con il telecomando.
Avvertenza:
L’apparecchio non contiene parti riparabili dall’utente.
Non togliere mai i coperchi, a meno di non essere qualificati
per farlo. All’interno dell’apparecchio ci sono tensioni
pericolose, per cui si deve sempre staccare la spina del cavo
d’alimentazione dalla presa di corrente prima di qualsiasi
interventodimanutenzione e quandonon si usal’apparecchio
per un lungo periodo di tempo.
●Wanneer de ON/STAND-BY toets in de STAND-BY stand
staat, loopt er nog steeds stroom (netspanning) in het toestel.
Wanneer de ON/STAND-BY toets in de STAND-BY stand
staat, kan het toestel ingeschakeld worden via de
afstandsbediening.
Waarschuwing:
Dit toestel bevat geen door de gebruiker te repareren
onderdelen. Verwijder de behuizing nooit tenzij u deskundig
bent op dit gebied. In het toestel loopt een gevaarlijke span-
ning; haal de stekker altijd uit het stopcontact alvorens
onderhoud uit te voeren of wanneer het toestel voor langere
tijd niet gebruikt wordt.
●Quando o botão ON/STAND-BY estiver ajustado na posição
STAND-BY, a voltagem de alimentação ainda se encontra
presente dentro do aparelho.
Quando o botão ON/STAND-BY estiver ajustado na posição
STAND-BY, o aparelho pode ser colocado em operação
através do controle remoto.
Advertência:
Neste aparelho não hápartes que podem ser consertadas
pelo usuário. Nunca retire a tampa, a menos que vocêtenha
qualificação para tal. Este aparelho contém voltagens
perigosas.Removasempre o cabode alimentação datomada
antes de efetuar qualquer conserto ou quando deixar o
aparelho muito tempo fora de uso.
●When the ON/STAND-BY button is set at STAND-BY posi-
tion, mains voltage is still present inside the unit.
When the ON/STAND-BY button is set at STAND-BY posi-
tion, the unit may be brought into operation by the remote
control.
Warning:
This unit contains no user serviceable parts. Never remove
covers unless qualified to do so. This unit contains danger-
ous voltages, always remove mains plug from the socket be-
fore any service operation and when not in use for a long
period.
1
SHARP TINSZA030SJZZ (H)

04/10/12 HT-X1H(H)_com.fm
iii
TINSZA030SJZZ
HT-X1H
DENNA APPARAT ÄR ANSLUTEN TILL 230 V
VÄXELSTRÖM NÄR STICKPROPPEN ÄR INSKJUTEN I
VÄGGUTTAGET. FÖR ATT FULLSTÄNDIGT KOPPLA IFRÅN
APPARATEN, V.G. DRAG UT STICKPROPPEN.
●Når ON/STAND-BY-knappen er sat i STAND-BY positionen,
er der stadig netspaending til stede i apparatet.
Når ON/STAND-BY-knappen er sat i STAND-BY position,
kan apparatet startes v.hj.a. fjernbetjeningen.
Advarsel:
Apparatet indeholder ingen dele, der kan repareres af
brugeren selv. Fjern aldrig kabinettet med mindre De er
kvalificeret hertil. Apparatet indeholder farlig
strømspaending. Traek altid stikket ud af stikkontakten før
der foretages reparationer, eller hvis apparatet ikke er i
brug i laengere tid.
●Vorsicht:
Das Gerät weder Tropf- noch Spritzwasser aussetzen.
Ansonsten besteht die Gefahr eines Brandes oder
elektrischen Schlages. Es dürfen keine mit Flüssigkeiten
gefüllten Gegenstände wie Vasen auf dem Gerät abgestellt
werden.
●Attention:
Pour éviter un incendie ou une secousse électrique, mettre
l’appareilàl’abridel’eau (éclaboussure,goutte).Ne pasposer
sur l’appareil un récipient contenant du liquide.
●Advertencia:
Para evitar incendios y descargas eléctricas, no exponga
el aparato a goteo o salpicadura de líquidos. No deberán
ponerse encima del aparato objetos que estén llenos de
líquido, como por ejemplo un florero.
●Varning:
Utsätt inte enheten för dropp eller stänk för att förhindra
brand eller elektriska stötar. Inga vätskefyllda föremål
såsom vaser får placeras påenheten.
●Attenzione:
Per prevenire incendi o scosse elettriche, non fare
gocciolare nessun liquido sull’apparecchio e non bagnarlo.
Non collocarvi sopra nessun oggetto riempito d’acqua,
come per esempio vasi.
●Waarschuwing:
Stel het toestel niet bloot aan druipend of spattend water
om brand en elektrische schokken te voorkomen. Met
vloeistoffen gevulde voorwerpen, zoals vazen, mogen niet
op het toestel geplaatst worden.
●Cuidado:
Para evitar incêndio ou choque elétrico, não exponha este
aparelho a gotejamento ou salpicamento de água. Não
coloque objetos com água como, por exemplo, um vaso de
flores, em cima do aparelho.
●Warning:
To prevent fire or shock hazard, do not expose this appli-
ance to dripping or splashing. No objects filled with liquids,
such as vases, shall be placed on the apparatus.

iv
HT-X1H
04/10/12 HT-X1H(H)_com.fm TINSZA030SJZZ
●Advarsel:
Til at forbygge ild og stød risiko, lad vaere med at undsaette
denne indretning for drypning eller overstaenkning. Der må
ikke anbringes nogen genstande fyldt med vand, som for
eksempel vaser, pådette apparat.
●Advarsel:
For åunngåbrann eller kortslutning, utsett ikke produktet for
vannellerfuktighet. Gjenstandersominneholder vaeske,feks.
en blomstervase, måikke plasseres oppåapparatet.
●Varoitus:
Älävie laitetta sateeseen tai kosteisiin tiloihin. Jos laite on
kostunut, anna sen kuivua ennen kuin käytät sitä
verkkovirralla. Nestettäsisältäviäastioita kuten esim.
kukkamaljakoita ei saa asettaa laitteen päälle.
Dieses Produkt ist ein Laserprodukt der Klasse 1.
Ce produit est classifiécomme étant un LASER DE CLASSE 1.
Este producto estáclasificado como un PRODUCTO LÁSER DE
CLASE 1.
Denna produkt klassificeras som KLASS 1 LASERPRODUKT.
Questo prodotto èclassificato come CLASS 1 LASER PRODUCT.
Dit product is geclassificeerd als een KLASSE 1 LASER PRODUCT.
This product is classified as a CLASS 1 LASER PRODUCT.
Este produto éclassificado como PRODUTO LASER DE CLASSE 1.
Dette produktet er klassifisert som et KLASSE 1 LASERPRODUKT.
Dette produkt er klassificeret som et KLASSE 1 LASERPRODUKT.
Tämälaite on luokiteltu LUOKAN 1 LASERLAITTEEKSI.
Denna produkt klassificeras som KLASS 1 LASERAPPARAT.
0402_A5_2

04/10/12 HT-X1H(H)_com.fm
v
TINSZA030SJZZ
HT-X1H
0403
●VORSICHT
Verwendung von Regelungen oder Einstellungen bzw.
Durchführung von anderen Verfahren als die hierin
angegebenen kann zum Aussetzen gefährlicher Strahlung
führen.
Da der in diesem Gerät verwendete Laserstrahl für die Augen
zerlegen. Wenden Sie sich für Wartungsarbeiten nur an
berechtigten Fachhändler.
schädlich ist, ist das Gehäuse unter keinen Umständen zu
●ATTENTION
Respecter les indications données relatives àla manipula-
tion, au réglage et au fonctionnement. En cas de non-respect,
on s’exposera àune radiation dangereuse.
Éviter absolument de démonter l’appareil, qui utilise un rayon
laser nuisible aux yeux. Pour toute réparation, s’adresser à
une personne qualifiée.
●PRECAUCIÓN
El uso de los controles, ajustes o ejecución de procedimientos
distintos de los especificados podría causar la exposición a
radiación peligrosa.
No intente desmontar la caja ya que el haz de láser usado en
este aparato es perjudicial para los ojos. Para el servicio de
reparación, consulte a una persona cualificada.
●OBSERVERA
Användning av reglage eller justeringar eller handhavande
påannat sätt än som anges kan leda till farlig bestrålning.
Försök inte ta isär höljet eftersom enhetens laserstråle är
skadlig för ögonen. Överlåt service endast till kvalificerad
personal.
●ATTENZIONE
L’uso dei comandi e l’effettuazione di regolazioni e
procedimenti diversi da quelli specificati nel manuale possono
provocare una pericolosa esposizione alle radiazioni.
Poichéil raggio laser usato in questo apparecchio può
danneggiare gli occhi, non smontare l’apparecchio. Per le
riparazioni rivolgersi a personale specializzato.
●LET OP
Gebruik van regelaars, het maken van instellingen, gebruik
of handelingen anders dan in deze gebruiksaanwijzing
vermeld, kan gevaarlijke straling blootleggen.
De laserstraal in dit toestel kan de ogen beschadigen,
Probeer derhalve de ombouw niet te verwijderen. Laat
reparaties alleen over aan erkend onderhoudspersoneel.
●CUIDADO
O uso de controles, ajustes ou a execução de procedimentos
além daqueles especificados aqui pode resultar em perigosa
exposição àradiação.
Comoosraios laser usadosnesta unidade sãoperigosospara
os olhos, não tente desmontar o aparelho. Solicite o
conserto somente para pessoas especializadas.
●CAUTION
Use of controls, adjustments or performance of procedures
other than those specified herein may result in hazardous ra-
diation exposure.
As the laser beam used in this unit is harmful to the eyes, do
not attempt to disassemble the cabinet. Refer servicing to
qualified personnel only.

vi
HT-X1H
04/10/12 HT-X1H(H)_com.fm TINSZA030SJZZ
Eigenschaften der Laserdiode
Material: AIGaAs/AIGaInP
Wellenlänge: 785 nm/650 nm
Emissionsdauer: kontinuierlich
Laser-Ausgang: max. 0,6 mW
Caractéristiques de la diode laser
Matière: AIGaAs/AIGaInP
Longueur d’onde: 785 nm/650 nm
Durée d’émission: ininterrompue
Puissance de sortie
laser maximale: 0,6 mW
Características del diodo láser
Material: AIGaAs/AIGaInP
Longitud de onda: 785 nm/650 nm
Duración de emisión : continua
Salida de láser: máx. 0,6 mW
Laserdiodens egenskaper
Material: AIGaAs/AIGaInP
Våglängd: 785 nm/650 nm
Utstrålningsvaraktighet: kontinuerlig
Lasereffekt: max. 0,6 mW
Proprietàdel diodo laser
Materiale: AIGaAs/AIGaInP
Lunghezza d’onda: 785 nm/650 nm
Durata di emissione: continua
Uscita massima del laser: 0,6 mW
Laser diode specificaties
Materiaal: AIGaAs/AIGaInP
Golflengte: 785 nm/650 nm
Stralingsduur: doorlopend
Laseruitgang: max. 0,6 mW
Propriedades do diodo de laser
Material: AlGaAs/AlGaInP
Comprimento de onda: 785 nm/650 nm
Duração da emissão: contínua
Saída de laser: máx. 0,6 mW
Laser Diode Properties
Material: AIGaAs/AIGaInP
Wavelength: 785 nm/650 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
0403 0408_A5 (3A_DVD+CD)
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYVÄLLE JANÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE.
VARNING - OM APPARATEN ANVÄNDS PÅANNAT SÄTT ÄN
I DENNA BRUKSANVISNING SPECIFICERAS. KAN
ANVÄNDAREN UTSÄTTAS FÖR SYNLIG OCH OSYNLIG
LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN FÖR
LASERKLASS 1.
ADVERSEL-SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING.
SE IKKE IND I STRÅLEN-HELLER IKKE MED OPTISKE INSTRUMENTER.
VARO!AVATTAESSA OLET ALTTIINANÄKYVÄLLE JANÄKYMÄTTÖMÄLLE
LASERSÄTEILYLLE ÄLÄTUIJOTA SÄTEESEEN ÄLÄKÄKATSO SITÄ
OPTISEN LAITTEEN LÄPI.
VARNING-SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD. STIRRA EJ IN I STRÅLEN OCH BETRAKTA EJ
STRÅLEN GENOM OPTISKT INSTRUMENT.

E-1
04/10/16 HT-X1H(H)E1.fm
ENGLISH
TINSZA030SJZZ
HT-X1H ENGLISH
General Information
Introduction
Special notes
Copy Protection:
This unit supports Macrovision copy protection.
On DVD discs that include a copy protection code, if the contents of
the DVD disc are copied using a VCR, the copy protection code pre-
vents the videotape copy from playing normally.
Thank you for purchasing this SHARP product. To obtain the
best performance from this product, please read this manual
carefully. It will guide you in operating your SHARP product.
HT-X1H Home Cinema with DVD consisting of HT-X1H (main unit
and subwoofer/amplifier unit), CP-X1HF (front speakers), CP-X1HC
(centre speaker) and CP-X1HS (surround speakers).
"DTS" and "DTS Digital Surround" are registered trademarks of
Digital Theater Systems, Inc.
Manufactured under license from Dolby Laboratories.
"Dolby", "Pro Logic" and the double-D symbol are trademarks of
Dolby Laboratories.
Copyright Information:
!Unauthorised copying, broadcast, public display, transmission,
public performance and rental (regardless of whether or not
such activities are for profit) of disc contents are prohibited by
law.
!This system is equipped with copy protection technology that
causes substantial degradation of images when the contents of
a disc are copied to a videotape.
Apparatus Claims of U.S. Patent Nos. 4,631,603, 4,577,216,
4,819,098 and 4,907,093 licensed for limited viewing uses only.
This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses only unless
otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited. 0403E

04/10/16 HT-X1H(H)E1.fm
E-2
ENGLISH
TINSZA030SJZZ
HT-X1H
8
General Information
Accessories
Please confirm that the following accessories are included.
Caution:
Do not use the supplied AC power lead for other equipment. Fire or
electric shock may result.
Note:
Only the above accessories are included.
Remote control 1 "AAA" size battery (UM-4,
R03, HP-16 or similar) 2 AM loop aerial 1
FM aerial 1 SCART cable 1 AC power lead 1
System connection cable
1 Pattern paper for main unit 1 Button name label 1 Speaker connection lead 5
Green
(for centre speaker)
approx. 5 m
White
(for left front
speaker)
approx. 5 m
Red
(for right front
speaker)
approx. 5 m
Blue
(for left surround
speaker)
approx. 15 m
Grey
(for right surround
speaker)
approx. 15 m

04/10/16 HT-X1H(H)E1.fm
E-3
ENGLISH
TINSZA030SJZZ
HT-X1H
General Information
Contents
Page
"General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 9
Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 12
"Preparation for Use
System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Main unit preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15 - 20
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
"DVD Operation
Playing a disc . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23 - 25
Basic operation
To locate the beginning of a chapter/track (skip) . . . . . . . . . . 26
Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . 26
To start playback from the desired point (direct play) . . . . . . 27
Useful operation
To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . 28
To change the audio language (audio output) . . . . . . . . . . . . 29
To brighten an image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
To improve the image quality . . . . . . . . . . . . . . . . . . . . . . . . . . 30
To select a title from the top menu of the disc . . . . . . . . . . . . 31
To select a subtitle or audio language from the disc menu . . 31
Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
To zoom in on an image (zoom) . . . . . . . . . . . . . . . . . . . . . . . . 32
To play in the desired order (programmed playback) . . . . . . 33
To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . 34
To play the contents between the specified points repeatedly
(A-B repeat) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
To change the display on the main unit . . . . . . . . . . . . . . . . . . 35
To change the display on TV screen . . . . . . . . . . . . . . . . . . . . 36
Page
"Audio CD Operation
Playing an audio CD
To play in random order (random play) . . . . . . . . . . . . . . . . . . 37
To start playback from the desired point (direct play) . . . . . . 38
"Super Video CD/Video CD Operation
Playing a super video CD or video CD
Playing a super video CD or video CD with P. B. C.
(playback control) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
"MP3, WMA and JPEG Disc Operation
Playing an MP3, WMA or JPEG disc . . . . . . . . . . . . . . . . . 40, 41
"Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42, 43
Using the Radio Data System (RDS) . . . . . . . . . . . . . . . . 44 - 48
"Advanced Features
Enjoying surround sound (sound mode) . . . . . . . . . . . . . 49 - 52
Changing the default setting of the amplifier . . . . . . . . . 53 - 55
Changing the initial setting of DVD . . . . . . . . . . . . . . . . . 56 - 59
Language code list for disc language . . . . . . . . . . . . . . . . . . . 60
Sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Audio connection to other equipment . . . . . . . . . . . . . . . . . . . 62
To install the main unit on the wall . . . . . . . . . . . . . . . . . . . . . 63
"References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64, 65
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . 66
Optional accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67, 68

04/10/16 HT-X1H(H)E1.fm
E-4
ENGLISH
TINSZA030SJZZ
HT-X1H
8
General Information
Precautions
"General
!Please ensure that the equipment is positioned in a well venti-
lated area and that there is at least 10 cm of free space along the
sides and back. There must also be a minimum of 15 cm of free
space on the top of the unit.
!Use the system on a firm, level surface free from vibration.
!Keep the system away from direct sunlight, strong magnetic
fields, excessive dust, humidity and electronic/electrical equip-
ment (home computers, facsimiles, etc.) which generate electri-
cal noise.
!Do not place anything on top of the components.
!Do not expose the system to moisture, to temperatures higher
than 60°C or to extremely low temperatures.
!If your system does not work properly, disconnect the AC power
lead from the wall socket. Plug the AC power lead back in, and
then turn on your system.
!The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, tablecloths, curtains,
etc.
!No naked flame sources, such as lighted candles, should be
placed on the components of the system.
!Attention should be drawn to the environmental aspects of bat-
tery disposal.
!The system is designed for use in moderate climate.
!This system should only be used within the range of 5°C - 35°C.
Warning:
The voltage used must be the same as that specified by this sys-
tem. Using this product with a higher voltage other than that speci-
fied is dangerous and may result in a fire or other types of accident,
causing damage. SHARP will not be held responsible for any dam-
age resulting from the use of this system with a voltage other than
that specified.
"Volume control
The sound level at a given volume setting depends on speaker effi-
ciency, location, and various other factors. It is advisable to avoid
exposure to high volume levels. Do not turn the volume on to full at
switch on and listen to music at moderate levels.
10 cm 10 cm
10 cm
15 cm
Subwoofer/amplifier unit
Main unit
10 cm 10 cm
10 cm
15 cm
10 cm
10 cm 10 cm 15 cm
!In case of an electrical storm, unplug the
subwoofer/amplifier unit for safety.
!Hold the AC power plug by the head when
removing it from the wall socket, as pulling
the lead can damage internal wires.
!Do not remove the outer cover, as this
may result in electric shock. Refer inter-
nal service to your local SHARP service
facility.

04/10/16 HT-X1H(H)E1.fm
E-5
ENGLISH
TINSZA030SJZZ
HT-X1H
General Information
Controls and indicators
"Top and front panel Reference page
1.Disc Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
2.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 24
3.Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.Chapter (Track) Skip Down or Fast Reverse Button . . . . . 26
5.Chapter (Track) Skip Up or Fast Forward Button . . . . . . . 26
6.Function Selector Button . . . . . . . . . . . . . . . . . . . . . . . . . . 50
7.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
8.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
9.Disc Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
10.Main Unit Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
11.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
12.Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
13.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
"Rear panel
1.FM 75 Ohm Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . 15, 16
2.Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16
3.AM Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16
4.Auxiliary (Audio Signal) Input Sockets. . . . . . . . . . . . . . . . 62
5.SCART Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
6.S-video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
7.Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8.System Connection Sockets
(to subwoofer/amplifier unit) . . . . . . . . . . . . . . . . . . . . . 15, 16
9.Optical Digital Audio Input Socket . . . . . . . . . . . . . . . . . . . 62
1 2 3 4 5 6 7 8
12
11
9
10 13
11
21 34 5 76 8 9
Display
Removing the back cover of
the main unit:
Forsystem connections,remove
the back cover first. 1
2

04/10/16 HT-X1H(H)E1.fm
E-6
ENGLISH
TINSZA030SJZZ
HT-X1H
8
General Information
"Display Reference page
1.Programme Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 33, 43
2.Random Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
3.Repeat/One Track Repeat/A - B Repeat Indicators . . . 34, 35
4.2 channel Stereo Sound Mode Indicator . . . . . . . . . . . . . . 51
5.Multi Channel Sound Mode Indicator . . . . . . . . . . . . . . . . . 52
6.PCM Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
7.DTS Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
8.Dolby Digital Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . 49
9.Dolby Pro Logic Indicator . . . . . . . . . . . . . . . . . . . . . . . . 49
10.Audio Signal/Speaker Indicators . . . . . . . . . . . . . . . . . . . . 50
11.Track Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
12.Chapter Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
13.Title Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
14.Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
15.Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
16.Total Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
17.Angle Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
18.RDS Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
19.Traffic Programme Indicator . . . . . . . . . . . . . . . . . . . . . . . . 44
20.Traffic Announcement Indicator . . . . . . . . . . . . . . . . . . . . . 44
21.Dynamic PTY Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
22.FM Stereo Mode Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . 42
23.FM Stereo Receiving Indicator . . . . . . . . . . . . . . . . . . . . . . 42
24.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
1
2
3
45
10
9
6
11
12
18 19 20 21 22 23 24
13
7
8
15
16
17
14

04/10/16 HT-X1H(H)E1.fm
E-7
ENGLISH
TINSZA030SJZZ
HT-X1H
General Information
Controls and indicators (continued)
"Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . 21
2.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
5.Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
6.Random or Programme Button . . . . . . . . . . . . . . . . . . . 33, 37
7.A - B Repeat or Repeat Button . . . . . . . . . . . . . . . . . . . 34, 35
8.Unit Display Select or Dimmer Button . . . . . . . . . . . . . 22, 35
9.On Screen Display On/Off Button . . . . . . . . . . . . . . . . . . . . 36
10.Top Menu or Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . 31
11.Chapter (Track) Skip Down or Fast Reverse Button . . . . . 26
12.Disc Eject Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
13.Multi Channel Select Button . . . . . . . . . . . . . . . . . . . . . . . . 52
14.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53, 56
15.Stereo (2 channel) Select Button . . . . . . . . . . . . . . . . . . . . 51
16.Chapter (Track) Skip Up or Fast Forward Button . . . . . . . 26
17.Angle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
18.DVD Audio Language Select or
CD Audio Output Select Button . . . . . . . . . . . . . . . . . . . . . 29
19.Gamma Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
20.RDS Programme Type/Traffic Information
Search Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
21.RDS Display Mode Select Button . . . . . . . . . . . . . . . . . . . . 44
22.Direct Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
23.Subtitle Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
24.Super Picture Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
25.Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
26.RDS ASPM (Auto Station Programme Memory) Button . . 46
27.Tuner Preset Down or Cursor Button . . . . . . . . . . . . . . 32, 43
28.Tuning Up or Cursor Button . . . . . . . . . . . . . . . . . . . . . 32, 42
29.Tuner Preset Up or Cursor Button . . . . . . . . . . . . . . . . 32, 43
30.Tuning Down or Cursor Button . . . . . . . . . . . . . . . . . . . 32, 42
31.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1
3
13
4
5
6
7
8
9
11
2
15
16
14
12
10
17
18
19
21
22
23
25
26
24
20
29
30 31
2827

04/10/16 HT-X1H(H)E1.fm
E-8
ENGLISH
TINSZA030SJZZ
HT-X1H
8
General Information
"Remote control Reference page
1.Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
2.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
3.Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
4.Frame Advance or Pause Button . . . . . . . . . . . . . . . . . 24, 31
5.DVD Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . . . . . 56
6.Amplifier Initial Setting Button . . . . . . . . . . . . . . . . . . . . . . 54
7.Shift Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
8.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . 22
9.Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
10.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 24
4
3
5
6
7
8
9
10
1
2
TV Operation Buttons
You can operate some functions of SHARP' TVs with the remote
control of this system.
However, some models cannot be operated.
TV Channel Up Button TVChannelDownButton
Switches the TV channel
up. Switches the TV channel down.
TV On/Stand-by Button TV Volume Up Button
Sets the TV power to "ON"
or "STAND-BY". Turns up the TV volume.
TV/VCR Input Select But-
ton TV Volume Down Button
Switches the input to TV or
VCR. Turns down the TV volume.
1
2
3
4
5
6

04/10/16 HT-X1H(H)E1.fm
E-9
ENGLISH
TINSZA030SJZZ
HT-X1H
General Information
Controls and indicators (continued)
"Front/surround speakers Reference page
1.Speaker
2.Speaker Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 17
4.Colour Label
"Centre speaker Reference page
1.Speaker
2.Speaker Stand
3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 17
4.Colour Label: Green
"Subwoofer/amplifier unit Reference page
1.Bass Reflex Duct
2.Woofer
3.Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5.System Connection Sockets (to main unit) . . . . . . . . . 15, 16
6.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 17
1
1
2
1
2
4
35
6
2
4
3
3
4
White ... Left Front Speaker
Red ... Right Front Speaker
Blue ... Left Surround Speaker
Grey ... Right Surround Speaker

04/10/16 HT-X1H(H)E1.fm
E-10
ENGLISH
TINSZA030SJZZ
HT-X1H
8
General Information
Description of discs
"Types of playable discs
The unit can play back discs bearing any of the following marks:
Some DVD discs may not function as described in the manual.
See the disc jacket for restrictions.
!For unplayable discs, see page 12.
DVD
DVD-Video Disc DVD-R DVD-RW DVD+R DVD+RW
Recorded in the vid-
eo mode (*1) (*2) Recorded inthevideo mode (*1)
(*1) Some discs may not play properly due to the status of the
equipment used for recording, characteristics of the discs,
scratches, dirt, or dirty optical pickup lens.
(*2) DVD-RWdiscs recordedinVRmode (VideoRecording format)
cannot be played back.
Video CD
Super video CD Video CD
4.7
CD
Audio CD Audio CD-R Audio CD-RW
Or CDV (*1) CD-R/RW recorded in MP3/WMA/JPEG
format (*2)
(*1) Only the audio on the CDV can be played.
(*2) Some discs may not play properly due to the status of the
equipment used for recording, characteristics of the discs,
scratches, dirt, or dirty optical pickup lens.
Icons used in this operation manual
Some functions may not be available depending on discs. The fol-
lowing icons indicate the discs that can be used in the section.
... Indicates DVDs.
... Indicates super video CDs.
... Indicates video CDs.
... Indicates audio CDs.
... Indicates CD-R/RW with MP3 recording.
... Indicates CD-R/RW with WMA recording.
... Indicates CD-R/RW with JPEG recording.
!Some operations may not be performed depending on discs
even if they are described in this manual.
!During operation, " " may be displayed on the screen. This
means that the operations described in this manual are prohibit-
ed by the disc.

04/10/16 HT-X1H(H)E2.fm
E-11
ENGLISH
TINSZA030SJZZ
HT-X1H
General Information
Description of discs (continued)
!DVD-Video
A popular type of DVD disc of the same size as a CD, mainly con-
taining video images.
Region number
Title and chapter
DVD-Video discs are divided into "titles" and "chapters". If the disc
has more than one movie on it, each movie is a separate "title".
"Chapters" are subdivisions of titles.
!DVD-R/DVD-RW/DVD+R/DVD+RW
"You can play DVD-R/DVD-RW/DVD+R/DVD+RW discs recorded
in the video mode.
"Before playing DVD-R/DVD-RW/DVD+R/DVD+RW discs with
this unit, finalize them with the equipment used for record-
ing.
!Super video CD/video CD/audio CD
Track
Super video CD, video CD and audio CD are composed of "tracks".
Tracks are equivalent to songs on a CD.
!MP3/WMA/JPEG format on CD-R/CD-RW
An MP3 file is an audio data compressed in the MPEG 1 audio layer
3 format. MP3 files have the extension ".mp3". (Files with the exten-
sion ".mp3" may not play, or noise may occur during playback if not
recorded in the MP3 format.)
WMA is an audio file format developed by Microsoft with the ".wma"
extension. This type of audio file is recorded through Microsoft Win-
dows operating system.
A JPEG file is still image data compressed in the JPEG (Joint Pho-
tographic Experts Group) format. JPEG files have the extension
".jpg".
Folder and file
MP3/WMA/JPEG discs consist of "folders" and "files".
DVD discs are programmed with region
numbers indicating countries in which
they can be played. This system can
play discs with region number "2" or
"ALL".
Region number
(playable area number)
2
ALL
Chapter 1
Title 1 Title 2
Chapter 2 Chapter 3 Chapter 1 Chapter 2
Track 1 Track 2 Track 3 Track 4
MP3
disc WMA
disc JPEG
disc
File 1
Folder 1
File 2 File 1
Folder 2
File 2

04/10/16 HT-X1H(H)E2.fm
E-12
ENGLISH
TINSZA030SJZZ
HT-X1H
8
General Information
!Icons used on DVD discs
Check the icons of the DVD jacket before playing your discs. !Discs that cannot be played
Notes:
"The discs above cannot be played at all, or no sound is heard
although images appear on the screen or vice versa.
"Faulty playback may damage the speakers and can have an
adverse effect on your hearing when played at high volume set-
tings.
"You cannot play illegally produced discs.
"A disc with scratches or fingerprints may not play properly. Refer
to "Care of discs (page 66)" and clean the disc.
Display Description
Format recorded on the DVD To adopt the video format to
the connected TVs ("wide-
screen TV" or "4:3 size TV").
Type of subtitles recorded Recorded subtitle languages.
Example: You can select a subtitle lan-
guage.
1. English
2. German
Number of camera angles Numberofanglesrecordedon
the DVD.
You can view scenes from dif-
ferent angles.
Number of audio tracks and au-
dio recording systems The number of audio tracks and audio recording systems
are indicated.
Example:
1: Original <English>
(Dolby Digital 5.1 Sur-
round)
"You can change the audio
language.
"Audio and recording sys-
tem vary depending on the
DVD. Check them in the
DVD's manual.
2. German
(Dolby Digital 2 ch)
2
2
"DVDs without the region num-
ber "2" or "ALL". "DVD-Audio
"CDG
"DVDs with SECAM system "Photo CD
"DVDs with MPEG sound "CD-ROM
"DVD-ROM "SACD
"DVD-RAM "Discs recorded in special for-
mats, etc.

04/10/16 HT-X1H(H)E2.fm
E-13
ENGLISH
TINSZA030SJZZ
HT-X1H
Preparation for Use
System installation
!Magnetically shielded speakers
The front and centre speakers may be placed beside or near the TV
as they are magnetically shielded. However, colour variation may
occur, depending on the type of the TV.
If colour variation occurs...
Turn off the TV (from the power switch).
After 15 - 30 minutes, turn the TV on again.
If the colour variation is still present...
Move the speakers further away from the TV.
Refer to the user's manual of the TV for details.
Note:
The surround speakers and subwoofer/amplifier unit are not mag-
netically shielded.
!Placing the speaker system
The best surround effect will be achieved by placing each
speaker at the same distance from the listening position.
It is recommended to arrange the speakers as shown below.
Notes:
"
The default distance is set to 2 m. If speakers cannot be placed at
equal distances, refer to "Speaker delay setting" (see page 54).
"Place the TV halfway between the front speakers.
"It is recommended that the centre speaker be placed near the
television.
"Place the surround speakers at a position just above the height of
your ears.
"You can place the subwoofer/amplifier unit anywhere you like. As
it vibrates whilst reproducing bass, place it on a stable, sturdy
surface.
Installation image (with optional accessories):
Surround
speaker
(left)
Surround
speaker
(right)
Front
speaker
(left)
Front
speaker
(right)
Main
unit
Subwoofer/
amplifier
unit
Centre
speaker
Front speaker (left)
Subwoofer/
amplifier unit
Front speaker (right)
Surround
speaker (left) Surround
speaker (right)
Default setting:
2 m
Centre
speaker
Front speaker
(left) Front speaker (right)
Centre speaker
Same distance
