8M-B120C Dismantle Instruction
1
Dismantle Instruction
LCD MONITOR
MODEL
8M-B120C

8M-B120C Dismantle Instruction
2
Table of contents
1. Scope ...............................................................................................................3
2. Tools for dismantling.............................................................................................3
3. Dismantle Procedure............................................................................................ 3
4. Batteries ...........................................................................................................4
5. Back covers ........................................................................................................4
6. Printed circuit boards ...........................................................................................5
7. LCD Module bezels/angles ...................................................................................... 6
8. Capacitors..........................................................................................................7
9. Parts List ........................................................................................................... 7

8M-B120C Dismantle Instruction
3
1. Scope
This document describes dismantling instruction according to Annex VII of Directive 2012/19/EU.
2. Tools for dismantling
Below tools are required to dismantle this product.
- Screw Driver
- Nipper
3. Dismantle Procedure
This product can be dismantled by below steps.
1. Remove battery (section 4)
2. Remove Back covers (section 5)
3. Remove Printed circuit boards (section 6)
4. Dismantle LCD (section 7)
5. Remove Electrolyte Capacitors (section 8)

8M-B120C Dismantle Instruction
4
4. Batteries
This model uses only AAA battery for remote control.
Battery can easily be removed.
5. Back covers
3 back covers (right/center/left) can be removed by screw driver.

8M-B120C Dismantle Instruction
5
6. Printed circuit boards
All PWBs can be removed by screw driver.
Main PWB (1pcs) Power PWB (4pcs) Back end PWB(1pcs)
Backlight Power Control PWB (1pcs) Main T-CON PWB (1pcs)
Sub T-CON PWB (8pcs) LED Driver PWB (4pcs) AC Detection PWB (1pcs)

8M-B120C Dismantle Instruction
6
7. LCD Module bezels/angles
- LCD Dismantle procedure
1. Remove screws (part 1)
2. Remove Corner Angle (part 9) and Bezels (part 8 and 10)
3. Remove screws (part 4 and 5)
4. Remove Middle Frame (Part 2, 3, 6, and 7)
LCD

8M-B120C Dismantle Instruction
7
8. Capacitors
Electrolyte Capacitors which diameter/height is larger than 25mm is installed on the Power PWB.
These capacitors can be removed by using nipper to cut the leads.
9. Parts List
Parts described in Annex VII of directive 2012/19/EU are as below.
Parts
Note
LCD
120inch LCD module
Batteries
Battery(AAA) of remote control
Printed Circuit Boards
Main PWB
Power PWB
Backend PWB
Backlight Power Control PWB
Main T-CON PWB
Sub T-CON PWB
LED Driver PWB
AC Detection PWB
Electrolyte capacitors
(height >25mm, diameter >25mm)
On the Power PWB
External electric cables
2 kinds of Power Cord
- CEE 7 (for EU)
- Type-BF (for UK)
