親愛的 SHARP 顧客/Dear SHARP customer
衷心感謝您購買 SHARP 液晶智能顯示器。。為確保安全使用本機及多年使用本機， 請務必在使用本產品前
仔細閱讀重要的安全注意事項。
重要事項：
請將顯示器的型號和序號抄在右側空格內，萬一本機遺失或遭竊時將
有助於資料的呈報。型號和製造號碼標示於顯示器的背面。
型號/Model No.：
製造號碼/Serial No.：
本產品僅適用於台灣。/ This product is only for Taiwan.
重要資訊/Important Information
Thank you for your purchase of the SHARP Liquid Crystal Smart Monitor. To ensure safety and
many years of trouble-free operation of your product, please read the Important Safety
Precautions carefully before using this product.
IMPORTANT:
To aid reporting in case of loss or theft, please record the Monitor’s
model and serial numbers in the space provided. The numbers are
located at the rear of the Monitor.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING:
/CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrow-head
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important
operating and maintenance
(servicing) instructions in the
literature accompanying the product.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE
/ Overuse may damage eyesight.
/ Use 30 minutes, please rest for 10 minutes.
/ Do not let children under age of 2 to
watch the screen, children over age of 2 should not watch the screen for more than 1 hour per day.
SLOT, FULLY INSERT.
CAUTION:
CT
-1
CT
-2
4T-C65FV1X
中國印製
TINS-H719WJN2
23P03-CH-ZJ
TINS-H719WJN2
LCD SMART MONITOR
Initial setup guide
請掃描上面的代碼以訪問 PDF 電子手冊。
將應用互聯網收費的網絡。
Please scan the code above to access PDF E-Manual.
The networks of the internet charges will be applied.
https://global.sharp/restricted/support/aquos/emanual/asia/pdf/fv/android11/index.html

CT
-3
CT
-4
1遙控器（ 2 支） 2“AAA”型鹼性電池（ 4 顆） 3初始設定指南
保證書
4
7
56
台座單位
台座安裝托架 (1 個 )
( g 1)
( g 2) ( g 4)
( g 1)
( g 8)
釘 ( 8 顆）絲螺
釘 絲螺
台座封蓋 (1 個 ) 交流電源線 將台座安裝托架插入台座基座。
台座基座
用四顆用於組裝台座的螺絲固定台座安裝托架與
台座基座。
拿出顯示器
1) 撕掉顯示器螢幕一側的膠帶，然後請把袋子滑下
1) 不要把顯示器螢幕向下。
Do not lay the Monitor
screen down.
2) 不要取下螢幕保護墊（紙板）
保護螢幕直到安裝完成。
To protect the screen, do not remove
the screen protector pad (cardboard)
until installation is complete.
3) 始終與兩個或更多人一起工作。
請勿握住顯示器的四個角。
Always work with two or more people.
Do not hold the four corners of the
Monitor.
來。
2) 顯示器裝完成前請勿取下螢幕保護墊。
確保與兩個或更多人一起工作。
將顯示部分垂直安裝到台座安裝托架上。
如示例圖所示，與
台座安裝托架中心
的 A 對齊。
慢慢放下顯示部分，
使顯示部分的 B 卡
在台座安裝 托架上。
A
B
•小心不要讓您的手指夾在顯示部分和台座安裝托
架之間。
組裝前請檢查以下注意事項。
/Supplied accessories /Attaching the stand
Please check the following precautions before assembling.
Remote control unit
Type A Type B
“AAA” size battery
Initial setup guide
Warranty Certificate
To insert stand mounting bracket to stand base.
台座安裝托架
Stand mounting
bracket
Front
Take out the Monitor.
Peel off the tape on the Monitor screen side and slide
the bag down.
Do not remove the screen protection pad until the
Monitor installation is complete.
Ensure to work with two or more people.
Attach the display part to the stand mounting bracket in
an upright position.
Align with A in the
center of the stand
mounting bracket as
shown in the
example figure.
Slowly lower the
display part so that B
of the display part is
caught in the stand
mounting bracket.
Be careful not to get your fingers caught between the
display part and the stand mounting bracket.
Fix the stand mounting bracket and the stand base with
four screws for assembling the stand.
Stand unit
Stand mounting bracket
Stand cover
( g 1)座 (1 個 ) 基座台 Stand base
Screws
(1 顆) (1 根)
8
( g 1)
Swivel lock screw ( g 1) AC cord
腳架旋轉鎖定螺絲
螢幕保護墊
前
後
前
Front
Screws
後
Back
Back
Caution
Stand base
4
6
5
9
Screen protector pad
1 2 3
B. 裝入電池
Type A
Type B
1 2 3
2“AAA”型鹼性電池
Inserting the batteries
“AAA” size battery
2“AAA”型鹼性電池
“AAA” size battery
Replacement of a battery with an incorrect type that can defeat a safeguard (for example, in the case of some lithium
battery types).
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a battery, can result in an explosion.
•在裝入電池時，要注意電池端子
•不可置換可能影響安全防護的錯誤型式的電池（例如，在某些鋰電池類型的情况下）。
•不可將電池丟入火焰或烤箱中，或將其擠壓或切割，都可能導致爆炸。
Leaving a battery in an extremely high temperature surrounding environment can result in an explosion or the leakage
of flammable liquid or gas.
•不可將電池置於可能爆炸或可燃性液體或氣體洩漏的高溫環境中。
A battery subjected to extremely low air pressure may result in an explosion or the leakage of flammable liquid or gas.
•不可將電池置於可能導致爆炸或可燃性液體或氣體洩漏的極度低氣壓。
Risk of fire or explosion if the battery is replaced by an incorrect type.
•如果更換的電池類型不正確，則有發生火災或爆炸的風險。
的極性要與電池艙內的極性標記
（e）和（f）一致。
Place batteries with their terminals corresponding to the (e) and f( ) indications in the
battery compartment. Recycle the battery
Caution

CT
-5
CT
-6
請使用附件的 4 根螺絲釘，固定顯示部分和台座
基座。
•
•
安裝顯示器和台座安裝托架時，請擰緊固定。
•固定完成後，請輕搖確認所有的螺絲釘是否擰緊。
•安裝完成后，如果發現顯示器有傾斜狀況，請稍稍擰鬆
螺絲釘，使顯示器回向水平方向移動后，再次擰緊螺絲
釘。
安裝台座封蓋。
台座封蓋
•把台座封蓋上方的 3 處凸起部分對準顯示器的凹
陷部分進行安裝。
完成上述步驟，結束“連接台座單位”。
•
•請注意在轉動顯示器螢幕時，小心顯示器傾倒。
另外，請小心夾手。
左右各能調整的範圍約為 15 度。
•在轉動顯示器螢幕時，請注意不要用力按顯示器
螢幕或者邊角部分。這可能會使顯示器螢幕的破
損，導致受傷。
使用隨附的腳架旋轉鎖定螺絲進行固定。 螢幕朝
前，將螺絲孔與支架孔對齊，然後擰上螺絲。
Use the supplied swivel lock screws to fix it.
With the screen facing the front, align the screw
holes with the stand holes and attach the screws.
Caution
Caution
請推動箭頭的部分，直到聽到“咔嗒”聲。
Please push the part of the arrow until you
hear a "click" sound.
當你想固定螢幕在前面時
When you want to fixed the screen in front
/ Attaching the stand (Continued)
用一字螺絲刀固定它。Secure it with flathead
screwdriver.
如果你使用的是腳架旋轉鎖定螺釘，請先卸下螺
釘，然後再卸下支架蓋。
If you are using the swivel lock screws, remove the screw
before removing the stand cover.
卸下支架蓋時，請提起下圖所示的箭頭部分並將其
卸下。
When removing the stand cover, lift the arrow part shown
in the figure below and remove it.
When installing the Monitor and the stand mounting
bracket, please tighten it.
Be careful not to tip the Monitor over when turning the
Monitor screen.
Complete the above steps to end the “Attaching the stand”.
Also, be careful of caught your hands.
The adjustable range for left and right is about
15 degrees.
When turning the Monitor screen, be careful not
to press the Monitor screen or the corners too
hard. This may break the Monitor screen,resulting
in injury.
Approx.15˚
Stand cover
Approx.15˚
Adjust the Monitor screen angle (Be careful not to caught
your hands)
Fix the Monitor and stand base with four screws provided.
Install the stand cover.
Align the 3 raised parts above the stand cover with the
recessed parts of the Monitor to install.
•After fixing, please shake to confirm whether all the
screws are tightened.
•After the installation is complete, if you find that the
Monitor is tilted, please loosen the screws slightly to
make the Monitor shift to the horizontal, and then
tighten the screws again.
請勿將顯示器螢幕正面朝下放置，
否則可能會損壞顯示器螢幕等，從
而造成人身傷害。
Do not place the Monitor screen
face down, as it may cause
damage to the Monitor screen,
etc., resulting in injury.
拆下支架時 When removing the stand
顯示器螢幕
移動本機時，請按照“連接台座單位”中相反的步
驟卸下支架。
When moving the unit, remove the stand by following the
steps in "Attaching the stand" in reverse order.
約15°
約15°
Do Not Touch
This Screen
不要觸摸這個螢幕
7
8腳架旋轉鎖定螺絲
Swivel lock screw
Screws
釘 絲螺
6
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
CT
中文
必須安裝臺座，以防止顯示器跌落造成傷害。
清理—清理產品前，請從交流電源插座上拔下交流電源線。使用柔軟濕潤的布料來清理產品。
請勿使用液態清潔劑，氣溶膠清潔劑或沾染化學藥品的布料來清理, 因為此類材料可能會損壞產品。
水和潮濕 — 不要在近水之處使用本機，例如在靠近洗澡盆，洗臉盆，廚房洗滌槽，洗衣盆，游泳池等，也不要在潮濕的
地下室中使用。
請勿在本機之上放置花瓶或任何其他盛水的容器。
若有水滴濺到本機上，就可能引起火災或觸電。
不要將本機放置於不穩定的推車，臺座，三腳架或桌面上。不穩固的基座可能會使本機掉落，導致嚴重的人身傷害以及
造成產品損壞。請僅使用本製造商所推薦或與本產品配套出售的推車，臺座，三腳架，托架或桌子。將本機安裝與牆上
時，請務必遵照本製造商的指示。而且只可以使用本製造商所推薦的安裝器材。
將本機放置於推車上搬運時， 必須小心注意安全。急停，用力過度，地面不平等等，都會導致本機從推車上掉落。
通風 — 本機外殼上的散熱孔與其他開口處都是用於散熱通風。請勿堵塞這些散熱孔或開口處，通風散熱不良會使本機過
熱和/或縮短本機的使用壽命。請勿將本機置於臥室，沙發，地毯或其他類似物品上，因為這些物品會堵塞散熱通風孔。
本機之設計不適用於嵌入式安裝； 所以不要將本機置於像書櫃，機架等封閉之處，除非提供合適的通風或遵照本製造商
的指示安裝。
本機所用之液晶顯示器用玻璃製造的。因此，在受到強力撞擊或遭到尖銳物品刻劃時會破損。萬一液晶顯示器破碎，請
小心不要被破碎玻璃割傷。
熱源 —請勿讓本機接近熱源，如暖氣機，加熱器，爐灶或者其他任何會產生熱能的產品（包括擴大機在內）。
為防止發生火災，請勿將任何種類的蠟燭或火焰置於顯示器上或其附近。
為了防止火災或觸電的危險，請勿將交流電源線置於顯示器或其他重物下。
請勿在本機之上放置重物或攀爬於本機之上。這樣做可能導致本機傾倒而造成傷害。特別要注意附近的兒童和寵物。
液晶螢幕採用極高精度技術製造，有效像素達到 99.99% 以上。
0.01% 或以下的缺失像素，或者那些始終亮著的像素不是故障。
在搬運顯示器時的注意事項
在搬運顯示器時，切勿握持或施加壓力於顯示器上。 任何時候都必須由兩個人或多人用雙手搬運 —顯示器的每一側用
一雙手握住。
請勿長時間顯示靜止畫面，這可能會導致殘留影像。
請將本機安裝於能夠很容易地將交流電源線從交流電源插座和本機機背後的 AC INPUT（交流電源輸入）端子上撥出的地
方。
穩定性的危險
此顯示器可能傾倒而導致人員嚴重傷亡。特別對於兒童之各種傷害，可藉由簡單的預警加以避免，例如：
請勿將顯示器安裝在空調機下方或加濕器附近等會受到水滴影響的位置。
- 使用顯示器製造商建議的櫃子、支架或安裝方法。
- 使用可安全支撐顯示器的家具。
- 確保顯示器不會懸垂於支撐家具之邊緣。
- 教導兒童有關攀爬家具觸碰顯示器或其控制器之危險。
- 將連接至顯示器之電線及電纜加以整理，使其不致發生跘倒、拉扯或纏繞。
- 勿置放顯示器於不穩固之位置。
- 勿放置設備在挑高家具（例：櫥櫃或書櫃）之上而未將家具及顯示器二者扣牢至合適的支撐上。
- 勿將顯示器置於任何放置於顯示器及支撐家具之間的衣物或其他材料之上。
- 勿放置吸引兒童攀爬之物品，如：將玩具或控制器放置於顯示器上或安置顯示器之家具上。
若既有之顯示器將保留原位或重新擺置，上述相同考量亦適用。
水滴掉落在顯示器上並進入其中可能會造成起火，電擊或故障。
建議您將顯示器安裝在距離冷氣出風口至少 1m 的位置。
重要的安全注意事項
※根據NCC低功率射頻器材技術規範3.8.2規定：
-取得審驗證明之低功率射頻器材，非經核准，公司、商號或使用者均不得擅自變更頻率、加大功率或變更原設計之特性
及功能。
-低功率射頻器材之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並改善至無干擾時方得
繼續使用。前述合法通信，指依電信管理法規定作業之無線電通信。
-低功率射頻器材須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。
設備上的符號
此標誌表示產品在交流電壓下工作。
此標誌表示 II 類或雙重絕緣電器，其中產品不需要電氣接地的安全連接。

-7-8
使用 AV IN 的說明。
需要 RCA 插孔轉换。
購買維修部件 （QCNWGA252WJPZ）。
側部端子
遊戲機，
DVD播放機等
Video
Audio L
Audio R
CT CT
初始安裝
端子圖
第一次使用本顯示器時，請按照以下步驟逐一操作。視您的顯示器安裝與連接而定，可能不需要進行某些
步驟。


將交流電源線插入主機的交流電源插座。
將交流電源線插入交流電源插座。
執行初始安裝。
•按照顯示器螢幕上的指示設置設定。
•將顯示器放在靠近交流電源插座的位置，以便電源插
頭就近使用。
將整線器插入束線帶。
將束線帶扣 (1) 往內壓，
將束線帶 (2) 往外拉並
完全鬆開。
注意
為避免電擊危險，切勿接觸連接了交流電的未絕緣零件
或任何電線。
顯示器 (背面)
(eARC/ARC)
耳機
(輸入 1)
(輸入 3) (輸入 4)
(輸入 2)
USB
(DC5V 0.5A
最大)
光纖數位聲音輸出
(10/100 BASE-T)
乙太網絡
僅供售後服務
使用
影音輸入
影音輸入
4-
聲音 R
1-GND
2-
3-視頻
聲音
L
(視頻)
(聲音 L)
(聲音 R)
黃
白
紅
按下顯示器上的 (飛梭鍵)。

觀看電子手冊
觀看內建操作手冊
內建操作指南顯示於螢幕上。您可以閱讀此裝
置的操作說明。
需要連接互聯網。
1按下 （首頁），顯示 HOME（首頁）
画面，按下 / 選擇 「手冊」。
然後按下 確定/OK。將顯示內建操作手冊
畫面。
2選擇目錄時，將顯示其頁面。
附錄
疑難排解
下述問題並非一定由於故障而引起。將顯示器送修之前，請再次檢查顯示器。
案方決解的能可題問
•沒有電源。 •檢查是否按下了遙控器上的 "電源" 按鍵。
•AC電源線是否中斷連接？
•主電源是否被打開？
•遙控器無法運作。 •電池是否按極性（e、f) 放入？
•沒有影像。 •與其他組件的連接是否正確？
•沒有聲音。 •與其他組件的連接是否正確？
清除密碼
如果您忘記了密碼，請依照下列步驟來清除密碼。
1在資訊主頁畫面中，選擇「設定」>「系統」>「關於」>「重設」>「恢復原廠設定」，然後按下
確定/OK。
2顯示器重置後將恢復原廠設定，需重設密碼。
註
•以防萬一，請記下密碼並妥善保管。
•預設 PIN 碼為「1234」。
2
HDMI 3 HDMI 4
HDMI 2
HDMI 1
免責聲明
• 本 SHARP 裝置促進存取第三方提供的內容和服務。透過本裝置存取的內容和服務屬於第三方，而且可
能專屬於第三方。因此，此類第三方內容和服務的任何使用都必須依照該內容或服務供應商提供的任何
授權或使用條款。若您未能遵從該授權或使用條款，SHARP 對於您或任何第三方概不負責。除非適用
內容或服務供應商特別授權，否則提供的所有第三方內容和服務僅供個人和非商業用途；您不得透過任
何方式或媒體修改、複製、分發、傳送、展示、執行、重製、上傳、發佈、授權、創建衍生創作、轉讓
或出售透過此裝置提供的任何內容或服務。
• 對於第三方內容或服務相關的顧客服務相關議題，SHARP 概不負責。對於與第三方內容或服務相關的
任何問題、意見或服務相關的疑問，應直接諮詢適用的內容或服務提供商。
• 所有可透過本裝置存取的第三方內容或服務係基於「可用性」以「現狀」提供給您，SHARP 與其子公司
沒有對您作出任何擔保或聲明，不論是明示或暗示，包括但不限於對於提供給您的內容或服務之適銷性、
不侵權、適合特定用途、適用性、可用性、準確性、完整性、安全性、所有權、實用性、無過失或無錯
誤或是不中斷操作或使用的任何擔保，也不擔保內容或服務將符合您的需求或期望。
• SHARP 並非第三方內容或服務供應商的代理人，而且對於第三方內容或服務供應商的行為或疏忽以及
與該第三方供應商相關的任何內容或服務方面概不負責。
• 在任何情況下，對於您或任何第三方的任何直接、間接、特殊、偶然、懲罰性、後果性或其他損失，不
論責任理論是基於合約、侵權、過失、違反保證、嚴格責任或其他方面，而且無論 SHARP 和/或其子公
司是否已被告知發生此類損害的可能性，SHARP 和/或其子公司概不負責。
您可能會由於與裝置本身無關的各種原因而無法從裝置存取內容或服務，包括但不限於停電、其他網際
網路連接，或未能正確配置裝置。對於此類故障或維修產生的中斷，不論原因為何或本來是否能夠避免，
SHARP、其董事、管理人員、僱員、代理人、承包商和子公司對於您或任何第三方概不負責。
電源及選單共
用十字按鍵
交流輸入

CT
-9
EN
-10
4T-C65FV1X
1442 896 304
1442 845 73
31.5 kg (37.0 kg)
寬 g 高 g 深 (mm)
寬 高 深 (mm)
作為不斷改進政策的一部份，SHARP 保留改進產品而變更設計和規格的權利，恕不另行通知。以上性能規格的數值為產
品設備的標稱值。個別設備的相關數值可能略有差異。
安裝液晶顯示器要專業技術，因此必須由合格的維修人員進行。顧客不應自行嘗試安裝。SHARP 對由於安裝不當或安
裝造成的事故或傷害不承擔任何責任。
開始操作前，請詳細閱讀托架隨附的說明。
請勿在傾斜狀態下安裝/壁掛顯示器。
164 cm）離距線角對斜（板面晶液
解析度 8,294,400 像素 (3840 g 2160)
音頻放大器 共 85W [(15W g
gg
gg
gg
2)e(10W g 2)e(10W g 2)e15W]
端子
僅供售後服務使用 2.5 mm 插孔
3.5 mm 插孔
HDMI 1 HDMI 4K, ALLM
HDMI 4K, ALLM
HDMI 4K, ALLM/VRR (120P)
HDMI 2
HDMI 3
HDMI 4K, ALLM/VRR (120P), eARC/ARCHDMI 4
USB USB 2.0 (DC5V 0.5A 最大)
USB USB 2.0 (DC5V 0.5A 最大)
乙太網絡
光纖數位聲音輸出
(10/100 BASE-T) 網路連接器
光學 S/PDIF 數位聲音輸出
耳機 3.5 mm 立體聲
額定電壓額定頻率 AC 110 V, 60 Hz
額定消耗電功率
360 W (0.5 W)
(待機)
尺寸 不含台座
含台座
不含台座重量（含台座重量)
操作溫度 0°C 到 e 40°C
(音頻輸入，視訊輸入)影音輸入
PAL / SECAM / NTSC 3.58 / NTSC 4.43 / PAL 60 視頻彩色系統
IEEE 802.11 a/b/g/n/ac 2T/2R 雙頻
WPA3-個人, WPA2-個人, WPA-個人
Bluetooth V2.1 e EDR / 4.2 / 5.1
螢幕顯示語言 英文/簡体中文/繁体中文(台灣)/繁體中文(香港)/阿拉伯語/法語/
泰語/葡萄牙語/越南語/印地語/俄語/馬來語/印尼語
規Important Safety Precautions [ENGLISH
EN
]
WIFI通訊協定
WIFI通訊安全
•Stand base must be attached to prevent the Monitor set from falling down and cause injuries.
•Cleaning — Unplug the AC cord from the AC outlet before cleaning the product. Use a soft damp cloth to clean the
product. Do not use liquid cleaners, aerosol cleaners or chemical cloth to clean it, as such materials may damage the
product.
•Water and moisture — Do not use the product near water, such as bathtub, washbasin, kitchen sink, laundry tub,
swimming pool and in a wet basement.
•Do not place vases or any other water-filled containers on this product.
The water may spill onto the product causing fire or electric shock.
•Stand — Do not place the product on an unstable cart, stand, tripod or table. Doing so can cause the product to fall,
resulting in serious personal injuries as well as damage to the product. Use only a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
•When relocating the product placed on a cart, it must be moved with utmost care. Sudden stops, excessive force and
uneven floor surface can cause the product to fall from the cart.
•Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not cover or block these
vents and openings since insufficient ventilation can cause overheating and/or shorten the life of the product. Do not
place the product on a bed, sofa, rug or other similar surface, since they can block ventilation openings. This product is
not designed for built-in installation; do not place the product in an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer’s instructions are followed.
•The LCD panel used in this product is made of glass. Therefore, it can break when the product is struck forcefully or
with a sharp object. If the LCD panel is broken, be careful not to be injured by broken glass.
•Heat sources — Keep the product away from heat sources such as radiators, heaters, stoves and other heat-generating
products (including amplifiers).
•To prevent fire, never place any type of candle or naked flames on the top or near the Monitor set.
•To prevent fire or shock hazard, do not place the AC power cord under the Monitor set or other heavy items.
•Do not place heavy objects on this product or stand on it. Doing so could cause injury if the product overturns. Take
special care near children and pets.
•The LCD panel is made with extremely high precision technology, and has 99.99% or more effective pixels.
The 0.01% or less missing pixels or those that are always lit is not a malfunction.
Precautions when transporting the Monitor
When transporting the Monitor, never carry it by holding or otherwise putting pressure onto the display. Be sure to always
carry the Monitor by two people holding it with two hands — one hand on each side of the Monitor.
•Do not display a still picture for a long time, as this could cause an afterimage to remain.
•Install the product on the place where the AC cord can be unplugged easily from the AC outlet or from the AC INPUT
terminal on the rear of the product.
Stability Hazard
•
A Monitor set may fall, causing serious personal injury or death. Many injuries, particularly to children, can be avoided
by taking simple precautions such as:
– ALWAYS use cabinets or stands or mounting methods recommended by the manufacturer of the Monitor set.
– ALWAYS use furniture that can safely support the Monitor set.
– ALWAYS ensure the Monitor set is not overhanging the edge of the supporting furniture.
– ALWAYS educate children about the dangers of climbing on furniture to reach the Monitor set or its controls.
– ALWAYS route cords and cables connected to your television so they cannot be tripped over, pulled or grabbed.
– NEVER place a Monitor set in an unstable location.
If the existing Monitor set is going to be retained and relocated, the same considerations as above should be applied.
– NEVER place the Monitor set on tall furniture (for example, cupboards or bookcases) without anchoring both the
furniture and the Monitor set to a suitable support.
– NEVER place the Monitor set on cloth or other materials that may be located between the Monitor set and
supporting furniture.
– NEVER place items that might tempt children to climb, such as toys and remote controls, on the top of the Monitor
or furniture on which the Monitor is placed.
•Do not install the Monitor in a location in which it will be subject to water drops such as underneath an air conditioning
unit or in the vicinity of a humidifier.
•Water drops falling onto the Monitor and water entering inside it may result in fire, electric shock, or malfunctions.
•We recommend that you install the Monitor at least 1m away from the outlet of an air conditioner.
Symbols placed on equipment
• This mark indicates the product operates on AC Voltage.
• This mark indicates a class II or double insulated electrical appliance wherein the product does not
require a safety connection to electrical earth (ground).

-11 -12

Press (JOG-KEY) on the Monitor.
Terminal Diagram
Initial installation
Follow the steps below one by one when using the Monitor for the first time. Some steps may not be necessary
depending on your Monitor installation and connection.
Plug the AC cord into the AC inlet of the main unit.
Plug the AC cord into the AC outlet.
Monitor (Rear)
• Place the Monitor close to the AC outlet, and keep the
power plug within reach.
Run the initial installation.
• Follow the guide on the Monitor screen to set
the settings.
Side terminal
3-Audio L
Yellow
(Video)
White
(Audio L)
Red
(Audio R)
Video
Audio L
Audio R
4-Video
1-GND
2-Audio R
Instruction for using AV IN.
Requires RCA jack conversion.
Buy the service parts (QCNWGA252WJPZ).
Game console,
DVD player, etc.
HDMI 2
HDMI 1
(FOR SERVICE
ONLY)
(eARC/ARC)
HDMI 3
(EAR PHONE)
HDMI 4
USB
(DC5V 0.5A Max)
(OPTICAL DIGITAL
AUDIO OUTPUT)
(10/100 BASE-T)
(LAN)
(AV IN)
Bundle the cables into
cable tie.
Press cable tie clip (1)
and pull out cable tie (2)
completely to release.
Viewing the Built-in Operation Manual
Displays the built-in operation manual on the
screen. You can read information about how to
use this device.
The internet connection will be required.
1Press (HOME) to display the HOME screen,
press / to select “Manual”, and then press
確定 (ENTER)/OK.
2When you select contents, its page will be
displayed.
Appendix
Troubleshooting
The problems described below are not always caused by malfunctions. Check the Monitor again before having the
Monitor serviced.
noituloSelbissoPmelborP
• No power. • Check if you pressed 電源 (POWER) on the remote control unit.
• Is the AC cord disconnected?
• Has the power been turned on?
• Remote control unit does
not operate. • Are batteries inserted with polarity ( e, f) aligned?
• No picture. • Is connection to other components correct?
• No sound. • Is connection to other components correct?
Viewing E-Manual
Clearing the password
If you forget the password, clear the password using the following procedure.
1From the Dashboard, select “Settings” > “System” > “About” > “Reset” > “Factory reset”, and then press
確定 (ENTER)/OK.
2When you perform a reset, the Monitor will be returned to the factory preset values, and you need to set the
password again.
NOTE
• As a precautionary measure, make a note of your password, and keep it in a safe place.
• The default PIN is “1234”.
耳機
光纖數位聲音輸出
乙太網絡
僅供售後服務
使用
影音輸入
2
DISCLAIMERS
• This SHARP device facilitates the access to content and services provided by third parties. The content and
services accessible via this device belong to and may be proprietary to third parties. Therefore, any use of such
third party content and services must be in accordance with any authorization or terms of use provided by such
content or service provider. SHARP shall not be liable to you or any third party for your failure to abide by such
authorization or terms of use. Unless otherwise specifically authorized by the applicable content or service provider,
all third party content and services provided are for personal and non-commercial use; you may not modify, copy,
distribute, transmit, display, perform, reproduce, upload, publish, license, create derivative works from, transfer or
sell in any manner or medium any content or services available via this device.
• SHARP is not responsible, nor liable, for customer service-related issues related to the third party content or
services. Any questions, comments or service-related inquiries relating to the third party content or service should
be made directly to the applicable content or service provider.
• ALL THIRD PARTY CONTENT OR SERVICES ACCESSIBLE VIA THIS DEVICE IS PROVIDED TO YOU ON AN
"AS-IS" AND "AS AVAILABLE" BASIS AND SHARP AND ITS AFFILIATES MAKE NO WARRANTY OR
REPRESENTATION OF ANY KIND TO YOU, EITHER EXPRESS OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, ANY WARRANTIES OF MERCHANTABILITY, NON-INFRINGEMENT, FITNESS FOR A
PARTICULAR PURPOSE OR ANY WARRANTIES OF SUITABILITY, AVAILABILITY, ACCURACY,
COMPLETENESS, SECURITY, TITLE, USEFULNESS, LACK OF NEGLIGENCE OR ERROR-FREE OR
UNINTERRUPTED OPERATION OR USE OF THE CONTENT OR SERVICES PROVIDED TO YOU OR THAT
THE CONTENT OR SERVICES WILL MEET YOUR REQUIREMENTS OR EXPECTATIONS.
• SHARP IS NOT AN AGENT OF AND ASSUMES NO RESPONSIBILITY FOR THE ACTS OR OMISSIONS OF
THIRD PARTY CONTENT OR SERVICE PROVIDERS, NOR ANY ASPECT OF THE CONTENT OR SERVICE
RELATED TO SUCH THIRD PARTY PROVIDERS.
• IN NO EVENT WILL SHARP AND/OR ITS AFFILIATES BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY
DIRECT, INDIRECT, SPECIAL, INCIDENTAL, PUNITIVE, CONSEQUENTIAL OR OTHER DAMAGES, WHETHER
THE THEORY OF LIABILITY IS BASED ON CONTRACT, TORT, NEGLIGENCE, BREACH OF WARRANTY,
STRICT LIABILITY OR OTHERWISE AND WHETHER OR NOT SHARP AND/OR ITS AFFILIATES HAVE BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
You may not be able to access content or services from the device for a variety of reasons which may be unrelated
to the device itself, including, but not limited to, power failure, other Internet connection, or failure to configure your
device properly. SHARP, its directors, officers, employees, agents, contractors and affiliates shall not be liable to
you or any third party with respect to such failures or maintenance outages, regardless of cause or whether or not it
could have been avoided.
影音輸入
JOG-KEY
AC Inlet

EN
-13
EN
-14
Specifications
W x H x D (mm)
W x H x D (mm)
1442 g 845 g 73
1442 g 896 g 304
31.5 kg (37.0 kg)
Model
Item 4T-C65FV1X
164 cmlenapDCL
Resolution 8,294,400 pixels (3840 g2160)
06LAP/34.4CSTN/85.3CSTN/MACES/LAPmetsysruolocoediV
Audio amplifier Total 85W [(15W g2) + (10W g 2) + (10Wg 2) + 15W ]
Terminals
(FOR SERVICE ONLY) 2.5 mm jack
3.5 mm jack (AUDIO in, VIDEO in)
HDMI 1 HDMI 4K, ALLM
HDMI 2 HDMI 4K, ALLM
HDMI 3 HDMI 4K, ALLM/VRR (120P)
HDMI 4 HDMI 4K, ALLM/VRR (120P), eARC/ARC
(AV IN)
USB USB 2.0 (DC5V 0.5A Max)
USB USB 2.0 (DC5V 0.5A Max)
LAN (10/100 BASE-T) Network connector
(OPTICAL DIGITAL AUDIO
OUT)
Optical S/PDIF digital audio output
(EAR PHONE) 3.5 mm stereo
egaugnalDSO
AC 110V, 60HztnemeriuqerrewoP
(0.5 W)360 W
noitpmusnocrewoP (Standby)
WIFI Protocol IEEE 802.11 a/b/g/n/ac 2T/2R Dual Band
WIFI Security WPA3-Personal, WPA2-Personal, WPA-Personal
Bluetooth V2.1 + EDR / 4.2 / 5.1
Dimensions without stand
with stand
Weight without stand (with stand)
Operating temperature 0°C to + 40°C
As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes
for product improvement without prior notice. The performance specification figures indicated are nominal values of
production units. There may be some deviations from these values in individual units.
CAUTION
Installing the Liquid Crystal Monitor requires special skill that should only be performed by qualified service
personnel. Customers should not attempt to do the work themselves. SHARP bears no responsibility for improper
mounting or mounting that results in accident or injury.
Carefully read the instructions that come with the bracket before beginning work.
Do not install / mount the Monitor with tilting condition.
English/Simplified Chinese/Traditional Chinese(TW)/
Traditional Chinese(HK)/ Arabic/French/Thai/Portuguese/Vietnamese/
Hindi/Russian/Bahasa Malaysia/ Bahasa Indonesia
Trademarks
Dolby, Dolby Vision IQ, Dolby Vision, Dolby Atmos, Dolby Audio, and the double-D symbol are trademarks of Dolby
Laboratories Licensing Corporation. Manufactured under license from Dolby Laboratories. Confidential unpublished
works. Copyright © 1992–2022 Dolby Laboratories. All rights reserved.
The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI trade dress and the HDMI Logos are trademarks
or registered trademarks of HDMI Licensing Administrator, Inc.
®.
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such
marks by SHARP Corporation is under license. Other trademarks and trade names are those of their respective
owners.
ANY USE OF THIS PRODUCT IN ANY MANNER OTHER THAN PERSONAL USE THAT COMPLIES WITH THE
MPEG-2 STANDARD FOR ENCODING VIDEO INFORMATION FOR PACKAGED MEDIA IS EXPRESSLY
PROHIBITED WITHOUT A LICENSE UNDER APPLICABLE PATENTS IN THE MPEG-2 PATENT PORTFOLIO,
WHICH LICENSE IS AVAILABLE FROM MPEG LA, LLC, 6312 S. Fiddlers Green Circle, Suite 400 E,
Greenwood Village, Colorado 80111 U.S.A.
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND
NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1
STANDARD (“VC-1 VIDEO”) AND/OR (ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER
ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF
A CONSUMER OR OTHER USES IN WHICH IT DOES NOT RECEIVE REMUNERATION TO (i) ENCODE VIDEO
IN COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A PERSONAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C.
SEE HTTP://WWW.MPEGLA.COM
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE
WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS
ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS
OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO PROVIDE MPEG-4 VIDEO. NO LICENSE IS
GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT
RELATING TO PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE OBTAINED
FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
Appendix
影音輸入
乙太網絡
光纖數位聲音輸出
僅供售後服務使用
耳機
Google TV is the name of this device's software experience and a trademark of Google LLC. Google, YouTube,
Google Photos, Chromecast built-in and other marks are trademarks of Google LLC.
Google Assistant is not available in certain languages and countries. Availability of services varies by country and
language.
Covered by one or more claims of the HEVC patents listed at patentlist.accessadvance.com.

EN
-15
EN
-16
Unit : mm
壁掛孔距規格 / VESA SPEC
上/下側壁掛螺釘孔深度 /
UPPER/LOWER VESA SCREW DEPTH
上/下側壁掛螺釘規格 /
UPPER/LOWER VESA SCREW TYPE
400 x 400
30
M6
輪廓圖/Dimensional Drawing
單位: 公釐 /
1442
73
304
134
1437
475
896
809
845
400 125125
334400111
設備名稱：液晶智能顯示器， 型號（型式）：4T-C65FV1X
Equipment name : LCD Smart Monitor , Type designation (Type) : 4T-C65FV1X
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
鉛Lead
(Pb)
汞Mercury
(Hg)
鎘Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr+6)
多溴聯苯
Polybrominated
biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
○○○○○○
○○○○○○
○○○○○○
電路板
後殼
面板 -○○○○○
電源線
其他線材 -○○○○○
配件 (例：遙控器等)
-○○○○○
備考1.〝超出0.1 wt %〞及〝超出0.01 wt %〞係指限用物質之百分比含量超出百分比含量基準值。
Note 1: “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage content of the restricted
substance exceeds the reference percentage value of presence condition.
備考2. “○” 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2: “○” indicates that the percentage content of the restricted substance does not exceed the percentage of
reference value of presence.
備考3. “–” 係指該項限用物質為排除項目。
Note 3: The “–” indicates that the restricted substance corresponds to the exemption.
Printed Circuit Board
Rear Cabinet
Panel
Electric current wires
Other Wiring Material
Accessories (Example:
Remote control etc.）
/Restricted substances and its chemical symbols
限用物質及其化學符號
SHARP CORPORATION
SHARP CORPORATION
16 7
/
/
/
