Sharp AN-PH80CW User manual

Printed in China
9NK5010098600
11P05-CH-NM
INSTALLATION MANUAL
IMPORTANT NOTE TO U.S. CUSTOMERS:
The Color Wheel is backed by a 3-year parts and labor limited warranty. All service of this projector
under warranty, including Color Wheel replacement, must be obtained through a Sharp Authorized Projector
Dealer or Service Center*. For the name of the nearest Sharp Authorized Projector Dealer or Service
Center*, please call toll-free: 1-888-GO-SHARP (1-888-467-4277).
U.S.A. ONLY
* Confirm the name of the Dealer or Service Center referring to your projector operation manual.
COLOR WHEEL FOR PROJECTOR
MODEL
AN-PH80CW
Replacing the Color Wheel
Warning!
Do not remove the color wheel from the projector
right after use. The lamp and parts around the lamp
will be very hot and may cause burns or injury.
•
1Press STANDBY/ON on the projector
or on the remote control to put the
projector into Standby mode.
2Switch the MAIN POWER switch on
the projector to “OFF” and then
disconnect the power cord.
Unplug the power cord from the AC socket.
Leave the lamp until it has fully cooled down
(about 1 hour).
3Remove the lamp unit cover.
Loosen the user service screw (1) that secures
the lamp unit cover. Remove the lamp unit cover
(2).
•
•
•
1
STANDBY/ON button
AC socket
MAIN POWER switch
STANDBY/ON button
AC socket
MAIN POWER switch
2
3
User service screw
(for lamp unit cover)
User service screw
(for lamp unit cover)
4Loosen the 4 retaining screws from
the four-segment color wheel.
5Hold the color wheel and pull it in the
direction of the arrow.
Caution
The module contains components that can be damaged
or destroyed by electrostatic discharge. Please pick the
module with the handle.
6Insert the six-segment color wheel,
and tighten the 4 retaining screws.
7Replace the lamp unit cover.
Align the lamp unit cover and slide it to close (1).
Then tighten the user service screw (2) to secure
the lamp unit cover.
Info
Storing the Unused Color Wheel:
Use the zipper bag in which the six-segment color wheel was
packaged to store the unused color wheel. This bag prevents
dust and dirt from collecting on the color wheel.
•
4
5
HandleHandle
6
7
AN-PH80CWColorWheel.indd1AN-PH80CWColorWheel.indd1 2011/04/2010:02:212011/04/2010:02:21

DEUTSCH
FRANÇAIS
ESPAÑOL
ITALIANO
SVENSKA
PORTUGUÊS
Richten Sie sich bitte nach der beim Projektor mitgelieferten
Bedienungsanleitung.
Sie können die Bedienungsanleitung auch von der Website
(http://sharp-world.com/products/index.html) herunterladen.
Reportez-vous au mode d'emploi fourni avec le projecteur.
Vous pouvez également télécharger le mode d'emploi sur le site
Internet (http://sharp-world.com/products/index.html).
Consulte el manual de manejo que se suministra con el proyector.
También puede descargar el manual de manejo del sitio Web
(http://sharp-world.com/products/index.html).
Fare riferimento al manuale d'uso fornito con il proiettore.
È inoltre possibile scaricare lo stesso manuale d'uso dal sito web
(http://sharp-world.com/products/index.html).
NEDERLANDS
Verwijs naar de gebruiksaanwijzing die bij de projector wordt
geleverd.
U kunt de gebruiksaanwijzing ook vanaf internet downloaden
(http://sharp-world.com/products/index.html).
Anlita bruksanvisningen som medföljer projektorn.
Bruksanvisningen kan också nerladdas från vår webbsajt
(http://sharp-world.com/products/index.html).
Consulte o manual de operação fornecido com o projetor.
Pode-se também baixar o manual de operação pela internet
(http://sharp-world.com/products/index.html).
