Sharp CD-BA3100 User manual

Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARPproduct.
CD-BA3100 Mini Component System consisting of CD-BA3100 (main
unit) and CP-BA3100 (speaker system).
MINI COMPONENT SYSTEM
MODEL
CD-BA3100
OPERATION MANUAL
*BA3100_F/R 00.12.8, 11:05 AM2

2
Special Notes
NOTE
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interfer-
ence in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular installa-
tion. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
●Consult the dealer or an experienced radio/TV technician for help.
WARNING
FCC Regulations state that any unauthorized changes or modifications to this equip-
ment not expressly approved by the manufacturer could void the user’s authority to
operate this equipment.
NOTE
It is the intent of Sharp that this product be used in full compliance with the copyright
laws of the United States and that prior permission be obtained from copyright owners
whenever necessary.
Important Instruction
– Special Notes –
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or theft, please record
below the model number and serial number which are located on the rear of the
unit.
Please retain this information.
Model number .................................................................................
Serial number .................................................................................
Date of purchase .................................................................................
Place of purchase .................................................................................
0005
Caution - use of controls or adjustments or performance of proce-
dures other than those specified herein may result in hazardous ra-
diation exposure.
0005
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
0005
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE. 000
5
*BA3100_P02_03 00.12.8, 11:32 AM2

3
CAUTION
All the safety and operating instructions should be read before the appliance is
operated, and should be retained for future reference.
Electrical energy can perform many useful functions. This unit has been engineered
and manufactured to assure your personal safety. Improper use can result in
potential electrical shock or fire hazards. In order not to defeat the safeguards,
observe the following basic rules for its installation, use and servicing.
1 Heed Warnings -All warnings on the appliance and in the operating instructions
should be adhered to.
2 Follow Instructions - All operating and use instructions should be followed.
3 Water and Moisture - The appliance should not be used near water - for
example, near a bathtub, washbowl, kitchen sink, laundry tub, in a wet base-
ment, or near a swimming pool, etc.
4 Carts and Stands - The appliance should be used only with a cart or stand that is
recommended by the manufacturer.
●An appliance and cart combination should be moved with care.
Quick stops, excessive force, and uneven surfaces may cause
the appliance and cart combination to overturn.
5 Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling
only as recommended by the manufacturer.
6 Ventilation -The appliance should be situated so thatits location or position does
not interfere with its proper ventilation. For example, the appliance should not be
situated on a bed, sofa, rug, or similar surface that may block the ventilation
openings; or, placed in a built-in installation, such as a bookcase or cabinet that
may impede the flow of air through the ventilation openings.
7 Heat - The appliance should be situated away from heat sources such as
radiators, heat registers, stoves, or other appliances (including amplifiers)
that produce heat.
8 Power Sources - The appliance should be connected to a power supply only of
the type described in the operating instructions or as marked on the appliance.
9 Power-Cord Protection - Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords at plugs, convenience receptacles, and the
point where they exit from the appliance.
10 Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.
11 Power Lines - An outdoor antenna should be located away from power lines.
12 OutdoorAntenna Grounding - If an outside antenna is connected to the receiver,
besure the antennasystem is groundedso as to provide someprotection against
voltage surges and built-up static charges. Section 810 of the National Electrical
Code, ANSI/NFPA No. 70-1984, provides information with respect to proper
grounding of the mast and supporting structure, grounding of the lead-in wire to
an antenna discharge unit, size of grounding conductors, location of antenna-
discharge unit, connection to grounding electrodes, and requirements for the
grounding electrode.
ANTENNA LEAD IN WIRE
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
POWER SERVICE GROUNDING ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
NEC - NATIONAL ELECTRICAL CODE
S2898A
ELECTRIC SERVICE
EQUIPMENT
GROUND CLAMP
EXAMPLE OF ANTENNA GROUNDING AS PER NATIONAL ELECTRICAL CODE
13 Nonuse Periods - The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
14 Object and Liquid Entry - Care should be taken so that objects do not fall and
liquids are not spilled into the enclosure through openings.
15 Damage Requiring Service - The appliance should be serviced by qualified ser-
vice personnel when:
A The power-supply cord or the plug has been damaged; or
B Objects have fallen, or liquid has been spilled into the appliance; or
C The appliance has been exposed to rain; or
D Theappliance doesnot appear to operate normallyor exhibitsa markedchange
in performance; or
E The appliance has been dropped, or the enclosure damaged.
16 Servicing - The user should not attempt to service the appliance beyond that
described in the operating instructions. All other servicing should be referred to
qualified service personnel.
17 Grounding or Polarization - Precautions should be taken so that the grounding or
polarization means of an appliance is not defeated.
0005
Important Safeguards
Important Instruction
– Important Safeguards –
*BA3100_P02_03 00.12.8, 11:32 AM3

4
■General Information Page
Accessories.........................................................................................4
Precautions .........................................................................................5
Controls and Indicators ................................................................6 - 9
■Preparation for Use
System Connections ..................................................................10, 11
Remote Control .................................................................................12
■Basic Operation
General Control.................................................................................13
Sound Control ...................................................................................14
Setting the Clock ..............................................................................15
■CD Playback
Listening to a CD (CDs)..............................................................16, 17
■Advanced CD Playback
To specify a disc to play...................................................................18
Repeat or Random Play ...................................................................18
Programmed Play .............................................................................19
Contents
■Radio Page
Listening to the Radio ...................................................................... 20
Listening to the memorized station ................................................21
■Tape Playback
Listening to a Cassette Tape (TAPE 1 or TAPE 2) ..........................22
■Tape Recording
Recording from the Radio................................................................ 23
Recording from a CD (CDs) .............................................................24
Dubbing from Tape to Tape..............................................................25
■Advanced Features
Timer and Sleep Operation ........................................................26, 27
Enhancing Your System ................................................................... 28
■References
Troubleshooting Chart ............................................................... 29, 30
Maintenance ...................................................................................... 30
Specifications ................................................................................... 31
CONSUMER LIMITED WARRANTY .....................................Back cover
Accessories
Please confirm that the following accessories are included.
Remote control × 1
(RRMCG0266AWSA) FM/AM loop antenna × 1 (QANTL0007AWZZ)
Note:
Only the above accessories are included.
General Information
– Contents / Accessories –
*BA3100_P04_09 00.12.8, 4:26 PM4

5
Precautions
■General
● Please ensure that the equipment is positioned in a well-ventilated area and
ensure that there is as least 4" (10 cm) of free space along the sides, top and
back of the unit.
●Use the unit on a firm, level surface free from vibration.
●Keep the unit away from direct sunlight, strong
magneticfields, excessivedust,humidity andelec-
tronic/electricalequipment (home computers, fac-
similes, etc.) which generates electrical noise.
●Do not place anything on top of the unit.
●Do not expose the unit to moisture, to temperatures higher than 140°F (60°C)
or to extremely low temperatures.
●If your system does not work properly, disconnect theAC power cord from the
AC outlet. Plug theAC power cord back in, and then turn on your system.
●Incase of anelectrical storm, unplugthe unit forsafety.
●HoldtheACpowerplug by the head when removing it
from the AC outlet, as pulling the cord can damage
internal wires.
●Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your lo-
cal SHARP service facility.
●This unit should only be used within the range of 41°F - 95°F (5°C - 35°C).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is specified is dan-
gerous and may result in a fire or other type of accident causing damage. SHARP
will not be held responsible for any damage resulting from use of this unit with a
voltage other than that which is specified.
■Volume control
Thesoundlevel at a given volume setting depends on speakerefficiency, location
and various other factors.
It is advisable to avoid exposure to high volume levels, which occur while turning
the unit on with the volume control setting up high, or while continually listening at
high volumes.
■Care of compact discs
Compact discs are fairly resistant to damage, however mistracking can occur due
to an accumulation of dirt on the disc surface.
Follow the guidelines below for maximum enjoyment from your CD collection and
player.
●Do not write on either side of the disc, particularly the non-label side from
which signals are read. Do not mark this surface.
●Keep your discs away from direct sunlight, heat, and excessive moisture.
●Always hold the CDs by the edges. Fingerprints, dirt, or water on the CDs can
cause noise or mistracking. If a CD is dirty or does not play properly, clean it
with a soft, dry cloth, wiping straight out from the center, along the radius.
4” (10 cm) 4” (10 cm) 4” (10 cm)
4” (10 cm)
NO YES
correct
General Information
– Precautions –
*BA3100_P04_09 00.12.8, 4:26 PM5

6
Controls and Indicators
■ Front panel Reference page
01. Disc Trays ........................................................................................ 16
02. Timer Set Indicator.......................................................................... 27
03. CD Direct Play Buttons....................................................... 18, 19, 24
04. CD Eject Buttons............................................................................. 16
05. Memory/Set Button .............................................................. 15,19, 21
06. Equalizer Mode Select Button........................................................14
07. Volume Control................................................................................ 14
08. Extra Bass/Demo Mode Button................................................13, 14
09. Tape 2 Record Pause Button.............................................. 23, 24, 25
10. Tape 2 Cassette Compartment.................................................22, 25
11. Tape 1 Cassette Compartment.................................................22, 25
12. CD Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down Button .................................................17, 21, 22
13. CD Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up Button ......................................................17, 21, 22
14. CD Button .................................................................................. 16, 24
15. Tuner (Band) Button ....................................................................... 20
16. Tape (1 VV
VV
V 2) Button .................................................................. 22, 25
17. Video/Auxiliary Button.............................................................. 26, 28
18. Power On/Stand-by Button ................................................15, 26, 30
19. Dimmer Button ................................................................................ 13
20. Headphone Jack.............................................................................. 28
21. CD or Tape Stop Button (with Indicator) .................................17, 22
22. CD Play or Repeat, Tape Play Button (with Indicator) ...... 17, 18, 22
23. Clock Button .............................................................................. 15, 26
24. Timer/Sleep Button ................................................................... 26, 27
25. Tuning and Time Down Button.................................................15, 20
26. Tuning and Time Up Button......................................................15, 20
21
22
12
26252423
13 14 15 16 17
18
19
20
1
2
34
5
6
7
8
9
10
11
General Information
– Controls and Indicators –
■Description of remote control (See page 8.)
*BA3100_P04_09 00.12.8, 4:27 PM6

7
■Display
01. CD Music Schedule Indicators
02. CD Play Indicator
03. CD Pause Indicator
04. Tape Play Indicator
05. CD Repeat Indicator
06. CD Indicators
07. FM Stereo Mode Indicator
08. FM Stereo Receiving Indicator
09. Memory Indicator
10. CD Random Play Indicator
11. Tape 2 Record Indicator
12. Extra Bass Indicator
13. Timer Recording Indicator
14. Timer Play Indicator
15. Sleep Indicator
16. Spectrum Analyzer/Volume Level Indicator
■Rear panel Reference page
01. Transport screw ........................................................................10, 30
02. FM/AM Loop Antenna Jack ...................................................... 10, 11
03. Video/Auxiliary (Audio Signal) Input Jacks ..................................28
04. Speaker Terminals ..................................................................... 10, 11
05. AC Power Cord .......................................................................... 10, 11
2
1
4
3
5
9
10
12
13
14
15
16
11
1234 5 6 7 8
General Information
– Controls and Indicators –
*BA3100_P04_09 00.12.8, 4:27 PM7

8
Controls and Indicators (continued)
■Remote control Reference page
01. Remote Control Transmitter ..............................................................12
02. CD Direct Play Buttons .........................................................18, 19, 24
03. CD Pause Button............................................................................. 17
04. CD Memory Button............................................................................ 19
05. CD Track Down or Fast Reverse Button ...........................................17
06. CD Clear Button .............................................................................. 19
07. Tape 1 Play Button ............................................................................ 22
08. Tape 1/Tape 2 Stop Button....................................................22, 23, 25
09. Equalizer Mode Select Button ...........................................................14
10. Tape 2 Record Pause Button ................................................23, 24, 25
11. CD Button.................................................................................... 16, 24
12. Tuner (Band) Button..........................................................................20
13. Power On/Stand-by Button.......................................................... 12, 26
14. Extra Bass Button .............................................................................14
15. CD Stop Button ........................................................................... 17, 24
16. CD Play or Repeat Button........................................................... 17, 18
17. CD Track Up or Fast Forward Button................................................17
18. CD Random Button .........................................................................18
19. Tuner Preset Up/Down Buttons ........................................................21
20. Tape 2 Play Button ............................................................................22
21. Tape 2 Rewind Button .......................................................................22
22. Tape 2 Fast Forward Button ..............................................................22
23. Video/Auxiliary Button ....................................................................... 28
24. Tape (1 V2) Button....................................................................22, 25
25. Volume Up or Down Buttons .............................................................14
1
215
16
17
18
19
20
21
24
3
6
4
7
8
9
10
14
13
12
11
5
25
22
23
✱
✱
✱
General Information
– Controls and Indicators –
Buttons with “✱” mark in the illustration can be operated on the remote control
only.
Other buttons can be operated both on the main unit and the remote control.
■Battery installation for remote control (See page 12.)
*BA3100_P04_09 00.12.8, 4:27 PM8

9
■Speaker system Speaker grilles are removable:
Make sure nothing comes into contact with the speaker
diaphragms when you remove the speaker grilles.
Placing the speaker system:
The left and right speakers have individual
shapes. For best performance, place the
speakers according to the illustration on the
right.
Bi-amp system:
Each speaker unit has a built-in subwoofer (low frequency range) which is driven
separately from the woofer and tweeter (mid-to-high frequency range). Two indepen-
dent amplifiers which have individual frequency characteristics are used.
By amplifying separately the two frequency bands, clearer sound is achieved.
01. Subwoofer
02. Bass Reflex Duct
03. Tweeter
04. Woofer
05. Speaker Wire for SUBWOOFER Terminals
06. Speaker Wire for MAIN Terminals
Left speaker Right speaker
3
4
2
1
3
4
1
2
5
6
5
6Power amplifier
Mid-to-high range
(200 Hz - 20 kHz)
Ultra-low range
(60 Hz - 200 Hz)
Pre-amplifier
Pre-amplifier
Power amplifier
L-ch
Tweeter
Woofer
Sub-
woofer
Left speaker
Right speaker
General Information
– Controls and Indicators –
*BA3100_P04_09 00.12.8, 4:27 PM9

10
,,,,
,,,,
,,,,,
,,,,,
System Connections
FM antenna
Right speaker Left speaker
AM loop antenna
AC outlet
(AC 120 V, 60 Hz)
VCR, DVD, etc.
Preparation for Use
– System Connections –
not supplied
Transport screw
*BA3100_P10_12 00.12.8, 4:27 PM10

11
Connections (continued)
■FM/AM loop antenna connection
Connect the FM/AM loop antenna to the ANTENNA jack.
■Connecting the AC power cord
After checking all the connections have been made correctly, plug the AC
power cord of this unit into the AC outlet. If you plug in the unit first, the unit
will enter the demonstration mode (see page 13).
Note:
Unplug the unit if it will not be used for a prolonged period of time.
■Speaker connection
Main terminals:
Connect the lower black wire to MAIN(-) terminal and the blue wire to the
MAIN(+) terminal.
Subwoofer terminals:
Connect the upper black wire to the SUBWOOFER(-) terminal and the red
wire to the SUBWOOFER(+) terminal.
Incorrect
,,
,,
Right speaker Left speaker
,
Black
Red
Blue
Caution:
●Never mistake the MAIN and the SUBWOOFER terminals.
The unit or the speakers may be damaged.
●Only the included speakers should be used with this product.
Do not use other speakers with this unit or use the supplied
speakers with other units.
●Do not mistake the right and the left channels.
The right speaker is the one on the right side when you face the
unit.
●Do not let the bare speaker wires touch each other.
●Do not stand or sit on the speakers. You may be injured.
Position the FM antenna wire and rotate theAM loop antenna for optimum reception.
Place theAM loop antenna on a shelf, or attach it to a stand or a wall.
Notes:
●Placing the antenna on the unit or near theAC power cord may cause noise pickup.
Place the antenna away from the unit for better reception.
●Do not connect the attached FM antenna to an external FM antenna. Otherwise,
trouble may occur.
Installing the AM loop antenna:
< Assembling >
< Attaching to the wall >
Screws
(not supplied)
Wall
Preparation for Use
– System Connections –
■Demonstration mode (See page 13.)
■Remove the transport screw
Before turning the power on, be sure to remove the transport screw on
the back of the unit using a flat-blade screwdriver or a coin.
Note:
This screw is required when transporting the unit again. Please keep it (see page 30).
*BA3100_P10_12 00.12.8, 4:27 PM11

12
■Battery installation
Use 2 “AA” size batteries (UM/SUM-3, R6, HP-7 or similar).
Batteries are not included.
1. Remove the battery cover.
2. Insert the batteries according to the direction indicated in the bat-
tery compartment.
When inserting or removing the batteries, push them toward the ëbattery termi-
nals.
3. Replace the cover.
Precautions for battery use:
●Replace all old batteries with new ones at the same time.
●Do not mix old and new batteries.
●Remove the batteries if the unit will not be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
●Do not use rechargeable batteries (nickel-cadmium battery, etc.).
●Installing the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:
●Replace the batteries if the operating distance is reduced or if the operation be-
comes erratic.
●Periodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
●Exposingthe sensor onthe unit tostrong light mayinterfere with operation.Change
the lighting or the direction of the unit.
●Keep the remote control away from moisture, heat, shock, and vibrations.
■Test of the remote control
Face the remote control directly to the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy the
music.
Remote Control
8" - 20'
(0.2 m - 6 m)
Remote sensor
Preparation for Use
– Remote Control –
*BA3100_P10_12 00.12.8, 4:27 PM12

13
Brightened
Dimmed
General Control
■Demonstration mode
The first time the unit is plugged, the unit will enter the demonstration mode. You will
see words scroll.
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode), press the
X-BASS/DEMObutton.
The demonstration mode will be canceled and the display will disappear.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the X-BASS/DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to select the extra bass
mode.
■Display brightness (2 levels)
You can switch the display brightness by pressing the DIMMER button.
Basic Operation
– General Control –
*BA3100_P13_15 00.12.8, 11:36 AM13

14
Sound Control
■Volume control
Main unit operation:
When the VOLUME control is turned clockwise, the volume will increase. When it is
turned counterclockwise, the volume will decrease.
Remote control operation:
Press the VOLUME „button to increase the volume and the VOLUME ˛button for
decreasing.
■Bass control
Whenthe power isfirst turned on,the unit will enter the extra bass modewhich empha-
sizes the bass frequencies, and “X-BASS” will appear.
To cancel the extra bass mode, press the X-BASS/DEMO (X-BASS) button.
■Equalizer
When the EQUALIZER (EQUALIZER MODE) button is pressed, the current mode set-
ting will be displayed. To change to a different mode, press the EQUALIZER (EQUAL-
IZER MODE) button repeatedly until the desired sound mode appears.
012 29 30 MAXIMUM
.....
X-BASS indicator
The sound is not modified.
Bass and treble are emphasized.
Bass and treble are slightly emphasized.
Treble is cut a little.
Treble is reduced a lot.
Vocals (midrange tones) are emphasized.
Basic Operation
– Sound Control –
*BA3100_P13_15 00.12.8, 11:36 AM14

15
To confirm the time display:
Press the CLOCK button.
The time display will appear for about 5 seconds.
Note:
The “CLOCK” or time will flash at the push of the CLOCK button when the AC power
supply is restored after a power failure or unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform “Setting the Clock” from the beginning.
If the time display is flashing, step 3 (for selecting the 12-hour or 24-hour display) will
be skipped.
To change the 12-hour or 24-hour display:
1. Clear all the programmed contents.
[Refer to step 3 under “If trouble occurs” on page 30 for details.]
2. Perform “Setting the Clock” from the beginning.
Setting the Clock
In this example, the clock is set for the 12-hour (AM 12:00) display.
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK button and within 5 seconds, press the
MEMORY/SET button.
3Press the TUNING/TIME (XX
XX
X or WW
WW
W) button to select the 12-hour or
24-hour display and then press the MEMORY/SET button.
4Press the TUNING/TIME (XX
XX
X or WW
WW
W) button to adjust the hour and
then press the MEMORY/SET button.
● Press the TUNING/TIME (X or W) button once to advance the time by 1
hour. Hold it down to advance continuously.
● When the 12-hour display is selected, “AM” will change automatically to “PM”.
5Press the TUNING/TIME (XX
XX
X or WW
WW
W) button to adjust the minutes
and then press the MEMORY/SET button.
● Press the TUNING/TIME (X or W) button once to advance the time by 1
minute. Hold it down to change the time in 5-minute intervals.
● The hour will not advance even if minutes advance from “59” to “00”.
●The clock begins counting from “0” seconds. (Seconds are not displayed.)
The time display will disappear after a few seconds.
“AM 12:00”→The 12-hourdisplay willappear. (AM 12:00- PM11:59)
“AM 0:00” →The 12-hour display will appear. (AM0:00 - PM 11:59)
“0:00” →The 24-hour display will appear. (0:00 - 23:59)
Basic Operation
– Setting the Clock –
Note that this can only be set when the unit is first installed or it has been reset.
( Refer to step 3 under “If trouble occurs” on page 30. )
*BA3100_P13_15 00.12.8, 11:36 AM15

16
CD Playback
– Listening to a CD (CDs) –
Listening to a CD (CDs)
■
To play discs in turn (from Disc 1 to Disc 6)
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the
ss
ss
s 1 77
77
7 button to open the disc tray 1.
4Place a CD on the disc tray 1, label side up.
Be sure to place 3" (8 cm) CD in the middle of the disc trays.
5Press the
ss
ss
s 1 77
77
7 button to close the disc tray 1.
The music schedule will display only the number of tracks on the disc.
If the CD contains more than 15 tracks, “ C ” will appear.
6You can place discs on the trays 2 - 6 by following steps 3 - 5.
Note:
The system will search CD trays until it finds a CD and will not search the rest of the
trays.
5” (12 cm) 3” (8 cm)
This system can play audio CD-R and CD-RW discs just as CD discs, but cannot
perform recording.
■Sound control (See page 14.)
Total number of tracks Total playing time
Means "disc inside".
Music schedule
*BA3100_P16_17 00.12.12, 4:41 PM16

17
7Press the 0/R0/R
0/R0/R
0/R (0 R0 R
0 R0 R
0 R) button to start playback.
●Playback will begin from track 1 on the DISC 1.
After that disc finishes playing, the next disc will automatically start playback.
●When the last track on the DISC 6 has finished playing, the CD player will
stop automatically.
●When there is no CD in one of the disc tray 1 - 6 positions, that position will
be skipped and the next CD will be played.
To interrupt playback:
Press the CD 6button on the remote control.
To resume playback from the same point, press the 0 R button.
To stop playback:
Press the ■(CD ■) button.
To exchange other CDs while playing a disc:
Press CD eject button for any stopped CD from s 1 7to s 6 7and exchange discs.
To remove the CDs:
While in the stop mode, press the CD eject button for any CD from s 1 7to s 6 7
to remove the disc.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
Caution:
●Do not place two CDs in one disc tray.
●Do not push the disc tray while it is moving.
●If the power fails while the tray is open, wait until the power is restored.
●If the disc tray is stopped forcibly, “ER-CD10” will appear in the display and the unit
will not function.
If this occurs, press the ON/STAND-BY button to enter the stand-by mode and then
turn the power on again.
●If TV or radio interference occurs during CD operation, move the unit away from the
TV or radio.
●If a disc is damaged, dirty, or loaded upside down, the disc will be skipped.
■To locate the desired portion
For audible fast forward:
Press and hold down the 2/ 4button during playback.
For audible fast reverse:
Press and hold down the 3/ 5button during playback.
Notes:
●Normal playback will resume when the 3/ 5 or 2/ 4button is released.
●You can locate the desired portion on a single disc only.
●When the end of the last track is reached during fast forward, “DISC END” will
appear on the display and CD operation will be paused. When the beginning of the
first track is reached during fast reverse, the disc will start playback automatically.
■To locate the beginning of a track
To move to the beginning of the next track:
Press the 2/ 4button for less than 0.5 seconds during playback.
●You can skip to any track by pressing the 2/
4buttonrepeatedlyuntil thedesired track num-
berappears.
To restart the track being played:
Press the 3/ 5 button for less than 0.5 seconds during playback.
●You can skip to any track by pressing the
3/ 5 buttonrepeatedly untilthe desired track
numberappears.
Note:
You can locate the beginning of a track on a single disc only.
Advanced CD playback (continued)
CD Playback
– Listening to a CD (CDs) –
*BA3100_P16_17 00.12.12, 4:41 PM17

18
■Repeat Play
All tracks on up to 6 discs, or a programmed sequence can be continuously repeated.
To repeat all tracks on up to 6 discs:
Press the 0/R (0 R) button twice.
By pressing the 0/R (0 R) button after one of the s1 - s6 buttons is pressed,
repeat play will be performed on that disc.
To repeat a desired track:
Perform steps 1 - 4 in the “Programmed Play” section and then press the 0/R (0 R)
button twice.
To cancel repeat play:
Press the 0/R (0 R) button again.
“R”will go out.
Repeat or Random Play
■Random Play
The tracks on the disc(s) can be played in random order automatically.
Press the RANDOM button on the remote control to begin random play.
By pressing the RANDOM button after one of the s1 - s6 buttons is pressed,
random play will be performed on that disc.
To cancel random play:
Press the 0R button.
Notes:
● If you press the 2 / 4 button during random play, you can move to the track selected
next by the random operation. On the other hand, the 3 / 5 button does not allow you
to move to the previous track. The beginning of the track being played will be located.
●In random play, the CD player will select and play tracks automatically.
(You cannot select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the ■(CD ■) button.
Otherwise, the disc(s) will play continuously.
Advanced CD Playback
– To specify a disc to Play / Repeat or Random Play –
You can play a disc by specifying the disc number.
Press one of the ss
ss
s1 - ss
ss
s6 buttons to play the desired disc.
Only the chosen disc will be played and stopped automatically.
Note:
Among discs 1 - 6, those with whitely illuminated CD indicators in the frame can be
played. However, if the button of the disc tray with no disc is pressed, playback will not
start and the indicator in the frame will go out.
To stop playback:
Press the ■(CD ■) button.
To specify a disc to Play
Selected disc number
*BA3100_P18_19 01.2.13, 2:17 PM18

19
Advanced CD Playback
– Programmed Play –
1While in the stop mode, press the
MEMORY/SET (MEMORY) button
to enter the programming save
mode.
2 Press one of the ss
ss
s1 - ss
ss
s6 buttons
to select the desired disc.
3Press the 33
33
3/ 55
55
5 or 22
22
2/ 44
44
4
button to select the desired track.
4 Press the MEMORY/SET (MEMORY)
button to save the track number.
5Repeat steps 2 - 4 for other tracks. Up to 32 tracks can be
programmed.
6Press the ■ (CD ■ ) button.
7Press the 0/R0/R
0/R0/R
0/R (0 R0 R
0 R0 R
0 R) button to start playback.
Note:
During program play, buttons s1 - s6 will not work.
Programmed Play
To clear the programmed selections:
Press the CLEAR button while the “MEMORY”
indicator is flashing.
Each time the button is pressed, one track will
be cleared, beginning with the last track pro-
grammed.
To cancel the programmed play mode:
While in the stop mode, press the CLEAR button. The “MEMORY” indicator will disap-
pear and all the programmed content will be cleared.
Adding tracks to the program:
If a program has been previously stored, the “MEMORY” indicator will be displayed.
Then follow steps 1 - 6 to add tracks.The new tracks will be stored after the last track
of the original program.
To check which tracks are programmed:
While the unit is stopped in the programmed play mode, press the 3 / 5 or 2 / 4
button.
Notes:
●Opening any tray of the programmed discs automatically cancels the programmed
sequence.
● Even if you press the ON/STAND-BY button to enter the stand-by mode or change
thefunction from CDto another function,the programmedselectionswill notbe cleared.
●During program operation, random play is not possible.
Up to 32 tracks can be programmed.
Selected
track number Playback order
Selected disc number
*BA3100_P18_19 01.2.13, 2:17 PM19

20
Listening to the Radio
1Press the ON/STAND-BY button to turn the power on.
2Press the TUNER (BAND) button repeatedly to select the desired
frequency band (FM or AM).
3Press the TUNING/TIME (XX
XX
Xor WW
WW
W) button to tune in to the desired
station.
Manual tuning:
Press the TUNING/TIME button as many times as required to tune in to the
desired station.
Auto tuning:
When the TUNING/TIME button is pressed for more than 0.5 seconds, scan-
ning will start automatically and the tuner will stop at the first receivable broad-
cast station.
Notes:
●When radio interference occurs, auto scan tuning may stop automatically at
that point.
● Auto scan tuning will skip weak signal stations.
●To stop the auto tuning, press the TUNING/TIME button again.
FM stereo mode indicator
FM stereo receiving indicator
Radio
– Listening to the Radio –
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the “ST” indicator.
●“j” will appear when an FM broadcast is in stereo.
●If the FM reception is weak, press the TUNER (BAND) button to extinguish the “ST”
indicator. The reception changes to monaural, and the sound becomes clearer.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
■Sound Control (See page 14.)
*BA3100_P20_21 00.12.8, 11:40 AM20
