Sharp CD-BK100W User manual

OPERATION MANUAL
MODE D’EMPLOI
MANUAL DE MANEJO
SHARP CORPORATION
MODEL
MODÈLE
MODELO
CD-BK100W
MINI COMPONENT SYSTEM
MINI-CHAÎNE
SISTEMA MINI
CD-BK100W Mini Component System consisting of CD-BK100W (main unit) and CP-
BK100 (speaker system).
Mini-chaîne CD-BK100W composée de CD-BK100W (appareil principal) et de CP-BK100
(enceintes acoustiques).
Sistema mini CD-BK100W que consta de CD-BK100W (aparato principal) y CP-BK100
(sistema de altavoces).
CD-BK100W CP-BK100CD-BK100W
Please refer to pages E-1 to E-25.
Se reporter aux pages F-1 à F-25.
Consulte las páginas S-1 a S-25.
ENGLISH
FRANÇAIS
ESPAÑOL

E-1 ENGLISH
CD-BK100W
ENGLISH
Important Instruction
- Introduction / Special Notes -
Introduction
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
Special Notes
Warning:
zWhen the ON/STAND-BY button is set at STAND-BY position, mains voltage is still
present inside the unit. When the ON/STAND-BY button is set at STAND-BY posi-
tion, the unit may be brought into operation by the timer mode or remote control.
zThis unit contains no user serviceable parts. Never remove covers unless qualified
to do so. This unit contains dangerous voltages, always remove mains plug from
the socket before any service operation and when not in use for a long period.
zTo prevent fire or shock hazard, do not expose this appliance to dripping or splash-
ing. No objects filled with liquids, such as vases, shall be placed on the apparatus.
Caution:
zThis product is classified as a CLASS 1 LASER PRODUCT.
zUse of controls, adjustments or performance of procedures other than those spec-
ified herein may result in hazardous radiation exposure.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
Note:
Audio-visual material may consist of copyrighted works which must not be recorded
without the authority of the owner of the copyright. Please refer to the relevant laws in
your country.
As the laser beam used in this compact disc player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel only.
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN.
DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH
OPTICAL INSTRUMENTS.
WARNUNG-UNSICHTBARE LASERSTRAHLUNG WENN GERÄT
GEÖFFNET. NICHT IN DIE STRAHLUNG SCHAUEN ODER
DIREKT MIT OPTISCHEN HILFSMITTELN BETRACHTEN.
ATTENTION-RAYON LASER INVISIBLE EN CAS D’OUVERTURE.
NE PAS REGARDER LE FAISCEAU DIRECTEMENT OU AVEC DES
INSTRUMENTS OPTIQUES.

E-2
ENGLISH
CD-BK100W
General Information
- Accessories / Contents -
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
„General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Controls and Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 6
„Preparation for Use
System Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 9
Remote Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
„Basic Operation
General Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Setting the Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
„CD Playback
Listening to a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 14
Repeat or Random Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Programmed Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
„Radio
Listening to the Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Listening to the Memorised Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
„Tape Playback
Listening to a Cassette Tape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
„Karaoke
Playing Karaoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
„Tape Recording
Recording to a Cassette Tape . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20, 21
„Advanced Features
Timer and Sleep Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22, 23
„References
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Remote control 1 "AA" size battery (UM/SUM-3, R6, HP- 7 or similar) 2
AM loop aerial 1 FM aerial 1
AC power lead 1

E-3 ENGLISH
CD-BK100W
General Information
- Precautions -
Precautions
„General
zPlease ensure that the equipment is positioned in a well-ventilated area and
ensure that there is at least 10 cm (4") of free space along the sides, top and back
of the unit.
zUse the unit on a firm, level surface free from vibration.
zKeep the unit away from direct sunlight, strong magnetic fields, excessive dust,
humidity and electronic/electrical equipment (home computers, facsimiles, etc.)
which generates electrical noise.
zDo not place anything on top of the unit.
zDo not expose the unit to moisture, to temperatures higher than 60°C (140°F) or to
extremely low temperatures.
zIf your system does not work properly, disconnect the AC power lead from the wall
socket. Plug the AC power lead back in, and then turn on your system.
zIn case of an electrical storm, unplug the unit for safety.
zHold the AC power plug by the head when removing it from the wall socket, as
pulling the lead can damage internal wires.
zDo not remove the outer cover, as this may result in electric shock. Refer
internal service to your local SHARP service facility.
zThe ventilation should not be impeded by covering the ventilation openings with
items, such as newspapers, tablecloths, curtains, etc.
zNo naked flame sources, such as lighted candles, should be placed on the appa-
ratus.
zAttention should be drawn to the environmental aspects of battery disposal.
zThis unit should only be used within the range of 5°C - 35°C (41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit. Using this product
with a higher voltage other than that which is specified is dangerous and may result in
a fire or other type of accident causing damage. SHARP will not be held responsible
for any damage resulting from use of this unit with a voltage other than that which is
specified.
„Volume control
The sound level at a given volume setting depends on speaker efficiency, location,
and various other factors. It is advisable to avoid exposure to high volume levels,
which occurs whilst turning the unit on with the volume control setting up high, or
whilst continually listening at high volumes.
„Condensation
„Care of compact discs
Compact discs are fairly resistant to damage, however mistracking can occur due to
an accumulation of dirt on the disc surface. Follow the guidelines below for maximum
enjoyment from your CD collection and player.
zDo not write on either side of the disc, particularly the non-label side from which
signals are read. Do not mark this surface.
zKeep your discs away from direct sunlight, heat, and excessive moisture.
zAlways hold the CDs by the edges. Fingerprints, dirt, or water on the CDs can
cause noise or mistracking. If a CD is dirty or does not play properly, clean it with a
soft, dry cloth, wiping straight out from the centre, along the radius.
10 cm (4")
10 cm (4") 10 cm (4")
10 cm (4")
Sudden temperature changes, storage or opera-
tion in an extremely humid environment may
cause condensation inside the cabinet (CD pick-
up, tape heads, etc.) or on the transmitter on the
remote control.
Condensation can cause the unit to malfunction.
If this happens, leave the power on with no disc
(or cassette) in the unit until normal playback is
possible (about 1 hour). Wipe off any condensa-
tion on the transmitter with a soft cloth before op-
erating the unit.
NO YES
Correct

E-4
ENGLISH
CD-BK100W
General Information
- Controls and Indicators -
Controls and Indicators
„Display
1.Disc Number Indicators
2.Timer Indicator
3.Tape 2 Record Indicator
4.Sleep Indicator
5.Extra Bass Indicator
6.CD or Tuner Memory Indicator
7.FM Stereo Mode Indicator
8.FM Stereo Receiving Indicator
9.CD Repeat Play Indicator
10.CD or Tape Play Indicator
11.CD Pause Indicator
„Front panel Reference page
1.Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
5.Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.Disc Skip Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7.Equaliser Mode Select/Extra Bass/Demo Mode Button . . . . . . . . . . . . 10
8.Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9.Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
10.Tuning and Time Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 16
11.CD Track Down or Fast Reverse, Tape 2 Rewind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17, 18
12.CD Track Up or Fast Forward, Tape 2 Fast Forward,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 17, 18
13.CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
14.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
15.Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
16.Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
17.Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22, 23
18.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
19.CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 18
20.CD Play or Repeat, Tape 1 Play or Tape 2 Play Button . . . . . . 13, 14, 18
21.Tuning and Time Down Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 16
22.Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11, 15, 17
23.Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
24.Microphone Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
25.Microphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
13 8
9
1
2
3
10
17
22
21
16
15141211
25
23 24
18
19
20
4
7
5
6
123 4 5 6 78
11109
Description of remote control (See page 6.)

E-5 ENGLISH
CD-BK100W
General Information
- Controls and Indicators -
Controls and Indicators (continued)
„Rear panel Reference page
1.AC Power Input Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
4.Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6.FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7.FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
„Speaker system
1.Full-Range Speaker
2.Bass Reflex Duct
3.Speaker Wire
„Placing the speaker system
There is no distinction between the right and the left speakers.
Note:
The speaker grill is not removable.
2
1
2
3
21 56743
Left speaker Right speaker

E-6
ENGLISH
CD-BK100W
General Information
- Controls and Indicators -
„Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2.Disc Number Select Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
3.CD Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.CD Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5.CD Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6.CD Track Down or Fast Reverse Button . . . . . . . . . . . . . . . . . . . . . . . . . . 13
7.CD Track Up or Fast Forward Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8.Tape 1 Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9.Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
10.Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
11.CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
12.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
13.Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
14.Disc Skip Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
15.CD Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
16.CD Play or Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
17.CD Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
18.Tuner Preset Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
19.Tape 1 or Tape 2 Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
20.Tape 2 Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
21.Tape 2 Rewind Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
22.Tape 2 Fast Forward Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
23.Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
24.Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
25.Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1
215
16
17
18
19
20
22
23
24
25
3
6
4
7
8
9
10
13
12
11
5
14
21
Buttons with " " mark in the illustration can be operated on the remote control
only.
Other buttons can be operated both on the main unit and the remote control.
Battery installation for remote control (See page 9.)

E-7 ENGLISH
CD-BK100W
Preparation for Use
- System Connections -
System Connections
„Aerial connection
Note:
Placing the aerial on the unit or near the AC power lead may cause noise pickup.
Place the aerial away from the unit for better reception.
Installing the AM loop aerial:
External FM aerial:
Use an external FM aerial if you require better reception. Consult your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM aerial wire.
To the wall socket
(See page 8.)
FM aerial
Left speaker
Right speaker
AM loop aerial
Supplied FM aerial:
Connect the FM aerial wire to the FM 75
OHMS terminal and position the FM aerial
wire in the direction where the strongest
signal can be received.
Supplied AM loop aerial:
Connect the AM loop aerial wire to the AM
LOOP socket. Position the AM loop aerial
for optimum reception. Place the AM loop
aerial on ashelf,etc.,or attachitto astand
or a wall with screws (not supplied).
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
External
FM aerial
75 ohm
coaxial cable

E-8
ENGLISH
CD-BK100W
Preparation for Use
- System Connections -
„Speaker connection
Connect the black wire to the minus (-) terminal, and the red wire to the plus (+) ter-
minal.
Caution:
„Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear panel before plug-
ging the unit into an AC socket. If necessary, adjust the selector to correspond to the
AC power voltage used in your area.
Turn the selector with a screwdriver until the appropriate voltage num-
ber appears in the window (110 V, 127 V, 220 V or 230 V - 240 V AC).
„Connecting the AC power lead
After making all connections, connect the AC power lead to the unit
and then into the wall socket. If you plug in the unit first, it will enter
the demonstration mode.
Notes:
zUnplug the AC power lead from the AC socket if the unit will not be in use for a pro-
longed period of time.
zNever use a power lead other than the one supplied. Use of a power lead
other than the one supplied may cause an electric shock or fire.
AC Plug Adaptor
In areas (or countries) where an AC socket as shown in illustration is used, con-
nect the unit using the AC plug adaptor supplied with the unit, as illustrated. The AC
plug adaptor is not included in areas where the AC wall socket and AC power plug
can be directly connected (see illustration ).
„Headphones
Right speaker Left speaker
zUse speakers with an impedance of 8 ohms or more, as lower impedance speakers
can damage the unit.
zDo not mistake the right and the left channels. The right
speaker is the one on the right side when you face the
unit.
zDo not let the bare speaker wires touch each other.
zDo not allow any objects to fall into or to be placed in the
bass reflex ducts.
zDo not stand or sit on the speakers. You may be injured. Incorrect
Black
Red
zBefore plugging in or unplugging the headphones, re-
duce the volume.
zBe sure your headphones have a 3.5 mm (1/8") diame-
ter plug and are between 16 ohms and 50 ohms imped-
ance. The recommended impedance is 32 ohms.
zPlugging in the headphones disconnects the speakers
automatically. Adjust the volume using the VOLUME
buttons.
1
2
Demonstration mode (See page 10.)

E-9 ENGLISH
CD-BK100W
Preparation for Use
- System Connections / Remote Control -
System Connections (continued)
„Setting the FM/AM Span Selector
The International Telecommunication Union (ITU) has established that member coun-
tries should maintain either a 100 kHz or a 50 kHz interval between broadcasting fre-
quencies of FM stations and 10 kHz or 9 kHz for AM station. The illustration shows
the 50/9 kHz zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
Before using the unit, set the SPAN SELECTOR switch (on the rear panel) to the
interval (span) of your area.
To change the tuning zone:
Caution:
This operation will erase all data stored in memory including clock, timer settings,
tuner preset, and CD programme.
Remote Control
„Battery installation
Precautions for battery use:
zReplace all old batteries with new ones at the same time.
zDo not mix old and new batteries.
zRemove the batteries if the unit will not be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
zDo not use rechargeable batteries (nickel-cadmium battery, etc.).
zInstalling the batteries incorrectly may cause the unit to malfunction.
Notes concerning use:
zReplace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).
zPeriodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
zExposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
zKeep the remote control away from moisture, heat, shock, and vibrations.
„Test of the remote control
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Set the SPAN SELECTOR switch (on the rear panel) as follows.
zFor 50 kHz FM interval (9 kHz in AM) 50/9
zFor 100 kHz FM interval (10 kHz in AM) 100/10
3 Whilst pressing down the / button and the EQUALIZER/X-BASS/DEMO button,
press the ON/STAND-BY button until "CLEAR AL" appears.
1 Remove the battery cover.
2 Insert the supplied batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the battery termi-
nals.
3 Replace the cover.
Face the remote control directly to the remote
sensor on the unit.
The remote control can be used within
the range shown:
Press the ON/STAND-BY button. Does the
power turn on? Now, you can enjoy the music.
Remote sensor
0.2 m - 6 m
(8" - 20')

E-10
ENGLISH
CD-BK100W
Basic Operation
- General Control -
General Control
„Demonstration mode
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode), press the
EQUALIZER/X-BASS/DEMO button. The demonstration mode will be cancelled and
the display will disappear.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the EQUALIZER/X-BASS/DEMO
button again.
Note:
When the power is on, the EQUALIZER/X-BASS/DEMO button can be used to select
the extra bass mode.
„To turn the power on
Press the ON/STAND-BY button to turn the power on.
To set the unit to stand-by mode:
Press the ON/STAND-BY button again.
„Volume control
Press the VOLUME button to increase the volume and the VOLUME button for
decreasing.
„Extra bass (X-BASS)/Pre-programmed
equaliser
(Main unit operation)
You can select the extra bass and pre-programmed equaliser modes with the same
button on the main unit.
Changing the mode:
When the EQUALIZER/X-BASS/DEMO button is pressed, the current mode setting
will be displayed. To change to a different mode, press the EQUALIZER/X-BASS/
DEMO button repeatedly until the desired sound mode appears.
(Remote control operation)
To enter or cancel the extra bass mode:
When the power is first turned on, the unit will enter the extra bass mode which
emphasises the bass frequencies, and "X-BASS" will appear. To cancel the extra
bass mode, press the X-BASS button.
Selecting a pre-programmed equaliser mode:
When the EQUALIZER MODE button is pressed, the current mode setting will be dis-
played. To change to a different mode, press the EQUALIZER MODE button repeat-
edly until the desired sound mode appears.
The first time the unit is plugged, the unit will enter
the demonstration mode. You will see words scroll.
012 29 30 MAXIMUM
.....
FLAT (X-BASS on)
ROCK (X-BASS on)
POPS (X-BASS on)
JAZZ (X-BASS on)
CLASSIC (X-BASS on)
VOCAL (X-BASS on)
VOCAL (X-BASS off)
CLASSIC (X-BASS off)
JAZZ (X-BASS off)
POPS (X-BASS off)
ROCK (X-BASS off)
FLAT (X-BASS off)
FLAT
ROCK
POPS
JAZZ
CLASSIC
VOCAL
The sound is not modified.
Bass and treble are emphasised.
Bass and treble are slightly emphasised.
Treble is cut a little.
Treble is reduced a lot.
Vocals (midrange tones) are emphasised.

E-11 ENGLISH
CD-BK100W
Basic Operation
- Setting the Clock -
Setting the Clock
In this example, the clock is set for the 24-hour (0:00) display.
Note:
The "CLOCK" or time will flash at the push of the CLOCK button when the AC power
supply is restored after a power failure or unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the Clock" from the beginning. If the time display is flashing, step 3
(for selecting the 24-hour or 12-hour display) will be skipped.
To change the 24-hour or 12-hour display:
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK button and within 5 seconds, press the MEMORY/
SET button.
3Press the TUNING/TIME ( or ) button to select 24-hour or 12-hour
display and then press the MEMORY/SET button.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"AM 0:00" The 12-hour display will appear.
(AM 0:00 - PM 11:59)
Note that this can only be set when the unit is first installed or it has been reset.
[Refer to "Clearing all the memory (reset)" on page 24 for details.]
4Press the TUNING/TIME ( or ) button to adjust the hour and then
press the MEMORY/SET button.
zPress the TUNING/TIME ( or ) button once to advance the time by 1 hour.
Hold it down to advance continuously.
zWhen the 12-hour display is selected, "AM" will change automatically to "PM".
5Press the TUNING/TIME ( or ) button to adjust the minutes and then
press the MEMORY/SET button.
zPress the TUNING/TIME ( or ) button once to advance the time by 1
minute. Hold it down to change the time in 5-minute intervals.
zThe hour will not advance even if minutes advance from "59" to "00".
zThe clock begins counting from "0" seconds. (Seconds are not displayed.)
The time display will disappear after a few seconds.
To confirm the time display:
Press the CLOCK button.
The time display will appear for about 5 seconds.
1 Clear all the programmed contents. [Refer to "Clearing all the memory (reset)" on
page 24 for details.]
2 Perform "Setting the Clock" from the beginning.

E-12
ENGLISH
CD-BK100W
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs)
Continued to the next page
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the OPEN/CLOSE button to open the disc tray.
4Place the CD(s) on the disc tray, label side up.
When loading a third disc, press the DISC SKIP button to turn the
disc tray, then place the CD in the open position.
zCDs can be placed on any open position on the disc tray.
zBe sure to place 8 cm (3") CD(s) in the middle of the disc positions.
5Press the OPEN/CLOSE button to close the disc tray.
Total number of tracks on
the CD Total playing time of the CD
6To select the CD you want to listen to first, press one of 1 - 3 but-
tons on the remote control.
12 cm (5") 8 cm (3")
General Control (See page 10.)

E-13 ENGLISH
CD-BK100W
CD Playback
- Listening to a CD (CDs) -
Listening to a CD (CDs) (continued)
To interrupt playback:
Press the button on the remote control.
To resume playback from the same point, press the button.
To stop playback:
Press the (CD ) button.
To remove the CDs:
Whilst in the stop mode, press the OPEN/CLOSE button.
The disc tray will open. Remove the two discs. Then, press the DISC SKIP button to
rotate the disc tray and remove the remaining disc.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
Caution:
zDo not place two CDs in one disc tray.
zDo not push the disc tray whilst it is moving.
zDo not turn the disc tray by hand. This may cause malfunctions.
zIf the power fails whilst the tray is open, wait until the power is restored.
zIf the disc tray is stopped forcibly, "ERR 0203" will appear in the display and the
unit will not function. If this occurs, press the ON/STAND-BY button to enter the
power stand-by mode and then turn the power on again.
zIf TV or radio interference occurs during CD operation, move the unit away from
the TV or radio.
zIf a disc is damaged, dirty, or loaded upside down, the disc will be skipped.
„To locate the beginning of a track
Note:
You can locate the beginning of a track on a single disc only.
„To locate the desired portion
Notes:
zNormal playback will resume when the or button is released.
zYou can locate the desired portion on a single disc only.
zWhen the end of the last track is reached during fast forward, "END" will appear on
the display and CD operation will be paused. When the beginning of the first track
is reached during fast reverse, the unit will enter the playback mode.
7Press the / button to start playback.
zPlayback will begin from track 1 on the disc you have selected to play. After
that disc finishes playing, the next disc will automatically start playback.
zWhen the last track on the third disc has finished playing, the CD player will
stop automatically.
zWhen there is no CD in one of the disc 1 - 3 positions, that position will be
skipped and the next CD will be played.
To move to the beginning of the next track:
Press the button for less than 0.5 seconds during playback.
zYou can skip to any track by pressing the
button repeatedly until the desired
track number appears.
To restart the track being played:
Press the button for less than 0.5 seconds during playback.
zYou can skip to any track by pressing the
button repeatedly until the desired
track number appears.
For audible fast forward:
Press and hold down the button during playback.
For audible fast reverse:
Press and hold down the button during playback.

E-14
ENGLISH
CD-BK100W
CD Playback
- Listening to a CD (CDs) / Repeat or Random Play -
„Starting playback with a desired track
You can play a disc starting with the desired track.
To stop playback:
Press the (CD ) button.
Notes:
zWhen the DISC SKIP button is pressed during playback, the next disc will begin
automatically.
zWhen one of the 1 - 3 buttons on the remote control is pressed during play-
back, the selected disc will begin automatically.
Repeat or Random Play
„Repeat play
All tracks on up to 3 discs, or a programmed sequence can be continuously repeated.
To repeat a desired track:
Perform steps 1 - 4 in the "Programmed Play" section and then press the / button
twice.
To cancel repeat play:
Press the / button again.
" " will go out.
„Random play
The tracks on the disc(s) can be played in random order automatically.
To cancel random play:
Press the button.
Notes:
zIf you press the button during random play, you can move to the track
selected next by the random operation. On the other hand, the button does
not allow you to move to the previous track. The beginning of the track being
played will be located.
zIn random play, the CD player will select and play tracks automatically. (You cannot
select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the (CD ) button. Other-
wise, the disc(s) will play continuously.
1Whilst in the stop mode, press one of the 1 - 3 buttons on the re-
mote control or DISC SKIP button to select the desired disc.
Selected disc number
2Press the or button to select the desired track.
Selected track number
3Press the / button to start playback.
Playback of the selected track is started. When the end of last track of the disc
selected is reached, the next disc will be automatically started.
To repeat all tracks on up to 3 discs:
Press the / button twice.
Press the RANDOM button on the remote control to begin random
play.
Programmed Play (See page 15.)

E-15 ENGLISH
CD-BK100W
CD Playback
- Programmed Play -
Programmed Play
By specifying discs from 1 to 3, and tracks from 1 to 99, you can choose up to 32
selections for playback in the order you like.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indicator will be dis-
played. Then follow steps 1 - 3 to add tracks. The new tracks will be stored after the
last track of the original programme.
Notes:
zOpening the disc tray automatically cancels the programmed sequence.
zEven if you press the ON/STAND-BY button to enter the stand-by mode or change
the function from CD to another, the programmed selections will not be cleared.
zDuring programme operation, random play is not possible.
1Whilst in the stop mode, press
one of the 1 - 3 buttons on the
remote control to select the de-
sired disc.
Selected disc number
2Press the or button to
select the desired track.
Selected track number
3Press the MEMORY/SET (MEMO-
RY) button to save the track num-
ber.
Playback order
When the track is memorised, "MEMORY" will appear.
4Repeat steps 1 - 3 for other tracks. Up to 32 tracks can be programmed.
If you make a mistake, the programmed tracks can be cleared by pressing the
CLEAR button.
5Press the / button to start playback.
To clear the programmed selections:
Press the CLEAR button on the remote control
whilst the "MEMORY" indicator is lit.
Each time the button is pressed, one track will
be cleared, beginning with the last track pro-
grammed. When all the tracks are cleared,
"MEMORY" will disappear.

E-16
ENGLISH
CD-BK100W
Radio
- Listening to the Radio -
Listening to the Radio
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST" indicator.
z" " will appear when an FM broadcast is in stereo.
zIf the FM reception is weak, press the TUNER (BAND) button to extinguish the
"ST" indicator. The reception changes to monaural, and the sound becomes
clearer.
After use:
Press the ON/STAND-BY button to enter the power stand-by mode.
1Press the ON/STAND-BY button to turn the power on.
2Press the TUNER (BAND) button repeatedly to select the desired
frequency band (FM or AM).
3Press the TUNING/TIME ( or ) button to tune in to the desired
station.
Manual tuning:
Press the TUNING/TIME button as many times as required to tune in to the de-
sired station.
Auto tuning:
When the TUNING/TIME button is pressed for more than 0.5 seconds, scanning
will start automatically andthe tuner willstop at the first receivable broadcast sta-
tion.
Notes:
zWhen radio interference occurs, auto scan tuning may stop automatically at
that point.
zAuto scan tuning will skip weak signal stations.
zTo stop the auto tuning, press the TUNING/TIME button again.
FM stereo mode indicator
FM stereo receiving indicator
General Control (See page 10.)

E-17 ENGLISH
CD-BK100W
Radio
- Listening to the Memorised Station -
Listening to the Memorised Station
„Memorising a station
You can store 40 AM and FM stations in memory and recall them at the push of a but-
ton. (Preset tuning)
Note:
The backup function protects the memorised stations for a few hours should there be
a power failure or the AC power lead disconnection.
„To recall a memorised station
„To scan the preset stations
The stations saved in memory can be scanned automatically. (Preset memory scan)
„To erase entire preset memory
1Perform the steps 1 - 3 in "Listening to the Radio" on page 16.
2Press the MEMORY/SET button to enter the preset tuning saving
mode.
3Within 30 seconds, press the PRESET or PRESET button to select
the preset channel number.
Store the stations in memory, in order, starting with preset channel 1.
4Within 30 seconds, press the MEMORY/SET button to store that sta-
tion in memory.
If the "MEMORY" and preset number indicators go out before the station is
memorised, repeat the operation from step 2.
5Repeat steps 1 - 4 to set other stations, or to change a preset station.
When a new station is stored in memory, the station previously memorised will
be erased.
Press the PRESET or PRESET button for less than 0.5 seconds
to select the desired station.
Preset channel Frequency and frequency band
1Press the PRESET or PRESET button for more than 0.5 seconds.
The preset number will flash and the programmed stations will be tuned in se-
quentially, for 5 seconds each.
2Press the PRESET or PRESET button again when the desired sta-
tion is located.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the TUNER (BAND) button and the EQUALIZER/X-BASS/
DEMO button, press the ON/STAND-BY button until "TUNER CL" appears.
Listening to the Radio (See page 16.)

E-18
ENGLISH
CD-BK100W
Tape Playback
- Listening to a Cassette Tape -
Listening to a Cassette Tape
Before playback: Playback is possible in TAPE 1 compartment as well as in TAPE 2.
To stop playback:
Press the (TAPE ) button.
Caution:
zTo remove the cassette, press the (TAPE ) button, and then open the compart-
ment.
zBefore changing from one tape operation to another, press the (TAPE ) button.
zIf a power failure occurs during tape operation, the tape head will remain engaged
with the tape and the cassette door will not open. Wait until power is restored.
zFor playback, use normal or low-noise tapes for the best sound.
(Metal or CrO tapes are not recommended.)
zDo not use C-120 tapes or poor-quality tapes, as they may cause mal-
functions.
zBefore loading a tape into the cassette compartment, tighten the slack
with a pen or a pencil.
1Press the ON/STAND-BY button to turn the power on.
2Press the TAPE (1 2) button to select TAPE 1 or TAPE 2.
3Open the cassette door by pushing the
area marked " PUSH EJECT".
4Load a cassette into the TAPE 1 or TAPE
2 cassette compartment.
5Press the / button to start playback.
When playback is performed using the remote control, press the TAPE 1 or
TAPE 2 button.
Fast forward/rewind: (TAPE 2 only)
1 Press the (TAPE ) button, then press the TAPE (1 2) button to select TAPE
2.
2 To advance the tape, press the button. To rewind it, press the button.
General Control (See page 10.)

E-19 ENGLISH
CD-BK100W
Karaoke
- Playing Karaoke -
Playing Karaoke
Note:
When excessively loud signals enter the microphone, your voice may be distorted
depending on the devices connected. If this happens, lower the microphone volume.
If squealing occurs:
zReduce the microphone volume.
zChange the direction that the microphone faces.
zReduce the volume of the main unit.
zMove the microphone away from the speaker.
Caution:
zWhen not using the microphone, remove the microphone plug from the MIC
socket.
zWhen connecting or disconnecting the microphone plug, set the MIC LEVEL con-
trol to MIN.
1To protect the speakers from shock noise and to avoid disturbing
noises, set the MIC LEVEL control to MIN.
2Connect the microphone to the MIC socket.
zUse a microphone with a 6.3 mm (1/4") plug, an impedance of 600 ohms.
zIf a microphone whose sensitivity is too high is used, howling may be gener-
ated.
zUnidirectional microphone is more appropriate for vocal use.
zUse a standard plug adaptor when using a microphone with a 3.5 mm (1/8")
diameter plug.
3Press the ON/STAND-BY button to turn the power on.
4Press the CD or TAPE (1 2) button to select the audio source.
If you wish to record, start recording in the TAPE 2 compartment.
5Adjust the volume of the audio source using the VOLUME buttons.
6Rotate the MIC LEVEL control towards MAX to increase the micro-
phone volume and towards MIN to decrease it.
7Press the / button to start playback.
