Sharp CD-C605H User manual

CD-C605H
– 1 –
CD-C605H
• In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
SERVICE MANUAL
SHARP CORPORATION
No. S5927CDC605H/
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CONTENTS Page
SAFETY PRECAUTION FOR SERVICE MANUAL ............................................................................................................2
IMPORTANT SERVICE NOTES (FOR U.K. ONLY ) ......................................................................................................... 2
SPECIFICATIONS ............................................................................................................................................................. 3
NAMES OF PARTS ........................................................................................................................................................... 4
OPERATION MANUAL ...................................................................................................................................................... 6
DISASSEMBLY.................................................................................................................................................................. 7
REMOVING AND REINSTALLING THE MAIN PARTS..................................................................................................... 9
ADJUSTMENT ................................................................................................................................................................. 10
NOTES ON SCHEMATIC DIAGRAM .............................................................................................................................. 12
TYPE OF TRANSISTOR AND LED ................................................................................................................................. 12
BLOCK DIAGRAM ........................................................................................................................................................... 13
SCHEMATIC DIAGRAM / WIRING SIDE OF P.W.BOARD..............................................................................................16
WAVEFORMS OF CD CIRCUIT...................................................................................................................................... 31
TROUBLESHOOTING ..................................................................................................................................................... 32
FUNCTION TABLE OF IC................................................................................................................................................ 36
FL SEGMENT ...................................................................................................................................................................41
PARTS GUIDE/EXPLODED VIEW
PACKING METHOD(FOR U.K. ONLY )
• Note for users in U.K.
Recording and playback of any material may require consent
which SHARP is unable to give. Please refer particularly to the
provisions of Copyright Act 1956, the Dramatic and Musical
Prefomers Protection Act 1956, the Preformers Protection Acts
1963 and 1972 and to any subsequent statutory enactments and
orders.
1
CD-C605H mini component system consisting of
CD-C605H(Mainunit),CP-C605H(Speakersystem).

CD-C605H
– 2 –
Precaution to be taken when replacing and servicing the
Laser Pickup.
The AEL (Accessible Emission Level) of Laser Power Output
forthismodelisspecifiedtobelowerthanClassIRequirements.
However, the following precautions must be observed during
servicing to protect your eyes against exposure to the Laser
beam.
(1) When the cabinet has been removed, the power is turned
on without a compact disc, and the Pickup is on a position
outerthanthelead-inposition,theLaserwilllightforseveral
seconds to detect a disc. Do not look into the Pickup Lens.
(2) The Laser Power Output of the Pickup inside the unit and
replacementservicepartshavealreadybeenadjustedprior
to shipping.
(3) No adjustment to the Laser Power should be attempted
when replacing or servicing the Pickup.
(4) Under no circumstances look directly into the Pickup Lens
at any time.
(5)CAUTION-Useofcontrolsoradjustments,or performance
of procedures other than those specified herein may result
in hazardous radiation exposure.
IMPORTANT SERVICE NOTES (FOR U.K. ONLY)
Beforereturning theunit tothe customer after completion of a
repairoradjustmentitisnecessaryforthefollowingwithstand
voltage test to be applied to ensure the unit is safe for the
customer to use.
Setting of Withstanding Voltage Tester and set.
Set name set value
Withstanding Voltage Tester
Test voltage 4,240 VPEAK
3,000 VRMS
Set time 6 secs
Set current(Cutoff current) 4 mA
Unit
Judgment
OK: The “GOOD” lamp lights.
NG: The “NG” lamp lights and the buzzor sounds.
SHORT-CIRCUIT
AC POWER
SUPPLY CORD
CONNECT THE PROBE
TO GND TERMINAL
OF PHONO TERMINAL
PROBE
AC
UNIT
WITHSTANDING
VOLTAGE TESTER
+
-
OUT
OF CHASSIS
SCREW
SAFETY PRECAUTION FOR SERVICE MANUAL
(For U.K.) (Except For U.K.)
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
CAUTION-INVISIBLE LASER RADIATION WHEN OPEN. DO NOT STARE INTO
BEAM OR VIEW DIRECTLY WITH OPTICAL INSTRUMENTS.
VARNING-OSYNLIG LASERSTRALNING NAR DENNA DEL AR OPPNAD. STIRRA
EJ IN I STRALEN OCH BETRAKTA EJ STRALEN MED OPTISKA INSTRUMENT.
ADVERSEL-USYNLIG LASERSTRALING VED ABNING. SE IKKE IND I
STRALEN-HELLER IKKE MED OPTISKE INSTRUMENTER.
VARO! AVATTAESSA OLET ALTTIINA NAKYMATON LASERSATEILYLLE.
ALA TUIJOTA SATEESEEN ALAKA KATSO SITA OPTISEN LAITTEEN LAPI.
VARNING-OSYNLIG LASERSTRALNING NAR DENNA DEL AR OPPNAD.
STIRRA EJ IN I STRALEN OCH BETRAKTA EJ STRALEN GENOM OPTISKT
INSTRUMENT.
ADVERSEL-USYNLIG LASERSTRALING NAR DEKSEL APNES. STIRR IKKE
INN I STRALEN ELLER SE DIREKTE MED OPTISKE INSTRUMENTER.
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN
TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄN TURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYMÄTTÖMÄLLE LASERSÄTEILYLLE.
VARNING - OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT
ÄN I DENNA BRUKSANVISNING SPECIFICERAS. KAN
ANVÄNDAREN UTSÄTTAS FÖR OSYNLIG
LASERSTRÅLNING, SOM ÖVERSKRIDER GRÄNSEN FÖR
LASERKLASS 1.
CHASSIS
SCREW
LASER KLASSE 1
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT
CLASS 1 LASER PRODUCT
APPAREIL À LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1

CD-C605H
– 3 –
Specifications for this model are subject to change without prior
notice.
CD-C605H
CP-C605H
SPECIFICATIONS
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
●General
Power source: AC 230 V, 50 Hz
Power consumption: 40 W
Dimensions: Width; 270 mm (10-5/8")
Height; 300 mm (11-13/16")
Depth; 353 mm (13-7/8")
Weight: 5.1 kg (11.2 lbs)
●Amplifier section
Output power: PMPO; 66 W
MPO; 33W (16.5 W + 16.5 W)
(DIN 45 324)
RMS; 20 W (10 W + 10 W)
(DIN 45 324)
RMS; 16 W (8 W + 8 W)
(DIN 45 500)
Output terminals: Speakers; 8 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
●Tuner section
Frequency range: FM; 87.5-108 MHz
AM; 522-1,620 kHz
●Cassette deck section
Frequency response: 50 - 14,000 Hz (Normal tape)
Signal/noise ratio: 55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Wow and flutter: 0.20 % (DIN 45 511)
●Compact disc player section
Type: 3-discmulti-play compactdisc player
Signal readout: Non-contact,3-beam semiconductor
laser pickup
D/A converter: 1-bit D/A converter
Frequency response: 20 - 20,000 Hz
Dynamic range: 90 dB (1 kHz)
●Speaker section
Type: 10cm (4") full-range speaker
Maximum input
power: 20 W
Impedance: 8 ohms
Dimensions: Width; 180 mm (7-1/8")
Height; 300 mm (11-13/16")
Depth; 204 mm (8-1/10")
Weight: 2.0 kg (4.4 lbs)/each

CD-C605H
– 4 –
NAMES OF PARTS
CD-C605H
4. (CD) Disc Number Indicator
5. (TAPE 2) Record Indicator
6. Sleep Indicator
7. Extra Bass Indicator
8. Function/CDTrack/CD Counter/Frequency/
Preset Channel/Volume/Timer/SleepTime
Indicator
9. (CD/TUNER) Memory Indicator
10. FM Stereo Mode Indicator
11. FM Stereo Indicator
12. (CD) Repeat Indicator
13. (CD) Play Indicator
14. (CD) Pause Indicator
15. Timer Indicators
16. (TAPE 2) Record Pause Button
17. (CD)Track Down/Review Button
(TUNER) Preset Down Button
(TAPE 2) Rewind Button
18. (CD)Track Up/Cue Button
(TUNER) Preset Up Button
(TAPE 2) Fast Foward Button
19. Timer/Sleep Button
20. Clock Button
21. On/Stand-by Button
22. Function Selector Buttons
23. Extra Bass/Demo Button
24. Volume Up/Down Buttons
25. Memory/Set Button
26. (CD/TAPE) Stop Button
27. (CD) Play/Repeat Button
(TAPE) Play Button
28. Tuning andTime Up/Down Buttons
29. Headphone Socket
■Front panel
1. DiscTray
2. Disc Skip Button
3. Open/Close Button
30. (TAPE 1) Cassette Compartment
31. (TAPE 2) Cassette Compartment
123
4567
8
1314
91011
12
15
123
X-BASS
kHz
MHz
SLEEP
STMEMORY
REC
19
21
25
16
23
24
22
20
27
17
26
18
28 29
30 31

CD-C605H
– 5 –
CD-C605H
■Rear panel
1. SpeakerTerminals
2. AC Power Input Socket
3. FM 75 Ohms Aerial Socket
4. AM Loop Aerial Input Socket
■Remote control
1. Remote Control Transmitter LED
●CD control section
2. Disc Number Select Buttons
3. Memory Button
4. Pause Button
5. Clear Button
6. Track Down/Review Button
7. Track Up/Cue Button
8. Disc Skip Button
9. Play/Repeat Button
10. Stop Button
11. Random Button
●Tuner control section
12. Preset Up/Down Buttons
●Tape control section
13. (TAPE 1) Play Button
14. (TAPE 1/2) Stop Button
15. (TAPE 2) Play Button
16. (TAPE 2) Rewind Button
17. (TAPE 2) Fast Forward Button
18. (TAPE 2) Record Pause Button
●Common section
19. Function Selector Buttons
20. On/Stand-by Button
21. Extra Bass Button
22. Volume Up/Down Buttons
■Speaker
1. Full-Range Speaker
2. Bass Reflex Duct
3. SpeakerWire
2
13
4
3
1
2
1
28
10
9
11
12
22
3
4
5
6
713
18
19
20
21
14 15 16 17
1
CP-C605H

CD-C605H
– 6 –
OPERATION MANUAL
TUNING/ TIME ( )
MEMORY/ SET
CLOCK
ON/ STAND-BY
SETTING THE CLOCK
1Press the ON/STAND-BY button to enter the stand-by mode. 2Press the CLOCK button. 3Within 5 seconds, press the MEMORY/SET button.
4Press the TUNING/TIME ( or ) button to select the time
display mode.
"0:00" → The 24-hour display will appear. (0:00 - 23:59) "AM 12:00" →The 12-hour display will appear. (AM or PM 12:00 - 11:59) "AM 0:00" →The 12-hour display will appear. (AM or PM 0:00 - 11:59)
●Note that this can only be set when the unit is first installed
or it has been reset.
5Press the MEMORY/SET button. 6Press the TUNING/TIME ( or ) button to adjust the hour.
●Press the TUNING/TIME ( or ) button once to advance
the time by 1 hour. Hold it down to advance continuously.
●When the 12-hour display is selected, "AM" will change auto-
matically to "PM".
7Press the MEMORY/SET button. 8Press the TUNING/TIME ( or ) button to adjust the
minutes.
●Press the TUNING/TIME ( or ) button once to advance
the time by 1 minute. Hold it down to change the time in 5 minute intervals.
●The hour setting will not advance even if minutes advance from
"59" to "00".
9Press the MEMORY/SET button. ●The clock starts operating from "0" seconds.
(Seconds are not displayed.)
To see the time display:
Press the CLOCK button. ●The time display will appear for about 5 seconds. Note: ●The clock display will flash on and off at the push of the CLOCK
button when the AC power supply is restored after a power failure occurs or after the AC power lead is disconnected. If this happens, follow the procedure below to change the clock time.
To change the clock time:
①Press the CLOCK button. ②Within 5 seconds, press the MEMORY/SET button. ③Perform steps 6 - 9 above. To change the time display mode: ①Perform steps 1 - 2 in the section "RESETTING THE MICRO-
COMPUTER".
②Perform steps 1 - 9 above.
(Main unit operation)
In this example, the clock is set for the 24-hour (0:00) system.
AM 0:00AM 12:000:00
2 3
4
7
6 5
8 9
2
1,2
RESETTING THE MICROCOMPUTER
Reset the microcomputer under the following conditions: ●To erase all of the stored memory contents (clock and timer
settings, and tuner and CD presets).
●If the display is not correct. ●If the operation is not correct.
1
Press the ON/STAND-BY button to enter the stand-by mode.
2
Whilst pressing down the button and the button, hold down the ON/STAND-BY button for at least 1 second.
Caution: ●The operation explained above will erase all data stored in
memory including clock and timer settings, and tuner and CD presets.
TRANSPORTING THE UNIT
Before you move this product to a new location, proceed as follows: 1
Press the ON/STAND-BY button to turn the power on.
2
Press the CD button.
3
Press the OPEN/CLOSE button to open the disc tray.
●Remove all CDs inserted in the unit.
4
Press the OPEN/CLOSE button to close the disc tray.
●Make sure that "NO DISC" is displayed.
5
Press the ON/STAND-BY button to enter the stand-by mode, and then unplug the AC power lead from theAC socket.
1,5
2
3,4
15
15
PREPARATION FOR USE
■Remote control
Notes concerning use: ●Replace the batteries if the operating distance is reduced or if
the operation becomes erratic.
●Periodically clean the transmitter LED on the remote control
and the sensor on the main unit with a soft cloth.
●Exposing the sensor on the main unit to strong light may in-
terfere with operation. Change the lighting or the direction of the unit.
●Keep the remote control away from moisture, excessive heat,
shock, and vibrations.
0.2 m - 6 m (8" - 20')

CD-C605H
– 7 –
DISASSEMBLY
Caution on Disassembly
Follow the below-mentioned notes when disassembling
the unit and reassembling it, to keep it safe and ensure
excellent performance:
1. Take cassette tape and compact disc out of the unit.
2. Be sure to remove the power supply plug from the wall
outlet before starting to disassemble the unit.
3.Take off nylon bands or wire holders where theyneed to
beremovedwhendisassemblingtheunit.Afterservicing
theunit, be sure to rearrange the leads where theywere
before disassembling.
4. Take sufficient care on static electricity of integrated
circuits and other circuits when servicing.
Figure 7-2
Figure 7-1
CD-C605H
Figure 7-3
CD-C605H
1 Top Cabinet 1. Screw .....................(A1) x4 7-1
2 Side Panel 1. Screw .....................(B1) x6 7-1
(Left/Right) 2. Hook .......................(B2) x2
3 CD Play Unit/ 1. Turn on the power supply, 7-2
CD Player Unit open the disc tray, take out
the CD tray cover, and close.
(Note 1)
2. Hook ...................... (C1) x5
3. Socket ................... (C2) x2
4 Back Board 1. Screw .................... (D1) x5 7-2
5 Main PWB 1. Screw .....................(E1) x3 8-1
2. Socket ....................(E2) x5
3. Flat wire..................(E3) x3
6 Tuner PWB 1. Screw ..................... (F1) x2 8-1
7 Front Panel 1. Screw .................... (G1) x2 8-1
8 Headphones 1. Screw .................... (H1) x1 8-2
PWB 2. Guide ......................(H2) x1
9 Display PWB/ 1. Screw ..................... (J1) x8 8-2
Switch PWB 2. Hook ....................... (J2) x7
3. Socket .................... (J3) x1
10 Tape Mechanism 1. Open the cassette holder. 8-2
2. Screw .....................(K1) x6
11 Turntable 1. Screw ..................... (L1) x1 8-3
2. Guide ...................... (L2) x1
12 Disc Tray 1. Screw .................... (M1) x2 8-3
2. Guide ..................... (M2) x2
13 CD Servo PWB 1. Screw .................... (N1) x1 8-4
(Note 2) 2. Socket ................... (N2) x4
14 CD Changer 1. Screw .....................(P1) x4 8-5
Mechanism
15 CD Mechanism 1. Screw ..................... (Q1) x1 8-5
REMOVAL PROCEDURE
STEP FIGURE
Note 1:
How to open the change manually.
1. First, turn fully the lock lever in the arrow direction through
the hole on the loading chassis bottom in this state.
After that, push forward the CD player base. (Fig. 7-3)
Note 2:
1. After disconnecting the optical pickup connector, wrap the
front end of connector in conductive aluminum foil to
prevent damage to the optical pickup by static electricity.
Top Cabinet
Front Panel
(A1)x2
ø3 x12mm
(A1)x2
ø3x12mm
(B2)x1
(B2)x1
Side Panel
(Left)
Side Panel
(Right)
(B1)x1
ø3x10mm
(B1)x1
ø3x10mm
(B1)x4
ø3x12mm
Back Board
Back Board
CD Tray Cover
CD Player
Unit
(C1) x3
(D1) x5
ø3x8mm
(C1) x1
(C2) x2
1
1
2
Pull
(C1) x1
CD Servo
PWB
Disc Tray
Front Panel
LOCK
LEVER

CD-C605H
– 8 –
Figure 8-3
Be careful when installing the CD changer mechanism.
InstalltheCDchangermechanismontheCDplayerbaseafter
the shift lever has been set in the highest position.
Figure 8-5
Figure 8-2
Figure 8-1
Figure 8-4
Main PWB
Main
PWB
Tuner PWB
Tuner PWB
(E2)x1
(E3)x2
Front Panel
(E2)x3
(E3)x1
(E2)x1
(E1)x3
ø3x8mm
(F1)x2
ø3x8mm
(G1)x2
ø3x8mm
Front Panel
(J2)x7
Display PWB
Switch
PWB
Open
Cassette
Holder
Tape Mechanism
(K1)x6
ø3x10mm
(J3)x1
(J1)x2
ø3x10mm
(J1)x6
ø3x10mm
(H1)x1
ø3x10mm (H2)x1
Headphones
PWB Tape Mechanism
PWB
Support PWB
(M1) x1
ø3x10mm
(M1) x1
ø3x10mm
(L1) x1
ø3x10mm
Turntable
Disc Tray
(L2) x1
(M2) x1
(M2) x1
CD Player Unit
Washer
(N1) x1
ø3x10mm
(N2) x2
(N2) x2 CD Player Unit
CD Servo PWB
(P1) x4
ø3x12mm
(Q1) x1
ø2.6x10mm
CD Changer
Mechanism
CD Mechanism
Shift Lever
CD Player Base

CD-C605H
– 9 –
How to remove the turntable up/down/loading
motor (See Fig. 9-2)
1. Remove the screws (A1) x 2 pcs., to remove the turntable
up/down/loading motor.
How to remove the pickup (See Fig. 9-3)
1. Remove the screws (B1) x 2 pcs., to remove the shaft (B2)
x 1 pc.
2. Remove the stop washer (B3) x 1 pc., to remove the gear
(B4) x 1 pc.
3. Remove the pickup.
Figure 9-3
REMOVING AND REINSTALLING THE MAIN PARTS
CD MECHANISM SECTION
Perform steps 1, 2, 3, and 11 ~15 of the disassembly method
to remove the CD mechanism.
Figure 9-2
Note:
After disconnecting the optical pickup connector, wrap the
front end of connector in conductive aluminum foil to prevent
damage to the optical pickup by static electricity.
Figure 9-1
CP-C605H
STEP REMOVAL PROCEDURE FIGURE
1 Speaker 1. Net Frame............... (A1) x1 9-1
2. Duct Panel .............. (A2) x1
3. Screw......................(A3) x4
(A1) x2
ø2.6x5mm
Turntable/Up/
Loading/Down Motor
Motor
PWB
(B1) x2
ø2.6x6mm
Shaft
(B2) x1
Stop Washer
(B3)x1
Gear
(B4) x1
CD Mechanism
Pickup
Speaker Box
(A1)x1
Net Frame (A3)x4
ø4x12mm
(A2)x1
Duct Panle

CD-C605H
– 10 –
MECHANISM SECTION
•Driving Force Check
Torque Meter Specified Value
Play: TW-2412 Tape 1: Over 80 g
Tape 2: Over 80 g
•Torque Check
Torque Meter
Tape 2
Play: TW-2111 30 to 60 g. cm 30 to 60 g.cm
Fast forward: TW-2231 — 60 to 120 g.cm
Rewind: TW-2231 — 60 to 120 g.cm
Specified
Value
Adjusting
Point Instrument
Connection
Test Tape
Normal MTT-111 Variable 3,000 ±Speaker
speed resistor in 30 Hz terminal
motor (Load
(MM1) resistance:
8 ohms)
ADJUSTMENT
Specified Value
Tape 1
•Tape Speed
Figure 10-1 ADJUSTMENT POINTS
TAPE MECHANISM
MM 1
Motor
Variable resistor in motor
Figure 10-2 ADJUSTMENT POINTS
TUNER SECTION
fL: Low-range frequency
fH: High-renge frequency
• AM IF/RF
Signal generator: 400 Hz, 30%, AM modulated
Test Stage Frequency Frequency
Display Setting/
Adjusting
Parts
Instrument
Connection
IF 450 kHz 1,620 kHz T351 *1
AM Band — 522 kHz (fL): T306 *2
Coverage 1.1 ±0.1 V
AM 990 kHz 990 kHz (fL): T302 *1
Tracking
*1. Input: Antenna, Output: TP302
*2. Input: Antenna, Output: TP301
• FM
Notes:
1: Description of the "FM IF Adjustment" is not carried on this
Manual. It is because the IF coil in the FM front end section
has been best adjusted in the factory so that its further
adjustment is not needed at the field. When replacing the
FM front end assembly, no adjustment is needed either.
2: The parts in the FM front end section are prepared in a
complete unit, so you can't obtain each part individually
Adjusting
Parts Instrument Connection
Frequency
Display
Frequency
• FM Mute Level
Signal generator: 1 kHz, 40 kHz dev., FM modulated
98.00 MHz 98.00 MHz VR351 Input: Antenna
(25 dBµV) Output: Speaker
Terminal
TP302
R357
T351 VR351
FM MUTE
LEVEL R336 TP301
FE301
T306
T302
SO301
FM ANTENNA
TERMINAL
CNP301
AM LOOP
ANTENNA
TERMINAL
TUNER PWB
CNP303
AM IF
AM BAND
COVERAGE fL
AM
TRACKING fL

CD-C605H
– 11 –
TEST MODE
Since this CD system incorporates the following automatic adjustment function, when the pickup is replaced, it is not necessary
to readjust it.
Since this CD unit does not need adjustment, the combination of PWB and laser pickup unit is not restricted.
CD SECTION Figure 11-1
Note:
Only in STOP state it is possible to slide the pickup with the ( ) or ( ) key.
VOL. --- Last memory
BAL. --- CENTER
R.GEQ. --- FLAT
X-BAS --- OFF
Canceling method - POWER OFF
• Setting the test mode
Any one of test mode can be set by pressing several keys as follows.
<REC. PAUSE> + <DISC. SKIP> + <POWER> TEST: CD operation test
• TEST mode
Function — CD test mode
Setting of TEST mode
Indication of CD TST mode (Fig. 11-1)
OPEN/CLOSE operation is manual operation.
The pickup can be moved by using the ( ) or ( ) key.
<MEMORY>
LASER ON
<PLAY> key input Press <STOP> key. Stop
TOC. IL is performed, and the ordinary PLAY is performed.
If the following key is pressed during PLAY, it is possible
to specify directly any Track No.
<Disc Number 1> key: Track 4
<Disc Number 2> key: Track 9
<Disc Number 3> key: Track 15
<MEMORY>
Tracking on the spot.
SERVO OFF PLAY
<MEMORY>
Tracking on the spot.
SERVO ON PLAY STOP
IL is not performed.
<STOP>
1 2 3
Figure 11-2
Figure 11-3
Figure 11-4
• Automatic adjustment item
1. Focus offset (Fig. 11-2)
2. Tracking offset (Fig. 11-3)
3. E/F balance (tracking error balance) (Fig. 11-4)
4. RF level AGC function (HF level: constant)
5. RF level automatic follow-up of the tracking gain
This automatic adjustment is performed each time a disc is
changed. Therefore, each disc is played back using the
optimal settings.
2
0.1s
0.50 V
IC1 20 FE
0.1s
0.50 V
IC1 7 TE
1
FOCUS
OFF-SET
ADJUST
TRACKING
OFF-SET
ADJUST
2
1
10ms
0.50 V
IC1 20 FE
10ms
0.50 V
IC1 7 TE
Enlarged
View
TRACKING
OFF-SET
ADJUST
2
1
TO
TE
200 ms
1V/diV
IC 1 15
200 ms
1V/diV
IC 1 7
TRACKING/
ERROR
BARANCE
ADJUST
CD ERROR CODE DESCRIPTION
When a malfunction occurs during CD operation, an error
code will be displayed to identify the function in CD operation
which failed.
Error State Code
0001 Cannot detect pickup-IN SW
0101 Tray close operation error
0105 Tray close operation error
0201 Tray open operation error
0203 Tray open operation error
0304 Disc skip operation error
0305 Disc skip operation error
0307 Disc skip operation error

CD-C605H
– 12 –
•The indicated voltage in each section is the one measured
by Digital Multimeter between such a section and the chas-
sis with no signal given.
1. In the tuner section,
( ) indicates AM
< > indicates FM stereo
2. In the main section, a tape is being played back.
3. In the deck section, a tape is being played back.
( ) indicates the record state.
4. In the power section, a tape is being played back.
5. In the CD section, the CD is stopped.
•Parts marked with “ ” ( ) are important for
maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and
performance of the set.
NOTES ON SCHEMATIC DIAGRAM
•Resistor:
To differentiate the units of resistors, such symbol as K and
M are used: the symbol K means 1000 ohm and the symbol
M means 1000 kohm and the resistor without any symbol is
ohm-type resistor. Besides, the one with “Fusible” is a fuse
type.
•Capacitor:
To indicate the unit of capacitor, a symbol P is used: this
symbol P means micro-micro-farad and the unit of the
capacitor without such a symbol is microfarad. As to
electrolyticcapacitor,theexpression“capacitance/withstand
voltage” is used.
(CH), (TH), (RH), (UJ): Temperature compensation
(ML): Mylar type
(P.P.): Polypropylene type
•Schematic diagram and Wiring Side of P.W.Board for this
model are subject to change for improvement without prior
notice.
Figure 12 TYPES OF TRANSISTOR AND LED
SW1 OPEN/CLOSE ON—OFF
SW2 MECHA UP ON—OFF
SW3 DISC NUMBER ON—OFF
SW4 PICKUP IN ON—OFF
SW701 ON/STAND-BY ON—OFF
SW702 CLOCK ON—OFF
SW703 TIMER/SLEEP ON—OFF
SW707 DISK SKIP ON—OFF
SW708 OPEN/CLOSE ON—OFF
SW709 REWIND ON—OFF
SW710 REC PAUSE ON—OFF
SW711 MEMORY/SET ON—OFF
SW712 STOP ON—OFF
REF. NO DESCRIPTION POSITION POSITION
SW713 TUNER(BAND) ON—OFF
SW714 TAPE ON—OFF
SW715 CD ON—OFF
SW716 FAST FORWARD ON—OFF
SW717 TUNING UP ON—OFF
SW718 TUNING DOWN ON—OFF
SW719 PLAY ON—OFF
SW720 VOLUME DOWN ON—OFF
SW721 VOLUME UP ON—OFF
SW722 X-BASS/DEMO ON—OFF
SWM3 FOOI PROOF ON—OFF
SWM4 F.A.S. ON—OFF
SWM5 CAM ON—OFF
REF. NO DESCRIPTION
SVC348S
2SC2389 SE
2SC380 O
KRC102 M
KRC104 M
KRC107 M
KTA1266 GR
KTA1271 Y
KTA1273 Y
KTC3199 GR
KTC3203 Y
FRONT
VIEW
E C B
(S)(G)(D)
(1) (2) (3)
2SA1318
FRONT
VIEW
B C E
(D)(G)(S)
(3) (2) (1)
1 2 3 SLI342UCJ1
VIEW
FRONT

CD-C605H
– 13 –
Figure 13 BLOCK DIAGRAM (1/3)
27
12341
67
18244020
45
15
23
16 26 27
2
25
20
3839284142 37 36
PU-IN SW
X1
16.93MHz
XIN
LD0
FIN2 JP–
CV+
SLC
SL1
FIN1 E F
TO
FD
SPO
SP
SLD
SL–
SL+
DRF
CL
DAT
CE
VCC1
5
+5V
SW4
PICKUP IN
FOCUS COIL
TRACKING COIL
M1
SPINDLE
MOTOR
M
M
M2
SLED
MOTOR
PICKUP UNIT
9
IC2
LC78622N
SERVO/SIGNAL
CONTROL
+B1
IC3
M63001FP
FOCUS/
TRACKING/
SPIN/SLIED
DRIVER
IC1
LA9241M
SERVO AMP.
/RES. /CQCK. COIN SQOUT. RWC. WRQ
~
~
~
CL, DAT, CE
Q51
SL+. SL–. DRF
987654321
GND (D) MECHA UP GND (D) DISK NO. OPEN CLOSE GND (D) M– M+
987654321
CNP10
M
+5V
+B1
62
64
45
36
23
43
37 36 38
40 24 25
10
123456
10
26
58
53
1012 20
32 40 43 44
53
52
51
54
31
30
29
23
27
16
15
41
44
Q1
Q52
+4.3V
+7V
VOLTAGE
REGULATOR
TO MAIN PWB
(TO IC401)
XOUT
EFMO EFMIN CLV+ JP–
CONT2 CONT1
LCHO
LVDD
LVSS
RCHO
ISET
VDD
LVDD
RVDD
XVDD
SW1 OPEN CLOSE
SW2 MECHA UP SW3 DISC NUMBER
M3 TURNTABLE UP/DOWN LOADING MOTOR
SOLM2 SOLENOID
TO DISPLAY
PWB
CNS10
+B5
CNP11
RVSS
39
CONT4
SWITCHING
REGULATOR
LASER DRIVER
6
VVDD
CONT3
17
–
+
SOL– SOL+
8
29
35
14
~~
21
22
R-CH
L-CH

CD-C605H
– 14 –
Figure 14 BLOCK DIAGRAM (2/3)
X351 456kHz
FM IF CF351
+B4
+B4
+B4
+B4
VOLTAGE
REGURATER
+5V
FM +B
VT
T306
T302
L341
CF302
DO
CE CL
DI
CF301
FE301
FM FRONT END
Q360
RL
Q354
Q353
Q361
SWITCHING
IF IN
IC303
LA1832
FM IF DET./FM MPX./AF IF
IF OUT
SD
MONO/ST
AM RF IN
FM AFC
AM OSC IN
AM
OSC
OUT
VR351
FM MUTE LEVEL
REG INOUT VCC
FM IF IN
12 3 4589
17 19
15
14
12
11
10
67 13
21
22
23
24
FM IF
AMP
Q301
FM IF
FM
X352
4.5MHz
STEREO
IC302
LC72131
PLL CONTROLLER
INAM
FM IN
FMOSC
T351
AM IF
GND
OSC
F OUT
FM IF
BALUN
AM OSC
VOLTAGE
REGULATOR
AM ANT
AM RF
AM LOOP
ANTENNA
CF352
AM IF
TUNER MUTE
MUTING
SO301
FM ANTENNA
TERMINAL
2
8
67 3 4
1
531
4
3 6
521
17
1213
10
1116
15
2220
7
1
Q371
+B4
1 3
31
1
2
1
2
PLL DATA
BUFFER
SWITCHING
BIAS OSC
1
24
2
23
3
4
4
21
5
20
6 7
17
8
9
16
10
14
12
13
18
H/N
T1/T2
R-CH
L-CH
L-CH
R-CH
P.B
REC
TAPE 2
TAPE 1
L NF
L(T1)
R(T1)
L(T2)
R(T2)
R NF
L
R
POP REDUCE
L REC
R REC
L
R REC
P.B.
REC
NC
NOR/
CRO2 T1/T2
RIPPLE L NF
R NF
PLAYBACK
HEAD
RECORD/
PLAYBACK HEAD
SWITCHING
Q501~Q509
AC BIAS
IC501
AN7345K
PLAYBACK AND RECORD
/PLAYBACK AMP.
PB
ERASE
HEAD
+B4
1
3
4
CNS401
FROM CD PWB
CNP11
SW
M
FOOL PRO
O
SW
M
F.A
.
SOL
M
SOLENO
SW
M
CA
4
17
3
18
2
19
1
20
11 10
9
IC401
M62439SP
AUDIO PROCESSOR L
R
L
R
L
R
L
R
TUNER
TAPE
CD
T1/T2
REC
SWITCHING
Q512
Q513
13
8
15 19
Q514
Q515
Q516
2
L-CH
R-CH

CD-C605H
– 15 –
Figure 15 BLOCK DIAGRAM (3/3)
Q704
52
IC903
KIA7812P
2
1
3
IC902
KIA7806P
2
1
3
IC901
AN78L05
3
1
2
SO901
SPEAKER
TERMINALS
FRONT
SPEAKER
F902
T1.6A L 250V
F901
T2.5A L 250V
F903
T500mA L
250V
18
Q631
Q632
L901
LINE
FILTER
MUTING
SWM3
FOOL PROOF
SWM4
F.A.S
SOLM1
SOLENOID
SWM5
CAM 1 2 3 14 17 18 21 30 31 3233
IC701
IX0300AW
SYSTEM MICROCOMPUTER
L
R
XL701
4.19MHz
+B5
KEY
SW901~SW703
SW707~SW722
+B5
M
TO CD
SECTION
CNP12
MM1
TAPE MOTOR
JK601
HEADPHONES
T.F
PT901
POWER
TRANSFORMER
RL901
RELAY
AC POWER
SUPPLY CORD
AC 230V 50Hz
PT902
BACK UP
TRANSFORMER
IC904
AN78L05
Q902
+B6
+B7 UNSWITCH
T1/T2
REC
D910,D911
D914,D915
D912,D913
D916,D917
2 3
1
+B7
RX701
Q703
7
3
L-OUT
IC601
LA4282
POWER AMP.
+B
R-OUT
3
Q401
Q402
+B1
+B4
+B5
+12V
+7V CD+B
+12V(MOTOR)
+5V
VOLTAGE
REGULATOR
VOLTAGE
REGULATOR
CONSTANT
VOLTAGE
REGULATOR
CONSTANT
VOLTAGE
REGULATOR
Q701
Q702 ~
2
5
12
10
17353416 9 12
58
2321
24
2725
47
46
43
42
44
54
51
49
61 71 7 56
PHM1
RUN PALS
SENSOR
D921~D924
~
~
~
41
36
~
8661 ~
34
LED701
1319 30
11
SO901
AC SOCKET
3
1
2
RESET
REMOTE
SENSOR
57
FL701
FL DISPLAY
+5V
L-CH
R-CH
53
,,,,
~~~
,
Q901
VOLTAGE
REGULATOR
RL901(RELAY)DRIVER
FL SEGMENT DRIVER
SOLENOID
DRIVER
MOTOR
DRIVER

CD-C605H
– 16 –
Figure 16 SCHEMATIC DIAGRAM (1/10)
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 12.
R791
1K
C775
2.2/50
C774 100/10
R792
33
R775 1K
R800
10
(1/2W)
X
L
4.
1
C703
1/50
R711 1K R704 1K R705 1K R706 1K
FL701
FL DISPLAY
R713 1K
C705
47/16
Q702
KTA1271 Y
R740
10K
R712 2.2K
R714
2.2K
R716 1K
R709 1K
R702 1K
R726 1K R728 1K
R707 1K
R703 1K
R739
10K Q701
KTA1273 Y
MOTOR DRIVER
C709 0.022
R729 1K
R721 1K
R723
1K
R725
1K
R727 1K
R719
1K
Q703
KRC107 M
FL SEGMENT
DRIVER
R708 1K R722 1K
C704
1/50
R741
100K
R710 1K R718 1K R717 1K R724 1K R715 1K
IC701
IX0300AW
SYSTEM MICROCOMPUTER
80
79
80
78
77
76
75
74
73
72
71
70
69
68
67
66
65
65
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
NC
NC NC
NC
NC
S MUTE
VLOAD
CD O/
C
CD PU
CD SL
CD SL
VDD
AVREF
AVDD
AVSS
RESET
CD COIN
CD PCCL
CD WRQ
CD RWC
CLK
VDD
T0 T1 T2 T3 T4 T5 T6
T7
T8
S0
S1
S2
S3
S4
S5
S6
S7
S8
S9
S11
S12 S13 S14 S15
9G 4G 3G 2G 1G 8G
7G
6G
5G
P17
P18
P19
P12
P1
P6
P7
P8
P9
P10
P11
P14
P20P13
P16 P15
F F
P15 P16 P13 P20 P14 P11 P10 P9 P8 P7 P6 5G
P5 P4
6G 7G
P3 P2
8G P1 P12 P19 P18 P17 1G 2G 3G 4G 9G F F
CD SQOUT
TIMER LED
CD CQCK
CD DSP RES
CD FRF
A/D T2 RUN
CD DI
S
CD U/D SW REC/PLAY T_BIAS
CE
T1FAS AC RLY CONT
DI
DO
T T1T2
CAM SW POWER TAMUTE T.MOTOR T.SOL REMOCON SYSTEM STOP FPA IC DIST0
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
1312
11
10
9
8
7
6
5
4321
64 63 62 61 60 59 58 57 56 55 54 53 52 51 50 49 48 47 46 45 44 43 42 41
24
23
22
21
20
19
18
17
16
15
14
1312
11
10
9
8
7
6
5
4321
28
27
26
25 A/D KEYIN 1
A/D KEYIN 2
A/D KEYIN 3
A/D DIST
R735
R736
R737
R738
R753
R745
10K
R746
10K
R747
10K
R749 10K
R
7
1
0
R748 10K
R772
3.3(1/2W)
C772
0.022
R743
1.2K
C706 0.022
C707 220/6.3
C773
0.0047
8 7 6 5 4 3 2 1
MOTOR
1
D7
D
S
D707
DS1SS133
S_MUTE
M_GND
UN_SW_+5V
SW_+5V
M_+12V D_GND
VF1
VF2 -VP
F
1
TO MAIN PWB
P21 12-F
+B
+B
+B
SOLENOIDO
CAM SW
T1FAS
FPA
+B
M_GND
A/D T2 RUN
BI702
+B
+B
1
2
3
4
5
6
7
8
9
10
11
1
2
3
4
5
6
7
8
9
10
11 1212
MOTOR
FOOL PROOF
T1 RUNPALS
MECHA STOP
SOLENOID
T2 RUNPALS
+B
GND
CNS702
CNPM1
PHM1
CNPM2
SWM3
FOOL PROOF
4
3
1
+
MM1
TAPE MOTOR
FWM1
M
FWM2
PHOTE
INTERRUPTER
SWM5
CAM
SWM4
F.A.S
SOLM1
SOLENOID
TAPE MECHANISM
PWB-E
10
1
2
2 MOTOR
+B
T2 RUNPALS
FOOL PROOF
T1 RUNPALS
MECHA STOP
SOLENOID
1
2
D701
DS1SS133
S10
SPN_P
R701 1K
R742
10K
SPN_P
4.8V23-25V
-25V
-24.8V
-24.8V
-22V
-24.8V -24.8V -24.8V -24.8V
4.7V 4.7V
0V 0V 0V 0V 0V 1.6V 1.9V 4.6V 4.6V
3.9V 0.5V 4.6V
4.6V
1.6V
4.2V
1.8V
4.6V
2.1V
5V
-24.8V
-24.8V
-24.8V
-27.8V
-27.8V
-27.8V
-27.8V
-18.2V
-18.2V
-21.2V
-21.2V
-28V
-28V
-28V
-18V
-18V
-21.3V
-21.3V
-21.2V
-21.2V
4.9V
0V
0V
0V
0V
0V
4.7V
4.7V
4.7V
4.7V 4.7V
12V
5V
5.2V
4.9V
1.6V
2.4V
0V 4.6V
5V
12V
12V
12V
12V
0V
SOLENOID
DRIVER

CD-C605H
– 17 –
Figure 17 SCHEMATIC DIAGRAM (2/10)
78 9 10 11 12
R760
3.3K
C770
0.1/50 R782
47K
XL701
4.19MHz C701
15P (CH)
R752
10K
R726 1K R728 1K
C709 0.022
R729 1K
R727 1K
R785
4.7K
C702
18P(CH)
R730 1K
R734 1K
C715
47/25
R786
100
C714 0.022
RX701
REMOTE
SENSOR
D704
DS1SS133
IC702
KIA7042P
RESET
3 1
D705
DS1SS133
C713
0.022
R783 100K
D703
DS1SS133
C712
3.3/50
Q704
KRC102 M
R731 1K
R732 1K
R733 1K
40
39
38
37
36
35
34
33
32
31
30
29
28
27
26
25
CD O/C SW
CD PUIN SW
CD SLM –
CD SLM +
AVREF
AVDD
CD
DSP
RES
CD FRF
A/D T2 RUN
CD DISC NO SW
CD U/D SW REC/PLAY
T
_
BIAS
3
42 41
24
23
2
R778
8.2K
R762
1.2K
R761
820
R776
3.3K
R773
2.2K
R765
1.2K R767 1.5K
R763
820 R770 1.8K
R764
820 R777 3.3K
R771
1.8K
R766
1.2K R774 2.2K
R768
1.5K
FW705
C710
0.01 D702
DS1SS133
R735 1K
R736 1K
R737 1K
R738 1K
R753 10K
R754 10K
R756 10K R757 10K R755
3.3K
LED701
SLI342UCJ1
TIMER
L701
100µH
R749 10K
R750
10K
R751
10K
R748 10K
C772
0.022
9 8 7 6 5 4 3 2 1
10
11
1213
14
15
9 8 7 6 5 4 3 2 1
10
11
1213
14
15
PCCL
U/D SW
DISC NO SW
O/C SW
PUIN SW
SLM–
SLM+
D_GND
FRF
DSP RES
CQCK
SQOUT
WRQ
COIN
RWC
2
1 2 3
R758
1.8K
+B
+B
SW707
DISC
SKIP
SW708
OPEN/
CLOSE
R780
3.9K
1
3
1
3
SW701 SW702 SW703
CLOCK
ON/
STANDBY TIMER/
SLEEP
SW709 SW710 SW711 SW712 SW713 SW714 SW715
CD
TUNER
(BAND)
MEMORY
/SET
STOP
RECORD
/PAUSE
SW716 SW717 SW718 SW719 SW720 SW721 SW722
TUNING
UP TUNING
DOWN
PLAY
VOLUME
UP
FAST
FORWARD
VOLUME
DOWN
+B
+B
+B
+B
+B
+B
1
2 3
BI701
CNS701
CNP12 TO CD SERVO PWB
P25 7-H
AC_RLY_CONT POWER T_T1T2 T_BIAS REC/PLAY
DI
CE DO
CLK
1
9
FW701
D708
DS1SS133
D707
DS1SS133
M_GND
UN_SW_+5V
SW_+5V
M_+12V D_GND
VF1
FW703
TO MAIN PWB
P21 12-E
P
WB
F
+B
SWITCH PWB-A4
DISPLAY PWB-A1
TAPE
REWIND
X-BASS
/DEMO
10
IC702
RESET
1.6V
4.2V
4.9V
4.9V
4.9V
4.9V
1.2V
4.7V
1.8V
4.6V
2.1V 0V
0V
0V
2.3V
5V
5V
5V
0V
4.6V
5V
4.6V
0V
0V
0V
4.8V 4.8V
R793 270K

CD-C605H
– 18 –
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 12.
Figure 18 SCHEMATIC DIAGRAM (3/10)
L65
0.29
µ
R606
1K
R608
120
C611
0.1
(ML)
R611
4.7
C613
0.1
(ML)
C911
3300/25
C612
0.1
(ML)
C614
0.1
C601
10/16
R632
820
R631
22K
Q632
KRC102 M
SWITCHING
Q631
KRC102 M
SWITCHING
C602
10/16
R602
560
R604
33K
R603
33K
C604
470P
C603 470P
C635
10/50
R612
4.7
R610
270
(1/2W)
R609
270(1/2W)
C633
220P
C634
0.022
(ML)
C632
47/25
C631
0.022
(ML)
IC601
LA4282
POWER AMP.
C610
470/25
C607
0.082(ML)
C608
100/25
C605
100/25
R633
56K
R607
1K
R605
120
C901 47/16
C907
100/16
C908
0.1
(ML)
C910
0.1
(ML)
C906
0.022(ML)
R901
10K
IC903
KIA7812P
3 1
C902
0.022(ML)
D902
DS1SS133
IC901
AN78L05
2 1
C904
0.047(ML)
D901
DS1SS133
C913
1000/25
D905
1N4004S D
9
1N4
0
C
1
D903
DS1SS133
D904
DS1SS133
IC902
KIA7806P
3 1
C903
47/25 C905
0.047(ML)
C912
2200/50
12
11
10
9
8
7
6
5
4321
2
3
2
C609
470/25
D919
DS1
S
Q902
KRC107 M
RL901(RELAY) DRIVER
C909
0.1 (ML)
F903
T500mA L 250V
12
13
14
15
16
10
18
26
19
20
22
21
24
23
25
18
17
CD+B
A_+12V
CD GND
A_GND
M_GND
0V GND_POWER 0V +VCC 0V GND_POWER 0V MUTE 0V OUT_A 0V OUT_B 0V –IN_B 0V +IN_B 0V GND_PRE 0V RIPPLE_FILTER 0V +IN_A 0V –IN_A
R_IN
L_IN
SW_+5V
UN_SW_+5V
M_+12V
–15V
VF1
–VP
VF2
D_GND
POWER
AC_RLY_CONT
1 2
3
1 2
3
IC901
CONSTANT VOLTAGE
REGULATOR
+B
+B
+B
+B
+B
IC903
VOLTAGE REGULATOR
3
1 2
+B
-B
+B
+B
+B
+B
+B
+B
-B
VOLTAGE REGULATOR
+B
TO MAIN SECTION
P20 1-D
C9
2
100
0
D918
DS1SS133
MAIN PWB-A2 (1/2)
FM SIGNAL
R601
560
TO MAIN SECTION
P21 12-G
C606
0.082(ML)
4.3V
0V
4.3V 0V 0V
0V
18.4V
0V
0.7V
C931
220P
23.2V
1.3V
7.3V
23.2V
0V
12V
12V
C637
68P
6.2V
1.2V

CD-C605H
– 19 –
Figure 19 SCHEMATIC DIAGRAM (4/10)
78 9 10 11 12
L902
2.2mH
L652
0.29µH
C636
0.001
L651
0.29µH
D631 DS1SS133
D632 DS1SS133
F901
T2.5A L 250V
F902
T1.6A L 250V
-28.2V
-28.2V
-40.8V
CNS901,902
with Transformer
LINE FILTER
R902
220(1/2W)
D905
1
N4004S D906
1N4004S
C914
100/25
D907
1N4004S
D908 1N4004S
D909
1N4004S
C919
100/50
C920
100/50
Q901
KTA1266 GR
VOLTAGE REGULATOR
R906
3.3K
R905
100
ZD901
DZ6.2BSA
C918
47/50
ZD902
DZ300BSB
C917
47/50
C916
47/50
R903
12K
R904
220(1/2W)
C915
100/35
C923
0.047(ML)
D914
RL203F
D913
1N4004S
D910
RL203F
C922
0.1(ML)
D912
1N4004S
D917
1N4004S
D915
RL203F
D916
1N4004S
D911
RL203F
C924
0.047(ML)
C921
0.1(ML)
C912
2
00/50 1
2
3
4
5
6
CNP902
SO601
SPEAKER
TERMINALS
R613
330
R614
330
C642
0.001
C641
0.001
JK601
HEADPHONES
D919
DS1SS133
R
IVER
1
5
1
5
L-CH
GND
GND
R-CH
+B
+
B
D925
1SS133
RL901 RELAY
CNP901
PT901
POWER
TRANSFORMER
CNS901
1
2
3
4
6
5
CNS902
1
2
1
2
SO901
AC SOCKET
NC
T.F
AC POWER
SUPPLY CORD
AC230V 50Hz
C929
0.0047
C927
470/25
PT902
C928
0.047
(ML)
D921
1N4004S D923
1N4004S
D924
1N4004S
D922
1N4004S
D920
DS1SS133
IC904
AN78L05
CONSTANT
VOLTAGE REGULATOR
1
2
3
C926
10/16
C925
1000/6.3
1
8
1SS133
R908
220
BACK UP TRANSFORMER
HEADPHONES PWB-A3
FW601
5.5V
C661
0.001
C662
0.001
C660
0.022
C659
0.022
C654
0.022
C658
0.022
R654
3.3
(1/4W)
R652
3.3
(1/4W)
C652
0.047
C656
0.047
C653
0.022
C657
0.022
R653
3.3
(1/4W)
R651
3.3
(1/4W)
C651
0.047
C655
0.047
L901
23.7V
0.6V
When Servicing pay,
attention as the area
enclosed by this
( ) is directly
connected with AC main
voltage.

CD-C605H
– 20 –
Figure 20 SCHEMATIC DIAGRAM (5/10)
A
B
C
D
E
F
G
H
123456
• NOTES ON SCHEMATIC DIAGRAM can be found on page 12.
C453
470P
R451
390
R452
390
C414
0.022(ML)
R561
22K
IC401
M62439SP
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
D
IC501
AN7345K
C515
47/25
L502
2.2µH
C514
47/25 L501
2.2µH
R408
4.7K
R515
1K
C507
0.001
Q507
KTC3199 GR
R512
47K
R513
4.7K
R510
4.7K
R543
82K
R501
10K
R545
R538
22K
R542
560
R518
1K C512
330P
C523
0.022
C525
3.3/50
C527
0.001
R508
10K
Q508
KRC104 M
Q509
KRC104 M
SWITCHING
C531
0
R502
10K
R540
6.8K
C521
1/50
R527 3.9K
C519
560P
C517
0.033
R537 22K
R536
68K
R541 560
C526 0.001
R539 6.8K
C
5
22
/
R533
27K
R522
56 C518
560P R531
5.6K
R514
1K
C510
330P
C508
100/16
R516
150
ZD401
DZ2.4BSB
C422
10/50
R420 1.5K
C416 0.22
C415 0.033(M
L
R422 1.5K
R421 1.5K
R423
15K
R419
10K
C417 4.7P
R418
5.6K
C413
10/50
C418
4
C412
0.22
C411(ML)
0.033
R416 1.5K
R415 1.5K R414
1.5K
C407
4.7/50
C406
4.7/50
C423
C410
0.22
R413
2.2K
R410
3.3K
C404
10/50
R412
330
Q401
KTC3199 GR
MUTING
C401
0.001
R509
10K
Q
KTC
3
SWI
T
R504
2.2K
R505
3.3K
R506
3.3K
R507
2.2K
R503
10K
C505
0.047
Q501
KTA1266 GR
SWITCHING
Q503
2SC2389 SE
Q502
2SC2389 SE
SWITCHING
Q504
2SC2389 SE
Q505
2SC2389 SE
SWITCHING
C501
0.001
C502
0.001
C504
180P
C503
180P
CNP502
CNP501
R523
56
C530
R544
C516
0.033
R524
100K
R526
3.9K
C520
1/50
C511
330P
R517
1K
C509
330P
Q506
KTC3199 GR
SWITCHING
R511
47K
C506
0.001
R532
5.6K
R525 100K
R534
27K
C
2
2
R405
2.2K
Q402
KTC3199 GR
MUTING
R406
2.2K
C402
0.001 R409
4.7K C405
10/50
R411
3.3K
R407
22K
C403
22/25
R417
560
R401
330
R402
330
NC
NC
NC
NC
R_IN
L_IN
A_+12V
CD_+B
0.5V 0.5V
0V
0V
0.2V
0.5V
0V
0V
1.5V
4.3V
0.5V0V0V
9.3V
9.3V 8.6V
3.4V
2.68V
0V
0V
0V
0V
0V
0V
0V
0V
0V0V
0V
0V
0V
0V
0V
0V
0V
0.7V
0V
0.7V
0V
M_GND
A_GND
CD_GND
(1/2W)
TO POWER SECTION
P18 1-E
–
+
–
+
Hich=T1
+ +
–
–
Hich=C
H
112K
112K
TAPE1_R
TAPE1_L
A_GND
A_GND
M_GND
ERASE
TAPE2_R2
TAPE2_R1
TAPE2_L1
TAPE2_L2
0V
0V
0V
0V
0V
0V 0.7V
0V 0V
0V
0.7V
0V
0V
0V
0.7V
0V 0V
0V
0V
0V 0.
ERASE
HEAD
RECORD/PLAYBACK HEAD
TAPE2
PLAYBACK HEAD
R-CH
L-CH
R-CH
L-CH
CNS102
CNS101
7
6
5
4
3
1
2
1
3
2
+12V
+7V
CD_GND
L-CH
A_GND
R-CH
1
6
4
5
3
2 1
6
4
5
3
2
24 23 22 21
20 19
18 17
8
7
6
5
4
32
1
7
6
5
4
3
1
2
1
3
2
TAPE1
CNS401
CNP11
TO CD SERVO PWB
25 12-C
BI401
AUDIO
PROCESSOR
4.3V
SWITCHING
SWITCHING
0.7V
10
11
12
13
14
15
16
1.3V 0.8V
SWITCHING
SWITCHING
+B
+B
+B
C552 680P C551 680P
C452
470P
C451
470P
MAIN PWB-A3 (2/2)
1
1
2
23
3
