Sharp XL-30H User manual

MICRO COMPONENT SYSTEM
OPERATION MANUAL
XL-30HMicroComponentSystemconsistingofXL-
30H (main unit) and CP-XL40H (speaker system).
Thank you for purchasing this SHARP product.
To obtain the best performance from this product
please read this manual carefully.
Itwill guide you inoperating your SHARP product.
Page
SPESIAL NOTES ...........................................1-2
ACCESSORIES ................................................. 3
PRECAUTIONS .............................................. 3-4
NAMES OF CONTROLS AND INDICATORS .. 5-6
PREPARATION FOR USE ............................. 7-8
SETTING THE CLOCK ..................................... 9
SOUND CONTROL ......................................... 10
COMPACT DISC OPERATION .................. 11-13
CONTENTS
Page
CASSETTE OPERATION ................................ 14
RADIO OPERATION .................................. 15-16
RECORDING ................................................... 17
HOW TO USE THE BUILT-IN TIMER......... 18-19
HEADPHONES................................................ 20
RESETTING THE MICROCOMPUTER........... 20
MAINTENANCE .............................................. 20
SPECIFICATIONS ........................................... 21
MODEL
XL-30H
**XL-30H(SUK).FRONT 00.2.4, 4:44 PM1
Downloaded from: http://www.usersmanualguide.com/

1
SPECIAL NOTES
NOTE FOR USERS IN THE U.K.
The mains lead of this product is fitted with a non-
rewireable(moulded)plugincorporatinga 3A fuse.
Shouldthefuseneedtobereplaced,aBSI orASTA
approved BS 1362 fuse marked or and of
the same rating as above, which is also indicated
on the pin face of the plug must be used.
Alwaysrefitthe fuse cover after replacingthefuse.
Never use the plug without the fuse cover fitted.
In the unlikely event of the socket outlet in your
homenot being compatible withthe plug supplied,
cut-off the mains plug and fit an appropriate type.
DANGER:
The fuse from the cut-off plug should be removed
and the cut-off plug destroyed immediately and
disposed of in a safe manner.
Under no circumstances should the cut-off plug
be inserted elsewhere into a 13A socket outlet as
a serious electric shock may occur.
To fit an appropriate plug to the mains lead, follow
the instructions below:
IMPORTANT:
The wires in the mains lead are coloured in ac-
cordance with the following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of
thisproduct may notcorrespond with the coloured
markings identifying the terminals in your plug,
proceed as follows:
●The wire which is coloured blue must be con-
nected to the plug terminal which is marked N
or coloured black.
●The wire which is coloured brown must be con-
nectedto the plug terminalwhich is marked Lor
coloured red.
Ensure that neither the brown nor the blue wire is
connected to the earth terminal in your three pin
plug.
Before replacing the plug cover, make sure that:
●If the new fitted plug contains a fuse, its value is
the same as that removed from the cut-off plug.
●The cord grip is clamped over the sheath of the
mains lead and not simply over the lead wires.
IF YOU HAVEANY DOUBT, CONSULTAQUALI-
FIED ELECTRICIAN.
SERVICE INFORMATION
In the unlikely event of your equipment requiring
repair, please contact the dealer or supplier from
whom it was purchased. Where this is not possi-
ble, please contact the telephone number listed
below.
You will then be given details of how to obtain ser-
vice. - 0345-125387 -
Please note; all calls will be charged at local rate.
Certain replacement parts and accessories may
be obtained from our main parts distributor.
WILLOW VALE ELECTRONICS LTD.
MANCHESTER 0161-682-1415
READING 01189-876444
In the unlikely event of this equipment requiring
repair during the guarantee period, you will need
to provide proof of the date of purchase to the re-
pairing company.
Please keep your invoice or receipt, which is sup-
plied at the time of purchase.
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM1
Downloaded from: http://www.usersmanualguide.com/

2
(Continued)
●Recording and playback of any material may
requireconsent,whichSHARP is unable to give.
Please refer particularly to the provisions of the
Copyright Act 1956, the Dramatic and Musical
Performers ProtectionAct 1958, the Performers
Protection Acts 1963 and 1972 and to any sub-
sequent statutory enactments and orders.
●This equipment complies with the requirements
of Directives 89/336/EEC and 73/23/EEC as
amended by 93/68/EEC.
●When the ON/STAND-BY button is set at
STAND-BYposition,mainsvoltageisstill present
inside the unit.
When the ON/STAND-BY button is set at
STAND-BYposition,theunitmaybebroughtinto
operation by the timer mode or remote control.
Warning:
●This unit contains no user serviceable parts.
Never remove covers unless qualified to do so.
This unit contains dangerous voltages, always
remove mains plug from the socket before any
service operation and when not in use for a long
period.
Warning:
●To prevent fire or shock hazard, do not expose
this appliance to dripping or splashing. No ob-
jects filled with liquids, such as vases, shall be
placed on the apparatus.
CAUTION
Useofcontrols,adjustmentsorperformanceof pro-
cedures other than those specified herein may re-
sult in hazardous radiation exposure.
As the laser beam used in this compact disc player
is harmful to the eyes, do not attempt to disassem-
blethe cabinet. Refer servicingto qualified person-
nel only.
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM2
Downloaded from: http://www.usersmanualguide.com/

3
PRECAUTIONS
■General
●Please ensure that the equipment is positioned
in a well ventilated area and ensure that there is
at least 10cm (4”) of free space along the sides
and back. There must also be a minimum of
20cm (8”) of free space on the top of the unit.
●Do not use oil, solvents, petrol, paint thinners or
insecticides on the unit.
●Do not expose the unit to moisture, to tempera-
tureshigherthan 60°C (140°F)or to extreme low
temperatures.
●Keep the unit away from direct sunlight, strong
magnetic fields, excessive dust, humidity and
electronic/electrical equipment (home comput-
ers, facsimiles, etc.) which generate electrical
noise.
●Hold the AC power plug by the head when re-
moving it from theAC socket, as pulling the lead
can damage internal wires.
ACCESSORIES
Note:
Parts and equipment mentioned in this operation manual other than those in the drawing are not included.
AC power lead ×1
Remote control ×1 FM/AM loop aerial ×1
●When cleaning the heads, pinch roller, etc., re-
move theAC power plug from the wall socket as
the unit contains high voltages.
Do not remove the outer cover, as this may re-
sult in electric shock. Refer internal service to
your local SHARP service facility.
●Use the unit on a firm, level surface free from vi-
bration, and do not place anything on the top of
the unit.
●If an electrical storm is taking place near you, it
is suggested that you disconnect the AC power
lead from the AC socket for safety.
●The ventilation should not be impeded by cover-
ing the ventilation openings with items, such as
newspapers, tablecloths, curtains, etc.
●No naked flame sources, such as lighted can-
dles, should be placed on the apparatus.
●Attention should be drawn to the environmental
aspects of battery disposal.
●The apparatus is designed for use in moderate
climate.
Warning:
The voltage used must be the same as that speci-
fied on this unit. Using this product with a higher
voltage than that which is specified is dangerous
and may result in a fire or other type of accident
causing damage.
SHARP will not be held responsible for any dam-
age resulting from use of this unit with a voltage
other than that which is specified.
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM3
Downloaded from: http://www.usersmanualguide.com/

4
■Volume control
Thesound level at agivenvolume setting depends
onacombinationofspeakerefficiency, location and
various other factors.
It is advisable to avoid exposure to high volume
levels, which occur whilst turning the unit on with
the volume control setting up high, or whilst con-
tinually listening at high volumes.
■Condensation
Sudden temperature changes, storage or opera-
tioninan extremely humid environment maycause
condensation inside the cabinet (CD pickup, tape
heads, etc.) or on the transmitter LED on the re-
mote control.
Condensation can cause the unit to malfunction.
If this happens, leave the power on with no disc (or
cassette) in the unit until normal playback is pos-
sible (about 1 hour). Wipe off any condensation on
the transmitter LED with a soft cloth before operat-
ing the unit.
Warning:
CD players use a laser pickup which can damage
theeyesifvieweddirectly.Donotlookatthepickup,
and do not touch the pickup directly.
■Care of compact discs
Compactdiscs are fairly resistanttodamage, how-
ever mistracking can occur due to the accumula-
tion of dirt on the disc surface.
Follow the guidelines below for maximum enjoy-
ment from your CD collection and player.
●Do not write on either side of the disc, particu-
larly the non-label side. Signals are read from
the non-label side. Do not mark this surface.
●Keep your discs away from direct sunlight, heat,
and excessive moisture.
●Alwayshold the CDs bythe edges. Fingerprints,
dirt, or water on the CDs can cause noise or
mistracking.IfaCDisdirtyor does not play prop-
erly, clean it with a soft, dry cloth, wiping straight
out from the centre, along the radius.
(Continued)
■Cassette tape
●For playback, use normal or low-noise tape for
the best sound. (Metal or CrO2tape is not rec-
ommended.)
For recording, use only normal tape.
●Do not use C-120 tapes, tapes with large diam-
eter reels, or poor-quality tapes, as they may
cause malfunctions.
●Before loading a tape into the cassette compart-
ment, tighten the slack with a pen or pencil.
●Cassettes have removable tabs which prevent
accidentalrecordingorerasingfromtakingplace.
Removing the tab will protect the corresponding
sidefrom being erased. Cover the tab holeswith
adhesive tape to erase or record again.
Side A (1)
Tab for side B (2) Tab for side A (1)
NO
YES
Correct
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM4
Downloaded from: http://www.usersmanualguide.com/

5
■Front panel
1. Timer Indicator
2. Record Indicator
3. Sleep Indicator
4. (CD) Repeat Indicator
5. (CD) Play Indicator
6. (CD) Random Indicator
7. (CD/TUNER) Memory Indicator
8. FM Stereo Mode Indicator
9. FM Stereo Indicator
10. CD Compartment
11. On/Stand-by Button
12. (CD/TAPE) Stop Button
(TUNER) Memory Clear Button
13. Record Pause Button
14. Bass/Treble Selector Button
15. Memory/Set Button
16. Clock/Timer/Sleep Button
17. Band Selector Button
18. (CD) Review Button
(TAPE) Rewind Button
(TUNER) Tuning Down Button
19. Function Selector Button
20. Headphone Socket
21. CD Eject Button
22. Remote Control Sensor
23. Volume Select Button
24. (CD) Play/Pause Button
(TAPE) Play Button
25. Jog Dial
26. (CD) Cue Button
(TAPE) Fast Forward Button
(TUNER) Tuning Up Button
27. Volume/Jog Dial Selector Button
28. Cassette Compartment
NAMES OF CONTROLS AND INDICATORS
123
46789
5
10
11
12
13
14
15
16
21
22
23
24
25
26
27
28
17
18
19
20
1
2
3
■Rear panel
1. AC Power Input Socket
2. FM/AM Loop Aerial Socket
3. Speaker Terminals
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM5
Downloaded from: http://www.usersmanualguide.com/

6
■Speaker section
1. Bass Reflex Duct
2. Full-Range Speaker
3. Speaker Wire
(Continued)
■Remote control
1. Remote Control Transmitter LED
●Tuner control section
2. Preset Up/Down Buttons
●CD control section
3. Clear Button
4. Random/Repeat Button
5. Memory Button
6. Stop Button
7. Play/Pause Button
8. Track Down/Review Button
9. Track Up/Cue Button
●Tape control section
10. Record Pause Button
11. Rewind Button
12. Stop Button
13. Play Button
14. Fast Forward Button
●Common section
15. Sleep Button
16. Bass Up/Down Buttons
17. Function Selector Buttons
18. On/Stand-by Button
19. Timer Button
20. Clock Button
21. Treble Up/Down Buttons
22. Volume Up/Down Buttons
1
2
3
3
4
5
10
11
2
6
7
8
9
12
13
14
20
22
15
16
17
18
19
21
1
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM6
Downloaded from: http://www.usersmanualguide.com/

7
PREPARATION FOR USE
Connect each speaker wire to the SPEAKER termi-
nals as shown.
Use speakers with an impedance of 4 ohms or
more.
Use of speakers with an impedance less than 4
ohms may damage your unit.
Notes:
●Connect the wire with the white line to the minus
(-) terminal and the plain wire to the plus (+) ter-
minal.
●Do not mix the right channel and left channel
wiring when connecting the speakers to the unit.
●Do not let the bare speaker wires touch each
other as this may damage the amplifier and/or
speakers.
●The speaker grille is not removable.
●Unplug theAC power lead from theAC socket
before connecting or disconnecting any com-
ponent.
■Aerial connection
■Speaker connection
2
13
Right speaker Left speaker
123
Connect the aerial wire to the ANTENNA socket.
FM aerial
Position the FM aerial wire in the direction where
the strongest signal can be received.
AM loop aerial
Position theAM loop aerial for optimum reception.
Place the AM loop aerial on a shelf, etc., or attach
it to a stand or wall with screws (not supplied).
Notes:
●Donot place the aerialon the main unitas it may
resultinnoisepickupfromtheinternaldigitalelec-
tronics.
Place the aerial away from the unit for better re-
ception.
●If the AM loop aerial and the FM aerial wire are
placedneartheACpowerlead,interferencemay
result.
●Do not connect the attached FM aerial to an ex-
ternal FM aerial. Otherwise, trouble may occur.
AM
loop
aerial
White
line
FM aerial
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM7
Downloaded from: http://www.usersmanualguide.com/

8
(Continued)
■Connecting the AC power lead
AC 230 V, 50Hz
To an AC socket
To AC INPUT
Connect the AC power lead to the AC power input
socket, then connect theAC power lead plug to an
AC socket.
Notes:
●Unplug theAC power lead from theAC socket if
the unit is not to be used for a prolonged period
of time.
●Never use a power lead other than the one sup-
plied. Otherwise, a malfunction or an accident
may occur.
15
15
●When inserting or removing the batteries, push
them towards the ëbattery terminals.
●Installingthe batteries incorrectly maycausethe
unit to malfunction.
Precautions for battery use:
●Insert the batteries according to the direction in-
dicated in the battery compartment.
●Replace all old batteries with new ones at the
same time.
●Do not mix old and new batteries.
●Remove the batteries if they are weak or if the
unitwill not be usedforlong periods of time.This
willpreventpotentialdamageduetobatteryleak-
age.
Caution:
Donotuserechargeablebatteries(nickel-cadmium
battery, etc.).
Notes concerning use:
●Replacethe batteries ifthe operating distance is
reduced or if the operation becomes erratic.
●Periodically clean the transmitter LED on the re-
mote control and the sensor on the main unit
with a soft cloth.
●Exposing the sensor on the main unit to strong
light may interfere with operation. Change the
lighting or the direction of the unit.
●Keep the remote control away from moisture,
excessive heat, shock, and vibrations.
●2 “AA” size batteries (UM/SUM-3, R6, HP-7
or similar)
●Batteries are not included.
0.2m - 6m
(8” - 20”)
■Remote control
10 cm (4") 10 cm (4")
20 cm (8")
10 cm (4")
■Placing the system
●Besureto keep space between the unitsforven-
tilation.
●Keep the top of this unit at least 20 cm (8") away
from the wall, and the back at least 10 cm (4")
away.
Note:
●Do not place the system or speakers near the
television set as the magnetic fields produced
may cause irregular colours to be displayed.
**XL-30H(SUK)P01-P08 00.2.2, 3:53 PM8
Downloaded from: http://www.usersmanualguide.com/

9
SETTING THE CLOCK
1Press the CLOCK/TIMER/SLEEP button to en-
ter the time check mode.
2Within3seconds,presstheMEMORY/SETbut-
ton.
3Turnthejogdial to select the time displaymode.
0:00 AM 12:00
“0:00” →The 24-hour display will appear.
(0:00 - 23:59)
“AM 12:00” →The 12-hour display will appear.
(AM 12:00 - PM 11:59)
●Note that this can only be set when the unit is
first installed or it has been reset (see page 20).
4Press the MEMORY/SET button.
5Adjust the hour by turning the jog dial.
●When the jog dial is turned one click clockwise,
thetimewillincreaseby1hour. When it is turned
one click anti-clockwise, the time will decrease
by 1 hour.
Keepturningthejogdialtochange the time con-
tinuously.
●When the 12-hour display is selected, “AM” will
change automatically to “PM”.
(Main unit operation)
In this example, the clock is set for the 24-hour
(0:00) system.
CLOCK/TIMER/
SLEEP
MEMORY/SET
Jog dial
6Press the MEMORY/SET button.
7Adjust the minutes by turning the jog dial.
●When the jog dial is turned one click clockwise,
the time will increase by 1 minute. When it is
turned one click anti-clockwise, the time will de-
crease by 1 minute.
Keepturningthejogdialtochange the time con-
tinuously.
●The hour setting will not advance even if min-
utes advance from “59” to “00”.
8Press the MEMORY/SET button.
●Theclockstartsoperatingfrom“0”second.(Sec-
onds are not displayed.)
Note:
●In the event of a power failure or when the AC
powerleadis disconnected, the clock display will
go out.
WhentheACpowersupplyisrestored,the clock
display will flash on and off to indicate the time
when the power failure occurred or when theAC
power lead was disconnected.
If this happens, follow the procedure below to
change the clock time.
To change the clock time:
Perform steps 1, 2 and 4 - 8 above.
To change the time display mode:
1Perform steps 1 - 3 in the section “RESETTING
THE MICROCOMPUTER”, on page 20.
2Perform steps 1 - 8 above.
*XL-30H(SUK)P09-P13 00.2.3, 2:00 PM9
Downloaded from: http://www.usersmanualguide.com/

10
SOUND CONTROL
■Volume
0 15 30
(Main unit operation)
WhentheVOLUME control is turned clockwise, the
volume will increase. When it is turned anti-clock-
wise, the volume will decrease.
(Remote control operation)
Press the VOLUME button to increase the vol-
ume and the VOLUME button to decrease the
volume.
-5 0 5
■Bass
(Main unit operation)
1Press the BASS/TREBLE button to select
“BASS”.
2Turn the jog dial to adjust the bass.
(Remote control operation)
Press the BASS ( or ) button to adjust the
bass.
(Main unit) (Remote control)
(Remote control)
(Main unit)
(Main unit operation)
1PresstheBASS/TREBLEbutton to select “TrE”.
2Turn the jog dial to adjust the treble.
(Remote control operation)
Press the TREBLE ( or ) button to adjust the
treble.
(Remote control)
(Main unit)
-5 0 5
Servo Powered Volume:
●The jog dial automatically comes out when the
poweris turned on, andgoes back when theunit
is set to the stand-by mode.
●When the power is turned on, you can put the
jog dial in and out by pressing the VOLUME
SELECT button.
Note:
Do not push in the jog dial forcibly with your finger.
■Treble
*XL-30H(SUK)P09-P13 00.2.3, 2:00 PM10
Downloaded from: http://www.usersmanualguide.com/

11
COMPACT DISC OPERATION
■CD playback 1Press the ON/STAND-BY button to turn the
power on.
2Press the FUNCTION button until “Cd” or “no
dISC” appears in the display.
●Press the CD button on the remote control.
●Ifno disc isloaded, the display will be “no dISC”
instead of “Cd”.
3Press the 7CD EJECT button to open the CD
compartment.
4Place a compact disc on the spindle, label side
up.
5Close the CD compartment by firmly pushing
the corner marked “PUSH CLOSE”.
●The total number of tracks and the total playing
time will be displayed.
6Press the
0 / CD 6 ( 0 6 ) button to start play-
back from track 1.
●Whenthelasttrackonthedischasfinishedplay-
ing, the unit will stop automatically.
To interrupt playback:
➀Press the 0/ CD 6(
0 6 ) button.
➁Press the 0/ CD 6(
0 6 ) button again to
resume playback from the same point.
To stop playback:
Press the ■button.
After use:
PresstheON/STAND-BYbuttontoenterthestand-
by mode.
Caution:
●Do not open the CD compartment during play-
back (or whilst paused).
●If the disc is damaged, dirty, or loaded upside
down, “no dISC” or “Cd Error” will appear in the
display.
Clean, replace, or reload the disc properly.
●Keepforeignobjectsoutof the CD compartment.
●Subjecting the unit to shock or vibration may
cause mistracking.
●Whenthe unit is notbeing used, be sureto close
the CD compartment. If it is left open, the lens
maybecome covered with dust and the unitmay
not operate properly.
●Playing certain compact discs at a high volume
may cause mistracking. In this case, listen at
lower volume.
●If TV or radio interference occurs during CD op-
eration, move the unit away from the TV or ra-
dio.
1
2
6
4
2
1
6
/CD
5
PUSH
CLOSE
3
7CD EJECT
Label side up
*XL-30H(SUK)P09-P13 00.2.8, 2:34 PM11
Downloaded from: http://www.usersmanualguide.com/

12
RANDOM/
REPEAT
VOLUME
/
JOG
Jog dial
(Continued)
■APSS (Auto Program Search System)
APSS automatically locates the beginning of any
track.
To listen again to the track being played:
(Main unit operation)
1Press the VOLUME/JOG button.
●The track number will flash.
2Whilst the track number is flashing, turn the jog
dial anti-clockwise.
(Remote control operation)
Press the 5 3 button for less than 0.5 seconds
during playback.
To move to the beginning of the next track:
(Main unit operation)
1Press the VOLUME/JOG button.
●The track number will flash.
2Whilst the track number is flashing, turn the jog
dial clockwise.
(Remote control operation)
Press the 2 4 button for less than 0.5 seconds
during playback.
●To skip a number of tracks at one time, press the
5 3 or 2 4 button on the remote control
repeatedly until the desired track number is
shown.
●To start playing at a desired track, press the 5
3or2 4 buttonontheremotecontrolwhilst
in the stop mode to select the track number, and
then press the 0/ CD 6(0 6) button.
■Cue and review
1Load a disc and begin playback.
2Hold the 2button down for audible fast for-
ward, and hold the 3button down for audible
fast reverse.
3Normal playback will resume when the 2or
3button is released.
Notes:
●When the end of the disc is reached whilst
cueing, the “End” will appear in the display and
CD operation is paused. Press the ■button to
stop CD operation.
●If the beginning of the disc is reached whilst re-
viewing,playback will start when yourelease the
3button.
■Repeat and random play
(Remote control operation)
1Press the RANDOM/REPEAT button.
●Each time this button is pressed, the mode will
change in the following order:
Repeat play Random play Normal play
2Press the 0 / CD 6 (0 6 ) button to start
playback.
To cancel repeat or random play:
Press the RANDOM/REPEAT button until “ R“ or
“RANDOM” disappears.
To repeat playback of selected tracks:
After entering the programme for the tracks you
want to listen to using “APMS”, select repeat play
and start playback.
Notes:
●If you press the 2 4 button during random
play,youcanmovetothenexttrack.Ontheother
hand, the 5 3 button does not allow you to
move to the previous track. The beginning of the
track being played will be located.
●When using random play or repeat play, be sure
to press the ■button after you are through lis-
tening.Otherwise,thedisc will play continuously.
●DuringAPMS operation, random playis not pos-
sible.
*XL-30H(SUK)P09-P13 00.2.8, 2:34 PM12
Downloaded from: http://www.usersmanualguide.com/

13
(Continued)
●The CD can be programmed to play the tracks
in any order, or skip certain tracks.
1Load a compact disc and close the CD com-
partment.
2Press the MEMORY/SET (MEMORY) button to
prepare for programming.
●“MEMORY” will flash.
3Within 30 seconds, turn the jog dial on the main
unit or press the 5 3 or 2 4 button on
the remote control to select the desired track.
4Press the MEMORY/SET (MEMORY) button.
●Theselectedtracknumberandtheprogrammed
playback order will be displayed.
●After 2 seconds, the total playing time of the
programmed tracks will be displayed automati-
cally.
5Repeat steps 3 - 4 for any other track. Up to 20
tracks can be programmed.
●If you make a mistake whilst in the program-
ming mode (when MEMORY is flashing) or if
you change your mind, the programmed tracks
can be cleared by pressing the CLEAR button
ontheremote control.Thetracks will be cleared
sequentially starting with the last entered track.
6Press the
0 / CD 6 ( 0 6 ) button to start play-
back of programmed selections.
To clear all the programmed selections:
To cancel a programmed sequence, press the
CLEARbutton on the remotecontrolwhilst the disc
is stopped and the “MEMORY” indicator is lit.
Notes:
●OpeningtheCDcompartmentautomaticallycan-
cels the programmed sequence.
●Even if you press the ON/STAND-BY button to
enter the stand-by mode or the function is
changed from CD to some other function, the
programmed selections will not be cleared.
●ProgrammingisnotpossibleduringCDplayback.
It must be performed whilst the CD is stopped.
●When in the random play mode (whilst “RAN-
DOM” is lit), programming is not possible.
To perform any programming, cancel the random
play mode.
CLEAR
6
2,4
3
6
3
2,4
■APMS (Automatic Programmable
Music Selector)
Selected track number Playback order
Total playing time
*XL-30H(SUK)P09-P13 00.2.3, 2:00 PM13
Downloaded from: http://www.usersmanualguide.com/

14
CASSETTE OPERATION
1Press the ON/STAND-BY button to turn the
power on.
2Pressthe FUNCTION buttonuntil “TP” appears
in the display.
●Press the TAPE button on the remote control.
3Open the cassette door by pushing the area
marked “7PUSH EJECT”.
4Load the cassette into the cassette compart-
ment.
5Press the
0 button.
To stop playback:
Press the ■button.
Fast forward/rewind:
To advance the tape, press the 2button. To re-
wind, press the 3button.
Caution:
●When removing the cassette tape, press the ■
button,andthenopenthecassettecompartment.
●Before changing from one tape operation to an-
other, press the ■button.
●If a power failure occurs during tape operation,
the tape head will remain engaged with the tape
and the cassette door will not open. In this case,
wait until power is restored.
●Even if the 0 / CD 6button is pressed during
tape playback, the unit will not enter the pause
mode.
The pause mode is only active during synchro-
nised operation of the cassette deck and CD.
In the normal cassette mode, use the ■button.
1
2
5
3
4
2
1
5
■Tape playback
*XL-30H(SUK)P14-P18 00.2.8, 2:35 PM14
Downloaded from: http://www.usersmanualguide.com/

15
RADIO OPERATION
To enter stations into memory:
1Perform steps 1 - 6 in the “Tuning” section.
2Press the MEMORY/SET button.
●“MEMORY” will flash.
3Within 5 seconds, turn the jog dial to make the
preset channel number flash in the display.
●Store the stations in memory, in order, starting
with preset channel 1.
4Within 5 seconds, press the MEMORY/SET
button to store that station in the selected sta-
tion preset number memory.
●If the “MEMORY” and preset number indicators
go out before the station is memorised, repeat
the operation from step 2.
5Repeat steps 1 - 4 to set other preset stations,
or to change a preset station.
After use:
PresstheON/STAND-BYbuttontoenterthestand-
by mode.
■Tuning
3,5,6
2
14
1Press the ON/STAND-BY button to turn the
power on.
2Press the FUNCTION button until “FM” or “AM”
appears in the display.
3PresstheBANDbutton to select the desired fre-
quency band. (FM ST, FM or AM)
4Press the TUNING (Xor W) button to tune in to
the desired station.
Manual tuning:
Press the TUNING (Xor W) button as many times
as required to adjust the frequency shown on the
display to the frequency of the desired station.
Auto tuning:
When the TUNING (Xor W) button is pressed for
more than 0.5 seconds, scanning will start auto-
matically and the tuner will stop at the first receiv-
able broadcast station.
Notes:
●Whenradiointerferenceoccurs during auto scan
tuning, auto scan tuning may stop automatically
at that point.
●Ifa weak station signalis found during autoscan
tuning, the station will be skipped.
●To stop the auto tuning, press the TUNING (X
or W) button again.
5To receive an FM stereo transmission,pressthe
BAND button so that the “ST” indicator on the
display lights up.
●“j” will appear when an FM broadcast is in
stereo.
6If the FM reception is weak, press the BAND
button so that the “ST” indicator goes out.
●The reception changes to monaural, the sound
becomes clearer.
Note:
●The last station tuned in will be recalled, even
after changing the tuning band or the function,
or after switching the unit to the stand-by mode.
■Preset tuning
You can store up to 30 stations in memory (30 sta-
tions consisting of any combination of FM and AM
stations you like) and recall them.
3
2,4
*XL-30H(SUK)P14-P18 00.2.2, 3:57 PM15
Downloaded from: http://www.usersmanualguide.com/

16
(Continued)
(Main unit operation)
1Press the VOLUME/JOG button.
●The preset channel number will flash.
2Whilst the preset channel number is flashing,
turn the jog dial to select the desired station.
(Remote control operation)
Press the PRESET ( or ) button for less than
0.5 seconds to select the desired station.
●The stations (preset channel number, frequency
and frequency band) which have been stored in
memory will appear in the display in numerical
order, irrespective of the frequency bands.
Note:
When searching for a memorised station, do not
press the PRESET button for more than 0.5 sec-
onds.
WhenthePRESET button is pressed formorethan
0.5 seconds, the unit will enter the preset memory
scan mode.
To recall a memorised station:
12
( )
PRESET
To clear a memorised station:
4
31
2
1Press the VOLUME/JOG button.
2Turn the jog dial to select the preset channel
number you want to erase.
3Press the MEMORY/SET button.
4Within 5 seconds, press the TUN CLEAR button.
1,2
1To scan the preset stations, press the PRESET
(or ) button for more than 0.5 seconds.
●The station preset number flashes and pro-
grammed stations are sequentially received for
5 seconds each.
2Press the PRESET ( or ) button again to
stop the memory scan at the desired station.
Note:
When the preset memory does not have any sta-
tions stored in it, the preset memory scan will not
function.
Backup function:
The backup function protects all station presets for
a few hours should there be a power failure or the
AC power lead is removed from the AC socket.
■Preset memory scan
The stations saved in the preset memory can be
scanned automatically.
*XL-30H(SUK)P14-P18 00.2.2, 3:57 PM16
Downloaded from: http://www.usersmanualguide.com/

17
RECORDING
1Press the ON/STAND-BY button to turn the
power on.
2Press the FUNCTION button until “Cd” or “no
dISC” appears in the display.
3Load the desired disc.
●Use the APMS function to store the tracks you
want to record in memory. (See page 13.)
4Loada cassette into thecassette compartment.
5Press the REC PAUSE button.
●“REC” will flash.
6Press the
0 button.
To stop recording:
Press the ■button.
●Thetapewillstop.Whenthe ■button is pressed
again, the CD will stop.
●When you press the CD ■buttonontheremote
control, the CD and tape will stop.
■Recording from the built-in radio
1Tune in to the desired station. (See pages 15 -
16.)
2Loada cassette into thecassette compartment.
3Press the REC PAUSE button.
●“REC” will flash.
Note:
●Ifa whistling noise isheard whilst recording from
anAM station, move the AM loop aerial to a po-
sition where noise is no longer heard from the
unit.
4Press the
0 button.
To stop recording:
Press the ■button.
■Erasing a recorded tape
1Pressthe FUNCTION buttonuntil “TP” appears
in the display.
2Press the REC PAUSE button.
●“REC” will flash.
3Press the
0 button.
●When recording important selections, be sure
to make a preliminary test to ensure that the
desired material is being properly recorded.
●The ALC (Automatic Record Level Control) cir-
cuit automatically controls the level of the input
signal used for recording.
●TheVOLUME,BASSandTREBLEcontrolsmay
be adjusted with no effect on the recorded sig-
nal. (Variable Sound Monitor)
●Metal and CrO2tapes should not be used for
recording.
■Recording from the built-in CD player
(CDSynchronisedRecordingSystem)
1
26
4
5
2
34
*XL-30H(SUK)P14-P18 00.2.2, 3:57 PM17
Downloaded from: http://www.usersmanualguide.com/

18
HOW TO USE THE BUILT-IN TIMER
■Timer playback
TIMER
4,5,6
2,5,6
1
3
2
6Turn the jog dial to set the minute at which to
start, and then press the MEMORY/SET but-
ton.
●The timer playback starting time, function, and
volume will be displayed, and then the unit will
enter the stand-by mode automatically.
●“f” will appear and the current time will be dis-
played.
7When the preset time is reached, the volume
will increase gradually.
8If you select CD or TAPE in the timer operation,
the unit will enter the stand-by mode after the
playback. If you select TUNER, it will enter the
stand-by mode one hour after the timer play-
back starts.
Caution:
●Timer recording is not possible.
●Recording operations are not possible during
timer playback.
To confirm the timer setting:
Press the CLOCK/TIMER/SLEEP button on the
main unit twice or press the TIMER button on the
remote control once.
●The timer playback starting time, function, and
volume will be displayed.
●If you press the TIMER button on the remote
control whilst confirming the timer setting (whilst
“f” is flashing), you can turn the timer playback
stand-by mode on or off.
To change the programmed contents:
After cancelling the timer mode, perform steps 1 -
6 above.
To cancel timer operation:
Press the ON/STAND-BY button to turn the power
on.
Note:
●The previously programmed timer starting time
will be stored until it is reprogrammed.
●Beforesettingthe timer,makesure that the clock
setting is correct. (Page 9)
1Press the ON/STAND-BY button to turn the
power on.
2Press the FUNCTION button to select the de-
sired function, and then adjust the sound vol-
ume using the jog dial.
3PresstheCLOCK/TIMER/SLEEPbuttonrepeat-
edly until “f” is displayed.
4Within6 seconds, press theMEMORY/SETbut-
ton.
●Ifmorethan6 seconds have passed, start again
from step 3.
5Turn the jog dial to set the hour at which to start,
and then press the MEMORY/SET button.
*XL-30H(SUK)P14-P18 00.2.2, 3:57 PM18
Downloaded from: http://www.usersmanualguide.com/

19
(Continued)
■Sleep operation
The radio, compact disc and cassette deck can all
be turned off automatically.
(Remote control operation)
1Play back the desired sound source.
2Press the SLEEP button.
●The sleep timer is initially set to 3 hours.
To change the sleep time:
Press the SLEEP button repeatedly to select the
desired sleep time. The time will decrease as fol-
lows.
●The amount of sleep time can also be changed
whilst in the sleep mode.
3The unit will enter the stand-by mode automati-
cally after the preset sleep time has elapsed.
(The sound volume will be reduced one minute
before the preset sleep time expires.)
To confirm the remaining sleep time:
Press the SLEEP button once.
To cancel the sleep operation:
PresstheON/STAND-BYbuttontoenterthestand-
by mode.
■Simultaneous sleep and timer op-
eration
1Prepare for timer playback.
(Perform steps 1 - 6 on page 18.)
2Press the SLEEP button repeatedly to select
the desired sleep time.
3Playthe desired item (compactdisc, tape, etc.).
4When the preset sleep time has elapsed, the
unit will automatically enter the stand-by mode.
5When the timer preset time is reached, timer
playback will start.
Caution:
●Be sure your tape length is long enough to per-
form both functions.
If you want to go to sleep and wake up listening
to a tape, and the length of the tape is shorter
than the sleep timer setting, timer playback will
not be possible.
4
3,5
2
SLEEP
(Main unit operation)
1Play back the desired sound source.
2PresstheCLOCK/TIMER/SLEEPbuttonrepeat-
edly until “SLEEP” is displayed.
3Within 5 seconds, press the MEMORY/SET
button.
4Turn the jog dial to set the time.
(Maximum 3 hours - Minimum 5 minutes, 5-
minute intervals)
OFF ↔ 5 minutes .... ↔ 3 hours
5Press the MEMORY/SET button.
6The unit will enter the stand-by mode automati-
cally after the preset sleep time has elapsed.
(Thevolumewill gradually decrease one minute
before the preset sleep time expires.)
To confirm the remaining sleep time:
Press the CLOCK/TIMER/SLEEP button three
times.
3 hours →2 hours →1 hour 30 minutes
↑ ↓
OFF ←15 minutes ←30 minutes ←1 hour
*XL-30H(SUK)P19-P21 00.2.3, 2:00 PM19
Downloaded from: http://www.usersmanualguide.com/
