14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
29
PARTS LIST
PARTS REPLACEMENT
Replacement parts which have these special safety characteristics
identified in this manual; electrical components having such features
areidentifiedbyåandshadedareasintheReplacementPartsLists
and Schematic Diagrams.The use of a substitute replacement part
which dose no have the same safety characteristic as the factory
recommended replacement parts shown in this service manual may
create shock, fire or other hazards.
"HOW TO ORDER REPLACEMENT PARTS"
To have your order filled promptly and correctly, please furnish the
following informations.
1. MODEL NUMBER 2. REF. NO.
3. PART NO. 4. DESCRIPTION
★MARK : SPARE PARTS-DELIVERY SECTION
'MARK : X- RAY RELATED PARTS
Ref. No. Part No. ★Description Code
PICTURE TUBE
14A-30MT
çå V101 VB37GDA86X/1E J Picture Tube CB
åL703 RCiLG0077PEZZ R Degaussing Coil AK
or
RCiLG0138PEZZ
çå DY601 RCiLH0149PEZZ R DeflectionYoke BA
PMAGF3041CEZZ J Magnet AG
MSPRT0001PEFJ R Spring AC
QEARC1433PEZZ R Ground-Part AF
21A-70ST
çå V101 VB51QAE020X*S J Picture Tube CE
or
VB540ADAC1S*S
åL703 RCiLG0025PEZZ R Degaussing Coil AW
çå DY601 RCiLH0146PEZZ R DeflectionYoke BF
QEARC2119PEZZ R Ground Part AG
PMAGF3003CEZZ J Magnet AK
PWB-A: DUNTKA020WEV1 (14A-30MT)
PWB-A: DUNTKA020WEV4 (21A-70ST)
MAIN Unit
TUNER
NOTE : THE PARTS HERE SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT INDEPENDENTLY.
åTU51 VTUVTST5UF78S J Tuner BD
INTEGRATED CIRCUITS
IC101 VHiKA78S05P-1 J KA78S05P AD
çå IC201 RH-iX3253CEZZ J TA1268AN AV
IC301 RH-iX3344CEZZ J I.C. (14A-30MT) AK
IC351 VHiTDA7056A-1 J TDA7056A (14A-30MT) AP
åIC501 VHiTA8403K/-1 J TA8403K AL
åIC701 VHiSTRF6654-1 J STRF6654 AX
åIC702 RH-FX0008GEZZ J PC123FY8 AE
åIC703 VHiMiP0254/-1 J MIP0254SPSCF AL
åIC704 RH-FX0008GEZZ J PC123FY8 AE
åIC751 VHiKA7809Pi-1 R KA7809PI AE
or
VHiTA7809S/-1
åIC752 VHiKA7809Pi-1 R KA7809PI AE
or
VHiTA7809S/-1
åIC753 VHiSE115N//-1 J SE115N AF
IC2001 RH-iX3315CEZZ J TMP87CK38F AU
IC2040 VHiPST994C/-1 J PST994C AD
IC2101 VHiM24C01B/-1 J M24C01-BN6 AF
or
RH-iX2447CEN1
IC3001 VHiCXA2074Q-1 J CXA2074Q (21A-70ST) AY
IC5301 VHiAN5276//-1 J AN5276 (21A-70ST) AR
TRANSISTORS
You can substitute "VC2SC2462-C-1" for "VS2SD601AR/-1".
Q201 VS2SC2735//1E J 2SC2735 AC
Q301 VS2SD601AR/-1 J 2SD601AR AC
Q351 VS2SC2462-C-1 J 2SC2462 (C) (14A-30MT) AB
Q401 VS2SD601AR/-1 J 2SD601AR AC
Q402 VS2SB709AR/-1 J 2SB709AR AC
Q403 VS2SD601AR/-1 J 2SD601AR AC
Q404 VS2SB709AR/-1 J 2SB709AR AC
Q451 VS2SB709AR/-1 J 2SB709AR AC
Q601 VS2SC2482//-1 J 2SC2482 AD
or
VS2SC2610/-1E
åQ602 VS2SD2586//1E J 2SD2586 AM
Q752 VS2SC1815YW-1 J 2SC1815 AC
Q753 VS2SC3198-Y-1 J 2SC3198 (Y) AA
Q951 VS2SD601AR/-1 J 2SD601AR AC
Q953 VS2SD601AR/-1 J 2SD601AR AC
Q961 VS2SD601AR/-1 J 2SD601AR (21A-70ST) AC
Q963 VS2SD601AR/-1 J 2SD601AR (21A-70ST) AC
Q971 VS2SD601AR/-1 J 2SD601AR AC
Q2001 VS2SD601AR/-1 J 2SD601AR AC
Q2002 VS2SD601AR/-1 J 2SD601AR AC
DIODES
D51 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D52 RH-EX0676GEZZ J Zener Diode, 32V AA
D53 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D103 VHD1SS119//-1 J Diode AB
D401 VHD1SS119//-1 J Diode AB
D402 RH-EX0092CEZZ J Zener Diode, 3.9V AB
D454 RH-EX0103CEZZ J Zener Diode, 5.6V AB
D455 VHD1SS119//-1 J Diode AB
D501 RH-DX0441CEZZ J Diode AC
åD502 RH-DX0131CEZZ J Diode AC
D604 VHD1SS119//-1 J Diode (21A-70ST) AB
D641 RH-EX0631GEZZ J Zener Diode, 9.1V AA
çå D651 RH-DX0131CEZZ J Diode AC
çå D652 VHD1SS119//-1 J Diode AB
çå D653 RH-EX0091CEZZ J Zener Diode, 22V AB
åD661 RH-DX0444CEZZ J Diode AH
PRINTED WIRING BOARD ASSEMBLIES
(NOT REPLACEMENT ITEM)
14A-30MT
PWB-A DUNTKA020WEV1 - Main Unit -
PWB-B DUNTK9432WEV7 - CRT Unit -
PWB-CDUNTKA060WEV1 - Front AV Unit -
21A-70ST
PWB-A DUNTKA020WEV4 - Main Unit -
PWB-B DUNTK9432WEV9 - CRT Unit -
PWB-CDUNTKA060WEV4 - Front AV Unit -

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
30
PWB-A: DUNTKA020WEV1 (14A-30MT)
PWB-A: DUNTKA020WEV4 (21A-70ST)
MAIN Unit
åD701 RH-DX0386CEZZ J Diode AG
åD702 RH-DX0279CEZZ J Diode AB
åD703 RH-DX0279CEZZ J Diode AB
åD704 RH-DX0279CEZZ J Diode AB
D705 RH-DX0492CEZZ J Diode AE
D706 VHD1SS82///1A J Diode AC
D707 VHD1SS82///1A J Diode AC
D708 RH-DX0400CEZZ J Diode AC
D709 RH-DX0164CEZZ J Diode AC
D710 RH-EX0601GEZZ J Zener Diode, 3.6V AA
åD711 RH-DX0279CEZZ J Diode AB
D712 RH-DX0132CEZZ J Diode AC
D751 VHD1SS119//-1 J Diode AB
D752 RH-DX0406CEZZ J Diode AD
D753 RH-EX0641GEZZ J Zener Diode, 12V AA
åD754 RH-DX0445CEZZ J Diode AL
D755 RH-DX0461CEZZ J Diode AG
D756 VHD1SS119//-1 J Diode AB
åD758 RH-DX0131CEZZ J Diode AC
D901 RH-EX0630GEZZ J Zener Diode, 9V (21A-70ST)AA
D902 RH-EX0630GEZZ J Zener Diode, 9V AA
D903 RH-EX0630GEZZ J Zener Diode, 9V AA
D960 VHD1SS119//-1 J Diode AB
D961 VHD1SS119//-1 J Diode(21A-70ST) AB
D2001 VHD1SS119//-1 J Diode AB
D2007 RH-EX0611GEZZ J Zener Diode, 5.1V AA
D2202 RH-PX0348CEZZ J Photodiode AB
åVA701 RH-VX0048CEZZ J Varistor AE
PACKGED CIRCUITS
åPR701 RMPTP0026CEZZ J Packaged Circuit AF
X801 RCRSB0001PEZZ J Crystal (14A-30MT) AL
or
RCRSB0205CEZZ
X801 RCRSB0205CEZZ J Crystal (21A-70ST) AF
or
RCRSB0001PEZZ
FILTERS
CF301 RFiLC0403CEZZ J Ceramic Filter AE
or
RFiLC0029TAZZ
CF302 RFiLC0404CEZZ J Ceramic Filter (21A-70ST) AF
or
RFiLC0007PEZZ
or
RFiLC0267CEZZ
CF401 RFiLC0013CEZZ J Ceramic Filter AE
or
RFiLC0004PEZZ
CF631 RFiLA0034CEZZ J Ceramic Filter AD
CF2040 RFiLC0121GEZZ J Ceramic Filter AD
COILS
L201 VP-XF1R2K0000 J Peaking 1.2µH AB
L202 RCiLi0612CEZZ J If Coil AE
or
RCiLi0588CEZZ
L301 VP-XF8R2K0000 J Peaking 8.2µH AB
L302 RCiLi0613CEZZ J If Coil AE
or
RCiLi0605CEZZ
L401 VP-XF6R8K0000 J Peaking 6.8µH AB
L402 VP-XF3R3K0000 J Peaking 3.3µH AB
L403 VP-XF2R2K0000 J Peaking 2.2µH AB
L404 VP-XF8R2K0000 J Peaking 8.2µH AB
L405 VP-DF390K0000 J Peaking 39µH AB
L406 VP-XF680K0000 J Peaking 68µH AB
L409 VP-XF100K0000 J Peaking 10µH AB
L631 VP-XF150K0000 J Peaking 15µH AB
åL702 RCiLF0012PEZZ R Coil AN
L751 RCiLP0225CEZZ J Coil AF
L2040 RCiLB0030PEZZ J Oscillation Coil AF
SF201 RFiLC0405CEZZ J SAW Filter AH
TRANSFORMERS
T601 RTRNZ0073CEZZ J H-Driver (14A-30MT) AF
T601 RTRNZ0367CEZZ J Transformer (21A-70ST) AK
çå T602 RTRNF0147PEZZ R H-Volt (21A-70ST) BC
çå T602 RTRNF0141PEZZ R H-Volt (14A-30MT) BC
åT701 RTRNZ0138PEZZ R Transformer AW
åT702 RTRNZ0103GJZZ J Transformer AM
CAPACITORS
[EL.···Electrolytic, M-Poly.···Metalized Polypro Film]
C51 VCEA0A1CW476M J 47 16V EL. AB
C52 VCSATA1CE226K J 22 16V Tantalum AD
(N.P)
C53 VCEA0A1HW105M J 1 50V EL. AB
C54 VCEA0A1HW225M J 2.2 50V EL. AB
C55 VCEA0A1CW108M J 1000 16V EL. AD
C102 VCEAGA1CW108M J 1000 16V EL. AD
C201 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C202 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C203 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C204 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C205 VCEA0A1HW474M J 0.47 50V EL. AB
C206 VCEA0A1CW227M J 220 16V EL. AC
C207 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C208 VCEA0A1HW474M J 0.47 50V EL. AB
C209 VCKYCY1HB222K J 2200p 50V Ceramic AA
C210 VCKYCY1HB102K J 1000p 50V Ceramic AA
C301 VCEA0A1HW225M J 2.2 50V EL. AB
(14A-30MT)
C302 VCCCCY1HH330J J 33p 50V Ceramic AA
C303 VCCCCY1HH390J J 39p 50V Ceramic AA
(21A-70ST)
C303 VCKYCY1HB272K J 2700p 50V Ceramic AA
(14A-30MT)
C305 VCKYPA1HB151K J 150p 50V Ceramic AA
C306 VCKYPA1HF103Z J 0.01 50V Ceramic AA
C307 VCEA0A1CW477M J 470 16V EL. AC
C308 VCKYCY1HB102K J 1000p 50V Ceramic AA
C309 VCEA0A1CW227M J 220 16V EL. AC
C312 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C313 VCE9GA1HW225M J 2.2 50V EL (N.P) AB
(14A-30MT)
C314 VCE9GA1HW225M J 2.2 50V EL (N.P) AB
(14A-30MT)
C316 VCEA0A1CW336M J 33 16V EL. AB
(14A-30MT)
C317 VCEA0A1CW336M J 33 16V EL. AB
(14A-30MT)
C351 VCQYTA1HM823K J 0.082 50V Mylar AB
(14A-30MT)
C352 VCKYCY1HB182K J 1800p 50V Ceramic AA
(14A-30MT)
C353 VCEA0A1CW108M J 1000 16V EL. AD
(14A-30MT)
C354 VCEA0A1CW106M J 10 16V EL. AB
(14A-30MT)
C355 VCQYTA1HM104K J 0.1 50V Mylar AC
(14A-30MT)
C401 VCCCCY1HH7R0D J 7p 50V Ceramic AA
C402 VCCCCY1HH331J J 330p 50V Ceramic AA
C403 VCCCCY1HH101J J 100p 50V Ceramic AA
C405 VCEA0A1HW335M J 3.3 50V EL. AB
C406 VCEA0A1HW335M J 3.3 50V EL. AB
C408 VCEA0A1CW106M J 10 16V EL. AB
C409 VCEA0A1HW105M J 1 50V EL. AB
C410 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C411 VCEAGA1CW108M J 1000 16V EL. AD
C413 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C414 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C419 VCCCCY1HH330J J 33p 50V Ceramic AA

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
31
C420 VCCCCY1HH221J J 220p 50V Ceramic AA
(14A-30MT)
C451 VCQYTA1HM563K J 0.056 50V Mylar AB
C454 VCEA0A1HW475M J 4.7 50V EL. AB
C502 VCEA0A1EW477M J 470 25V EL. AD
C504 VCKYPA2HB391K J 390p 500V Ceramic AA
C505 VCQYTA1HM473K J 0.047 50V Mylar AB
C507 VCQYTA1HM103K J 0.01 50V Mylar AB
C508 VCEAGA1VW107M J 100 35V EL. AC
C509 VCKYPA2HB102K J 1000p 500V Ceramic AA
C510 VCEAGA1VW477M J 470 35V EL. AD
C511 VCQYTA1HM473K J 0.047 50V Mylar AB
C513 VCEACA1HC225M J 2.2 50V EL. AC
C514 VCEACA1HC225J J 2.2 50V EL. AC
(21A-70ST)
C514 VCEACA1HC335J J 3.3 50V EL. AC
(14A-30MT)
C517 VCKYPA1HB102K J 1000p 50V Ceramic AA
C522 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C551 VCSATA1CE225K J 2.2 16V Tantalum AB
(N.P)
C552 VCEA0A1HW225M J 2.2 50V EL. AB
C553 VCCCCY1HH390J J 39p 50V Ceramic AA
C603 VCKYPA2HB222K J 2200p 500V Ceramic AA
(14A-30MT)
C603 VCKYPA2HB562K J 5600p 500V Ceramic AC
(21A-70ST)
åC604 VCEAGH2CW227M J 220 160V EL. AH
çå C608 VCFPPD3CA682H J 6800p 1600V M-Poly. AE
(14A-30MT)
çå C608 VCFPPD3CA872H J 8700p 1600V M-Poly. AF
(21A-70ST)
C609 VCKYPA2HB102K J 1000p 500V Ceramic AA
(14A-30MT)
C609 VCKYPA2HB222K J 2200p 500V Ceramic AA
(21A-70ST)
C612 VCFPPJ2EB474J J 0.47 250V M-Poly. AF
(14A-30MT)
C612 VCFPPJ2EB564J J 0.56 250V M-Poly. AF
(21A-70ST)
C631 VCEA0A1HW225M J 2.2 50V EL. AB
C632 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C634 VCEA0A1HW107M J 100 50V EL. AB
C652 VCEA0A1HW475M J 4.7 50V EL. AB
C653 VCEA0A1CW106M J 10 16V EL. AB
C661 VCKYPA2HB152K J 1500p 500V Ceramic AA
C662 VCEA0A1CW477M J 470 16V EL. AC
åC701 RC-FZ017SCEZZ J 0.22 275V M-Poly. AD
or
RC-FZ032CUMZZ
or
RC-FZ067SGEZZ
or
RC-FZ004SCEZZ
or
RC-FZ021SCEZZ
or
RC-FZ012SGEZZ
or
RC-FZ029SCEZZ
C702 VCKYPB2HE103P J 0.01 500V Ceramic AB
C703 VCKYPB2HE103P J 0.01 500V Ceramic AB
C704 VCEAGA2EW106M J 10 250V EL. AC
C705 VCFYHA1HA103J J 0.01 50V Mylar AA
C706 RC-KZ0029CEZZ J 0.01 250V Ceramic AC
or
RC-KZ0160GEZZ
åC707 RC-EZ0804CEZZ J 220 400V EL. AU
C708 RC-KZ1022CEZZ J 47p 1kV Ceramic AC
C709 VCKYPB2HE103P J 0.01 500V Ceramic AB
C710 VCQYTA1HM471J J 470p 50V Mylar AB
C711 RC-KZ0339CEZZ J 680p 2kV Ceramic AD
C712 VCQYTA1HM102J J 1000p 50V Mylar AA
C713 RC-KZ007JCEZZ J 0.01 250V Ceramic AC
C714 RC-KZ0338CEZZ J 560p 2kV Ceramic AD
C715 VCKYPA2HB102K J 1000p 500V Ceramic AA
C716 VCEAGA1EW107M J 100 25V EL. AD
C717 VCQYTA1HM182J J 1800p 50V Mylar AA
C718 VCKYPB2HE103P J 0.01 500V Ceramic AB
C719 VCKYPB2HE103P J 0.01 500V Ceramic AB
C720 VCKYPB2HE103P J 0.01 500V Ceramic AB
C721 VCKYPA2HB821K J 820p 500V Ceramic AA
åC730 RC-KZ0311CEZZ J 3300p 125V Ceramic AD
or
RC-KZ0092CEZZ
C750 VCEA0A1CW476M J 47 16V EL. AB
C751 VCEA0A1CW477M J 470 16V EL. AC
C752 VCEA0A1CW477M J 470 16V EL. AC
C754 VCEAGA1EW108M J 1000 25V EL. AD
C755 VCKYPA2HB102K J 1000p 500V Ceramic AA
C756 VCKYD41HB102K J 1000p 50V Ceramic AA
åC757 VCEA4W2CN227M J 220 160V EL. AG
C758 VCEAGA2EW106M J 10 250V EL. AC
C759 VCKYPA2HB102K J 1000p 500V Ceramic AA
C760 VCEA0A1CW337M J 330 16V EL. AC
C761 VCQYTA1HM104K J 0.1 50V Mylar AC
C762 RC-KZ0339CEZZ J 680p 2kV Ceramic AD
C763 VCFYHA1HA184J J 0.18 50V M-Poly. AC
C767 VCEA0A1CW107M J 100 16V EL. AC
C801 VCQYTA1HM223K J 0.022 50V Mylar AB
C802 VCEA0A1HW474M J 0.47 50V EL. AB
C803 VCCCCY1HH120J J 12p 50V Ceramic AA
C804 VCEA0A1HW104M J 0.1 50V EL. AB
C805 VCEA0A1HW104M J 0.1 50V EL. AB
C806 VCEA0A1HW104M J 0.1 50V EL. AB
C807 VCCCCY1HH820J J 82p 50V Ceramic AA
C901 VCKYCY1EF104Z J 0.1 25V Ceramic AA
C904 VCEA0A1HW335M J 3.3 50V EL. AB
(21A-70ST)
C905 VCEA0A1HW335M J 3.3 50V EL. AB
C950 VCEAGA1CW108M J 1000 16V EL. AD
C951 VCEA0A1HW335M J 3.3 50V EL. AB
C953 VCEA0A1HW335M J 3.3 50V EL. AB
(21A-70ST)
C954 VCQYTA1HM103K J 0.01 50V Mylar AB
(21A-70ST)
C955 VCEA0A1HW335M J 3.3 50V EL. AB
C956 VCEA0A1HW335M J 3.3 50V EL. AB
(21A-70ST)
C960 VCEAGA1CW336M J 33 16V EL. AB
C961 VCEA0A1HW335M J 3.3 50V EL. AB
(21A-70ST)
C963 VCEA0A1HW335M J 3.3 50V EL. AB
C964 VCQYTA1HM103K J 0.01 50V Mylar AB
C971 VCCCCY1HH101J J 100p 50V Ceramic AA
C973 VCEA0A1CW106M J 10 16V EL. AB
C974 VCEAGA1CW106M J 10 16V EL. AA
C980 VCEA0A1CW477M J 470 16V EL. AC
C2001 VCCCCY1HH101J J 100p 50V Ceramic AA
C2002 VCCCCY1HH101J J 100p 50V Ceramic AA
C2003 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C2004 VCKYCY1HF103Z J 0.01 50V Ceramic AA
C2021 VCCCCY1HH101J J 100p 50V Ceramic AA
C2022 VCCCCY1HH101J J 100p 50V Ceramic AA
C2023 VCCCCY1HH101J J 100p 50V Ceramic AA
C2024 VCCCCY1HH101J J 100p 50V Ceramic AA
C2040 VCEA0A1AW107M J 100 10V EL. AB
C2041 VCEA0A1HW105M J 1 50V EL. AB
C2062 VCEA0A1AW107M J 100 10V EL. AB
C2401 VCCCPA1HH560J J 56p 50V Ceramic AA
C2402 VCCCPA1HH560J J 56p 50V Ceramic AA
C2601 VCEA0A1CW476M J 47 16V EL. AB
C2602 VCCCCY1HH101J J 100p 50V Ceramic AA
C3001 VCE9GA1HW475M J 4.7 50V EL (N.P) AB
(21A-70ST)
C3002 VCKYCY1HB562K J 5600p 50V Ceramic AA
(21A-70ST)
PWB-A: DUNTKA020WEV1 (14A-30MT)
PWB-A: DUNTKA020WEV4 (21A-70ST)
MAIN Unit

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
32
PWB-A: DUNTKA020WEV1 (14A-30MT)
PWB-A: DUNTKA020WEV4 (21A-70ST)
MAIN Unit
C3003 VCQYTA1HM123K J 0.012 50V Mylar AA
(21A-70ST)
C3004 VCEA0A1HW105M J 1 50V EL. AB
(21A-70ST)
C3005 VCEA0A1HW475M J 4.7 50V EL. AB
(21A-70ST)
C3006 VCEA0A1HW106M J 10 50V EL. AB
(21A-70ST)
C3007 VCEA0A1HW475M J 4.7 50V EL. AB
(21A-70ST)
C3008 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3009 VCEA0A1CW227M J 220 16V EL. AC
(21A-70ST)
C3010 VCE9GA1HW475M J 4.7 50V EL (N.P) AB
(21A-70ST)
C3011 VCEA0A1HW475M J 4.7 50V EL. AB
(21A-70ST)
C3012 VCE9GA1HW475M J 4.7 50V EL (N.P) AB
(21A-70ST)
C3013 VCKYCY1HB272K J 2700p 50V Ceramic AA
(21A-70ST)
C3014 VCQYTA1HM473K J 0.047 50V Mylar AB
(21A-70ST)
C3015 VCSATA1CE335K J 3.3 16V Tantalum AC
(N.P)(21A-70ST)
C3016 VCE9GA1HW475M J 4.7 50V EL. (N.P) AB
(21A-70ST)
C3017 VCSATA1CE106K J 10 16V Tantalum AD
(N.P)(21A-70ST)
C3018 VCEA0A1HW105M J 1 50V EL. AB
(21A-70ST)
C3019 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3020 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3021 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3022 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3023 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3024 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3025 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C3026 VCKYCY1HF103Z J 0.01 50V Ceramic AA
(21A-70ST)
C5301 VCEAGA1VW108M J 1000 35V EL. AD
C5302 VCEAGA1HW225M J 2.2 50V EL. AB
(21A-70ST)
C5303 VCEAGA1HW225M J 2.2 50V EL. AB
(21A-70ST)
C5304 VCEAGA1HW225M J 2.2 50V EL. AB
(21A-70ST)
C5305 VCEAGA1HW106M J 10 50V EL. AC
(21A-70ST)
C5306 VCQYTA1HM472K J 4700p 50V Mylar AB
(21A-70ST)
C5307 VCQYTA1HM472K J 4700p 50V Mylar AB
(21A-70ST)
C5308 VCEAGA1VW107M J 100 35V EL. AC
(21A-70ST)
C5309 VCEAGA1EW108M J 1000 25V EL. AD
(21A-70ST)
C5310 VCEAGA1EW108M J 1000 25V EL. AD
(21A-70ST)
RESISTORS
[M-Ox.··· Metal Oxide, M-Film···Metal Film]
RJ1 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ2 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ3 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ6 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ7 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ10 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ11 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ12 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ14 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ15 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ16 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ17 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ18 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ19 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ20 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ21 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ22 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ23 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ24 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ25 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ26 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ27 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ28 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ29 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ31 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ32 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(21A-70ST)
RJ33 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ37 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ39 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ41 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ42 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ43 VRS-CY1JF000J J 0 1/16W M-Ox. AA
RJ44 VRS-CY1JF000J J 0 1/16W M-Ox AA
(21A-70ST)
RJ45 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ46 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ47 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
RJ48 VRS-CY1JF000J J 0 1/16W M-Ox. AA
(14A-30MT)
åR51 VRS-VV3DB151J J 150 2W M-Ox. AA
R52 VRS-VV3DB470J J 47 2W M-Ox. AA
åR53 VRS-VV3LB223J J 22k 3W M-Ox. AB
R54 VRD-RA2BE101J J 100 1/8W Carbon AB
R55 VRD-RA2BE101J J 100 1/8W Carbon AB
R56 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R57 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R201 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R202 VRS-CY1JF122J J 1.2k 1/16W M-Ox. AA
R203 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R204 VRS-CY1JF270J J 27 1/16W M-Ox. AA
R205 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R206 VRD-RA2EE151J J 150 1/4W Carbon AA
R208 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R301 VRD-RA2BE222J J 2.2k 1/8W Carbon AA
R302 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R303 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R304 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R305 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
(21A-70ST)
R306 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R307 VRD-RA2BE683J J 68k 1/8W Carbon AA
(14A-30MT)
R308 VRD-RA2BE391J J 390 1/8W Carbon AA
(14A-30MT)
R309 VRD-RA2BE473J J 47k 1/8W Carbon AA
(14A-30MT)

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
33
PWB-A: DUNTKA020WEV1 (14A-30MT)
PWB-A: DUNTKA020WEV4 (21A-70ST)
MAIN Unit
R311 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
(14A-30MT)
R351 VRD-RA2BE153J J 15k 1/8W Carbon AA
(14A-30MT)
R352 VRD-RA2BE4R7J J 4.7 1/8W Carbon AA
(14A-30MT)
R355 VRD-RA2BE101J J 100 1/8W Carbon AB
R401 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R402 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R403 VRS-CY1JF331J J 330 1/16W M-Ox. AA
R404 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R405 VRD-RA2BE102J J 1k 1/8W Carbon AA
R406 VRS-CY1JF470J J 47 1/16W M-Ox. AA
R407 VRS-CY1JF680J J 68 1/16W M-Ox. AA
R408 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R409 VRS-CY1JF471J J 470 1/16W M-Ox. AA
R410 VRD-RA2BE563J J 56k 1/8W Carbon AA
R411 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R412 VRD-RA2EE561J J 560 1/4W Carbon AA
R413 VRD-RA2BE470J J 47 1/8W Carbon AA
R414 VRD-RA2BE470J J 47 1/8W Carbon AA
R415 VRD-RA2BE470J J 47 1/8W Carbon AA
R416 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R417 VRD-RA2BE101J J 100 1/8W Carbon AB
R418 VRS-CY1JF152J J 1.5k 1/16W M-Ox. AA
R419 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R423 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R426 VRS-CY1JF271J J 270 1/16W M-Ox. AA
R440 VRS-CY1JF821J J 820 1/16W M-Ox. AA
åR451 VRS-VV3AB103J J 10k 1W M-Ox. AA
R452 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R454 VRD-RA2BE334J J 330k 1/8W Carbon AA
R455 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
R456 VRS-CY1JF223J J 22k 1/16W M-Ox. AA
R457 VRD-RA2BE102J J 1k 1/8W Carbon AA
R458 VRD-RA2BE334J J 330k 1/8W Carbon AA
(21A-70ST)
R458 VRD-RA2BE564J J 560k 1/8W Carbon AA
(14A-30MT)
R459 VRD-RA2BE123J J 12k 1/8W Carbon AA
R504 VRD-RA2BE471J J 470 1/8W Carbon AA
R505 VRD-RA2BE101J J 100 1/8W Carbon AB
R506 VRD-RA2BE683G J 68k 1/8W Carbon AA
R507 VRD-RA2BE104G J 10k 1/8W Carbon AA
R508 VRD-RA2BE473J J 47k 1/8W Carbon AA
R510 VRD-RM2HD1R2J J 1.2 1/2W Carbon AA
(21A-70ST)
R510 VRD-RM2HD1R5J J 1.5 1/2W Carbon AA
(14A-30MT)
åR511 VRN-VV3AB1R5J J 1.5 1W M-Film. AA
(21A-70ST)
åR511 VRN-VV3AB3R9J J 3.9 1W M-Film. AA
(14A-30MT)
R512 VRD-RM2HD271J J 270 1/2W Carbon AA
(14A-30MT)
R512 VRD-RM2HD331J J 330 1/2W Carbon AA
(21A-70ST)
R516 VRD-RA2BE153G J 15k 1/8W Carbon AA
(14A-30MT)
R516 VRD-RA2BE683G J 68k 1/8W Carbon AA
(21A-70ST)
R517 VRD-RA2BE103G J 10k 1/8W Carbon AA
(21A-70ST)
R517 VRD-RA2BE123G J 12k 1/8W Carbon AA
(14A-30MT)
R518 VRD-RA2BE154J J 150k 1/8W Carbon AA
R524 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R525 VRD-RA2BE473J J 47k 1/8W Carbon AA
R552 VRD-RA2BE102J J 1k 1/8W Carbon AA
R553 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R554 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R602 VRD-RM2HD392J J 3.9k 1/2W Carbon AA
(14A-30MT)
R602 VRD-RM2HD472J J 4.7k 1/2W Carbon AA
(21A-70ST)
åR603 VRS-SV3LB182J J 1.8k 3W M-Ox. AB
R608 VRD-RA2BE471J J 470 1/8W Carbon AA
R609 VRD-RA2BE331J J 330 1/8W Carbon AA
åR610 VRS-VV3DB391J J 390 2W M-Ox. AA
R620 VRD-RA2BE473J J 47k 1/8W Carbon AA
R621 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R631 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R632 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R633 VRD-RA2BE472J J 4.7k 1/8W Carbon AA
åR641 VRS-VV3AB682J J 6.8k 1W M-Ox. AA
R642 VRD-RA2BE102J J 1k 1/8W Carbon AA
(14A-30MT)
R642 VRD-RA2BE821J J 820 1/8W Carbon AA
(21A-70ST)
çå R651 VRD-RM2HD1R0J J 1 1/2W Carbon AA
çå R653 VRD-RA2BE102J J 1k 1/8W Carbon AA
çå R654 VRD-RA2BE473J J 47k 1/8W Carbon AA
çå R655 VRS-CY1JF104J J 10k 1/16W M-Ox. AA
åR659 VRN-VV3AB1R8J J 1.8 1W M-Film. AA
(14A-30MT)
åR659 VRN-VV3ABR82J J 0.82 1W M-Film. AA
(21A-70ST)
åR661 VRN-VV3ABR47J J 0.47 1W M-Film. AA
åR701 VRW-KP41C3R3K J 3.3 15W Cement AD
(21A-70ST)
åR701 VRW-KQ41C3R3K J 3.3 15W Cement AG
(14A-30MT)
åR702 VRS-KT3LB473J J 47k 3W M-Ox. AE
åR703 VRS-KT3LB473J J 47k 3W M-Ox. AE
R704 VRD-RM2HD330J J 33 1/2W Carbon AA
R705 VRD-RA2BE122J J 1.2k 1/8W Carbon AA
R706 VRD-RM2HD152J J 1.5k 1/2W Carbon AA
åR707 VRS-KT3LB473J J 47k 3W M-Ox. AE
R708 VRD-RA2BE272J J 2.7k 1/8W Carbon AA
R709 VRD-RA2BE681J J 680 1/8W Carbon AA
åR710 VRN-VV3ABR39J J 0.39 1W M-Film. AA
åR711 VRN-VV3ABR33J J 0.33 1W M-Film. AA
R712 VRD-RM2HD150J J 15 1/2W Carbon AA
R714 VRD-RM2HD104J J 100k 1/2W Carbon AA
R717 VRD-RM2HD124J J 120k 1/2W Carbon AA
R718 VRD-RM2HD124J J 120k 1/2W Carbon AA
R719 VRD-RA2BE102J J 1k 1/8W Carbon AA
R722 VRD-RM2HD124J J 120k 1/2W Carbon AA
åR725 RH-HZ0046CEZZ J 2.7M 1/2W Solid AQ
or
RH-DZ0047CEZZ
R751 VRD-RA2BE104J J 100k 1/8W Carbon AA
R752 VRD-RA2BE473J J 47k 1/8W Carbon AA
åR753 VRS-KA3HG3R3K J 3.3 5W M-Ox. AD
R754 VRD-RA2BE101J J 100 1/8W Carbon AB
(14A-30MT)
R754 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
(21A-70ST)
åR755 VRS-VV3DB470J J 47 2W M-Ox. AA
R756 VRD-RA2BE562J J 5.6k 1/8W Carbon AA
åR757 VRN-VV3DB1R8J J 1.8 2W M-Film. AB
(14A-30MT)
åR758 VRS-SV2HC180J J 18 1/2W M-Ox. AA
R760 VRD-RA2BE101J J 100 1/8W Carbon AB
R801 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R802 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R803 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
(14A-30MT)
R803 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
(21A-70ST)
R804 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
(14A-30MT)
R804 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
(21A-70ST)
R805 VRS-CY1JF182J J 1.8k 1/16W M-Ox. AA
(14A-30MT)

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
34
PWB-A: DUNTKA020WEV1 (14A-30MT)
PWB-A: DUNTKA020WEV4 (21A-70ST)
MAIN Unit
R805 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
(21A-70ST)
R806 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R902 VRS-CY1JF750J J 75 1/16W M-Ox. AA
R905 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
(21A-70ST)
R906 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
(21A-70ST)
R924 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
(21A-70ST)
R925 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R950 VRN-VV3AB1R0J J 1 1W M-Film. AA
R951 VRS-CY1JF154J J 150k 1/16W M-Ox. AA
(14A-30MT)
R951 VRS-CY1JF334J J 330k 1/16W M-Ox. AA
(21A-70ST)
R952 VRS-CY1JF154J J 150k 1/16W M-Ox. AA
(21A-70ST)
R952 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
(14A-30MT)
R953 VRD-RA2BE392J J 3.9k 1/8W Carbon AA
(14A-30MT)
R954 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
R957 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R958 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
(21A-70ST)
R960 VRS-CY1JF683J J 68k 1/16W M-Ox. AA
R961 VRS-CY1JF334J J 330k 1/16W M-Ox. AA
(21A-70ST)
R962 VRS-CY1JF154J J 150k 1/16W M-Ox. AA
(21A-70ST)
R963 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
R964 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
(21A-70ST)
R965 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
(21A-70ST)
R966 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
(21A-70ST)
R967 VRS-CY1JF332J J 3.3k 1/16W M-Ox. AA
(21A-70ST)
R968 VRS-CY1JF101J J 100 1/16W M-Ox. AA
(14A-30MT)
R968 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
(21A-70ST)
R969 VRS-CY1JF472J J 4.7k 1/16W M-Ox. AA
(21A-70ST)
R971 VRD-RA2BE101J J 100 1/8W Carbon AB
R972 VRD-RA2BE101J J 100 1/8W Carbon AB
R973 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R974 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R975 VRD-RA2EE221J J 220 1/4W Carbon AA
R976 VRS-VV3AB100J J 10 1W M-Ox. AA
R977 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R978 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R980 VRS-CY1JF470J J 47 1/16W M-Ox. AA
R981 VRS-CY1JF104J J 100k 1/16W M-Ox. AA
R2002 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2003 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2004 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2005 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2006 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2007 VRD-RA2BE472J J 4.7k 1/8W Carbon AA
R2008 VRD-RA2BE333J J 33k 1/8W Carbon AA
R2009 VRD-RA2BE102J J 1k 1/8W Carbon AA
R2010 VRD-RA2BE102J J 1k 1/8W Carbon AA
R2012 VRS-CY1JF391J J 390 1/16W M-Ox. AA
R2020 VRD-RM2HD223J J 22k 1/2W Carbon AA
R2022 VRD-RA2BE333J J 33k 1/8W Carbon AA
R2024 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2025 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2026 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2027 VRD-RA2BE682J J 6.8k 1/8W Carbon AA
R2028 VRD-RA2BE102J J 1k 1/8W Carbon AA
R2029 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R2032 VRD-RA2BE471J J 470 1/8W Carbon AA
R2033 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2040 VRS-CY1JF102J J 1k 1/16W M-Ox. AA
R2041 VRD-RA2BE333J J 33k 1/8W Carbon AA
R2042 VRD-RA2BE101J J 100 1/8W Carbon AB
R2043 VRD-RA2BE101J J 100 1/8W Carbon AB
R2044 VRS-CY1JF682J J 6.8k 1/16W M-Ox. AA
R2045 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2047 VRS-CY1JF221J J 220 1/16W M-Ox. AA
R2048 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2049 VRS-CY1JF333J J 33k 1/16W M-Ox. AA
R2054 VRS-CY1JF222J J 2.2k 1/16W M-Ox. AA
R2055 VRD-RA2BE103J J 10k 1/8W Carbon AA
R2060 VRD-RA2BE221J J 220 1/8W Carbon AA
R2061 VRS-CY1JF562J J 5.6k 1/16W M-Ox. AA
R2062 VRS-CY1JF183J J 18k 1/16W M-Ox. AA
R2066 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2067 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2068 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2070 VRS-CY1JF103J J 10k 1/16W M-Ox. AA
R2101 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2102 VRS-CY1JF101J J 100 1/16W M-Ox. AA
R2201 VRD-RA2EE102J J 1k 1/4W Carbon AA
R2501 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2503 VRS-CY1JF273J J 27k 1/16W M-Ox. AA
R2504 VRS-CY1JF123J J 12k 1/16W M-Ox. AA
R2505 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2506 VRS-CY1JF563J J 56k 1/16W M-Ox. AA
R2507 VRS-CY1JF823J J 82k 1/16W M-Ox. AA
R2508 VRS-CY1JF153J J 15k 1/16W M-Ox. AA
R2509 VRS-CY1JF272J J 2.7k 1/16W M-Ox. AA
R2601 VRD-RA2BE470J J 47 1/8W Carbon AA
R3001 VRD-RA2BE221J J 220 1/8W Carbon AA
(21A-70ST)
R3002 VRD-RA2BE221J J 220 1/8W Carbon AA
(21A-70ST)
R3003 VRS-CY1JF105J J 1M 1/16W M-Ox AA
(21A-70ST)
R3004 VRS-CY1JF104J J 100k 1/16W M-Ox AA
(21A-70ST)
R3005 VRS-CY1JF623J J 62k 1/16W M-Ox AA
(21A-70ST)
R3007 VRS-CY1JF332J J 3.3k 1/16W M-Ox AA
(21A-70ST)
R3008 VRS-CY1JF302J J 3k 1/16W M-Ox AA
(21A-70ST)
R3010 VRS-CY1JF392J J 3.9k 1/16W M-Ox AA
(21A-70ST)
R3011 VRD-RA2BE102J J 1k 1/8W Carbon AA
(21A-70ST)
R3012 VRD-RA2BE102J J 1k 1/8W Carbon AA
(21A-70ST)
R5302 VRD-RA2BE822J J 8.2k 1/8W Carbon AA
(21A-70ST)
R5303 VRS-CY1JF683J J 68k 1/16W M-Ox AA
(21A-70ST)
R5304 VRD-RA2BE103J J 10k 1/8W Carbon AA
(21A-70ST)
R5305 VRS-CY1JF103J J 10k 1/16W M-Ox AA
(21A-70ST)
R5306 VRS-CY1JF683J J 68k 1/16W M-Ox AA
(21A-70ST)
R5307 VRD-RA2BE102J J 1k 1/8W Carbon AA
(21A-70ST)
SWITCHES
S2501 QSW-P0593CEZZ J Power AE
S2502 QSW-K0079GEZZ J Vol-Down AB
S2503 QSW-K0079GEZZ J Vol-Up AB
S2504 QSW-K0079GEZZ J Ch-Down AB
S2505 QSW-K0079GEZZ J Ch-Up AB
S2506 QSW-K0079GEZZ J Menu AB

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
35
MISCELLANEOUS PARTS
åRY751 RRLYJ0081CEZZ J Relay AL
åF701 QFS-B4023CEZZ J Fuse,4A (125V) AC
or
QFS-B4021GEZZ
FB602 RBLN-0037CEZZ J Ferrite Bead AB
FB603 RBLN-0037CEZZ J Ferrite Bead AB
FB701 RBLN-0037CEZZ J Ferrite Bead AB
FB702 RBLN-0037CEZZ J Ferrite Bead AB
FB703 RBLN-0037CEZZ J Ferrite Bead AB
FB704 RBLN-0037CEZZ J Ferrite Bead AB
FB751 RBLN-0037CEZZ J Ferrite Bead (21A-70ST) AB
FB752 RBLN-0037CEZZ J Ferrite Bead AB
FB753 RBLN-0037CEZZ J Ferrite Bead (14A-30MT) AB
FB754 RBLN-0037CEZZ J Ferrite Bead AB
åFH701 QFSHD1013CEZZ J Fuse Holder AC
åFH702 QFSHD1014CEZZ J Fuse Holder AC
P51 QPLGN0160CEZZ J Plug, 1-Pin (SG) AB
P52 QPLGN0160CEZZ J Plug, 1-Pin (SG) AB
P302 QPLGN0461CEZZ J Plug, 4-Pin (S) (14A-30MT) AB
P401 QPLGN0561CEZZ J Plug, 5-Pin (GBN) AB
P601 QPLGN0603CEZZ J Plug, 6-Pin (K) AB
P651 QPLGN0361CEZZ J Plug, 3-Pin (PL) AB
P702 QPLGN0207CEZZ J Plug, 2-Pin (m) AA
P751 QPLGN0461CEZZ J Plug, 4-Pin (YBN) AB
P998 QPLGN0450CEZZ J Plug, 3-Pin (E) (14A-30MT) AA
P998 QPLGN0550CEZZ J Plug, 5-Pin (E) (21A-70ST) AB
P999 QPLGN0450CEZZ J Plug, 3-Pin (D) (14A-30MT) AA
P999 QPLGN0550CEZZ J Plug, 5-Pin (D) (21A-70ST) AB
P2001 QPLGN0561CEZZ J Plug, 5Pin AB
P5301 QPLGN0461CEZZ J Plug, 4-Pin (21A-70ST) AB
RMC2601 RRMCU0222CEZZ J R/C Receiver AL
RDA351 PRDAR0142PEFW R Heat Sink (14A-30MT) AD
RDA501 PRDAR0218PEFW R Heat Sink AD
RDA602 PRDAR0216PEFW R Heat Sink AE
RDA701 PRDAR0260PEFW R Heat Sink AH
RDA754 PRDAR0160PEFW R Heat Sink AF
RDA5301 PRDAR0258PEFW R Heat Sink (21A-70ST) AG
TAN901 QJAKH0011AJZZ J Terminal (14A-30MT) AK
TAN901 QTANJ0644CEZZ J Terminal (21A-70ST) AM
PRDAR0160PEFW R Heat Sink AF
QCNW-2396PEZZ J Connecting Cord AE
(14A-30MT)
PWB-A: DUNTKA020WEV1 (14A-30MT)
PWB-A: DUNTKA020WEV4 (21A-70ST)
MAIN Unit TRANSISTORS
Q852 VS2SC2229O/1E J 2SC2229O AD
Q854 VS2SC2229O/1E J 2SC2229O AD
Q856 VS2SC2229O/1E J 2SC2229O AD
Q881 VS2SA1266-Y-1 J 2SA1266(Y) AA
DIODES
You can substitute "RH-DX0045GEZZ" and "VHD-DX0446CEZZ" for
"VHD1SS119//-1".
D881 VHD1SS119//-1 J Diode AB
D882 VHD1SS119//-1 J Diode AB
D885 VHD1SS119//-1 J Diode AB
COIL
L851 VP-DF151K0000 J Peaking 150µH AB
CAPACITORS
[EL.···Electrolytic]
C851 VCKYPA1HB271K J 270p 50V Ceramic AA
C852 VCKYPA1HB271K J 270p 50V Ceramic AA
C853 VCKYPA1HB271K J 270p 50V Ceramic AA
C854 RC-KZ0016CEZZ J 0.01 1.4kV Ceramic AC
C881 VCEA0A1CW106M J 10 16V EL. AB
C883 VCEA0A1CW336M J 33 16V EL. AB
RESISTORS
[M-Ox.··· Metal Oxide]
R851 VRD-RA2BE470J J 47 1/8W Carbon AA
(21A-70ST)
R852 VRD-RA2BE221J J 220 1/8W Carbon AA
(21A-70ST)
R852 VRD-RA2BE271J J 270 1/8W Carbon AA
(14A-30MT)
R853 VRD-RA2BE121J J 120 1/8W Carbon AA
R854 VRD-RA2BE470J J 47 1/8W Carbon AA
(14A-30MT)
R855 VRD-RA2BE470J J 47 1/8W Carbon AA
(14A-30MT)
åR857 VRS-VV3AB123J J 12k 1W M-Ox. AA
R858 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R859 VRD-RA2BE470J J 47 1/8W Carbon AA
R860 VRD-RA2BE221J J 220 1/8W Carbon AA
(21A-70ST)
R860 VRD-RA2BE271J J 270 1/8W Carbon AA
(14A-30MT)
R861 VRD-RA2BE121J J 120 1/8W Carbon AA
åR865 VRS-VV3AB123J J 12k 1W M-Ox. AA
R866 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R867 VRD-RA2BE470J J 47 1/8W Carbon AA
(21A-70ST)
R868 VRD-RA2BE221J J 220 1/8W Carbon AA
(21A-70ST)
R868 VRD-RA2BE271J J 270 1/8W Carbon AA
(14A-30MT)
R869 VRD-RA2BE121J J 120 1/8W Carbon AA
åR873 VRS-VV3AB123J J 12k 1W M-Ox. AA
R874 VRD-RM2HD332J J 3.3k 1/2W Carbon AA
R881 VRD-RA2BE102J J 1k 1/8W Carbon AA
R882 VRD-RA2BE391J J 390 1/8W Carbon AA
R883 VRD-RA2BE561J J 560 1/8W Carbon AA
R884 VRD-RA2BE152J J 1.5k 1/8W Carbon AA
R885 VRD-RA2BE470J J 47 1/8W Carbon AA
MISCELLANEOUS PARTS
P851 QPLGN0561CEZZ J Plug, 5-Pin (GBN) AB
P852 QPLGN0461CEZZ J Plug, 4-Pin (YBN) AB
SC851 QSOCV0842CEZZ J CRT Socket (14A-30MT) AH
SC851 QSOCV0933CEZZ J CRT Socket (21A-70ST) AH
PWB-B: DUNTK9432WEV7 (14A-30MT)
PWB-B: DUNTK9432WEV9 (21A-70ST)
CRT UNIT

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
36
MISCELLANEOUS PARTS
J1001 QJAKE0108CEZZ J Jack, Video in AC
J1002 QJAKE0183CEZZ J Jack, Audio in (14A-30MT) AE
J1002 QJAKE0183CEZZ J Jack, Audio in (L) AE
(21A-70ST)
J1003 QJAKE0184CEZZ J Jack, Audio in (R) AE
(21A-70ST)
P1001 QPLGN0550CEZZ J Plug, 5-Pin (D) (21A-70ST) AB
P1002 QPLGN0550CEZZ J Plug, 5-Pin (E) (21A-70ST) AB
P1001 QPLGN0450CEZZ J Plug, 4-pin (D) (14A-30MT) AA
P1002 QPLGN0450CEZZ J Plug, 4-pin (E) (14A-30MT) AA
SP1 VSP9050PB108A J Speaker (L) (14A-30MT) AP
SP2 VSP9050PB108A J Speaker (R) (14A-30MT) AP
SP1 VSP1206PB406E J Speaker (L) (21A-70ST) AU
SP2 VSP1206PB406E J Speaker (R) (21A-70ST) AU
åQACCD3044CESA J AC Cord AM
or
QACCD3092CESA
QCNW-2048PEZZ R Connecting Cord (21A-70ST) AL
QCNW-2106PEZZ R Connecting Cord (14A-30MT) AE
QCNW-2110PEZZ R Connecting Cord (14A-30MT) AG
QCNW-2160PEZZ R Connecting Cord (21A-70ST) AG
QCNW-2171PEZZ R Connecting Cord (21A-70ST) AF
QCNW-2384PEZZ R Connecting Cord (14A-30MT) AF
QCNW-2385PEZZ R Connecting Cord (14A-30MT) AG
QCNW-2386PEZZ R Connecting Cord (14A-30MT) AG
QCNW-2387PEZZ R Connecting Cord (21A-70ST) AH
QCNW-2388PEZZ R Connecting Cord (21A-70ST) AH
QCNW-2396PEZZ R Connecting Cord (14A-30MT) AE
QCNW-2403PEZZ R Connecting Cord (14A-30MT) AE
QCNW-2404PEZZ R Connecting Cord (21A-70ST) AE
MISCELLANEOUS PARTS
SUPPLIED ACCESORRIES
PACKING PARTS
(NOT REPLACEMENT ITEM)
TiNS-6778PEZZ R Operation Manual AF
(14A-30MT)
TiNS-6781PEZZ R Operation Manual AF
(21A-70ST)
QPLGF0125CEZZ R Antenna Adapter AM
(21A-70ST)
RRMCG1519CESA R Infrared R/C Unit AR
TGAN-0167PEZZ R Guarantee Card AF
(14A-30MT)
TGAN-0170PEZZ R Guarantee Card AF
(21A-70ST)
TCAUA0002PEZZ R Caution Card AB
SPAKC6558PEZZ - Packing Case -
(21A-70ST)
SPAKC6560PEZZ - Packing Case -
(14A-30MT)
SPAKP0056PEZZ - Wrapping Sheet -
(14A-30MT)
SPAKP0119PEZZ - Wrapping Sheet -
(21A-70ST)
SPAKX2651PEZZ - Buffer Material -
(21A-70ST)
SPAKX2653PEZZ - Buffer Material -
(14A-30MT)
PWB-C: DUNTKA060WEV1 (14A-30MT)
PWB-C: DUNTKA060WEV4 (21A-70ST)
FRONT AV UNIT

14A-30MT
21A-70ST
Ref. No. Part No. ★Description Code Ref. No. Part No. ★Description Code
37
CABINET PARTS
14A-30MT
1 CCABA2522WEV0 R Front Cabinet Ass’y BC
1-1 Not Available - Front Cabinet -
1-2 JBTN-0268PESC R Power Button AC
1-3 GCOVA0080PESA R Cover for R/C AD
1-4 HBDGB0019PESA R Badge “SHARP” AD
1-5 JBTN-0264PESC R Control Button AE
1-6 GCOVA0079PESA R Cover for LED AC
2 CCABB2399WEV0 R Rear Cabinet Ass’y AX
2-1 Not Available - Rear Cabinet -
21A-70ST
1 CCABA2516WEV0 R Front Cabinet Ass’y BG
1-1 Not Available - Front Cabinet -
1-2 JBTN-0264PESC R Control Button AE
1-3 JBTN-0265PESC R Power Button AE
1-4 GCOVA0079PESA R Cover for LED AC
1-5 GCOVA0080PESA R Cover for R/C AD
1-6 HBDGB0015PESA R Badge “SHARP” AE
2 CCABB2401WEV0 R Rear Cabinet Ass’y AZ
2-1 Not Available - Rear Cabinet -
21A-70ST
14A-30MT
BEAT
12 1-1 2-1
1-2 1-6 1-5 1-3
1-4
BEAT
12 1-1
1-3 1-4 1-2 1-6 1-5
2-1
CABINET PARTS LOCATION
