Sharp 19L-M100 User manual

1
19L-M100, CL19M10
19L-M100S, 20ML10
COLOR TELEVISION
Chassis No. SN-80
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its
original condition and only parts identical to those specified should be used.
»ELECTRICAL SPECIFICATIONS......................................................................................................... 1
»IMPORTANT SERVICE SAFETY PRECAUTION ................................................................................. 2
»LOCATION OF USER'S CONTROL..................................................................................................... 6
»INSTALLATIONAND SERVICE INSTRUCTIONS................................................................................7
»CHASSIS LAYOUT ............................................................................................................................ 12
»BLOCK DIAGRAM ............................................................................................................................. 13
»SCHEMATIC DIAGRAMS .................................................................................................................. 14
»PRINTED WIRING BOARD ASSEMBLIES ........................................................................................ 18
»REPLACEMENT PARTS LIST ........................................................................................................... 23
»PACKING OF THE SET ..................................................................................................................... 35
Page
SHARP CORPORATION This document has been published to be used for after
sales service only.
The contents are subject to change without notice.
CONTENTS
SERVICE MANUAL
POWER INPUT ................................ 120 V AC 60 Hz
POWER RATING
19L-M100 ....................................................... 82 W
19L-M100S, CL19M10, 20ML10 ....................84 W
PICTURE SIZE.......................1,194cm2(185sq inch)
CONVERGENCE ........................................Magnetic
SWEEP DEFLECTION................................Magnetic
FOCUS........................... Hi-Bi-Potential Electrostatic
INTERMEDIATE FREQUENCIES
Picture IF Carrier Frequency ................. 45.75 MHz
Sound IF Carrier Frequency .................. 41.25 MHz
Color Sub-Carrier Frequency ................ 42.17 MHz
(Nominal)
ELECTRICAL SPECIFICATIONS
AUDIOPOWER
OUTPUT RATING ...........0.9 W (at 10% distortion)
SPEAKER
SIZE ..................................................8 cm (Round)
VOICE COILIMPEDANCE...........8 ohm at 400 Hz
ANTENNA INPUT IMPEDANCE
VHF/UHF................................ 75 ohm Unbalanced
TUNING RANGES
VHF-Channels.......................................... 2 thru 13
UHF-Channels........................................ 14 thru 69
CATV Channels ...................................... 1 thru 125
(EIA, Channel Plan U.S.A.)
Specifications are subject to change without
prior notice.
MODELS
19L-M100, CL19M10
19L-M100S, 20ML10
S59G719L-M100

16
19L-M100, CL19M10
19L-M100S, 20ML10
87109654321
A
B
C
D
E
F
G
H
SCHEMATIC DIAGRAM: MAIN Unit

17
19L-M100, CL19M10
19L-M100S, 20ML10
1716 1918151413121110
