Shimano EDISON COMP I-12 User manual

22-Q-0007 … 22-Q-0009, 22-Q-0049 … 22-Q-0056, 22-Q-0097 … 22-Q-0099, 22-Q-0103, 22-Q-0109
MY22H03 - 22_1.0_01.10.2021
EDISON COMP I-12 | EDISON GR I-11 | EDISON SPORT I-10
NOS FS SUV 2.1 | NOS FS SUV 2.2 | NOS SUV 2.1 | NOS SUV 2.2
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP SAFE TO CONSULT AT A LATER DATE
Translation of the original operating instructions for
HERCULES pedelecs with SHIMANO SC-E6100
on-board computer

MY22H03 - 22_1.0_01.10.2021 1
Contents
Contents
1 About these operating instructions
1.1 Manufacturer 10
1.2 Laws, standards and directives 10
1.3 Language 10
1.4 For your information 10
1.4.1 Warnings 10
1.4.2 Markups 10
1.5 Type number and model 11
1.6 Frame number 11
1.7 Identifying the operating instructions 11
1.8 Aim of the operating instructions 12
2 Safety
2.1 Residual risks 13
2.1.1 Risk of fire and explosion 13
2.1.1.1 Rechargeable battery 13
2.1.1.2 Overheated charger 13
2.1.1.3 Hot components 13
2.1.2 Electric shock 14
2.1.2.1 Damage 14
2.1.2.2 Water penetration 14
2.1.2.3 Condensation 14
2.1.3 Risk of a crash 14
2.1.3.1 Incorrect quick release setting 14
2.1.3.2 Incorrect tightening torque 14
2.1.3.3 Incorrect component 14
2.1.4 Risk of amputation 14
2.1.5 Key breaking off 14
2.1.6 Malfunctions due to Bluetooth® 15
2.2 Toxic substances 16
2.2.1 Brake fluid 16
2.2.2 Suspension oil 16
2.2.3 Lubrication oil 16
2.2.4 Defective battery 16
2.3 Requirements for riders 16
2.4 Vulnerable groups 16
2.5 Personal protective equipment 16
2.6 Safety guards 16
2.7 Safety markings and safety instructions 17
2.8 What to do in an emergency 17
2.8.1 Dangerous situation in road traffic 17
2.8.2 Leaked brake fluid 17
2.8.3 Battery vapours emitted 18
2.8.4 Battery fire 18
2.8.5 Oil and lubricant leaks from the rear frame damper 18
2.8.6 Oil and lubricant leaks from the fork 18
3 Description
3.1 Proper use 19
3.1.1 Improper use 20
3.1.2 Permitted total weight (PTW) 21
3.1.3 Environmental requirements 22
3.2 Nameplate 24
3.3 Components 25
3.3.1 Overview 25

MY22H03 - 22_1.0_01.10.2021 2
Contents
3.3.2 Chassis 26
3.3.2.1 Frame 26
3.3.2.2 Steering system 26
3.3.2.3 Steering headset 26
3.3.2.4 Stem 26
3.3.2.5 Handlebars 27
3.3.2.6 Fork 27
3.3.3 Suspension 28
3.3.3.1 Rigid fork 28
3.3.3.2 Suspension fork 28
3.3.3.3 Rear frame damper 32
3.3.3.4 Suntour rear frame damper 35
3.3.3.5 RockShox rear frame damper 36
3.3.4 Wheel 37
3.3.4.1 Tyres 37
3.3.4.2 Rim 37
3.3.4.3 Valve 37
3.3.4.4 Spoke 38
3.3.4.5 Spoke nipples 38
3.3.4.6 Hub 38
3.3.5 Braking system 39
3.3.5.1 Mechanical brake 39
3.3.5.2 Hydraulic brake 39
3.3.5.3 Disc brake 40
3.3.6 Seat post 41
3.3.6.1 Patent seat post 41
3.3.6.2 Suspension seat post 41
3.3.7 Mechanical drive system 42
3.3.7.1 Chain drive layout 42
3.3.7.2 Belt drive layout 42
3.3.8 Electric drive system 43
3.3.8.1 Motor 43
3.3.9 Rechargeable battery 44
3.3.10 Riding light 44
3.3.11 Charger 44
3.3.12 On-board computer 45
3.4 Description of controls and screens 46
3.4.1 Handlebars 46
3.4.2 On-board computer 47
3.4.3 Warnings and errors 49
3.4.3.1 Warnings 49
3.4.3.2 Error messages 49
3.4.4 Gear shift 50
3.4.4.1 Control panel functions on right 50
3.4.5 Hand brake 52
3.4.6 Battery level indicator (battery) 53
3.5 Technical data 54
3.5.1 Pedelec 54
3.5.2 Motor 54
3.5.2.1 SHIMANO EP8 DU-EP800 54
3.5.3 On-board computer 54
3.5.3.1 SHIMANO SC-E6100 54
3.5.3.2 Specifications for wireless systems 54
3.5.4 Emissions 54
3.5.5 Rechargeable battery 54
3.5.5.1 SHIMANO, BT-E8036 54
3.5.6 Charger 54
3.5.6.1 SHIMANO, EC-E6002 54
3.5.7 Tightening torques 55

MY22H03 - 22_1.0_01.10.2021 3
Contents
4 Transporting and storing
4.1 Weight and dimensions for transportation 57
4.2 Designated handles, lifting points 57
4.3 Transportation 58
4.3.1 Using the brake transport securing system 58
4.3.2 Transporting the pedelec 58
4.3.3 Shipping a pedelec 58
4.3.4 Transporting the battery 58
4.3.5 Shipping the battery 58
4.4 Storing 59
4.4.1 Break in operation 59
4.4.1.1 Preparing a break in operation 59
4.4.1.2 Carrying out a break in operation 59
5 Assembly
5.1 Unpacking 60
5.2 Required tools 60
5.3 Commissioning 61
5.3.1 Checking the battery 61
5.3.2 Preparing the wheel 62
5.3.3 Installing the wheel in the SUNTOUR fork 63
5.3.3.1 Screw-on axle (12AH2 and 15AH2) 63
5.3.3.2 20 mm cross axle 64
5.3.3.3 Q-LOC quick release 66
5.3.4 Fitting the pedals 67
5.3.5 Preparing the LIMOTEC seat post 68
5.3.6 Checking the stem and handlebars 69
5.3.6.1 Checking the connections 69
5.3.6.2 Checking stem is firmly in position 69
5.3.6.3 Checking the headset backlash 69
5.4 Pedelec sale 69
6 Operation
6.1 Risks and hazards 70
6.2 Tips for a greater range 72
6.3 System messages 73
6.3.1 On-board computer warnings 73
6.3.2 Error message screen 74
6.3.3 Battery error message 75
6.4 Instruction and customer service 76
6.5 Adjusting the pedelec 76
6.5.1 Preparing 76
6.5.2 Pedelec adjustment procedure 77
6.5.3 Determining the sitting position 78
6.5.4 Adjusting the saddle 80
6.5.4.1 Straightening the saddle 80
6.5.4.2 Adjusting the saddle height 80
6.5.4.3 Setting the saddle height with the remote control 81
6.5.4.4 Adjusting the saddle position 82
6.5.4.5 Adjusting the saddle tilt 82
6.5.4.6 Checking saddle stability 82
6.5.5 Handlebars 83
6.5.5.1 Handlebar width 83
6.5.5.2 Hand position 83
6.5.5.3 Adjusting the handlebars 83
6.5.6 Stem 84
6.5.6.1 Adjusting the handlebar height with quick release 84
6.5.6.2 Setting the quill stem 85

MY22H03 - 22_1.0_01.10.2021 4
Contents
6.5.6.3 Adjusting the Ahead stem 85
6.5.6.4 Adjusting the angle-adjustable stem 86
6.5.7 Ergonomic handles 87
6.5.7.1 Checking handlebar stability 87
6.5.8 Tyres 88
6.5.9 Brake 89
6.5.9.1 Brake handle position 89
6.5.9.2 Brake handle tilt angle 89
6.5.9.3 Determining the grip distance 90
6.5.9.4 Grip distance on a SHIMANO ST-EF41 brake lever 91
6.5.9.5 Grip distance on a SHIMANO ST-EF41 brake lever 92
6.5.9.6 Retracting the brake linings 93
6.5.10 Suspension 94
6.5.11 Fork sag 94
6.5.11.1 ROCKSHOX Paragon Silver coil spring 95
6.5.11.2 Adjusting the RockShox coil spring with an external preload adjuster 97
6.5.11.3 Adjusting the ROCKSHOX fork coil spring with spacer for pre-tensioning 98
6.5.12 Adjust the rear frame damper sag 100
6.5.12.1 Adjusting the Suntour fork steel suspension 101
6.5.12.2 Adjusting the Suntour fork air suspension 102
6.5.13 Fork rebound damping 103
6.5.13.1 Adjusting the Suntour fork rebound damping 104
6.5.13.2 Adjusting the Suntour rear frame damper 105
6.5.13.3 Adjusting the RockShox rear frame damper 106
6.5.13.4 Adjusting the RockShox suspension fork 108
6.5.14 Adjusting the rear frame damper rebound damper 109
6.5.14.1 Adjusting the RockShox rear frame damper 110
6.5.15 Compression adjuster on rear frame damper 111
6.5.15.1 Adjusting the Suntour compression adjuster 112
6.5.15.2 Adjusting the RockShox compression adjuster 113
6.5.15.3 Adjusting the RockShox threshold 114
6.5.16 Lighting 115
6.5.16.1 Adjusting the lights 115
6.6 Adjust on-board computer 117
6.6.1 Opening the settings menu 118
6.6.1.1 Closing the settings menu 118
6.6.2 Setting the language 119
6.6.3 Setting units 119
6.6.4 Adjusting the time 119
6.6.5 Setting the start ratio 120
6.6.6 Setting the automatic gear sequence 120
6.6.7 Adjusting gear shift info 120
6.6.8 Adjusting the backlight 120
6.6.9 Adjusting the Brightness 121
6.6.10 Adjusting the font colour 121
6.6.11 Sets the beep sound 121
6.7 Connect external devices 122
6.7.1 Connect via Bluetooth® LE 122
6.7.2 Connect via ANT 122
6.8 Using E-TUBE PROJECT 122
6.9 Accessories 123
6.9.1 Child seat 123
6.9.2 Trailer 124
6.9.3 Pannier rack 124
6.10 Personal protective equipment and accessories for road safety 125
6.11 Before each ride 125
6.12 Straightening the quickly adjustable stem 126
6.13 Using the pannier rack 126
6.14 Raising the kickstand 127

MY22H03 - 22_1.0_01.10.2021 5
Contents
6.15 Using the saddle 127
6.15.1 Using the leather saddle 127
6.16 Using the pedals 127
6.17 Using the multifunctional handlebars or bar ends 127
6.17.1 Using leather handles 127
6.18 Using the bell 127
6.19 Rechargeable battery 128
6.19.1 Removing the BT-E8036 battery 128
6.19.2 Inserting the BT-E8036 battery 129
6.19.3 Charging the battery 129
6.20 Using pedelec with the electric drive system 130
6.20.1 Switching on the electric drive system 130
6.20.2 Switching off the electric drive system 130
6.21 Using the on-board computer 131
6.21.0.1 Using the riding light 132
6.21.1 Using the push assist system 132
6.21.1.1 Select WALK level of assistance 132
6.21.1.2 Switching on the push assist 132
6.21.1.3 Switching off the push assist 132
6.21.1.4 Exit WALK level of assistance 132
6.21.1.5 Selecting the level of assistance 133
6.21.2 Switching the journey information 133
6.21.2.1 Opening the settings menu 133
6.21.2.2 Closing the settings menu 133
6.21.2.3 Clearing the journey information 134
6.22 Brake 135
6.22.1 Using the brake lever 135
6.23 Suspension and damping 136
6.23.1 Adjusting the Suntour compression adjuster 137
6.23.1.1 Adjusting the RockShox compression adjuster 138
6.24 Gear shift 139
6.24.1 Using the derailleur gears 139
6.25 Gear shift 140
6.25.1 Using the belt gear shift 140
6.26 Parking 142
6.26.1 Screwing in the All Up handlebars 142
7 Cleaning, servicing and maintenance
7.1 Before each ride 148
7.1.1 Checking the guards 148
7.1.2 Checking the frame 148
7.1.3 Checking the fork 148
7.1.4 Checking the rear frame damper 148
7.1.5 Checking the pannier rack 148
7.1.6 Checking the guards 148
7.1.7 Checking wheel concentricity 148
7.1.8 Checking the quick releases 148
7.1.9 Checking the suspension seat post 148
7.1.10 Checking the bell 149
7.1.11 Checking the handles 149
7.1.12 Checking the USB cover 149
7.1.13 Checking the lighting 149
7.1.14 Checking the brake 149
7.2 After each ride 150
7.2.1 Cleaning the lights and reflectors 150
7.2.2 Cleaning the suspension fork 150
7.2.3 Caring for the suspension fork 150
7.2.4 Cleaning the pedals 150
7.2.5 Cleaning the brake 150

MY22H03 - 22_1.0_01.10.2021 6
Contents
7.2.6 Cleaning the suspension seat post 150
7.2.7 Cleaning the rear frame damper 150
7.3 Basic cleaning 151
7.3.1 On-board computer and control panel 151
7.3.2 Rechargeable battery 151
7.3.3 Motor 151
7.3.4 Frame, fork, pannier rack, guards and kickstand 152
7.3.5 Stem 152
7.3.6 Handlebars 152
7.3.7 Handles 152
7.3.7.1 Leather handles 152
7.3.8 Seat post 152
7.3.9 Saddle 152
7.3.9.1 Leather saddle 153
7.3.10 Tyres 153
7.3.11 Spokes and spoke nipples 153
7.3.12 Hub 153
7.3.13 Switching elements 153
7.3.13.1 Shifter 153
7.3.14 Cassette, chain wheels and front derailleur 153
7.3.15 Brake 154
7.3.15.1 Brake lever 154
7.3.16 Brake disc 154
7.3.17 Belt 154
7.3.18 Chain 154
7.3.18.1 Chain with all-round chain guard 154
7.4 Servicing 155
7.4.1 Frame 155
7.4.2 Fork 155
7.4.3 Pannier rack 156
7.4.4 Mudguard 156
7.4.5 Servicing the kickstand 156
7.4.6 Stem 156
7.4.7 Handlebars 156
7.4.8 Handle 156
7.4.8.1 Rubber handles 156
7.4.8.2 Leather handle 156
7.4.9 Seat post 157
7.4.9.1 Suspension seat post 157
7.4.9.2 Carbon seat post 157
7.4.10 Rim 157
7.4.11 Leather saddle 157
7.4.12 Hub 157
7.4.13 Spoke nipples 157
7.4.14 Gear shift 158
7.4.14.1 Rear derailleur articulated shafts and jockey wheels 158
7.4.14.2 Shifter 158
7.4.15 Pedal 158
7.4.16 Caring for the chain 158
7.4.16.1 Caring for the chain and all-round chain guard 159
7.4.17 Caring for the battery 159
7.4.18 Caring for the brake 159
7.4.18.1 Caring for the brake 159
7.4.19 Lubricating the Eightpins seat post tube 159
7.5 Maintenance 160
7.5.1 Wheel 160
7.5.1.1 Checking the tyre pressure 160
7.5.1.2 Checking the tyres 162
7.5.1.3 Checking the rims 163

MY22H03 - 22_1.0_01.10.2021 7
Contents
7.5.1.4 Checking the nipple holes 163
7.5.1.5 Checking the nipple well 163
7.5.1.6 Checking the rim hooks 163
7.5.1.7 Checking the spokes 163
7.5.2 Checking the brake system 164
7.5.2.1 Checking the hand brake 164
7.5.2.2 Checking the hydraulic system 164
7.5.2.3 Checking the Bowden cables 164
7.5.2.4 Checking the disc brake 165
7.5.2.5 Checking the back-pedal brake 166
7.5.2.6 Checking the rim brake 167
7.5.3 Checking the lighting 168
7.5.4 Checking the stem 169
7.5.5 Check the handlebars 169
7.5.6 Checking the saddle 169
7.5.7 Checking the seat post 169
7.5.8 Checking the chain 169
7.5.9 Checking the chain and belt tension 169
7.5.9.1 Checking the derailleur gears 170
7.5.9.2 Checking the hub gear 170
7.5.10 Checking the gear shift 170
7.5.10.1 Electric gear shift 170
7.5.10.2 Mechanical gear shift 170
7.5.10.3 Checking the derailleur gears 170
7.5.11 Adjusting gear shift 171
7.5.11.1 ROHLOFF hub 171
7.5.12 Bowden-cable-operated gear shift, single-cable 171
7.5.13 Bowden-cable-operated gear shift, dual-cable 171
7.5.14 Bowden-cable-operated twist grip, dual-cable 172
7.5.15 Checking kickstand stability 172
8 Maintenance
8.1 Initial inspection 173
8.2 Maintenance 173
8.3 Component-specific maintenance tasks 173
8.4 Carry out initial inspection 176
8.5 Maintenance instructions 177
8.5.1 Servicing the frame 184
8.5.1.1 Servicing the carbon frame 184
8.5.2 Checking the pannier rack 184
8.5.3 Servicing axle with quick release 184
8.5.4 Maintaining the stem 185
8.5.5 Servicing the gear hub 185
8.5.5.1 Adjusting the hub with cone bearing 185
8.5.6 Servicing the steering headset 186
8.5.7 Servicing the fork 186
8.5.7.1 Servicing the carbon suspension fork 187
8.5.7.2 Servicing the suspension fork 187
8.5.8 Servicing seat post 188
8.5.8.1 Servicing the carbon seat post 188
8.5.8.2 by.schulz suspension seat post 189
8.5.8.3 Suntour suspension seat post 189
8.5.8.4 eightpins NGS2 seat post 190
8.5.8.5 eightpins H01 seat post 196
8.5.9 Rear frame damper 200
8.5.9.1 FOX component-specific maintenance 201
9 Troubleshooting, fault clearance and repair
9.1 Troubleshooting and fault clearance 202

MY22H03 - 22_1.0_01.10.2021 8
Contents
9.1.1 The drive system or display do not start up 202
9.1.2 RD protection reset 202
9.1.3 Warning messages and LEDs 202
9.2 Assistance function 203
9.3 Rechargeable battery 204
9.4 Lighting 205
9.4.1 On-board computer error 205
9.5 Miscellaneous 206
9.5.1 Other errors 207
9.5.2 Suntour suspension fork 208
9.5.2.1 Rebound too fast 208
9.5.2.2 Rebounding too slowly 209
9.5.2.3 Suspension too soft on inclines 210
9.5.2.4 Excessively hard damping on bumps 211
9.5.3 RockShox suspension fork 212
9.5.3.1 Rebound too fast 212
9.5.3.2 Rebounding too slowly 213
9.5.3.3 Suspension too soft on inclines 214
9.5.3.4 Excessively hard damping on bumps 215
9.5.4 Rear frame damper 216
9.5.4.1 Rebound too fast 216
9.5.4.2 Rebounding too slowly 217
9.5.4.3 Suspension too soft on inclines 218
9.5.4.4 Excessively hard damping on bumps 219
9.5.5 RockShox rear frame damper 220
9.5.5.1 Rebound too fast 220
9.5.5.2 Rebounding too slowly 221
9.5.5.3 Suspension too soft on inclines 222
9.5.5.4 Excessively hard damping on bumps 223
9.6 Repair 224
9.6.1 Original parts and lubricants 224
9.6.2 Replacing the lighting 224
9.6.3 Setting the front light 224
9.6.4 Checking tyre clearance 224
10 Recycling and disposal
10.1 Removal of waste guidelines 225
11 Documents
11.1 Assembly report 227
11.2 Maintenance log 229
11.2.1 Edison Comp I-12 233
11.2.2 Edison GR I-11 235
11.2.3 Edison Comp I-12 237
11.2.4 Nos FS SUV 2.1 239
11.2.5 Nos FS SUV 2.2 241
11.2.6 Nos SUV 2.1 243
11.2.7 Nos SUV 2.2 245
12 Glossary
12.1 Abbreviations 250
12.2 Simplified terms 250
13 Appendix
I. Translation of the original EC/EU Declaration of Conformity 251
1.1 RED Declaration of Conformity 253
14 Keyword index

MY22H03 - 22_1.0_01.10.2021 9
About these operating instructions
Thank you for your trust!
HERCULES pedelecs are premium quality
bicycles. You have made an excellent choice.
Your specialist dealer will provide you with
guidance and instruction and assemble your
product. Your specialist dealer will also be happy
to assist you in the future, whether you require
maintenance, conversion or repair.
You are receiving these operating instructions
with your new pedelec. Please take time to
become familiar with your new pedelec. Use the
tips and suggestions in the operating instructions.
They will help you to enjoy your pedelec for a long
time to come. We hope you have fun and wish you
well on all of your rides!
Download the operating instructions onto your
phone at the following link, so that you can use
them when you are out riding:
https://www.hercules-bikes.de/de/de/index/
downloads.html.
Copyright
© HERCULES GmbH
Distribution or reproduction of these operating
instructions and utilisation or communication of
their content is prohibited unless expressly
approved. Any infringement will render the
offender liable for compensation. All rights
reserved in the event that a patent, utility model or
industrial design is registered.
Subject to internal changes
The information contained in these operating
instructions are the approved technical
specifications at the time of printing. In addition to
the functions described here, software changes
may be introduced to rectify errors and extend
functions at any time.
Any significant changes are included in a new
published version of the operating instructions. All
changes to the operating instructions are
published on the following website:
https://www.hercules-bikes.de/de/de/index/
downloads.html
Editing
Text and images:
ZEG Zweirad-Einkaufs-Genossenschaft eG
Longericher Strasse 2
50739 Köln, Germany
Translation
RKT Übersetzungs- und Dokumentations-GmbH
Bahnhofstrasse 27
78713 Schramberg, Germany
In case of any questions or problems
regarding these operating instructions,
please contact:
[e-mail]

MY22H03 - 22_1.0_01.10.2021 10
About these operating instructions
1 About these operating instructions
1.1 Manufacturer
HERCULES GMBH
Longericher Straße 2
50739 Köln, Germany
Tel.: [phone]
Fax: [phone]
Email: [email protected]
1.2 Laws, standards and directives
The operating instructions comply with the
essential requirements specified in:
• Machinery Directive 2006/42/EC
• Electromagnetic Compatibility
Directive 2014/30/EU
• ISO 20607:2018 Safety of machinery– Operating
instructions– General drafting principles
• EN 15194:2018 Cycles – Electrically power
assisted cycles – pedelec bicycles
• EN 11243:2016, Cycles – Luggage carriers for
bicycles – Requirements and test methods
• ISO 17100:2016-05 Translation Services –
Requirements for translation services.
1.3 Language
The original operating instructions are written in
German. A translation is invalid without the
original operating instructions.
1.4 For your information
Different markings are used in the operating
instructions to make them easier to read.
1.4.1 Warnings
Warnings indicate hazardous situations and
actions. You will find three warnings in the
operating instructions:
1.4.2 Markups
You will find ten text markups in the operating
instructions:
May lead to serious or even fatal injuries if ignored. Medium-
risk hazard.
May lead to minor or moderate injuries if ignored. Low-risk
hazard.
Notice
May lead to material damage if ignored.
Stylised form Use
Italics Glossary term, first mention in
section
Underlined in blue Link
Underlined in grey Cross references
Requirements
Instructions for actions without
specific order
6Instructions for actions in
specified order
Result of action step
BLOCKED On-board computer indicators
• Bulleted lists
Only applies to pedelecs
with this equipment
Each type has a different kind
of equipment. A note beneath
the heading indicates
components which can be used
as an alternative.
Table 1: Markups
WARNING
!
CAUTION
!

MY22H03 - 22_1.0_01.10.2021 11
About these operating instructions
1.5 Type number and model
These operating instructions are an integral part of
pedelecs with the type numbers:
1.6 Frame number
Each frame has an individual frame number
stamped on it (see Figure 2). The frame number
can be used to associate the pedelec with the
owner. The frame number is the most important
identifier for verifying ownership.
1.7 Identifying the operating
instructions
The operating instructions identification number is
located in bottom left-hand corner of each page.
The identification number is composed of the
document number, the version number and the
release date.
Type no. Model Pedelec type
22-Q-0007 Edison Sport I-10,
Diamant City and trekking bicycle
22-Q-0008 Edison Sport I-10, Trapez City and trekking
bicycle
22-Q-0009 Edison Sport I-10, Wave City and trekking
bicycle
22-Q-0049 Nos FS SUV 2.1 Mountain bike
22-Q-0050 Nos FS SUV 2.2 Mountain bike
22-Q-0051 Nos SUV 2.1, Diamant Mountain bike
22-Q-0052 Nos SUV 2.1, Trapez Mountain bike
22-Q-0053 Nos SUV 2.1, Wave Mountain bike
22-Q-0054 Nos SUV 2.2, Diamant Mountain bike
22-Q-0055 Nos SUV 2.2, Trapez Mountain bike
22-Q-0056 Nos SUV 2.2, Wave Mountain bike
22-Q-0097 Edison Comp I-12,
Diamant City and trekking bicycle
22-Q-0098 Edison Comp I-12, Trapez City and trekking
bicycle
22-Q-0099 Edison Comp I-12, Wave City and trekking
bicycle
22-Q-0103 Edison GR I-11, Diamant City and trekking
bicycle
22-Q-0109 Edison GR I-11, Wave City and trekking
bicycle
Table 2: Type number, model and pedelec type
Identification number MY22H03 - 22_1.0_01.10.2021

MY22H03 - 22_1.0_01.10.2021 12
About these operating instructions
1.8 Aim of the operating instructions
These operating instructions are not a substitute
for personal instruction by the specialist dealer
supplying the bike. These operating instructions
are an integral part of the pedelec. Therefore, if it
is re-sold at a later time, they must be handed
over to the subsequent owner.
These operating instructions are mainly designed
for riders and operators of the pedelec.
Paragraphs with a white background are intended
to enable non-professionals to make safe settings
on the pedelec, use it, clean it and identify and
eliminate any faults.
Sections intended for technical staff are
highlighted in blue and marked with a spanner
symbol.
These paragraphs aim to allow trained technical
staff (bicycle mechatronics engineers, bicycle
mechanics or similar) to carry out initial
assembly, adjustment, maintenance and repair
safely.
Technical staff also need to read all sections for
riders and operators to ensure they can provide
a better customer service.
All documents in Section 11 need to be filled out
whenever any work is performed on the vehicle
(assembly report, maintenance report).
Section
Rider Specialist dealer
1About these instructions  
2Safety  
3Description  
4 Transportation and storage  
5 Assembly and installation 
6Operation  
7Cleaning and servicing  
8Maintenance  
9.1 Troubleshooting and fault clearance 
9.2 Repair 
10 Disassembly and disposal  
11 Documents 
12 Glossary  
13 Appendix 
14 Keyword index 
Table 3: Target groups-section matrix

MY22H03 - 22_1.0_01.10.2021 13
Safety
2 Safety
2.1 Residual risks
2.1.1 Risk of fire and explosion
2.1.1.1 Rechargeable battery
The safety electronics may fail if the batteries are
damaged or faulty. The residual voltage can
cause a short circuit. The battery may self-ignite
and explode.
Only use and charge the battery and
accessories if they are in perfect condition.
Never open or repair the battery.
Batteries with external damage must be
removed from service immediately.
If a battery is dropped or struck, remove it from
service and keep it under observation for at
least 24 hours.
If a charger is connected to the drive system
when the drive system reports a critical error, the
battery may be damaged permanently and may
catch fire.
Connect charger to error-free drive system
only.
The battery is only protected from spray water.
Penetration by water can cause a short circuit.
The battery may self-ignite and explode.
Never immerse battery in water.
Take battery out of service if you suspect
water has penetrated it.
Temperatures over 60 °C can also cause liquid to
leak from the battery and the battery will become
damaged. The battery may self-ignite and
explode.
Protect the battery against heat.
Never store next to hot objects.
Never expose battery to continuous direct
sunlight.
Avoid wide temperature fluctuations.
Chargers with excessive voltage damage
batteries. This may cause a fire or an explosion.
Only use approved batteries to charge.
Metal objects may interconnect the battery's
electrical terminals. The battery may self-ignite
and explode.
Never insert paper clips, screws, coins, keys
and other small parts into the battery.
Place the battery on clean surfaces only.
Prevent charging socket and contacts against
contamination from dirt, sand and similar.
Faulty batteries are hazardous goods.
Dispose of faulty batteries in the correct
manner.
Store battery in a dry place until disposal.
Never store near flammable substances.
2.1.1.2 Overheated charger
The charger heats up when charging the battery.
If the battery is not allowed to cool down
sufficiently, it can cause a fire or burns to the
hands.
Never use charger on a highly flammable
surface.
Never cover the charger during charging.
Never leave battery unattended during
charging.
2.1.1.3 Hot components
The brakes and the motor may become very hot
during operation. There is a risk of burns or fire in
case of contact.
Never touch the brakes or the motor
immediately after a ride.
Never place the pedelec on a flammable
surface, such as grass or wood, directly after
use.

MY22H03 - 22_1.0_01.10.2021 14
Safety
2.1.2 Electric shock
2.1.2.1 Damage
Damaged chargers, cables and plug connectors
increase the risk of electric shock.
Check the charger, cable and plug connector
before each use. Never use a damaged
charger.
2.1.2.2 Water penetration
If water penetrates into the charger, there is a risk
of electric shock.
Never charge the battery outdoors.
2.1.2.3 Condensation
Condensation may form in the charger and battery
when the temperature changes from cold to hot,
causing a short circuit.
Wait until both charger and battery are at room
temperature before connecting them.
2.1.3 Risk of a crash
2.1.3.1 Incorrect quick release setting
Excessively high clamping force will damage the
quick release and cause it to lose its function.
Insufficient clamping force will result in
unfavourable transmission of force. This can
cause components to break. This will cause a
crash with injuries.
Never fasten a quick release using a tool (e.g.
hammer or pliers).
Only use the clamping lever with the specified
set clamping force.
2.1.3.2 Incorrect tightening torque
If a screw is fastened too tightly, it may break. If a
screw is not fastened enough, it may loosen. This
will cause a crash with injuries.
Always observe the indicated tightening torque
on the screw or in the operating instructions.
2.1.3.3 Incorrect component
The wheels are designed exclusively for use with
rim brakes or disc brakes. The wheel may break if
an incorrect brake is used. This will cause a crash
with injuries.
Never use the wheel with a different brake.
2.1.4 Risk of amputation
The brake disc in disc brakes is so sharp that it
can cause serious injuries to fingers if they are
inserted into the brake disc openings.
Always keep fingers well away from the
rotating brake discs.
2.1.5 Key breaking off
If you leave a key inserted when riding or
transporting the pedelec, it may break off or the
locking system may open accidentally.
Remove the key to the battery lock.

MY22H03 - 22_1.0_01.10.2021 15
Safety
2.1.6 Malfunctions due to Bluetooth®
If you use the on-board computer with Bluetooth®
and/or Wi-Fi®, it may cause interference with
other devices, other equipment, aircraft and
medical devices, such as pacemakers and
hearing aids.
Likewise, harm to people and animals in the
immediate vicinity cannot be completely excluded.
Never use the pedelec with Bluetooth® when
in close proximity to medical devices, filling
stations, chemical plants, areas at risk of
explosion and in blasting zones.
Never use pedelec with Bluetooth® in aircraft.
Avoid operating for longer periods in close
proximity to the body.

MY22H03 - 22_1.0_01.10.2021 16
Safety
2.2 Toxic substances
2.2.1 Brake fluid
Brake fluid may leak out after an accident or due
to material fatigue. Brake fluid can be fatal if
swallowed or inhaled.
Never dismantle the brake system.
Avoid contact with skin.
Do not inhale vapours.
2.2.2 Suspension oil
Suspension oil in the fork and the rear frame
damper is toxic to the touch, irritates respiratory
tracts and can cause cancer, sterility and changes
to the genetic make-up of germ cells.
Never dismantle the rear frame damper or the
suspension fork.
Avoid skin coming into contact with suspension
oil.
2.2.3 Lubrication oil
eightpins seat post lubrication oil is toxic if inhaled
and can be fatal if swallowed.
Never remove the eightpins seat post from the
frame.
Lubricate seat post in the open air or in a well-
ventilated room only.
Avoid skin coming into contact with lubrication
oil. Wear nitrile gloves when lubricating,
cleaning and servicing the vehicle.
2.2.4 Defective battery
Liquids and vapours may leak from damaged or
faulty batteries. Excessively high temperatures
may also cause liquids and vapours to leak from
the battery. Such liquids and vapours can irritate
the airways and cause burns.
Never dismantle the battery.
Avoid contact with skin.
Do not inhale vapours.
2.3 Requirements for riders
The rider must have the required mental capacity
and physical and motor skills to ride on public
roads. A minimum age of 14 years is
recommended.
2.4 Vulnerable groups
Keep batteries and the charger away from
children and people with reduced physical,
sensory or mental capacities or lacking in
experience and knowledge.
If minors use the pedelec, a legal guardian must
should provide them with comprehensive
instructions.
2.5 Personal protective equipment
Wear a suitable helmet for your protection. The
helmet must have a reflective strip or a light in a
clearly visible colour.
Wear sturdy shoes.
Clothing should be retroreflective or as light as
possible. Fluorescent materials are also suitable.
High-visibility jackets and straps on your upper
body ensure even greater safety. Never wear a
skirt. Always wear trousers which reach down to
your ankles instead.
2.6 Safety guards
Three safety guards protect riders against heat or
moving parts:
• Chain or belt guards prevent clothing from being
pulled into the drive train
• Mudguards protect against dirt and water
splashing up from the road.
• Motor covers on the motor casing protect against
heat.
Never remove the guards.
Check the guards on a regular basis.
Take pedelec out of service if a guard is
damaged or missing. Contact specialist dealer.

MY22H03 - 22_1.0_01.10.2021 17
Safety
2.7 Safety markings and safety
instructions
The pedelec and battery nameplates contain
these safety markings and safety instructions:
2.8 What to do in an emergency
2.8.1 Dangerous situation in road traffic
In the event of any hazards or dangers in road
traffic, apply the brakes on the pedelec until it
comes to a halt. The brake acts as an
emergency stop system in such cases.
2.8.2 Leaked brake fluid
Remove those affected from the danger area to
fresh air.
Never leave those affected unattended.
Remove any clothing contaminated with brake
fluid immediately.
Never inhale vapours. Ensure sufficient
ventilation.
Wear gloves and safety gloves as protective
equipment.
Keep unprotected persons away.
Take care with leaked brake fluid as it poses a
slip hazard.
Keep leaking brake fluid away from naked
flames, hot surfaces and sources of ignition.
Avoid contact with skin and eyes.
After inhalation
Take in fresh air. Immediately consult a doctor
in case of any discomfort.
After skin contact
Wash affected skin with soap and water and
rinse well. Remove contaminated clothing.
Consult doctor in the event of pain or
discomfort.
After contact with eyes
Rinse eyes under flowing water for at least ten
minutes with the lids open; also rinse under
lids. Immediately consult a doctor in case of
any pain or discomfort.
Symbol Explanation
General warning
Adhere to the instructions for use
Table 4: Meaning of safety markings
Symbol Explanation
Read the instructions
Separate collection of electrical
and electronic devices
Separate collection of ordinary
and rechargeable batteries
Must not be thrown into fire
(burning prohibited)
It is forbidden to open any
batteries
Device of protection class II
Only suitable for use indoors
Fuse (device fuse)
EU conformity
Recyclable material
Protect from temperatures
above 50 °C and direct sunlight
Table 5: Safety instructions
max. 50°C

MY22H03 - 22_1.0_01.10.2021 18
Safety
After swallowing
Rinse out mouth with water. Never induce
vomiting. Risk of aspiration.
If a person is lying on their back and vomiting,
place them in the recovery position. Seek
medical advice immediately.
Environmental protection measures
Never allow brake fluid to flow into the sewage
system, water courses or groundwater.
Notify the relevant authorities if fluid
penetrates the ground, water courses or the
sewage system.
Dispose of leaked brake fluid in an
environmentally responsible way in accordance
with statutory regulations (see Section 10.1).
The brake system must be repaired
immediately if brake fluid leaks out. Contact
specialist dealer.
2.8.3 Battery vapours emitted
Vapours may be emitted if the battery is damaged
or used improperly. The vapours may cause
respiratory tract irritation.
Get into fresh air.
Consult doctor in the event of pain or
discomfort.
After contact with eyes
Carefully rinse eyes with plenty of water for at
least 15 minutes. Protect unaffected eye. Seek
medical advice immediately.
After skin contact
Remove any solid particles immediately.
Rinse the affected area with plenty of water for
at least 15 minutes. Then dab the affected skin
gently. Do not rub dry.
Remove contaminated clothing immediately.
Immediately consult a doctor if there is any
redness, pain or discomfort.
2.8.4 Battery fire
The safety electronics may fail if the battery is
damaged or faulty. The residual voltage can
cause a short circuit. The battery may self-ignite
and explode.
1Keep your distance if the battery becomes
deformed or starts to emit smoke.
2If charging, remove the plug connector from
the socket.
3Contact the fire service immediately.
Use Class fire extinguishers to put out the fire.
Never extinguish damaged batteries with water
or allow them to come into contact with water.
Inhaling vapours can cause intoxication.
Stand on the side of the fire where the wind is
blowing from.
Use breathing apparatus if possible.
2.8.5 Oil and lubricant leaks from the rear
frame damper
Dispose of leaked oils and lubricants in an
environmentally responsible way in
accordance with statutory regulations (see
Section 10.1).
Contact specialist dealer.
2.8.6 Oil and lubricant leaks from the fork
Dispose of leaked oils and lubricants in an
environmentally responsible way in
accordance with statutory regulations (see
Section 10.1).

MY22H03 - 22_1.0_01.10.2021 19
Description
3 Description
3.1 Proper use
All check lists and instructions for actions in these
operating instructions must be met. Approved
accessories can be installed by specialist staff.
Use the pedelec when it is in perfect, proper
working order only. National requirements may
apply to the pedelec which the standard
equipment may not meet. Different regulations
apply across the country to the riding light,
reflectors and other components when riding on
public roads. The general laws and the
regulations for the prevention of accidents and
environmental protection in the respective country
of use must be adhered to.
The rechargeable batteries are designed to
supply power to the pedelec motor only. Never
use the batteries for other purposes.
Each pedelec is assigned a pedelec type, which
determines its proper use, function and area of
use.
City and trekking
bicycles
Child's bicycles/
bicycles for young
adults
Mountain bikes Racing bicycle Cargo bike Folding bicycle
City and trekking
bicycles are designed
for comfortable, daily
use and are suitable
for riding on public
roads.
Cycles for children
and young adults are
suitable for riding on
public roads.
Legal guardians must
read the operating
instructions before
putting the bike into
use. Tell children and
young people what
the operating
instructions contain
in a way appropriate
to their age.
Check the size of the
pedelec every 3
months for ortho-
paedic reasons.
Check compliance
with the maximum
permitted total weight
(PTW) every 3
months.
Mountain bikes are
designed for sports
use. The design char-
acteristics include a
short wheelbase, a
sitting position with
the rider inclined
towards the front, and
a brake requiring low
actuation force.
Mountain bikes are
sports bikes and not a
means of transport.
They require an
adaptation period in
addition to physical
fitness. Learning how
to ride a mountain
bike takes practice,
especially braking
and riding around
bends.
The strain on hands,
wrists, arms, shoul-
ders, the neck and
back is considerable.
Inexperienced riders
tend to brake too hard
and lose control as a
result.
Racing bikes are
designed for fast
rides on roads and
paths with a good,
undamaged road
surface.
Racing bikes are
sports bikes and not a
means of transport.
Racing bikes are
characterised by their
lightweight structure
and a design which is
stripped to the
minimum parts
required for riding.
The frame geometry
and the layout of the
operating elements
are designed to allow
the bike to be ridden
at high speeds.
Learning how to ride
slowly, apply the
brakes and get on
and off the bike safely
takes practice due to
the frame design.
The sitting position is
athletic. The physical
strain on hands,
wrists, arms, shoul-
ders, the neck and
back is considerable.
The sitting position
requires a high level
of physical fitness.
Cargo bikes are suit-
able for transporting
loads on public roads
on a daily basis.
The transportation of
loads requires skill
and physical fitness
in order to balance
the additional weight.
The very varied
loading conditions
and weight distribu-
tions require special
practice and skill
when braking and
riding in bends.
A longer period is
required to adaptation
to the length, width
and turning circle.
You need to be
cautious when riding
a cargo bike. You
must pay attention to
traffic on public roads
and the condition of
the route.
Folding bicycles are
suitable for riding on
public roads.
Folding bikes can be
folded together and
thus save space
when they are trans-
ported, e.g. in cars or
on local transport.
The folding function
of the folding bicycle
makes it necessary to
use smaller wheels
and longer brake
cables and Bowden
cables. Therefore, in
case of an increased
load, a reduction in
riding stability and
braking power, dimin-
ished comfort and
reduced durability are
to be expected.
Table 6: Proper use for each pedelec type
