Shimano STEPS E6000 User manual
Original User Guide
Version 1 | 04.01.2017
SHIMANO STEPS E6000
BATTERY AND CHARGER
© Copyright, reprinting, reproduction and distribution, even in part, only with the permission of Derby Cycle Werke GmbH.
Subject to misprints, errors and technical alterations.
DERBY CYCLE WERKE GMBH
Siemensstraße 1-3
49661 Cloppenburg, Germany
+ 49 (4471) 966-0
www.derby-cycle.com
www.kalkhoff-bikes.de
EN-2 Original User Guide | Pedelec Shimano Steps E6000 Version 1
Notes
User guides, service book and declarations of conformity
are available for download in PDF format at:
www.derby-cycle.com/en/downloads/downloads.html
Find a retailer in your area:
http://www.kalkho-bikes.com/en/service/dealer-search.html
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-3
I.Introduction EN-4
I.I Explanationofthe
safetyinformationsymbols EN-4
I.II ThePedelecShimano
StepsE6000 EN-5
II.Informationpack EN-5
II.I Shimanooriginaluserguide EN-5
II.II BookletandCD EN-6
II.III Componentguides EN-6
II.IV Servicebook EN-7
II.V EUdeclarationsofconformity EN-7
II.VI Guaranteecard* EN-7
III.Cycledealers EN-7
IV.Legalregulationsforpedelecs EN-7
IV.I International EN-7
IV.II Germany EN-8
IV.II.I Lights EN-8
IV.II.I.I Replacement bulbsEN-9
IV.II.II Disposal EN-9
V.Intendeduse EN-10
V.I Pedelec EN-10
VI.Pedelecweight* EN-10
VI.I Overallweight EN-10
1.Generalsafetyinformation EN-11
2.Protectionfromtheft,manipulation
andloss EN-13
3.Beforeyourrstride EN-14
3.1 Attachingthepedals EN-14
3.2 Adjustingthesaddleheight EN-15
3.2.1 Determining the correct
saddle height EN-15
3.2.2 Adjusting the saddle height:
Saddle clamp bolt(s)* EN-15
3.2.3 Adjusting the saddle height:
Quick-release skewer* EN-16
3.3 Shiftingandtiltingthesaddle EN-17
3.3.1 Single-screw support:
Shifting and tilting the saddle EN-17
3.3.2 Twin-screw supports: Shifting
and tilting the saddle EN-18
3.3.3 Clamp attachment: Shifting
and tilting the saddle EN-18
3.4 Adjustingthesprungseatpost EN-19
3.5 Adjustingtheheightand
angleofthehandlebars EN-19
3.6 Switchingthelightsonando* EN-19
3.7 Braking EN-19
3.8 Chain* EN-20
3.8.1 Measuring and adjusting
the chain tension EN-21
3.8.2 Checking for chain wear EN-21
3.8.3 Chain cleaning and
maintenance EN-21
3.9 Gears EN-22
3.10 Wheel EN-23
3.10.1 Changing the wheel EN-23
3.10.1.1 Wheel with axle nuts* EN-23
3.10.2 Quick-release wheels* EN-23
3.10.3 Wheel with axle shaft* EN-25
3.10.4 Rims EN-26
3.10.5 Tyres EN-27
3.11 Suspensionfork* EN-27
3.11.1 Compression rate EN-27
3.11.2 Rebound damping EN-27
3.11.3 Lockout system EN-27
3.11.4 Air system* EN-28
4.Beforeeverytrip EN-28
4.1 Tips EN-29
4.1.1 Transporting your pedelec EN-29
4.1.2 Trailer bikes and trailers EN-29
4.1.3 Luggage rack EN-30
4.1.3.1 Safety information EN-30
5.Battery EN-31
5.1 Safetyinformation EN-31
5.2 Technicaldetails EN-34
5.3 Overviewandbasicfunctions EN-34
5.3.1 Display panel EN-35
5.3.1.1 Battery charge level EN-35
5.3.1.2 Capacity EN-35
5.3.1.3 Sleep mode EN-36
5.3.2 Inserting and locking the battery EN-36
5.3.3 Unlocking and removing
the battery EN-37
5.4 Tips EN-37
5.4.1 Range EN-37
5.4.2 Storage EN-38
5.4.3 Cleaning EN-38
6.Batterycharger EN-39
6.1 Safetyinformation EN-39
6.2 Technicaldetails EN-41
6.3 Functions EN-41
6.3.1 Charging the battery EN-41
6.3.1.1 Battery display during charging EN-42
6.4 Tips EN-43
6.4.1 Cleaning EN-43
6.4.2 Storage EN-43
7.Fault EN-44
7.1 Battery EN-44
7.2 Charger EN-46
8.Torquesettings EN-46
CONTENTS
*dependent on model
EN-4 Original User Guide | Pedelec Shimano Steps E6000 Version 1
I. Introduction
This user guide contains information on how to use, maintain and look
after the battery and battery charger of your Pedelec Shimano Steps
E6000.
DANGER
Beforeusingyourpedelecforthersttime,carefullyreadthisuser
guide.Pleasealsoreadtheotheritemsintheinformationpack
II. Information pack Page EN-5.Familiariseyourselfwiththe
appearanceandmeaningofthesafetyinformationsymbols. Ensure to
contact your cycle dealer III. Cycle dealers Page EN-7 in the event
clarication is required. Failure to comply with safety symbols and
instructions can result in death, very serious injuries and/or damage
to the bicycle. The manufacturer's liability and any warranty are
deemed null and void for any damage or injury caused by a failure to
adhere to safety symbols and instructions.
Ensurethatyourcycledealerhasprovidedyouwithallthedocuments
includedwiththebikeupondelivery.Keepthisusermanualandthe
otherdocumentsintheinformationpackforfuturereference.Please
passontheusermanualandinformationpacktootherpeoplewho
willuse,maintainorrepairthispedelec.Failure to do so can lead to
uncertainty which may cause death, severe injuries and/or damage to
equipment.
You can download this guide, the “Original
User Guide | General” and parts of the
information pack as PDFs from our website
(www.derby-cycle.com/en/downloads/
downloads.html). There you will also
nd links to the websites of the various
component manufacturers.
You will nd a dealer's user guide for our
cycle dealers on si.shimano.com.
I.I Explanationofthesafetyinformationsymbols
DANGER
This symbol combined with the signal word "DANGER" indicates
a potentially dangerous situation. Failure to comply with this safety
instruction can result in death or very serious injuries.
WARNING
This symbol in conjunction with the signal word "WARNING"
indicates a potentially dangerous situation. Failure to comply with
this safety warning can result in serious injury.
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-5
I.II ThePedelecShimanoStepsE6000
Your Pedelec Shimano Steps E6000 is an EPAC (electrically power assisted
cycle). When the assist mode is switched on, the electric motor provides
assistance as long as you are pedalling. You can control the degree of
assistance, which is adjusted using various assist modes. The drive
assistance is dependent on the force and speed of your pedalling and the
speed you are travelling. Motor assist stops as soon as you stop pedalling
and when the battery is discharged or if you reach a speed of 25 km/h. So
pedalling harder is required if you want to travel faster than 25 km/h.
II. Informationpack
In addition to this user guide, your Pedelec Shimano Steps E6000 comes
with a Shimano original user guide, booklet and CD, service book, two
declarations of conformity and component guides, and if you have bought
a Kalkho or Raleigh pedelec, a guarantee card. The following points
describe the contents of the information pack in more detail.
II.I Shimanooriginaluserguide
The Shimano original user guide contains information on the display and
the Pedelec motor. You can download the guide in dierent languages from
si.shimano.com.
CAUTION
This symbol combined with the signal word "CAUTION" indicates
a potentially dangerous situation. Failure to comply with this safety
instruction can result in minor injuries.
IMPORTANT
This symbol combined with the signal word "IMPORTANT"
indicates a potentially dangerous situation. Failure to comply with
this safety instruction can result in damage to the pedelec and its
components.
This symbol indicates helpful tips, useful or important
information about the product or its additional uses. It does
not indicate a dangerous or harmful situation.
EN-6 Original User Guide | Pedelec Shimano Steps E6000 Version 1
You will need the Adobe Acrobat Reader software to read
the manuals. It is included on the CD; you can also download
it for free from https://acrobat.adobe.com/uk/en/acrobat/
pdf-reader.html.
The paper version of ‘Original User Guide | General’ can be
ordered free of charge from:
Derby Cycle Werke GmbH
Siemensstraße 1-3
49661 Cloppenburg, Germany
II.III Componentguides
In the component guides you will nd important information on using and
maintaining the components of your pedelec. They often also provide
information on any warranties. If there is no specic user guide included
for the particular component you are interested in, look in our “Original
User Guide | General” (CD) II.II Booklet and CD Page EN-6 or on
the component manufacturer's website. You can also nd
a list of our component manufacturers at
www.derby-cycle.com/en/downloads/downloads.html.
II.II Booklet and CD
The booklet contains a “Quick-start guide” describing how to check the
torque settings, attach the pedals and adjust the height of the saddle. At
the back of the booklet is a CD. The CD includes the "Original User Manual
| General" in several languages, which provides general information on
the dierent types of bikes and their components. If you go online you can
follow a link to our website. The CD can be played on any standard PC or
laptop. Proceed as follows:
Method A
1. Insert the CD.
2. Left-click the shelexec.exe le twice.
3. Select the required language.
4. Select "Open User Guide from CD" or "Check Online for New Version of
User Guide".
Method B
1. Insert the CD.
2. Right-click once "Open Folder to Show Files".
3. Left-click "Start" twice.
4. Select the required language.
5. Select "Open User Guide from CD" or "Check Online for New Version of
User Guide".
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-7
III. Cycle dealers
Ask our cycle dealers for advice. On Page 2 you will nd a link to the brand
website with all cycle dealers in your region.
IV. Legalregulationsforpedelecs
IV.I International
DANGER
Neverride"handsfree".You could fall o and seriously injure or even
kill yourself – and also be liable for prosecution. You must always
have at least one hand on the handlebars.
Alwaysobservetherelevantnationaltracregulations.Otherwise
you run the risk of a serious accident. Before using your pedelec
abroad, nd out about the regulations applicable in that country.
Likeallbicycles,thepedelecmustcomplywiththerespectivenational
roadtracregulationsandapplicablestandards.Ifyoucarryout
anytechnicalmodications,bearinmindtherelevantnationaltrac
regulationsandapplicablestandards. If the cut-o speed exceeds
25 km/h and/or the speed of the push assist exceeds 6 km/h, the
pedelec will become liable to mandatory registration and insurance.
Technical modications can impair the function of your pedelec,
resulting in damage to components. If this happens while you are
riding the bike you could be severely injured or killed. Furthermore,
it will invalidate the manufacturer's liability, warranty and guarantee
(where applicable).
II.IV Servicebook
In the accompanying service book, you will nd the warranty terms, a
list of wearing parts, a cycle passport, and forms to use for initial sale,
maintenance and owner changes.
DANGER
Keeptheservicebookappropriatelyup-to-dateandadheretothe
maintenance
intervals. Components can fail if wear and damage are
not identied in good time. If this happens whilst you are cycling, you
could injure yourself very seriously or even die. Replace any worn,
damaged or bent components before using the bike again.
II.V EUdeclarationsofconformity
EU declarations of conformity conrm that we have complied with all of
the safety requirements of the regulations applicable to the pedelec and
the battery charger.
II.VI Guarantee card*
Since model year 2014 we have been oering you a guarantee of 10 years
for all pedelec and S-pedelec frames – exclusively for Kalkho and Raleigh
brands. You will nd the terms of the guarantee on the guarantee card.
*dependent on model
EN-8 Original User Guide | Pedelec Shimano Steps E6000 Version 1
» The use of cycle paths is regulated as for normal bicycles.
» The use of children trailers and cycle trailers is generally permitted for
pedelecs.
DANGER
Beforeyouuseatrailerbikeortrailer,makesureyoureadSection
4.1.2 Trailer bikes and trailers Page EN-29. Otherwise there is a risk of
serious injury or death.
IV.II.I Lights
In Germany, the requirements for lights on bicycles is regulated in Section
67 of the Road Trac Licensing Regulation (StVZO) and in the Technical
Requirements for vehicle parts. Lights include both battery and dynamo-
powered lights, and include reectors that work without a power supply
and simply reect external light.
Lighttype Number Position Characteristics
Front light 1 Front White light
The illuminance must be at least 10 lux at
the centre of the beam at a distance of 10
metres.
Reector At least 1 Front White
The reector can be integrated into the
front light.
Observetherespectivenationalregulationsregarding
thedisposalofthedrivesystem,display,easy-reach
control,pedelecbatteryandcharger. Otherwise you will be
committing an oence and run the risk of a ne.
IV.II Germany
The following regulations (not exhaustive) were applicable in Germany
when this guide was compiled (01/2017):
» The motor may only be used as an aid to pedalling, i.e. it may only
"help" when the rider is actively pedalling.
» The average motor power must not exceed 250 W.
» The motor power must continue to fall as the speed of the bike
continues to increase.
» The motor must cut out automatically at 25 km/h.
For you, this means:
» There is no obligation to wear a helmet.
DANGER
Intheinterestsofyourownsafety,asuitablehelmetshouldalwaysbe
worn. A cycle helmet can protect you from severe injuries. Make sure
that the helmet ts properly.
» You do not require a driving licence.
» There is no requirement for compulsory insurance.
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-9
IV.II.I.IReplacementbulbs
The replacement bulbs you will need depend on the type of lights tted on
your bike. The table below tells you what type of bulb you need:
Type Power supply
Front light (LED, incandescent) 6 V 2.4 W
Front light halogen 6 V 2.4 W
Rear light 6 V 0.6 W
Rear light with parking light 6 V 0.6 W
Lighting with LED lamps LED lamps are not replaceable
Hub dynamo 6 V 3 W
IV.II.II Disposal
Do not dispose of the drive system, display, easy-
reach control, pedelec battery or charger in the
household waste. Hand them in at the designated
places (such as a recycling centre, battery collection
point or cycle dealer). Electrical devices marked
with this symbol must not
be disposed of in house-
hold waste.
Lighttype Number Position Characteristics
Rear light 1 Rear Red light
The lowest point of the illuminating
surface must not be lower than 250 mm
above the road surface.
A parking light function is also permitted.
Reector At least 1 Rear Red
The highest point of the illuminating
surface must not be higher than 600 mm
above the road surface.
Large reector 1 Rear Red
The large reector is marked with a Z.
It can be integrated in the rear light.
Reector 2 Per pedal Yellow
They reect light in both directions
(forwards and backwards).
Reector (or
reective wheel
stripe)
At least 2 Per wheel Yellow
Attached to the spokes at an angle of
180˚.
They reect light to the sides.
Reective stripe (or
wheel reector)
1 Per wheel Ring-shaped reecting white stripe.
EN-10 Original User Guide | Pedelec Shimano Steps E6000 Version 1
VI. Pedelecweight*
Pedelecs are heavier than normal bicycles. The exact weight
depends on the equipment tted. If you want to know the
precise weight of your pedelec, we recommend having it
weighed by a cycle dealer. Most dealers have a professional
and accurate cycle weigher.
VI.I Overallweight
DANGER
Donotexceedthepermittedoverallweightofthepedelecasthiscan
resultinfracturingorfailingofimportantsafetyparts(suchasthe
brakes). If this happens while you are riding the bike, it can lead to
severe falls – with fatal consequences.
Overallweight= Weight of the bike + weight of the rider + weight of
the trailer bike or trailer + weight of luggage and/or child
Biketype Overallweightpermitted Weightofrider**
Pedelec Shimano
Steps E6000 130 kilograms Max. 102 kilograms
** for a pedelec weighing 28 kilograms.
V. Intended use
V.I Pedelec
This bicycle is designed and equipped for use on public roads and paved
paths. It can also be used on non-challenging terrain.
The manufacturer and dealer accept no liability for damage resulting from
any use beyond this denition and/or failure to comply with the safety
information and instructions in the user guide.
This applies particularly to o-road use, overloading and failure to
properly rectify faults.
Also included in the denition of intended use are conformance to the
operating, maintenance and repair conditions in the user guide and service
book II.IV Service book Page EN-7 stipulated by the manufacturer.
Fluctuations in the consumption and power of the battery and a reduction
of capacity 5.3.1.2 Capacity Page EN-35 with increasing age are common
and technically unavoidable, and as such do not constitute material
defects.
*dependent on model
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-11
DANGER
Checkthatthebrakesworkandthatthehandlebarscanmovefreely
beforeeveryride.Donotusethebikeifitisnotinperfecttechnical
condition.If you are unsure, ask your cycle dealer to check it over.
Inspectyourpedelecbeforeeverytrip,andaftereachtimeithasbeen
transportedanywhereorleftunattended4. Before every trip Page
EN-28. Components might fail if wear and damage are not detected
early enough. If this happens whilst you are cycling, you could injure
yourself very seriously or even die. The additional power means
higher loads are applied to wearing parts on a pedelec than on a
normal cycle. Replace any worn, damaged or bent components before
using the bike again.
Donotexceedtheoverallweightpermittedforthepedelecbecause
partsimportantforsafetymightfractureorfailVI.I Overall weight
Page EN-10. If this happens while you are riding the bike, severe falls
might result – with fatal consequences.
Contactyourcycledealerwhenwearingpartsandothercomponents
needtobereplaced.Werecommendaskingyourcycledealertoas-
sembleandadjustthebike.
Otherwise, components could become loose due to a faulty assembly.
If this happens whilst you are cycling, you could injure yourself very
seriously or even die. If you do have to tighten something yourself, a
full list of torque settings is in Section 8. Torque settings Page EN-46
(strict adherence to which is a requirement).
1. Generalsafetyinformation
Comply with the safety and user instructions at the start of the following
sections.
DANGER
Wediscourageallowingchildrenundertheageof14yearstoride
pedelecs. They may not be able to cope with the speed. Serious
accidents and falls might result.
Wearacyclehelmet. While there is no legal obligation to wear one,
you should always wear a suitable cycle helmet for your own safety. A
cycle helmet can protect you from severe injuries. Make sure that the
helmet ts properly.
Keepyourhandsandotherbodypartsandclothingawayfrommoving
parts, otherwise you can become ensnared, have a serious fall and
injure yourself.
Adaptyourridingstyletotheprevailingtracconditions,otherwise
you could fall o and involve yourself and others in a serious
accident. Take into consideration the longer braking distances needed
on wet or icy roads. Think ahead, anticipating the actions of other
road users and reduce your speed. Avoid sudden jerky movements of
the handlebars and braking actions. Dismount if you ever feel unsafe.
OnlyusethebicycleforitsintendedpurposeV. Intended use Page
EN-10, otherwise component failure may result. If this happens whilst
you are cycling, you could injure yourself very seriously or even die.
EN-12 Original User Guide | Pedelec Shimano Steps E6000 Version 1
CAUTION
Donotopenupthemotor,display,batteryorchargeras you could
injure yourself. Parts might also be damaged beyond repair,
invalidating the warranty. Contact your cycle dealer when problems
arise.
IMPORTANT
Alwaysparkyourpedelecsothatitcannottipover.Components can
be damaged if the bike tips over. If your bike is not equipped with
a kick stand, one can be tted if required. Please contact your cycle
dealer.
Donotcleanthepedelecwithawaterhoseorhighpressurewasher.
Although the components are sealed, damage to the cycle may still
result. Clean the pedelec with a soft damp cloth.
DANGER
Onlyuseoriginalreplacementparts. Replacement parts from other
manufacturers can impair the function of your pedelec. Serious acci-
dents can result.
Askyourcycledealertoshowyouhowtouse,andexplain,the
specialfeaturesofthecomponents.Pleasealsofollowthecomponent
guides.Werecommendaskingyourcycledealertoassembleand
adjustthebike. Otherwise, components could become loose due
to a faulty assembly. If this happens whilst you are cycling, you
could injure yourself very seriously or even die. If you do have to
tighten something yourself, a full list of torque settings is in Section
8. Torque settings Page EN-46 (strict adherence to which is a
requirement).
WARNING
Donotrideinunfavourablelightingconditions(fog,rain,dusk,
darkness)withoutadequatelightsIV.II.I Lights Page EN-8.Failure
to do so can result in accidents and serious injuries.
Alwaysremovethebatterybeforestartingtoworkonthepedelec.
The pedelec could switch on unexpectedly and you could be seriously
injured.
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-13
Quick-releasewheelsshouldbeattachedtoaxedobject
togetherwiththeframe.This prevents the wheel from being
stolen. Alternatively, the quick-release skewers can be
replaced by an anti-theft device. Contact your cycle dealer if
you have questions on this.
Useahigh-qualitybikelock. Invest about 10% of the
purchase price of the bike in locks. Your cycle dealer will be
able to t a suitable frame lock if your bike does not already
have one. You can also use other types of bike lock. Ask
your cycle dealer for advice.
Makeanoteoftheimportantdetailsofyourpedelec(e.g.
in the service book II.IV Service book Page EN-7, bike
passport) and have it registered by the police. This makes it
easier to describe and identify if stolen.
Havethepolicecodeyourpedelec; the address and initials
of the owner are engraved on the frame in an encrypted
form. Coding makes the illegal resale of a bike more dicult
and deters thieves. A coded bike also makes it easier to
identify the owner.
Bicycletheftisoftencoveredbyhouseholdcontents
insurance. Check the terms of your insurance policy as soon
as possible.
2. Protectionfromtheft,manipulationandloss
DANGER
Protectyourpedelecfromunauthorisedaccess.Serious injury may
result if third parties modify components (e.g. the brakes) without
your knowledge. Inspect your pedelec before every trip, and after
each time it has been transported anywhere or left unattended
4. Before every trip Page EN-28.If your bike is damaged, only ride
it again once the damage has been rectied. Your bike will not be
replaced under warranty if lost or stolen.
The following measures can help you to protect your pedelec from theft
and manipulation and to recover it if it has been stolen:
Alwayslockthebikeandbatteryevenifyouleaveitfor
ashortwhile.Ideally,thelock(s)shouldblockthewheel
powered by the motor. Do not leave the key in. To be on the
safe side, you can also remove the battery. A pedelec must
also be secured with a lock when parked outside residential
areas (e.g. in a shed or basement).
Donotparkyourpedelecindesertedlocations–
especially for long periods. If possible, park your pedelec
in private or communal garages or individual bike lockers
which have surveillance.
Attachyourpedelectoaxedobject(suchasatree,street
lamporfence)so that it cannot be carried away.
EN-14 Original User Guide | Pedelec Shimano Steps E6000 Version 1
3.1 Attachingthepedals
1. Screw the right-hand pedal (marked ‘R’) into the right-hand pedal
crank in a clockwise direction.
2. Screw the left-hand pedal (marked ‘L’) anticlockwise into the left-hand
pedal crank.
DANGER
Screwthepedalsinstraight,otherwise you could damage the thread
on the pedal crank; if this happens when you are cycling, a severe fall
could result.
3. Tighten both pedals towards the front wheel to a torque of 40 Nm.
3. Beforeyourrstride
Make sure that your pedelec is adjusted to your height and ready to use.
Familiarise yourself with the basic functions of your pedelec.
DANGER
Askyourcycledealertoshowyouhowtouse,andexplain,thespecial
featuresofthepedelecanditscomponents.Pleasealsofollowthe
componentguides.Werecommendhavingyourcycledealerperform
allassemblyandadjustmentwork.Otherwise, components could
become loose due to a faulty assembly. If this happens whilst you are
cycling, you could injure yourself very seriously or even die. If you do
have to tighten something yourself, a full list of torque settings is in
Section 8. Torque settings Page EN-46 (strict adherence to which is a
requirement).
Adjustthepedelectoyourheight.If the bike is not correctly adjusted
to your height, you can lose control of the bike and fall badly.
Practisebrakingandridingwiththeassistfunctioninasafeplace
beforeventuringintotrac.If you do not familiarise yourself with the
operation and higher speed of your pedelec, you could cause a serious
accident. Ride in ECO mode until you feel condent enough to try the
higher modes. Dismount if you ever feel unsafe.
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-15
3.2 Adjustingthesaddleheight
3.2.1 Determiningthecorrectsaddleheight
1. Sit on the pedelec and at the same time lean against a wall.
2. Turn the foot pedal on the opposite side to the wall to its lowest point.
3. Place your heel on the pedal. Your leg should be fully extended.
4. If your leg is not fully extended when your heel is
on the pedal, raise the saddle. Lower the saddle
if you cannot reach the pedal. The following
sections explain how to adjust the saddle height
on your bike. The seatpost can be fastened using
the saddle clamp bolt 3.2.2 Adjusting the
saddle height: Saddle clamp bolt(s)* Page EN-15 or
quick-release skewer 3.2.3 Adjusting the
saddle height: Quick-release skewer* Page EN-16.
WARNING
Seatpost marking
Theseatpostismarkedtoindicatehowfaryou
maypullitoutfromtheframe.Neverpullthe
seatpostfurtheroutthanthemarking.This could
cause it to bend or break, and cause you to fall.
For3. Extend leg
3.2.2 Adjustingthesaddleheight:Saddleclampbolt(s)*
1. Undo the saddle clamp bolt(s) by turning
it/them anticlockwise with an Allen key.
2. Move the seatpost into the right position.
3. Tighten the saddle clamp bolt(s) again
by turning it/them clockwise 8.
Torque settings Page EN-46.
4. Test the tightness of the saddle by trying
to move it.
For1. Loosen the saddle clamp bolt(s)
For3. Tighten the saddle clamp bolt(s)
*dependent on model
EN-16 Original User Guide | Pedelec Shimano Steps E6000 Version 1
DANGER
Itshouldbesohardtoclosethequick-releaseskewerthatyouneed
tousetheballofyourhand(120N:correspondstoaweightforce
of12kg).Youshouldhavethemarkoftheleverimprintedonyour
hand. Otherwise, it could open when you are cycling, which could
lead to the seatpost coming loose and causing you to fall. If you close
the quick-release skewer too tightly, the seatpost can break; if this
happens when you are cycling, you could fall.
Quick-release
skeweristooeasy
to close
1. Turn the adjustment nut
clockwise.
2. Swing the quick-release
skewer closed again.
Quick-release skewer
Adjustment nut
Quick-release skewer opened
Quick-release
skeweristoosti
to close
1. Turn the adjustment nut
anticlockwise.
2. Swing the quick-release
skewer closed again.
3. Try to twist the saddle to check that it is rmly xed.
3.2.3 Adjustingthesaddleheight:Quick-releaseskewer*
DANGER
Thequick-releaseskewermustbecorrectlyclosedbeforeyouseto.
Otherwise the seatpost can loosen or fracture – if that happens while
you are riding the bike you could fall o, resulting in serious injuries.
1. Open the quick-release skewer by
swinging the lever by 180˚. You will
now usually be able to see the word
‘OPEN’ on the inside of the lever.
2. Close the quick-release skewer by
swinging the lever by 180˚. You will
now usually be able to see the word
‘CLOSE’ on the outside of the lever.
Quick-release skewer
For1. Quick-release skewer open
For2.Quick-release skewer closed
*dependent on model
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-17
3.3 Shiftingandtiltingthesaddle
DANGER
Neverclampthesaddleinthecurveofthesaddlerail;alwaysdoitin
thestraightsection.Onlyshiftthesaddlewithinthestraightsection
(g.1). Saddles that stay clamped outside this area can fail (g. 2).
correct
Clampingscrew
Fig.1
wrong
Fig. 2
Use a torque wrench to tighten the clamping screws. Observe the
specied torque setting. If no value is shown on the component, use
the torque settings from the following table:
Thread Tighteningtorque[Nm]
M5 / M6 / M8 M5: 5.5 / M6: 5.5 / M7: 14 / M8: 20
Failure to comply can result in screws/bolts becoming loose, tearing
away or fracturing. If that happens while you are riding the bike,
components may come o and you could have a severe crash. If
screws are overtightened, components can also be damaged.
3.3.1 Single-screwsupport:Shiftingandtiltingthesaddle
1. Loosen the clamping screw by turning it
anticlockwise. Turn the screw completely
two to three times at most or the whole
mechanism could fall apart.
2. Move the saddle backwards or forwards as
required.
3. Tilt the bicycle saddle to the desired angle.
4. Tighten the clamping screw by turning it clockwise with a torque
wrench.
5. Ensure that the newly-tightened saddle does not tip; test it by pressing
down on the front and back alternately.
For 1. Loosen the clamping screw
EN-18 Original User Guide | Pedelec Shimano Steps E6000 Version 1
5. Tighten the front screw by the same number of turns.
6. Ensure that the newly-tightened saddle does not tip; test it by pressing
down on the front and back alternately.
3.3.3 Clampattachment:Shiftingandtiltingthesaddle
1. Turn the clamping nut clockwise
to loosen it. You may need to
keep the nut on the other side in
place with a second key.
2. Move the saddle backwards or
forwards as required.
3. Tilt the bicycle saddle to the desired angle.
4. Turn the clamping nut clockwise to tighten it. You may need to keep
the nut on the other side in place with a second key. Observe the
correct torque setting.
5. Ensure that the newly-tightened saddle does not tip; test it by pressing
down on the front and back alternately.
For1.
Loosen clamping nut
3.3.2 Twin-screwsupports:Shiftingandtiltingthesaddle
DANGER
Screwtheclampingscrewsfullyinastraightpositioninthenuts.
Failuretodosocanresultinthescrewstearingoutofthenuts.
correct
Clampingscrew
wrong
1. To move the saddle, loosen the front
and rear screws by turning them
anticlockwise. Turn the screws
completely two to three times at
most or the whole mechanism could
fall apart.
2. Move the saddle backwards or forwards as required.
3. Tighten the screws using a torque wrench to turn them clockwise.
4. To alter the angle of the saddle, loosen the front screw by turning it
anticlockwise. Turn the screw completely two to three times at most or
the whole mechanism could fall apart.
For1. Loosen screws
Original User Guide | Pedelec Shimano Steps E6000 Version 1 EN-19
3.4 Adjustingthesprungseatpost
DANGER
It is best to ask your cycle dealer to adjust the suspension elements of
the seatpost.
1. Remove the seatpost.
2. Tighten the suspension adjustment screw with an Allen key (6 mm
AF) in the clockwise direction to reduce the suspension or loosen
anticlockwise to increase the suspension.
DANGER
Thesuspensionadjustmentscrewmustnot
protrudefromtheseatpost,otherwise the
screw/seatpost can loosen – if this happens
while riding you could fall o, resulting in
serious injuries.
Suspension
adjustment
screw
Screw must not protrude
from the seatpost
3.5 Adjustingtheheightandangleofthehandlebars
DANGER
Askyourcycledealertoperformtheseadjustments.You can otherwise
run the risk of loosening the handlebars which could lead to a fall
causing severe injuries.
3.6 Switchingthelightsonando*
A slider control is located on the rear of the front light. Depending on
which way you move it, the front and rear light will be on or o when you
are riding.
3.7 Braking
Make sure that you can always reach the brakes comfortably and that you
are familiar with their operation and position. Note which brake lever
operates the front and rear brakes. If your pedelec is tted with a back
pedal or coaster brake, you can operate it by pedalling backwards.
*dependent on model
EN-20 Original User Guide | Pedelec Shimano Steps E6000 Version 1
3.8 Chain*
Bicycle chain
WARNING
Alwaysremovethebatterybeforestartingtoworkonthepedelec.
The cycle could switch on without warning and you could be seriously
injured.
CAUTION
Checkthechainforsignsofwearbeforeeverytrip.A worn or
damaged chain can break. If this happens while you are riding the
bike, you can easily injure yourself.
DANGER
Practisebrakinginasafeplacebeforeventuringintoroadtrac.In
some instances, the braking eect can be dierent or stronger than
what you are used to. If you do not take the time to familiarise yourself
with the braking eect, you could cause a serious accident. Practise
until you feel safe. Dismount if you ever feel unsafe.
Rim brake
Rimbrakes:Avoidcontinual,uninterrupted
brakingonlongdownhillstretchesbecause
it causes the braking eect to diminish and/
or tyre damage. Brake intermittently with
intervals in between to allow the airow to
cool the braking system.
If necessary, make regular stops to ensure
adequate cooling.
Replacethebrakepadswhentheyreachthesafewearlimit.Using
worn brake pads can result in serious injuries with fatal consequences.
CAUTION
Disc brake
Discbrakes:Avoidtouchingthebrakediscs
afterintensiveuseofthebrakes – they can
become very hot. You could burn yourself if
you touch them.
*dependent on model
