Shini SICC-A-R2 Series User manual

SICC-A-R2
CFC-free RefrigerantAir-cooled
CentralWaterChiller
Date Nov, 2017
Version:Ver.B(English)

3(44)
Contents
1. General Description..................................................................................... 7
1.1 CodingPrinciple......................................................................................8
1.2 Feature....................................................................................................8
1.3 TechnicalSpecifications........................................................................ 10
1.3.1 SICC-A-R2SeriesOutline Dimensions....................................... 10
1.3.2 Flange......................................................................................... 11
1.3.3 TechnicalSpecification............................................................... 12
1.4 SafetyRegulations................................................................................ 13
1.4.1 NoticeforSafeOperation........................................................... 13
1.4.2 SafetySignsand Labels............................................................. 14
1.4.3 Signsand Labels........................................................................ 14
1.5 ExemptionClause................................................................................. 15
2. StructureCharacteristics and WorkingPrinciple.................................... 16
2.1 WorkingPrinciple.................................................................................. 16
2.1.1 WorkingFlowInstruction............................................................ 16
3. Installation and Debugging........................................................................ 17
3.1 Installation Notice.................................................................................. 17
3.2 Select Installation Site........................................................................... 18
3.3 BearingPlatform ................................................................................... 19
3.4 Hangingand Transportingof theUnit................................................... 20
3.5 WaterSystemTubing............................................................................ 21
3.6 Combined Installation ofModules......................................................... 23
3.7 EssentialsforElectricWiring................................................................. 23
3.8 Communication Connection.................................................................. 25
3.8.1 SettingtheControllerAddress ofthe Host Machine................... 25
3.8.2 ControllerAddress SettingoftheSlaveMachine....................... 25
3.8.3 DisplayerReset.......................................................................... 26
3.8.4 Communication Connection........................................................ 26
4. Operation Guide......................................................................................... 28
4.1 IntroductionofOperation Menu............................................................. 28

4(44)
4.2 InterfaceOperation ............................................................................... 28
4.2.1 InitialInterface............................................................................ 28
4.2.2 MainInterface............................................................................. 29
4.2.3 Interfaceof on”and off”............................................................ 29
4.2.4 Current FaultChecking and Resetting........................................ 31
4.2.5 PasswordInput and Change ...................................................... 32
4.3 Instructionof MenuInterface................................................................. 33
4.3.1 Menu Instructionof ASetting”................................................... 33
4.3.2 Menu Instructionof BClock”..................................................... 34
4.3.3 Menu Instructionof Cinputandoutput”..................................... 35
4.3.4 Menu Instructionof Dalarmrecord”.......................................... 35
4.3.5 Menu Instructionof EUnit Switch”............................................. 35
4.3.6 Menu Instructionof FMaintenance”.......................................... 36
5. Trouble-shooting ........................................................................................ 38
6. Maintenance and Repair............................................................................ 39
6.1 DailyRepair and CheckItems............................................................... 40
6.2 MonthlyPeriodicalCheckingItems....................................................... 40
6.3 YearlyPeriodicalCheckingItems.......................................................... 40
6.4 MaintenanceSchedule.......................................................................... 41
6.4.1 About theMachine...................................................................... 41
6.4.2 Installation &Inspection.............................................................. 41
6.4.3 DailyChecking............................................................................ 41
6.4.4 WeeklyCheck............................................................................. 41
6.4.5 MonthlyCheck............................................................................ 41
6.4.6 TrimonthlyChecking................................................................... 41
6.4.7 Check Half-yearly....................................................................... 42
6.4.8 YearlyChecking.......................................................................... 42
6.4.9 3yearChecking.......................................................................... 42
Attachment ElectricalDiagram................................................................... 43
TableIndex
Table1-1:TechnicalSpecification.................................................................... 12

5(44)
Table3-1: NoticeforLiftingMatters.................................................................. 20
Table4-1: InstructionofKeys........................................................................... 28
PictureIndex
Picture1-1: Outline Dimensions....................................................................... 11
Picture1-2: FlangeOutline Dimensions........................................................... 11
Picture2-1:WorkingPrinciple.......................................................................... 16
Picture3-1: Installation Space.......................................................................... 18
Picture3-2: PlatformInstallation....................................................................... 19
Picture3-3: Hangingand Transportingof theUnit............................................ 20
Picture3-4: SameDirection Way1................................................................... 22
Picture3-5: SameDirection Way2................................................................... 22
Picture3-6: Combined Installation of Modules................................................. 23
Picture3-7: EssentialsforElectricWiring......................................................... 24
Picture3-8: Communication Line Connection................................................... 27
Picture3-9: Communication InterfaceDiagram................................................ 27
Picture4-1: OperationMenu............................................................................. 28

6(44)

7(44)
1.General Description
Read thismanualcarefullybeforeoperation topreventdamageofthe
machine orpersonalinjuries.
SICC-A-R2seriesisapplicableforcoolingmouldstoreduceproduct’smolding
cycle. Theycan alsobeusedforequipmentcoolinginordertomaintainanormal
temperatureaswell asotherindustrialcooling.
Model SICC-90A-R2

8(44)
1.1CodingPrinciple
1.2Feature
Standard configuration
lModularized designmakesiteasiertocombine moduleunits1to15.
Coolingcapacitycan beenlarged byincreasingthe numberofmodules
orchooseappropriatemodulestoconnect toexistingsystem.
lThewaterrouteof themodulescan be linkedbyone moduleconnecting
totheinlet/outlet watertube. Noneed toinstall the inlet/outlet watertube
foreachmodulealone.The rubbersoftpipe isusedtoconnectthe
modulesforconvenient construction.
lAdoptsimportedcomponentslikescroll compressor, expansionvalve
whichensurestableperformance.The wholeunit will not stopduetoone
modulefailure.
lWhen the wholeunit isrunning, the microcomputerwill autoadjustthe
performanceof eachmoduleoropen /shutrespectivemoduleunit
accordingtosystemload.Themoduleunitadoptsdoublecompressors
and itspoweradjustablerangeisenlarged aftercombination tosaveup
powerwheneverpossible.
lWiredcontrolsystemenablesthemainunitand itscontrollertobe
separated fromeachother.
lProtectiongrade IP54
Accessoryoption
lOptionalRS485 communicationrealizestheremotemonitoringand
networkfunction.

9(44)
All serviceworkshouldbe carried out byaperson withtechnicaltrainingor
correspondingprofessionalexperience.The manualcontainsinstructionsforboth
handlingand servicing.Chapter6, whichcontainsserviceinstructionsintendedfor
serviceengineers. Otherchapterscontaininstructionsforthedailyoperator.
Anymodificationsofthemachinemustbe approved bySHINI inordertoavoid
personalinjuryand damagetomachine.Weshall not beliableforanydamage
causedbyunauthorized changeof themachine.
Ourcompanyprovidesexcellent after-salesservice. Shouldyou haveanyproblem
duringusingthemachine,pleasecontactthecompanyorthelocalvendor.
HeadquarterandTaipeifactory
Tel:[phone]
ShiniPlastics Technologies(Dongguan), Inc
Tel:[phone]
ShiniPlastics TechnologiesIndiaPvt.Ltd.
Tel:[phone]

10(44)
1.3Technical Specifications
1.3.1SICC-A-R2SeriesOutline Dimensions
(SICC-60A-R2)
(SICC-90A-R2)

11(44)
(SICC-120A-R2)
Picture1-1: Outline Dimensions
1.3.2Flange
Picture1-2: FlangeOutline Dimensions

12(44)
1.3.3TechnicalSpecification
Table1-1:TechnicalSpecification
Model
Item
SICC-60A-R2 SICC-90A-R2 SICC-120A-R2
RefrigerationCapacity
kW 60 90 120
Kcal/hr 51,600 77,400 103,200
Power --- 3Ф400VAC50Hz
TotalPower kW 19 28 37
RunningCurrent A 35 50 65
StartupCurrent A 140 175 230
Compressure
Type Scroll
Power kW 8.6×2 12.5×2 17×2
CrankCaseHeater kW 0.08×2 0.08×2 0.056×2
Refrigeratnt
Type --- R410A
Filling Quantity kg 15 17 26
Evaporator
Type --- Tube-in-shell Evaporator
Coolingflow
Flow
m3/h 10.3 15.5 20.6
Pressureloss kPa 27 39.2 49
PipeCoupler inch 5 5 5
Condenser
Type --- Fin Style Air-cooledCondenser
Blower power kW 1.68 2.2 3.36
Air quantity m3/h 26,000 39,000 52,000
Material
dimension
Length mm 2,163 2,163 2,163
Width mm 9,75 1,170 1,825
Highly mm 2,230 2,230 2,230
Weight
Beforpacking
Packing kg 810 940 1,300
Afterpacked kg 850 1,000 1,370
NoiseLevel dB(A) 78 80 85
MeasuresExchange 1kW=860kcal/hr 1RT=3,024kcal/hr10,000Btu/hr=2,520kcal/hr
Notes:Refrigerationcapacityis measuredbasedonthe flow(0.172m3/h.kW)and theoutlet
temperature(15 /59 ℉)ofchilledwaterunderthe environment temperature of35 /95 ℉.

13(44)
1.4SafetyRegulations
Strictlyabide bythe followingsafetyregulationstoprevent damageofthe
machine orpersonalinjuries.
1.4.1NoticeforSafeOperation
Read the followingregulationsbeforeinstallation orusingunderthe
consideration ofsafety.
1)Donotdropwaterintheelectricalpart toavoidinsulation damage.
2)Put deviceconnect toground accordingtoelectrician operatingregulationto
avoidcreepage.
3)Anytubesorelectricaldevicemounton air conditionermust beinstalled by
professionaltechnicians.
4)Pleaseinstall unitsinflat and ventilativeplaceandkeepsuitabledistances.
5)Keepawayfromfiresource, suchaswaterheater, gasand electricstove.
6)Avoidbeingexposedtoweather.
7)Constructaccordingtoinstallationinstructionsandnotice.
8)Thistype ofair-conditionerisdesigned foradults. Keep children awayfrom
it.
9)Anydeedstryingtochangeitsspecificationaredangerous.
10)Don't useevaporablesolvents, oil ortoluene toavoidaccidents.
11)Ensurethismachine not topress on the electricalwirestoavoidcreepage
and burning.
12)Donottouchthe machine withwet handsincaseof accident.
13)Undernocircumstancesshouldyou trytorepair thewaterchiller. Because
oftheunqualified person maycausegreaterdamagesorfailures. Please
inquirelocalserviceagents.
14)Donotpourwaterordetergenton the surfaceofmachinewhen cleaningit.
Pleasewipe it withclothorneutraldetergent.
15)Donotplacethingsonthe uppersurfaceof thewaterchillerinordertoavoid
dangerduringrunning.
16)Connect thewaterchillertospecialelectricitysupply. It isforbidden toshare
circuit withotherdevices.
17)Donotchangeorrepairthe electricalwireswithout authority.
18)Donotinsertanythingintoair outlet of thewaterchillertoavoiddamageor
danger.

14(44)
1.4.2SafetySignsand Labels
Attention!
Theinstallationofelectricaldevicesshouldbe conductedbyprofessional
electricians.
Duringrepairing and maintenance, must turnoff themainswitchand
controlswitch.
Warning!
HighVoltagedanger!
Put upthissymbolinthe shell oftheelectriccabinet.
Warning!
Be careful!
Thissymbolshouldtakemorecarefulhereby!
Attention！
Noneed forregularinspectionbecauseall theelectricalpartsinthe
controlunit arefixed tightly！
1.4.3Signsand Labels
Thisisforindicatingmotorrotating
direction.
When phasereversalhappens, thealarm
soundsandindicatoroncontrolpanelwill
indicate. Pleaseexchangetheplaceof
the twoelectricalwirestosolvethis
problem.
Wateroutlet: drainageoutlet/ cooling
wateroutlet.
Waterinlet: replenishwaterformachine/
coolingwaterinlet.

15(44)
Drainageport: wateroutletofwater
system.
1.5 Exemption Clause
Thefollowingstatementsclarifiedthe responsibilitiesand regulationsbornby
anybuyeroruserwho purchasesproductsandaccessoriesfromShini
(includingemployeesand agents).
Shiniisexempted fromliabilityforanycosts,fees,claimsandlossescausedby
reasonsbelow:
1. Anycarelessorman-madeinstallations,operation andmaintenancesupon
machineswithoutreferringtothe Manualpriortomachineusing.
2. Anyincidentsbeyondhumanreasonablecontrols, whichincludeman-made
viciousordeliberatedamagesorabnormalpower,and machine faultscaused
byirresistiblenaturaldisastersincludingfire,flood,stormand earthquake.
3. Anyoperationalactionsthatarenotauthorized byShiniuponmachine,
includingaddingorreplacingaccessories, dismantling,deliveringorrepairing.
4. Employingconsumablesoroil mediathatarenotappointed byShini.

16(44)
2. Structure Characteristics andWorkingPrinciple
2.1WorkingPrinciple
Picture2-1:WorkingPrinciple
2.1.1WorkingFlowInstruction
Coolingcirculation: thehightemp.highpressureair fromcompressor’shigh
pressuresprayingoutlet comesintofin-type-air side heatexchanger, which
works asacondensertocooldowntheair intoliquid. Thenit comesinto
expansion valveafterfiltration.There,afterapressuredownfall, it comesinto
shell -tubeevaporator.Thelowtemp. lowpressureandsaturated refrigerant
absorbstheheatfromcoolingwatertolowdownitstemp..Theshell -tube
evaporator’srefrigerant outlet islowtemp.lowpressureair state. Itthen comes
toair and liquidseparatorforseparation.Therefore,theair returnsthe
compressor’slow-pressureair suctioninlet toget compressed.Thehigh
pressuresprayingoutlet (compressor)→condenser(air sideheat
exchanger)→filterexpansionvalve→evaporator(waterside heat
exchanger)→air and liquidseparator→thelowpressureair suctioninlet.

17(44)
3. Installation and Debugging
Note Beforeinstallation, pleasereadthischaptercarefullyandinstall
according totheprocedures as follows!
Install the waterchillernearwindowsorplaceswithgood air flowingbecause
air-cooled centralwaterchillerneedsagood heat-releasingcondition.Ifthe water
chillerisinstalled insidethefactory, thenthesurroundingtemperatureshouldnot
be higherthan35 and theremust havefanstomakeairflowflowfluentlyorair
tubepipingthehotair produced bywaterchilleroutside. If thewaterchilleris
installed outdoor,aveil isneededtocoverthetop ofthe chiller.
3.1InstallationNotice
1)Makesurethat voltageofelectricitymatcheswiththe nameplate.
2)Connect the electricitywireand earthwireaccordingtolocalregulations.
3)Useindependentelectricitywireand powerswitch.The diameterofthewire
shouldnotbeless thanthat of electriccabinet’swire.
4)The endoftheelectricitywireshouldbesafeand firm.
5)There-phaseelectricityand fivewiresareutilized. Connect thepowertolive
wire, (N) tozerowireand (G)toground wire.
6)Electricpowerdistributiondemand.
Mainpowervoltage: ±10%
Mainpowerfrequency: ±2%.
7)Install pipe worksystemaccordingtoschemeofwiring. Protect waterchilling
pipeswithhear-insulatingmaterials.
8)Makesurethat the diameterofthe recyclingpumppipeline notless than that
ofcondenser’sconnection tube. (Install theinlet oroutletpipelinesystem
accordingtothedrawingoftheassemblyline)Large-diametertube shouldbe
used toconnect tocoolingwaterforlong-rangetransmission.
9)The verytop ofthecoolingwaterrecyclingloop systemmustbe configured
withself-dischargingvalve, the lowest withdrainvalve.
10)Install filterinthe coolingwaterrecycingloop duetobadwaterqualityinthe
watersourceandwashthefilterat certaintimes.
11)Test if thepipeline leaks afterinstallation.Wrapinsulatinglayerontothe
coolingwaterrecyclingpipe toaviod loss ofrefrigeration capacityand
pipeline leakage.

18(44)
Note:Powerconnection mustbeconductedbyprofessionalelectricians!
Donotchangethecircuitofthewaterchillerwithoutour company's
authority. Ifthemachineisdamagedbyunauthorizedchangewearenot
responsiblefor this.
3.2Select Installation Site
1)Noheat sourceexistencenearbytoacoidefficiencyreduction dueto
absorbinghotair.
2)Noimpact imposedbyhightemperature, vapororoil stain.
3)Avoidbeingspattered bywatervaporwhen choosinginstallation sitenear
coolingwatertower, sotoavoidanyshort ciruit orcreepage.
4)Properventilation without hindranceforair inhaledexhaled.
5)Noexistenceofinflammablesubstance.
6)Whenusingconcretebearingplatform,theplatformmustbefirmand flat.
Install shockprooofmat inthebolt of bearingplatformifnecessary.
7)Setapart someservicespace.Spacerangesarerecommendedasshownin
figure3-1.
Lengthunit: mm
Picture3-1: Installation Space

19(44)
3.3Bearing Platform
1)The unit shouldbeinstalledon concreteorsteelstructurebearingplatform
that isfirmand thesurfaceof thebaringplatformshouldbesmoothand flat.
Theintensityofthe platformshouldholdthewholeunit, iftheintensityisnot
strongenough, it iseasytocausevibrationand noise.
2)The surfaceofthe concretebaseplatformnormallyhascompo ashorizontal
ornament andwithwaterprooftreatment，the surroundingofit shouldhave
drainagesinkplaced,and theslopeangleshouldbe noless than0.5%，and
the slope shouldleadtodrainageoutlet.
3)Inordertomaintainquiet operationandprevent thevibration andnoise
transmissionfrominterferingthe underfloors，the absorbershouldbe laid
between the unitbaseand baseplatform. Pleasemaintainhorizontalwhen
install theunitandmountantivibration padwhen it isnecessary.
4)Inordertokeepconnectionpipefrombeing twisted tocrackbyearthquake,
typhoon,orbylongtimerunningcausedmovement. The fixationmethod
shouldbe takenintoconsideration,referstofollowingexamplesforplatform
installationandfixation
Picture3-2: PlatformInstallation
Note:1)Photo3-2theplatform sizeisfor moduleunit, payspecial
attention tothereallocation and sizeofinstallation holes.
2)Whenadoptsphoto3-3showedfixationway,keepbearing boltholes
for platform and itsabsorberasphoto3-2showedinstallation hole
location.

20(44)
3.4Hangingand TransportingoftheUnit
1)Proposeplansofhangingand transportingbeforepractise,includingentering
dateforeachunit,dimensionsofappearance, weight, path,reserved holes,
hangingandtransportingdeviceaswell. Figure3-1showsthe details.
Table3-1: NoticeforLiftingMatters
Items Check points
Transporting
Path 1. Check aisle,stair gateandtransportingpath.
2. Check roof, baseroomand hanging path.
Unload
1. Check the weightof theunit.
2. Prepareunloaddevices.
3. Check the temporarylayingplaceandkeep the unitclean.
Transporting
1. If the large-scale machinecan be decomposed, then decompose
it andtransport eachpart respectivelyand then combinethem
finally.
2. If the large-scale machinecannotbe decomposed, then dighole
in thewall or earthtotransportit.
Pathadjustment Adjust withthe wall,floor tofacilitatetransporting.
Others Arrangenentof laborand hanging device;problems of wokerand
unitsafety.
2)Accordingtosafetycommand, when hangingand transportingunits, assign
specialperson todirect andtheremustbewarningand precaution measures
toensuresafetyofpeopleand machines.
3)Considerthe weight ofthe unit. Takewoven beltashangingdeviceandadd
bearingarticlestoavoiddamagetometalboard.Keephorizontalorvertical
state.It isforbidden theunitinclinedbyover30 degrees.
4)Protecttheunitfrombeingcutordeformation.Placeprotectivemat orwood
polesinthecontactplacesbetween woven belt andtheunit.
Picture3-3: Hangingand Transportingof theUnit
