TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow
for sufficient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update or
to keep current the information contained in this document.
We reserve the right to make improvements to this document and/
or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed,stored inaretrieval system,or anyofits parttranslated
into any language or computer file, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise — without express written permission and consent
© Copyright 1997. All Rights Reserved.
Version 1.3 MAR 2014
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
CONTENTS
INTRODUCTION ..............................................................1
FEATURES & SPECIFICATIONS .....................................2
FRONT PANEL .................................................................3
BACK PANEL ....................................................................6
REMOTE CONTROL .......................................................7
REMOTE PROTOCOL COMMANDS ................................8
IR EXTENDER ................................................................9
RS-232 SERIAL INTERFACE .........................................11
TYPICALAPPLICATION..................................................12
INTRODUCTION
Congratulationsonyourpurchaseofoneofthemostinnovative8x8
Component Video (YPBPR) matrix product on the market Today.
The SB-8802 is a true Matrix Routing Switcher for Component
Video YPBPR signals. Support Higher Full HD resolution 480p,
720p and 1080i/p. It is a 8 individual Component Video inputs
with 8 individual Component Video outputs. Because it is a matrix
router, any input may be routed to any output; or the same input
maybe routed to all outputs or any combination. It completely
eliminates the need to constantly move around video YPBPR
input and output cables. The SB-8802 is useful for Matrix signals
from Component Video YPBPR source devices (such as: VCRs,
Camcorders, Video Game Consoles, Video CDs, DVDs, Satellite
Receivers,CAT5 SetTopBoxes,etc.)toComponentVideoYPBPR
destination devices (such as: LCD TV, HDTV, Plasma displays,
Projectors, etc.). Selection of inputs is made via the Front Panel
push buttons or an Infrared Remote Control unit or RS-232 control
by computer.
PACKAGE CONTENTS
Check that you have the following components;
• SB-8802 Matrix Switcher
• IR Remote Controller (SW-8802)
• 19 inch Ear mount bracket (Part # 1U-440L)
• IR Extender receiver (SB-100)
• CD Contents: This manual, Windows GUI
• RS-232 Cable
• Users Guide
• AC/DC Adapter: 12VDC, 2A Universal Type 50/60Hz,
100~230 VAC
1
