Shinybow USA SB-5688LCM-CT User manual

INSTRUCTION MANUAL
MODEL : SB-5688LCM-CT
8x8 HDMI-CAT6 MATRIX SWITCHER
8x8 HDMI-CAT6 Matrix Switcher
HDMI-CAT6 Matrix Switcher Series
Thank you for purchasing the SB-5688LCM-CT HDMI Matrix Switcher. You will find this unit easy to install and
highly reliable but it is essential that you read this manual thoroughly before attempting to use 8x8 HDMI-CAT6
Matrix Switcher.
MULTIMEDIA AUDIO AND VISUAL

SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power off and disconnect unit from AC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
flow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualified service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports first, then remove the power cable; finally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualifier service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF AGENERAL NATUREAND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL

TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow
for sufficient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update or
to keep current the information contained in this document.
We reserve the right to make improvements to this document and/
or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed,stored in aretrieval system,or anyof itspart translated
into any language or computer file, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise — without express written permission and consent
© Copyright 1997. All Rights Reserved.
Version 1.4 MAR 2014
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
CONTENTS
INTRODUCTION .............................................................. 1
PACKAGE CONTENTS .................................................... 1
FEATURES ...................................................................... 2
SPECIFICATIONS ............................................................ 3
FRONT PANEL ..................................................................4
REAR PANEL ...................................................................7
REMOTE CONTROL ....................................................... 9
EDID FUNCTION ............................................................ 13
TYPICAL APPLICATION ................................................ 16
IR EXTENDER ................................................................19
RS-232 SERIAL INTERFACE ......................................... 21
INTRODUCTION
The SB-5688LCM-CT is high-performance 8x8 matrix routing
switcher with eight (8) HDMI inputs and supports simultaneously
eight(8)HDMIandeight(8)CAT5e/6outputs.TheSB-5688LCM-CT
is based on HDBaseT technology and that supports full resolution
HDMI Video with embedded audio, RS-232, and IR bi-directional,
alloverasingleCAT5e/6cable.Withasignalbandwidthof340Mhz,
there is no signal degradation. High Definition Digital signals can
be selected and distributed to any 16 outputs simultaneously (8x
channels x2). The Switcher is certified as being fully CEC and
HDCP 2.0 compliant, HDMI V1.4a 3D formats, data rates up to
6.75 Gbps. Supports UXGA/WUXGA/DVI 1920x1200 resolution
to any HD displays. The SB-5688LCM-CT has one CAT5e/CAT6
and HDMI connector for each output, effectively making this an
8x16 switcher (same signal on both outputs). 1 RJ-45 connection
on each output extends the HDMI signal to remote location via
HDBaseT CAT5e/6 HDMI Receiver SB-6335R. The EDID can be
selected between seven (8) different modes. Control is provided
via Front panel push buttons, IR remote or via RS-232.An RS-232
Windows GUI interface is provided for matrix routing.
PACKAGE CONTENTS
Check that you have the following components;
• SB-5688LCM-CT Matrix Switcher
• RS-232 V2.0 Protocol Instructions
• Master wireless IR Remote Control (SW-5688)
• 8 ea. Individual wireless IR Control (SW-5688CT IR01~IR08)
• 19 inch Ear mount bracket (Part # 2U-440L)
• IR Extender Transmitter (SB-101)
• IR Extender Receiver (SB-100)
• 2 ea. IR Extender Cable 10 feet (3M)
• CD Contents: Manual, Windows GUI, ISP V1.0 Windows driver
• RS-232 Cable 6 feet (2M)
• Users Guide
• Worldwide Universal Power Supply 100~230 VAC, AC
50/60Hz, 10A
1

FEATURES
Based on HDBaseT, bi-directional IR, RS-232, Multi formatAudio, Ethernet and full resolution HD Video all, signals over CAT5e/6/7 cable.
FEATURES
• 8x HDMI source devices matrix switched to 8x HDMI and 8x CAT 5e/6/7 Extender output devices.
• Application HDBaseT IR, RS-232, MultiAudio Format and HD Video Signals over CAT 5e/6/7 Cable.
• HDMI digital Video w/ embeddedAudio, DVI format and CEC/HDCP 2.0 compliant
• Worldwide control EDID modes for HD Video resolutions.
• Link speeds of up to 6.75 Gbps (link clock rate of 340MbHz), Support HDMI 1.4a 3D formats.
• Wide range of HD resolutions from PC XGA to WUXGA 1920x1200 and HDTV/DTV HDMI resolutions 480i/480p, 576i/576p, 720p,
1080i & 1080p
• Compatible with all HDMI source devices, PC monitors, Plasma HD display, HDTV and audio receivers/amplifiers.
• Digital Video TMDS formats Resolution up to 1080p-60 with Deep color 36-bit.
• Digital Audio Support:
• Dolby TrueHD
• Dolby Digital
• Dolby Digital Plug/ex
• DTS
• DTS-HD
• DTS-HD Master
• DTS-EX
• PCM, PCM2, LPCM2
• Various User Interface control:
• Windows based GUI control via RS-232 port
• Front Panel push button
• IR wireless remote control
• Third party RS-232 controller (via simple ASCII)
• Support world wide control functions: ALL/OFF/RECALL/ENTER/MEMORY/EDID/LOCK
• Support EDID modes :
• Internal modes : AUTO/1080p-2CH/1080p-5.1/1080p-7.1/1080i-2CH/720p-2CH
• External modes : Passing mode with learning function.
• Automatic scanning input & output status via LED show on front panel.
• Support IR Remote and IR Extender with distance up to ~ 1000ft (300M) Maximum.
• EDID configuration via Internal modes.
• Consumer Electronic Control (CEC) switch all open or OFF
The Switcher will remember that last state during a power cycle. When power is removed and resorted, the last configuration will be invoked.
2

SPECIFICATIONS
SPECIFICATIONS
• Type of HDMI Switcher: 8x HDMI inputs To 8x HDMI and 8x CAT5e/6/7 Outputs Matrix Switcher
• HDMI Support: HD 1080p-@60Hz, H36-bit Deep color, 3D (1.4a) formats
• HDCP / CEC Support: HDCP 2.0 Compliant, CEC Compliant
• Video Bandwidth: Double Data Rates: 340Mhz, Total 6.75Gbps bandwidth
• Digital Video Support: Full HD Resolution: 480i / 480p / 720p / 1080i / 1080p up to 36bit deep color
• Inputs 8x HDMI Sources:
• 1x IR Ext. in ( IR To Switcher)
• 8x IRs (To 8x Rooms - Via HDBaseT)
• 1x ALL IR in (IR to Room - Via HDBaseT)
• 1x RS-232 (Command Switcher)
• 8x RS-232 (To 8x Rooms - Via HDBaseT)
• Outputs 8x HDMI Destinations:
• 8x CAT5e/6/7 (Via HDBaseT)
• 1x ALL IR out (IR from Room - via HDBaseT)
• 8x IRs (From 8x Rooms - Via HDBaseT)
• 8x RS-232 ( From 8x Rooms - Via HDBaseT)
• Digital Audio Support:
• Multi Audio Formats 5.1 / 7.1, MAT(MLP)
• Dolby Digital,
• Dolby TrueHD,
• Dolby Digital Plus,
• DTS, DTS-ES 6CH,
• DTS-HD, DTS-HD-HRA, DTS-HD Master,
• (PCM-2CH)
• Controls:
• IR Remote Controller (remote switcher)
• 8x IR Room Remote Controller
• IR External port x 1 (OD 3.5mm Ear phone Jack)
• Select & Function buttons on front panel
• RS-232 series interface
• Source Status: Automatically Scan Sources Inputs via LED
• Function Control Key: ALL / OFF / RECALL / ENTER / MEMORY / LOCK / EDID
• Infrared Frequency: 38 Khz
• IR External Distance: ~1000 feet / 300 meters max
• CAT5e/6 Extender Distance: ~300 feet / 100 meters maximum.
• HDMI I/O Connector: HDMI Type A - SMD 19pin Female Type
• Temperature: 32 °F - 100 °F Operation (0°C - 38 °C)
• Dimensions (LxWxH): 19* x 9.85 x 3.5 in (*with rackmount bracket) (482 x 250 x 88 mm)
• Rack Mount: Rack Mount 1RU High 19 ”Rack Mount (with rack mount)
• Power Supply: AC 100~230 VAC 50/60Hz
• Power Consumption: 6A Maximum
• Safety Approvals: CE, FCC, RoHS (2002/95/EC)
• Product Weight: 4.75 Kgs / 7.91 lb
As product improvements are continuous, specifications are subject to change without notice.
3

4
FRONT PANEL
FRONT PANEL
1. POWER SWITCH
The power switch turns the unit on and off. The LED will illuminate red to indicate that the switcher is ON and is receiving power.
The Switcher will remember that last state during a power cycle.
When power is removed and resorted, the last configuration will be evoked.
2. INPUT STATUS DISPLAY
Input sources 1 to 8 LED illuminates blue to indicate that a video source is present on that input.
3. OUTPUT STATUS DISPLAY
Each Output (destination) Channel shows which input (source) is assigned.
4. DESTINATION SELECT BUTTONS
Separate outputs 1 thru 8 select buttons are provided for each destination assignment. Routing can be Source to Destination or one
source to multiple destinations. Example : Press Destination 1,3,5 then press Source 2 will route Input 2 to Output 1,3,5 respectfully.
5. EDID MODE SELECT BUTTONS
Used to select EDID mode using Input buttons #1 and #2.
6. IR SENSOR
The IR sensor receives IR commands from the supplied remote controller or third party IR emitter.
7. SOURCE SELECT BUTTONS
Separate inputs 1 thru 8 select buttons are provided each source selection.
15. 19 INCH EAR MOUNT PAIR
Converts desktop to 19 inch rack mount. Bracket (part # 2U-440L) INCLUDED. Image shows rack mount bracket attached.

5
FRONT PANEL
FRONT PANEL
8. FUNCTION KEY - ALL
Disables (mute) video on all destinations OR Selects the same source to all destinations.
Option 1
- Press ALL followed by OFF button. The display will show “ 0 “ indicating all destinations have no video selected.
Option 2
- Press ALL followed by Source 1 thru 8. The display will show the Source selected.
- Press ENTER The pre-set source selection will be assigned all destinations.
9. FUNCTION KEY - OFF
Disables (mute) video to selected channels. Either destinations.
- Press OFF button followed by any Destination channel.
- Press 1 thru 8 output destination. The display will show “ 0 “ for the selected channel indicating no video selected.
10. FUNCTION KEY - ENTER
Press ENTER to confirm entries.
11. FUNCTION KEY - LOCK
- Press and hold LOCK button for two seconds lockout the front panel.
- Press and hold LOCK button for two seconds to enable the front panel.

6
FRONT PANEL
FRONT PANEL
12. FUNCTION KEY - RECALL
The system will show previously stored presets, up to a total of 16.
Presets are stored in local memory using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory preset location.
- Press RECALL button.
- Press 1 thru 8 on either Source or Destination row.
- Press ENTER The pre-set configuration will execute.
Operation completes.
Note: Operation will abort if no keys are dressed within 5 seconds.
13. FUNCTION KEY - MEMORY
The system will show store presets, up to a total of 16.
Presets are stored in local memory using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory preset location.
- Configure desired matrices.
- Press MEMORY button.
- Press 1 thru 4 on either Source or Destination row.
- Press ENTER to ready memory location.
- Or press MEMORY again to cancel operation.
Operation completes.
Note : Operation will abort if no keys are pressed within 5 seconds.
14. FUNCTION KEY - EDID
- Press EDID to select new EDID mode or select source row #1 or #2 for LINK source EDID again.
- Press DESTINATION again, press the same DESTINATION # to learn CATx EDID, The EDID for CATx has been learned.

7
REAR PANEL
REAR PANEL
1. DC POWER INLET
The Switcher is fitted with a AC power plug input connector. Ensure that the
used is of an approved type and is of sufficient current carrying connector
capacity with the correct voltage and connector polarity. 1100~240Volt AC,
50/60Hz power supply.
2. IR EXTENDER IN (EXT. IR TO CONTROL SWITCHER)
Support one of IR Extender to control Switcher. Extend distance maximum
300M / ~1000 ft. When you plug the External IR extender into the switcher,
the front panel IR receiver remain active.
3. RS-232 CONNECTION (SWITCHER)
RS-232 control port to allow for interfacing to a PC, Such as a computer
or touch panel control, to the switcher via this DB-9pin Female connector
for serial RS-232 control.
4. OUTPUTS- 1,2,3,4,5,6,7 & 8 HDMI
Connect a signal link of HDMI direct digital video/audio to this Female
HDMI connector. This connector supports HDMI digital video/audio and
DVI digital video sources.
HDMI Digital Video/Audio, Connector with fix screw Output 1 ~ Output 8
5. INPUTS- 1,2,3,4,5,6,7, & 8 HDMI
Connect a signal link of HDMI direct digital video/audio to this Female
HDMI connector. This connector supports HDMI digital video/audio and
DVI digital video sources.
HDMI Digital Video/Audio, Connector with fix screw Input 1 ~ Input 8
Power Plug:
Power input - AC100~240V,50/60Hz, 10A
IR Extender Jack:
Female Jack - inner OD O 3.5 mm
Remote port :
DB-9pin Female connector
HDMI digital video/audio connector:
HDMI Female connector.
Note: With the proper adapters, the
switcher can be used with DVI digital
video signals HDCP compliant.
HDMI digital video/audio connector:
HDMI Female connector.
Note: With the proper adapters, the
switcher can be used with DVI digital
video signals HDCP compliant. DVI
does not support audio.

8
REAR PANEL
REAR PANEL
6. RS-232- 1,2,3,4,5,6,7 & 8 CONNECTION TO CONTROL ROOM
8x RS-232 control port to allow for interfacing to a PC such as a computer
or touch panel control, to the switcher via this DB-9pin Female connector
for serial RS-232 control.
7. OUTPUT - 1,2,3,4,5,6,7 & 8 CAT
CAT Transmitter extend a signal link of HDMI / RS-232 / IR Remote to this
RJ-45 Female connector via CAT5e/6 cable.
Connector with RJ-45 Output 1 ~ Output 8
8. IR REMOTE INPUT - 1,2,3,4,5,6,7 & 8 IR SIGNAL TO ROOM
Support eight of IR Extender to control signal to eight rooms. Extend
cable distance maximum 300M / ~1000 ft. When you plug the CAT5e/6/7
IR extender into the external port, the room IR receiver remain active.
9. IR REMOTE OUTPUT - 1,2,3,4,5,6,7 & 8 IR SIGNAL FROM ROOM
Support eight of IR Extender to receive signal from eight rooms. Extend
cable distance maximum 300M/ ~1000 ft. When you plug the CAT5e/6/7
IR extender into the external port, the room IR receiver remain active.
10. ALL IN : ALL HDBaseT IR REMOTE 1,2,3,4,5,6,7 & 8 (IR SIGNAL TO ROOM)
Support eight of IR remote signals to control to eight rooms via ALL IN port.
Extend cable distance maximum 300M / ~1000 ft. When you plug the
CAT5e/6/7 IR extender into the external port, the room IR receiver
remain active.
11. ALL OUT : ALL HDBaseT IR REMOTE - 1,2,3,4,5,6,7 & 8 (IR SIGNAL FROM ROOM)
Support eight of IR remote signals from eight rooms via ALL OUT port.
Extend cable distance maximum 300M / ~1000 ft. When you plug the
CAT5e/6/7 IR extender into the external port, the room IR receiver
remain active.
Remote port :
DB-9pin Female connector
CAT connector: RJ-45Femaleconnector
IR Extender Jack:
Female Jack - inner OD O 3.5 mm
IR Extender Jack:
Female Jack - inner OD O 3.5 mm
IR Extender Jack:
Female Jack - inner OD O 3.5 mm
IR Extender Jack:
Female Jack - inner OD O 3.5 mm

REMOTE CONTROL
Before making any connections to the switcher. Observe the following:
> Ensure the mains voltage supply matches the label on the
supplied plug-pack (+/- 10%)
> Ensure that the power switch is OFF
> Ensure that all system grounds (earth) are connected to a
common point.
>Avoid powering equipment within a system from multiple power
sources that may be separated by large distances
> Connect all audio video sources and destination equipment
> Power up all source and destination audio-visual sources
> For each destination output select the appropriate input source
by using the front panel input 1~8 select buttons. The supplied
IRremotecontrol.OrthroughtheRS-232serialcommunications
port.
> Upon power up the switcher will return to its last used setting
before powered down.
REMOTE CONTROL
IR REMOTE : SW-5688
IR REMOTE CONTROL KEY :
1. / 2. SWITCH 1 POWER ON or OFF
Controller with a separate power ON and OFF
3. DESTINATION : 1 thru 8 OUTPUT SELECTION
Press the destination button to select the output display channel.
4. SOURCE : 1 thru 8 INPUT SOURCE SELECTION
Press input 1~8 sources with selection button
5. FUNCTION KEY
ALL - function selection button
OFF - function selection button
EDID - function selection button
RECALL - function selection button
MEMORY - function selection button
ENTER - function selection button
LOCK - function selection button
9

REMOTE CONTROL
ROOM REMOTE CONTROL #1 ~ #8 CUSTOM CODE AND DATA CODES
IR CUSTOM AND DATA CODES (NEC Standard)
PRESS Number To Select SOURCE
CUSTOM CODE : 09F6
IR-01 DATA CODE: IR-02 DATA CODE:
SOURCE #1 : 09F6 11EE SOURCE #1 : 09F6 21DE
SOURCE #2 : 09F6 12ED SOURCE #2 : 09F6 22DD
SOURCE #3 : 09F6 13EC SOURCE #3 : 09F6 23DC
SOURCE #4 : 09F6 14EB SOURCE #4 : 09F6 24DB
SOURCE #5 : 09F6 15EA SOURCE #5 : 09F6 25DA
SOURCE #6 : 09F6 16E9 SOURCE #6 : 09F6 26D9
SOURCE #7 : 09F6 17E8 SOURCE #7 : 09F6 27D8
SOURCE #8 : 09F6 18E7 SOURCE #8 : 09F6 28D7
IR-03 DATA CODE: IR-04 DATA CODE:
SOURCE #1 : 09F6 31CE SOURCE #1 : 09F6 41BE
SOURCE #2 : 09F6 32CD SOURCE #2 : 09F6 42BD
SOURCE #3 : 09F6 33CC SOURCE #3 : 09F6 43BC
SOURCE #4 : 09F6 34CB SOURCE #4 : 09F6 44BB
SOURCE #5 : 09F6 35CA SOURCE #5 : 09F6 45BA
SOURCE #6 : 09F6 36C9 SOURCE #6 : 09F6 46B9
SOURCE #7 : 09F6 37C8 SOURCE #7 : 09F6 47B8
SOURCE #8 : 09F6 38C7 SOURCE #8 : 09F6 48B7
10

REMOTE CONTROL
ROOM REMOTE CONTROL #1 ~ #8 CUSTOM CODE AND DATA CODES
IR CUSTOM AND DATA CODES (NEC Standard)
PRESS Number To Select SOURCE
CUSTOM CODE : 09F6
IR-05 DATA CODE: IR-06 DATA CODE:
SOURCE #1 : 09F6 51AE SOURCE #1 : 09F6 619E
SOURCE #2 : 09F6 52AD SOURCE #2 : 09F6 629D
SOURCE #3 : 09F6 53AC SOURCE #3 : 09F6 639C
SOURCE #4 : 09F6 54AB SOURCE #4 : 09F6 649B
SOURCE #5 : 09F6 55AA SOURCE #5 : 09F6 659A
SOURCE #6 : 09F6 56A9 SOURCE #6 : 09F6 6699
SOURCE #7 : 09F6 57A8 SOURCE #7 : 09F6 6798
SOURCE #8 : 09F6 58A7 SOURCE #8 : 09F6 6897
IR-07 DATA CODE: IR-08 DATA CODE:
SOURCE #1 : 09F6 718E SOURCE #1 : 09F6 817E
SOURCE #2 : 09F6 728D SOURCE #2 : 09F6 827D
SOURCE #3 : 09F6 738C SOURCE #3 : 09F6 837C
SOURCE #4 : 09F6 748B SOURCE #4 : 09F6 847B
SOURCE #5 : 09F6 758A SOURCE #5 : 09F6 857A
SOURCE #6 : 09F6 7689 SOURCE #6 : 09F6 8679
SOURCE #7 : 09F6 7788 SOURCE #7 : 09F6 8778
SOURCE #8 : 09F6 7887 SOURCE #8 : 09F6 8877
11

REMOTE PROTOCOL COMMANDS
IR REMOTE CUSTOM AND DATA CODES (NEC Standard)
HOW TO SETUP IR CODES :
CUSTOM CODE : 09F6
POWER ON : 09F6 A15E
POWER OFF : 09F6 A25D
ALL : 09F6 B04F
OFF : 09F6 B14E
EDID : 09F6 B748
LOCK : 09F6 B54A
RECALL : 09F6 B24D
MEMORY : 09F6 B44B
ENTER : 09F6 B34C
PRESS DESTINATION - # then PRESS SOURCE - #
DESTINATION #1 : 09F6 10EF
DESTINATION #2 : 09F6 20DF
DESTINATION #3 : 09F6 30CF
DESTINATION #4 : 09F6 40BF
DESTINATION #5 : 09F6 50AF
DESTINATION #6 : 09F6 609F
DESTINATION #7 : 09F6 708F
DESTINATION #8 : 09F6 807F
SOURCE #1 : 09F6 01FE
SOURCE #2 : 09F6 02FD
SOURCE #3 : 09F6 03FC
SOURCE #4 : 09F6 04FB
SOURCE #5 : 09F6 05FA
SOURCE #6 : 09F6 06F9
SOURCE #7 : 09F6 07F8
SOURCE #8 : 09F6 08F7
For example;
Select Destination # 1 to show Source #1~8,
The IR Data Code list :
Destination # 1 , Source #1 09F6 10EF 09F6 01FE
Destination # 1 , Source #2 09F6 10EF 09F6 02FD
Destination # 1 , Source #3 09F6 10EF 09F6 03FC
Destination # 1 , Source #4 09F6 10EF 09F6 04FB
Destination # 1 , Source #5 09F6 10EF 09F6 05FA
Destination # 1 , Source #6 09F6 10EF 09F6 06F9
Destination # 1 , Source #7 09F6 10EF 09F6 07F8
Destination # 1 , Source #8 09F6 10EF 09F6 08F7
12

EDID FUNCTION
EDID FUNCTION FOR HDMI MATRIX SWITCHER
EDID Setup To Change the EDID Setup
Step 1. Press the EDID button The display will show the currently selected EDID mode
Step 2. Press SOURCE #1 or #2 button row The button will flash blue and the display will show the current Embedded EDID Status.
Step 3. Press the ENTER button To set EDID mode. The switcher will return to operation mode.
Operation will abort if no keys are pressed within 5 seconds.
RESET EDID Return To Factory default
How to RESET EDID mode
Press EDID > RECALL > ENTER
RESET To the FACTORY DEFAULT (1080p-2CH).
Press EDID button : The LCM will show the current EDID status.
Press RECALL button : The LCM will show the RESET EDID.
Press ENTER to confirm entries.
The EDID will return to FSS mode and resolution 1080p-2CH.
Embedded EDID Modes Total 8 EDID Modes
Embedded EDID setup
Press EDID > SOURCE > ENTER
SOURCE #1
or
SOURCE #2
Select Embedded EDID :
Mode 1 : FSS
Mode 2 : H24-3D
Mode 3 : H24-3D-M
Mode 4 : H36-3D
To select Embedded EDID mode or LEARNING mode.
Press EDID button: The LCM will show the current EDID status.
Repeatedly depressing the Source 1 button will cycle up thru the options.
Repeatedly depressing the Source 2 button will cycle down thru the options.
LEARNING EDID Learning EDID from Destination to Source
Learning EDID Setup
Press
EDID > DESTINATION > SOURCE > ENTER
Press EDID > DESTINATION Button:
Switcher will LEARN destination HDMI EDID and pass the selected source.
Switcher will LEARN destination EDID and pass the selected source.
Learning EDID setup for HDMI: Key Press Sequence:
EDID > DESTINATION # > SOURCE # > ENTER
The EDID for HDMI has been learned
Press
EDID > DESTINATION > DESTINATION >
SOURCE > ENTER
Switcher will LEARN destination CATx EDID and pass the selected source.
Learning EDID setup for CATx: Key Press Sequence:
EDID > DESTINATION # > DESTINATION # > SOURCE # > ENTER
Again, Press the same DESTINATION # to learn CATx EDID The EDID for CATx
has been learned
13
Mode 5 : H36-3D-M
Mode 6 : 1280x1024-60Hz
Mode 7 : 1920x1200-60Hz
Mode 8 : AUTO

EDID FUNCTION
NOTE : The already learned EDID cannot be modified. You can only rebuild a new Learning EDID.
For example:
When the Source has “Learned” the EDID data from a destination, It will save that EDID information into EPROM and the
EDID data cannot change. Please select new learning destination to sources or change to one of the embedded EDID modes
when you want to remove the learning EDID memory from EPRPM.
Mode 1. FSS (Fast Speed Start)
Automatic capture most suitable EDID from Destination to Source.
Mode 5. H36-3D-M (1080p-36 bits)
Audio Support : MAT(MLP) 7.1CH, PCM 2CH, One Bit Audio 2CH,AC-3
5.1CH, DTS 5.1CH, PCM 7.1CH, Dolby Digital + 7.1CH, DTS-HD 7.1CH
Mode 2. H24-3D (1080p-24 bits)
Audio Support : PCM 2CH
Mode 6. 1280x1024-60Hz (DVI-D)
DVI-D 1280x1024 60Hz
Mode 3. H24-3D-M (1080p-24bits)
Audio Support : MAT(MLP) 7.1CH, PCM 2CH, One Bit Audio 2CH,AC-3
5.1CH, DTS 5.1CH, PCM 7.1CH, Dolby Digital + 7.1CH, DTS-HD 7.1CH
Mode 7. 1920x1200-60Hz (DVI-D)
DVI Support : DVI-D 1920 x 1200 60Hz
Mode 4. H36-3D (1080p-36 bits)
Audio Support : PCM 2CH
Mode 8. AUTO <Default>
All Outputs will be set to the highest common resolution of all connected
display devices.
Learning EDID Single to Single Example : Learn Destination #8 EDID To Source #5.
Step 1. Press EDID button The button will flash blue and the display will show the current Embedded EDID
Status.
Step 2. Press the Destination #8 button row Copy the Destination #8 Display EDID.
Step 3. Press the Source #5 button row Learning the Destination #8 EDID to Source # 5.
Step 4. Press ENTER button To confirm entries.
Learning EDID Single to Multiple Learning destination EDID link to the majority Sources
Step 1. Press EDID button The button will flash blue and the display will show the current Embedded EDID Status.
Step 2. Press the Destinations #1 ~ 8 button row Copy any 1~8 Destinations EDID.
Step 3. Press the Source #1, #6~#8 button row Learning the Destination EDID link to Source #1, #6 ~ #8 .
Step 4. Press ENTER button To confirm entries.
Learning EDID Single to ALL Learning destination EDID link to All Sources
Step 1. Press EDID button The button will flash blue and the display will show the current Embedded EDID
Status.
Step 2. Press destination button 1 thru 8 Learning anyone 1~8 Destination EDID to all sources.
Step 3. Press ALL button Learning selected destination EDID to all sources.
Step 4. Press ENTER button To confirm entries.
14

EDID FUNCTION
EDID FUNCTION FOR HDMI MATRIX SWITCHER
EDID Status To view the current EDID status.
Step 1. Press EDID button The button will flash blue and the display will show the current Embedded EDID Status.
Step 2. Press EDID button To exit.
How to setup FSS Function Fast Speed Start
Step 1. Press the Destination #1~8 button row
Then Press the Source #1~8 button row To setup and Install all devices.
Step 2. Press EDID button Select a optimum status of Embedded EDID mode.
Step 3. Press ENTER button To conform entries
Step 4. Press EDID button To select the EDID FSS mode.
Step 5. Press ENTER button To confirm entries.
LEARNING EDID Definition Learning EDID from Destination to Source
1. Switcher will LEARN destination EDID and pass the selected source.
2. To set up learning between a single destination and single source:
Press EDID button > Press Destination 1 thru 8 > Press Source 1 thru 8 > Press ENTER to confirm.
Switcher will learn destination EDID to source device.
3. To set up learning between a single destination and Multiple sources:
Press EDID button > Press Destination 1 thru 8 > Press the majority Sources 1 thru 8 > Press ENTER.
Switcher will learn single destination EDID to many source devices.
4. How to Learning single destinations with all sources.
Press EDID button > Press ALL button > Press ENTER to confirm.
Auto Mode Definition Common Resolution and Audio
Switcher will find highest common Resolution and Audio from all destination EDID to link Source.
Example for single source
Destination > press #1 and then Source > press #1
Destination device #1 will set to the highest common resolution and Audio of source #1
Example for multiple sources
Destination device #1, #2, #3 will be set to the highest common resolution and Audio available and source device #1 will output
this same resolution.
15

TYPICALAPPLICATION
INSTALLING DIAGRAM
Sample connection using IR Transmitters (SB-101) and IR Receiver (SB-100) with SB-6335R & SB-5688LCM-CT to control a projector.
NOTE:
1. IR Control Projector Over HDBaseT Extender:
SB-5688LCM-CT HDBaseT Transmitter
SB-6335R HDBaseT Receiver
2. Projector RS-232 Control by a PC via CAT6 TX.
3. Projector IR control via CAT6 IR in (IR To projector).
4. IR Extender Transmitter (SB-101): Use SB-101 IR Transmitter to
Extend IR signal to Projector.
5. IR Extender Receiver (SB-100): Use SB-100 IR Receiver to receive
the Projector IR Remote signal.
Support HDBaseT Extender by SB-6335T Transmitter and SB-6335R Receiver via CAT5e/6/7 cable.
16

TYPICALAPPLICATION
INSTALLING DIAGRAM
Sample connection using IR Transmitters (SB-101) with SB-5688LCM-CT and SB-6335R to control a IR signal from Satellite Receiver.
NOTE:
1. IR Control Satellite Receiver Over HDBaseT CAT5e/6/7 Extender from room:
SB-5688LCM-CT HDBaseT CAT5e/6/7 Transmitter
SB-6335R HDBaseT CAT5e/6/7 Receiver
2. Destination RS-232 Control :
Via SB-5688LCM-CT TX RS-232 in.
3. IR Extender Transmitter (SB-101):
Use SB-101 IR Transmitter to Extend IR signal
Support HDBaseT Extender by SB-6335T Transmitter and SB-6335R Receiver via CAT5e/6/7 cable.
17

TYPICALAPPLICATION
INSTALLING DIAGRAM
Sample connection using Audio Extractor To Recode Audio (SB-5609) or to control ARC (SB-5610) and Extend the HDMI signal via
HDBaseT Transmitter to IR Receivers (SB-6335R) with SB-5688LCM-CT to extend 100M distance between switcher and destination.
NOTE:
1. Audio Extractor To Recode Audio : SB-5609 HDMI Audio Extractor.
2. Control HDMI ARC: SB-5610 ARC Control Box.
3. Switcher RS-232 Control Via a PC.
4. Switcher IR External port : Via SB-100 IR Extender Receiver.
5. HDMI Display : Signal from Blu-Ray or HD Satellite Receiver.
Application HDBaseT IR, RS-232, Multi formatAudio and HD Video signals to pass over CAT5e/6/7 cable.
18
