OWNER'S MANUAL
(FOR MODELS MANUFACTURED SINCE 10/15)
MODEL W1741W/W1741SW
8" JOINTER
Phone: [phone] • Online Technical Support: [email protected]
COPYRIGHT © FEBRUARY, 2016 BY WOODSTOCK INTERNATIONAL, INC.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
# 17934BL Printed in China

This manual provides critical safety instructions on the proper setup,
operation, maintenance, and service of this machine/tool. Save this
document, refer to it often, and use it to instruct other operators.
Failure to read, understand and follow the instructions in this manual
may result in fire or serious personal injury—including amputation,
electrocution, or death.
The owner of this machine/tool is solely responsible for its safe use.
This responsibility includes but is not limited to proper installation in
a safe environment, personnel training and usage authorization,
proper inspection and maintenance, manual availability and compre-
hension, application of safety devices, cutting/sanding/grinding tool
integrity, and the usage of personal protective equipment.
The manufacturer will not be held liable for injury or property
damage from negligence, improper training, machine modifications or
misuse.
Some dust created by power sanding, sawing, grinding, drilling, and
other construction activities contains chemicals known to the State of
California to cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints.
• Crystalline silica from bricks, cement and other masonry products.
• Arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals:
Work in a well ventilated area, and work with approved safety equip-
ment, such as those dust masks that are specially designed to filter
out microscopic particles.

SET UPELECTRICAL MAINTENANCE SERVICE PARTS
OPERATIONS
SAFETYINTRODUCTION
USE THE QUICK GUIDE PAGE LABELS TO SEARCH OUT INFORMATION FAST!
INTRODUCTION .....................................2
Contact Info....................................... 2
Manual Accuracy.................................. 2
Machine Specifications .......................... 3
Controls & Components ......................... 7
SAFETY ...............................................9
Standard Machinery Safety Instructions ...... 9
Additional Safety for Jointers................ 11
ELECTRICAL ....................................... 12
Circuit Requirements .......................... 12
Grounding Requirements...................... 13
Extension Cords ................................ 13
SETUP .............................................. 14
Unpacking ....................................... 14
Items Needed for Setup....................... 14
Inventory ........................................ 15
Cleaning Machine............................... 16
Machine Placement ............................ 17
Assembly......................................... 18
Knife-Setting Jig (W1741W) .................. 24
Dust Collection ................................. 24
Test Run.......................................... 25
Recommended Adjustments .................. 26
Tighten Belt ..................................... 26
OPERATIONS....................................... 27
General .......................................... 27
Stock Inspection & Requirements ........... 28
Squaring Stock .................................. 29
Surface Planing ................................. 30
Edge Jointing ................................... 31
Bevel Cutting ................................... 32
Rabbet Cutting ................................. 33
ACCESSORIES ...................................... 34
Jointer Accessories............................. 34
MAINTENANCE .................................... 35
General .......................................... 35
Cleaning & Protecting ......................... 35
Lubrication ...................................... 36
SERVICE ............................................ 37
General .......................................... 37
Inspecting Knives ............................... 37
Setting/Replacing Knives (W1741W) ........ 38
Rotating/Replacing Cutterhead Inserts
(W1741SW) ...................................... 41
Checking/Adjusting Table Parallelism ...... 43
Setting Outfeed Table Height ................ 47
Adjusting Infeed Table Stop Bolts ........... 48
Calibrating Depth-of-Cut Scale .............. 48
Setting Fence Stops............................ 49
Replacing/Tensioning Belt .................... 51
Aligning Pulleys................................. 52
Troubleshooting................................. 53
Electrical Safety Instructions................. 55
Wiring Diagram ................................. 56
PARTS .............................................. 57
Table ............................................. 57
Cutterhead (W1741W) ......................... 58
Cutterhead (W1741SW)........................ 59
Fence............................................. 60
Stand ............................................. 61
Labels & Cosmetics ............................ 62
WARRANTY ........................................ 65
Contents

-2-
Model W1741W/W1741SW (Mfd. Since 10/15)
INTRODUCTION
INTRODUCTION
We are proud to provide a high-quality owner’s
manual with your new machine!
We
made every effort to be exact with
the
instructions, specifications, drawings, and pho-
tographs contained inside. Sometimes we make
mistakes, but our policy of continuous improve-
ment
also means that sometimes the
machine
you receive will be slightly different than what
is shown in the manual
.
If you find this to be the case, and the difference
between the manual and machine leaves you
confused about a procedure
,
check our website
for an updated version. W
e post current
manuals
and
manual updates for free
on our website at
www.
woodstockint.com.
Alternatively, you can call our Technical Support
for help. Before calling, make sure you write
down the
Manufacture Date and Serial Number
from the machine ID label (see below). Also, if
available, have a copy of your original purchase
receipt on hand. This information is required for
all Tech Support calls.
MODEL XXXX
MACHINE NAME
Motor:
Specification:
Specification:
Specification:
Specification:
Weight:
Specifications
To reduce risk of serious personal injury when using this
machine:
1. Read & understand owner’s manual before operating.
2. Always wear approved eye protection and respirator.
3. Only plug power cord into a grounded outlet.
4. Only use this machine to collect wood dust/chips—never
use to collect glass, metal, liquids, asbestos, silica,
animal parts, biohazards, burning material/ashes, etc.
5. Always disconnect power before servicing or cleaning.
6. Do not expose to rain or wet areas.
7. Keep hands, long hair, and loose clothing away from
inlet.
8. Never leave machine unattended while it is running.
9. Do not use if cord/plug becomes damaged—promptly
repair and protect cord from future damage.
10. Do not use without dust bag or filters in place.
11. Always wear a respirator when emptying bags.
12. Prevent unauthorized use by children or untrained users.
Date
Serial Number
Manufactured for Woodstock in Taiwan
WARNING!
Manufacture
Date
Serial Number
Manual Accuracy
We are committed to customer satisfaction. If
you have any questions or need help, use the
information below to contact us.
IMPORTANT: Before contacting, please get the
original purchase receipt, serial number, and
manufacture date of your machine. This infor-
mation is required for all Technical Support
calls and it will help us help you faster.
Woodstock International Technical Support
Phone: [phone]
Email: [email protected]
We want your feedback on this manual. What did
you like about it? Where could it be improved?
Please take a few minutes to give us feedback.
Technical Documentation Manager
P.O. Box 2309
Bellingham, WA 98227
Email: [email protected]
Contact Info

-3-
Model W1741W/W1741SW (Mfd. Since 10/15)
INTRODUCTION
MODEL W1741W, W1741SW
8" JOINTER
Model Number W1741W W1741SW
Product Dimensions
Weight 475 lbs. 477 lbs.
Width (side-to-side)/Depth
(front-to-back)/Height 76-1/2 x 26-1/2 x 45-1/2 in.
Foot Print (Width/Depth) 41 x 17 in.
Shipping Dimensions
Carton #1
Type Wood Crate
Content Machine
Weight 387 lbs. 389 lbs.
Length x Width x Height 80 x 26 x 12 in.
Carton #2
Type Cardboard
Content Stand
Weight 167 lbs.
Length x Width x Height 39 x 19 x 29 in.
Electrical
Power Requirement 240V, Single-Phase, 60 Hz
Full-Load Current Rating 12A
Minimum Circuit Size 20A
Connection Type Cord & Plug
Power Cord Included Yes
Power Cord Length 6 ft.
Power Cord Gauge 12 AWG
Plug Included Yes
Included Plug Type 6-20
Switch Type Magnetic w/Thermal Overload Protection
Main Motor
Type TEFC Capacitor-Start Induction
Horsepower 3 HP
Phase Single-Phase
Amps 12A
Speed 3450 RPM
Power Transfer Belt Drive
Bearings Sealed & Permanently Lubricated
© Woodstock International, Inc. • Phone #: [phone] • Web: www.shopfox.biz
MACHINE
SPECIFICATIONS
