Show Tec NanoQ 19 Q4 IP V1 User manual

NanoQ 19 Q4 IP V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 43712
MANUAL
ENGLISH

1
Ordercode: 43712
NanoQ 19 Q4 IP
Table of contents
Warning ...............................................................................................................................................................................3
Safety Instructions .........................................................................................................................................................3
Operating Determinations ..........................................................................................................................................5
Rigging ............................................................................................................................................................................5
Connection with the mains.........................................................................................................................................6
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Features ..........................................................................................................................................................................7
Beam angle: 25°, Spot angle: 55°..............................................................................................................................8
Beam angle: 10°, Spot angle: 29°..............................................................................................................................8
Frontside..........................................................................................................................................................................9
Backside .......................................................................................................................................................................10
Installation.........................................................................................................................................................................10
Set Up and Operation .....................................................................................................................................................10
Control Modes.............................................................................................................................................................11
One NanoQ (Auto test, Manual)..........................................................................................................................11
Multiple NanoQs (DMX Control) ...........................................................................................................................11
Fixture Linking...............................................................................................................................................................12
Data Cabling...............................................................................................................................................................12
Control Panel ...............................................................................................................................................................13
Control Mode ..............................................................................................................................................................13
DMX Addressing ..........................................................................................................................................................13
Menu Overview...........................................................................................................................................................14
Main Menu Options....................................................................................................................................................15
1. DMX Sets................................................................................................................................................................15
1.1 DMX address.......................................................................................................................................................15
1.2 DMX Hold ............................................................................................................................................................15
2. Options ..................................................................................................................................................................15
2.1 Curve ...................................................................................................................................................................16
2.2 Dim mode ...........................................................................................................................................................16
2.3 Channel...............................................................................................................................................................16
2.3 Zoom invert .........................................................................................................................................................16
3. Backlight................................................................................................................................................................17
4. Manual control.....................................................................................................................................................17
5. Test..........................................................................................................................................................................17
6. Factory...................................................................................................................................................................17
7. Reset.......................................................................................................................................................................18
DMX Channels .............................................................................................................................................................18
14 Channels ..............................................................................................................................................................18
10 Channels ..............................................................................................................................................................19
9 Channels ................................................................................................................................................................20
8 Channels ................................................................................................................................................................20
7 Channels ................................................................................................................................................................21
6 Channels ................................................................................................................................................................21
5 Channels ................................................................................................................................................................22
Maintenance....................................................................................................................................................................23

2
Ordercode: 43712
NanoQ 19 Q4 IP
Troubleshooting ...............................................................................................................................................................23
No Light.........................................................................................................................................................................23
No Response to DMX..................................................................................................................................................23
Product Specification .....................................................................................................................................................25
Dimensions........................................................................................................................................................................26

3
Ordercode: 43712
NanoQ 19 Q4 IP
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Showtec NanoQ 19 Q4 IP
Schuko to PowerCON connector power cable (1,5 m)
User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving your lifespan expectancy is of a higher priority, place care in providing
for lower operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

4
Ordercode: 43712
NanoQ 19 Q4 IP
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s life.
Do not touch the device’s housing bare-handed during its operation. Allow the fixture to cool for at
least 5 minutes before handling.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoors, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of the reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the NanoQ 19 Q4 IP. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

5
Ordercode: 43712
NanoQ 19 Q4 IP
Operating Determinations
●This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
●The minimum distance between light-output and the illuminated surface must be more than 1 meter.
●The maximum ambient temperature ta = 40°C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
●If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
●Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself!
Always let the installation be carried out by an authorized dealer!
Procedure:
●If the NanoQ 19 Q4 IP is lowered from the ceiling or high joists, professional trussing systems have to
be used.
●Use a clamp to mount the NanoQ 19 Q4 IP, with the mounting-bracket, to the trussing system.
●The NanoQ 19 Q4 IP must never be fixed swinging freely in the room.
●The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety-cable.
●When rigging, derigging or servicing the NanoQ 19 Q4 IP, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
Improper installation can cause serious injuries to people and/or damage of property!

6
Ordercode: 43712
NanoQ 19 Q4 IP
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

7
Ordercode: 43712
NanoQ 19 Q4 IP
Description of the device
Features
The Showtec NanoQ 19 Q4 IP is a rental outdoor LED spot with zoom function. It has a clear lens plate
with an RGB backlight glare effect and a zoom range between 6° - 60°. It is equipped with 19 x RGBW
10W LEDs, to create a massive output. You can control colors, dimmer and strobe of the wash LEDs and
backlight LEDs. The LED spot has a die-cast black powder coated aluminum housing with a double
bracket which makes it sturdy and rental proof. Original PowerCON True1 IN/OUT connections and
dedicated IP-rated 3-pin XLR chassis for easy daisy chaining. The large bright display makes it convenient
to access your settings, whenever needed.
Input voltage: 100-240V AC, 50/60Hz
Power consumption: 220W
Light output @ 2 m: 29300 lux (6°)
Backlight system: 21 x RGB 5050 SMD
Light source: 19 x 10W RGBW LEDs
Refresh rate: 1kHz
Driver current: 750mA/color
DMX modes: 5, 6, 7, 8, 9, 10, 14 channels
Beam angle: 6-60°
Color mixing: RGBW
IP rating: IP54
DMX-control via standard DMX-controller
Onboard: LCD display for easy setup
Control mode: Auto run, Manual mode, DMX512
Dimmer: 0-100%
Strobe: 0-20Hz
Housing: Die-cast aluminum powder coat finish
Power connector: PowerCON True1 connector IN/OUT
Data connectors: 3-pin IP XLR IN/OUT
Cooling: Convection (no fans) which eliminates the use of fans and noise
Dimensions: 310 x 270 x 390 mm (LxWxH)
Weight: 7,4 kg
Note: Knowledge of DMX is required to fully utilize this unit.

8
Ordercode: 43712
NanoQ 19 Q4 IP
Beam angle: 28°, Spot angle: 55°
Lux @ 1 - 5m
1 m
2 m
3 m
4 m
5 m
Red
1346
338
158
87
58
Green
3834
993
452
259
169
Blue
660
170
748
45
30
White
4874
1251
7570
322
213
FULL ON
8610
2212
1017
580
378
Beam angle: 10°, Spot angle: 29°
Lux @ 1 - 5m
1 m
2 m
3 m
4 m
5 m
Red
11150
4420
2093
1192
767
Green
29230
12440
5856
3341
2151
Blue
5012
2090
970
550
360
White
36110
15290
7227
4138
2661
FULL ON
61460
27700
13020
7430
4790

9
Ordercode: 43712
NanoQ 19 Q4 IP
Frontside
Fig. 01
01) 19 x 10W RGBW LEDs + 21 x RGB 5050 SMD
02) Adjustment screw
03) Double mounting bracket

10
Ordercode: 43712
NanoQ 19 Q4 IP
Backside
Fig. 02
04) LCD display + menu buttons
05) 3-pin DMX IP signal connector IN
06) PowerCON True1 power connector 100-240V IN
07) PowerCON True1 power connector 100-240V OUT
08) 3-pin DMX IP signal connector OUT
Installation
Remove all packing materials from the NanoQ 19 Q4 IP. Check that all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

11
Ordercode: 43712
NanoQ 19 Q4 IP
Control Modes
There are 3 modes:
Auto test
Manual mode
DMX-512 (5CH, 6CH, 7CH, 8CH, 9CH, 10CH, 14CH)
One NanoQ (Auto test, Manual)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the NanoQ 19 Q4 IP is not connected with a DMX cable, it functions as a stand-alone device.
05) Please see page 17 for more information about Auto and Manual modes.
Multiple NanoQs (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin XLR cable to connect the NanoQ 19 Q4 IP and other devices.
04) Link the units as shown in (fig.03). Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's PowerCON True1 power
connector socket, then plug the other end of the mains power cord into proper electric power
supply sockets, starting with the first unit. Do not supply power before the whole system is set up and
connected properly.
Multiple NanoQs (DMX Set Up)
b
Fig. 03

12
Ordercode: 43712
NanoQ 19 Q4 IP
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master / slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of NanoQs on a DMX data link: 30 fixtures
Maximum recommended number of NanoQs on a Power link: 4 fixtures @110V
Maximum recommended number of NanoQs on a Power link: 8 fixtures @240V
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
Note: connect the NanoQ 19 Q4s with the dedicated special XLR cables for outdoor use.
FL73150 1,5 m IP65 XLR/M 3p. > XLR/F 3p. Neutrik
FL733 3,0 m IP65 XLR/M 3p. > XLR/F 3p. Neutrik
FL736 6,0 m IP65 XLR/M 3p. > XLR/F 3p. Neutrik
FL7310 10 m IP65 XLR/M 3p. > XLR/F 3p. Neutrik
The NanoQ 19 Q4 IP can be operated with a controller in control mode or without the controller in stand-
alone mode.

13
Ordercode: 43712
NanoQ 19 Q4 IP
Control Panel
A)
B)
C)
D)
E)
LCD display
MODE button
SETUP button
UP button
DOWN button
Fig. 04
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the NanoQ 19 Q4 IP will respond to the controller.
Please note when you use the controller, the unit has 14 channels.
When using multiple NanoQs make sure you set the DMX addresses right.
Therefore, the DMX address of the first NanoQ should be 1(d001); the DMX address of the second NanoQ
should be 1+14=15 (d015); the DMX address of the third NanoQ should be 15+14=29 (d029), etc.
Please, be sure that you do not have any overlapping channels in order to control each NanoQ
correctly. If two or more NanoQs are addressed similarly, they will work similarly.
Controlling:
After having addressed all NanoQ fixtures, you may now start operating these via your lighting controller.
Note: After switching on, the NanoQ will automatically detect whether DMX 512 data is received or not. If
not, the problem may be:
The XLR cable from the controller is not connected with the input of the NanoQ 19 Q4 IP.
The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It’s necessary to insert a XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 15 seconds
When no button is pressed for 15 seconds, the display will turn off.
To light up the display, you have to press the MODE, SETUP, UP or DOWN button.
Once you have pressed the button, the display will light up.
You can set the backlight in the menu, see chapter 3. Backlight.

14
Ordercode: 43712
NanoQ 19 Q4 IP
Menu Overview

15
Ordercode: 43712
NanoQ 19 Q4 IP
Main Menu Options
There are 7 menu modes:
•1. DMX Sets
•2. Option
•3. Backlight
•4. Man control
•5. Test
•6. Factory
•7. Reset
The NanoQ19 Q4 IP starts up with screen:
1. DMX Sets
With this menu you can set the DMX address and the behavior of the device in case of a DMX failure.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu, the display shows .
1.1 DMX address
01) Press the SETUP button to open the menu .
02) You can choose 512 different DMX addresses.
Press the UP / DOWN buttons to select the required address from 001-512.
03) Press the MODE button to go back to the previous step.
1.2 DMX Hold
01) Press the UP / DOWN buttons to choose DMX Hold.
02) Press the SETUP button to enter the menu, the display will show .
01) If you choose “Hold”, the device will use the last properly received DMX signal until DMX connection
is restored.
04) If you choose “Off”, the device will black out.
05) Press the MODE button to go back to the previous step.
2. Options
With this menu you can adjust several settings.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu, the display shows .

16
Ordercode: 43712
NanoQ 19 Q4 IP
2.1 Curve
01) Press the SETUP button to open the menu .
02) Press the UP / DOWN buttons to scroll through the 4 curves modes.
03) Press the MODE button to go back to the previous step.
2.2 Dim mode
01) Press the UP / DOWN buttons to choose Dim mode.
02) Press the SETUP button to enter the menu, the display shows .
03) You can choose Fast or Smooth.
04) Press the MODE button to go back to the previous step.
2.3 Channel
01) Press the UP / DOWN buttons to choose Channel.
02) Press the SETUP button to enter the menu, the display shows .
03) You can choose 14, 10, 9, 8, 7, 6 or 5 channels.
04) Press the MODE button to go back to the previous step.
2.3 Zoom invert
01) Press the UP / DOWN buttons to choose Zoom invert.
02) Press the SETUP button to enter the menu, the display shows .
03) If you choose “No”, the device has a normal zoom (in the manual mode).
04) If you choose “Yes”, the device has an inverted zoom (in the manual mode).
05) Press the MODE button to go back to the previous step.

17
Ordercode: 43712
NanoQ 19 Q4 IP
3. Backlight
With this menu you can set the backlight of the display.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu, the display shows .
03) If you choose “Off”, the display will blackout after 15 seconds.
04) If you choose “On”, the display will always light up, even if there is no operation at the device.
05) Press the MODE button to go back to the previous step.
4. Manual control
With this menu you can set the manual control.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu, the display shows .
03) Press the UP / DOWN buttons to select Zoom, Red, Green, Blue, White, Redb, Greenb or Blueb.
04) Press the SETUP button again until the display shows .
05) Now you can adjust the intensity of the sections by pressing the UP / DOWN buttons from 000-255.
06) Press the MODE button to go back to the previous step.
5. Test
With this menu you can activate the automatic test programs.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu, the display shows .
03) If you choose “Exit”, the device will stop its DMX running mode.
04) If you choose “Slow”, the device will start automatically with its slow running program.
05) If you choose “Fast”, the device will start automatically with its fast running program.
06) Press the MODE button to go back to the previous step.
6. Factory
With this menu you can reset the device to its factory settings.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu, the display shows .
03) If you choose “Back”, you will go back to the main menu.
04) If you choose “Sure”, the device will reset to its factory settings.
05) Press the MODE button to go back to the previous step.

18
Ordercode: 43712
NanoQ 19 Q4 IP
7. Reset
With this menu you can reset the device.
01) Press the MODE button until the display shows .
02) Press the SETUP button to enter the menu, the display shows .
03) If you choose “Back”, you will go back to the main menu.
04) If you choose “Sure”, the device will reset.
05) Press the MODE button to go back to the previous step.
DMX Channels
14 Channels
Channel 1 –Master Dimmer
0-255
From black to brightest
Channel 2 –Master Strobe (CH1 and CH3, CH4, CH5, CH6 or CH7 must be set between 001-255 )
0-255
Strobe effect, from slow to fast (0-20Hz)
Channel 3 –Master Colors (CH1 must be set between 001-255 )
1-17
Red
18-35
Green
36-53
Blue
54-71
White
72-89
Red + Green
90-107
Red + Blue
108-125
Green + Blue
126-142
Red + Green + Blue + White (Full on)
143-192
Color pulse
193-224
Color fade
225-255
Color jump
Channel 4 –Red Dimmer intensity (CH1 must be set between 001-255 )
0-255
Red from 0 –100%
Channel 5 –Green Dimmer intensity (CH1 must be set between 001-255 )
0-255
Green from 0 –100%
Channel 6 –Blue Dimmer intensity (CH1 must be set between 001-255 )
0-255
Blue from 0 –100%
Channel 7 –White Dimmer intensity (CH1 must be set between 001-255 )
0-255
White from 0 –100%
Channel 8 –Background LED Dimmer
0-255
From black to brightest
Channel 9 –Background LED Strobe
(CH8 and CH10, CH11, CH12 or CH13 must be set between 001-255 )
0-255
Strobe effect, from slow to fast (0-20Hz)

19
Ordercode: 43712
NanoQ 19 Q4 IP
Channel 10 –Background LED Colors (CH8 must be set between 001-255 )
1-17
Red
18-35
Green
36-53
Blue
54-71
White
72-89
Red + Green
90-107
Red + Blue
108-125
Green + Blue
126-142
Red + Green + Blue (Full on)
143-192
Color pulse
193-224
Color fade
225-255
Color jump
Channel 11 –Background LED Red Dimmer intensity (CH8 must be set between 001-255 )
0-255
Red from 0 –100%
Channel 12 –Background LED Green Dimmer intensity (CH8 must be set between 001-255 )
0-255
Green from 0 –100%
Channel 13 –Background LED Blue Dimmer intensity (CH8 must be set between 001-255 )
0-255
Blue from 0 –100%
Channel 14 –Zoom
0-255
Zoom from 0 - 100%
10 Channels
Channel 1 –Total Dimmer
0-255
From black to brightest
Channel 2 –Strobe (CH1 and CH3, CH4, CH5, CH6, CH7, CH8 or CH9 must be set between 001-255 )
0-255
Strobe effect, from slow to fast (0-20Hz)
Channel 3 –Red Dimmer intensity (CH1 must be set between 001-255 )
0-255
Red from 0 –100%
Channel 4 –Green Dimmer intensity (CH1 must be set between 001-255 )
0-255
Green from 0 –100%
Channel 5 –Blue Dimmer intensity (CH1 must be set between 001-255 )
0-255
Blue from 0 –100%
Channel 6 –White Dimmer intensity (CH1 must be set between 001-255 )
0-255
White from 0 –100%
Channel 7 –Background LED Red Dimmer intensity (CH1 must be set between 001-255 )
0-255
Red from 0 –100%
Channel 8 –Background LED Green Dimmer intensity (CH1 must be set between 001-255 )
0-255
Green from 0 –100%
