Shure MXA920 Assembly instructions

Shure Array Microphone Setup Tips
for Lumens CamConenct

Copyright © Lumens. All rights reserved.
Purpose
•Help users quickly install Lumens CamConnenct Pro
and Shure Array Microphones.
•Especially focus on the setting tips of Shure array
microphone.
•These setting tips are the sharing of the key steps
summarized after we have installed this system many
times.

Copyright © Lumens. All rights reserved.
Prepare
•This document uses Shure MXA920 as an example of setting.
•Please install Shure array microphone, Lumens CamConnect
processor and Lumens PTZ cameras on the same LAN (same
class C network).
•For the first installation, you need to prepare a router or
Switcher with DHCP server function.
•Shure MXA920 installed in the ceiling above the center of a
conference table

Copyright © Lumens. All rights reserved.
Device Discovery
1. Download “Shure Web Device
Discovery“ software from below hyperlink.
https://www.shure.com/en-
US/products/software/shure_web_device_discover
y_application
2. Install and run this software.
3. You will get the IP address for the Shure ceiling
microphone.
4. Open the web browser and enter the webpage of
MXA920.

Copyright © Lumens. All rights reserved.
Automatic coverage: off
It is recommended to set “Automatic coverage” to off

Copyright © Lumens. All rights reserved.
Coverage
1. Go to the “Coverage” page.
2. If someone has set other channels before, please remove all channels first. Only
keep channel 1.

Copyright © Lumens. All rights reserved.
Add channel
Manually add the channel

Copyright © Lumens. All rights reserved.
Auto position
1. Need to find someone to speak at this seat position in the conference room
2. Select channel N, then press “Auto positon” button.
3. Press “Listen” button in Auto position windows.
4. Then the position of channel N will be found automatically.

Copyright © Lumens. All rights reserved.
Lobe width for the channel
Set the lobe width of each channel as “Narrow” or “Medium”.
This will reduce the area covered by each lobe and increase the accuracy of
voice tracking.

Copyright © Lumens. All rights reserved.
IntelliMix
Please go to the “IntelliMix” page.
There are also some settings here that will affect the tracking results of
CamConenct.

Copyright © Lumens. All rights reserved.
Priority
• If we enable “Priority”on channel 1. This means that when both channel 1 and channel 2 are
talking, the signal of Channel 1 will be sent first
•For example, in a meeting. The main speaker is in the position of Channel 1. Channel 1 can be set
with higher priority.

Copyright © Lumens. All rights reserved.
Always On
•If we enable “Always on”on channel 1.
•This means that Shure MXA920 will continue to send channel 1 is active.
•For example, in a meeting. The main speaker is in the position of Channel 1. Channel 1 can be set
with higher priority.

Copyright © Lumens. All rights reserved.
Send to mix
•If a certain channel has a fixed noise that keeps interfering, you can turn off its "Send to mix", and
the voice trigger signal will not be sent from this channel.

Copyright © Lumens. All rights reserved.
Leave Last Mic On
•Leave Last Mic On
Keeps the most recently used microphone channel active.
The purpose of this feature is to keep natural room sound in the
signal so that meeting participants on the far end know the audio
signal has not been interrupted.
•Off Attenuation
Sets the level of signal reduction when a channel is not active
•Hold Time
Sets the duration for which the channel remains open after the level
drops below the gate threshold

Copyright © Lumens. All rights reserved.
Gating Sensitivity
•Gating Sensitivity
Changes the threshold of the level at which the gate is opened
Generally set between 2~5.
You can start testing from 2.
Find the most appropriate effect for your meeting space.
The higher the number, the more sensitive the trigger of Voice will be,
and the chance of Camera switch will be relatively increased.
This parameter will affect the sensitivity of voice tracking, and can also
avoid some low-volume interference.

Copyright © Lumens. All rights reserved.
Voice activation
•On the IntelliMix page, you
can test whether the
correct channel is
activated when someone
speaks on different
channels

Copyright © Lumens. All rights reserved.
CamConnect Pro Setting
• 1. Select the device as “Shure MXA920”
• 2. Mapping the “Array No.” to the Shure “Lobe channel number”.
•3. Lumens will continue to provide videos of CamConnect Pro settings. So, other settings will
not be repeated in this document.
