SHURflo 1500 Installation instructions

MOUNTING (Suggested installation & operation only. Your installation may vary)
Mount scoop-type thru-hull [high speed pick-up] to hull. Do not drive screws through hull! Below water level thru-hull fittings must
have a seacock shut-off valve. Install a 1” NPT-M brass nipple fitting into pump inlet and mount directlyto seacock.
PLUMBING
Use smooth I.D. discharge tubing . Tubing should be rated for below water line use. Always use double clamps for connec-
tions below the water line.Tubing should enter tank at top to avoid tank draining while pump is off. (See illustration for recom-
mended installation).
Avoid airlock & maximize performance: Avoid any sagging or loops in the tubing. Tubing must go up from pump to tank. Use full
-flow style valves only. Valve is used to regulate flow to tank while at rest and while under way (2 different settings).
Bait & Livewell Pump Installation & Operation Instructions
911-1000-G Page 1 of 2
ELECTRICAL
Use 16GA wire for all circuits. If installation is over 20 feet, use 14GA wire. Brown pump wire must be connected to positive power. When the controller
detects a lock rotor condition (high amps) for more than 10 seconds it will turn the pump off until power gets reset. Use waterproof connectors and splices. Attach
all wires to UL Marine approved duty switch rated at or above 15 amps. Wire connections should be made above water level at the highest possible position.
Seal wire connections to prevent corrosion and electrolysis.
Always use fuse with amps rating specified on pump label. Failure to do so may result in serious personal injury, fire hazards and will void
the warranty.
WARNING
Other installation options:

OPERATION
Never operate equipment if gasoline fumes are present. Always test pump before leaving dock. Open sea cock before running
pump, do not run pump dry. Tank fill time should be tested at rest and under way. Pump will fill tank faster while boat is running at
higher speeds. General tank fill times are between 7 minutes [warmer water] and 10 minutes [colder water]. Measure tank fill time from
empty while at rest and adjust valve position for desired time. Measure tank fill time at normal cruising speed and adjust valve to
desired time. Refer to tank size chart for optimal pump size. Note position for later reference. Always remember to adjust valve when
at rest or under way. Flow should be circular and slightly upward so debris clears from bottom of tank. Flowshould not be too fast that
fish get tired.
WARNING
Do not disassemble base from pump body. Warranty will be voided upon disassembly. SHURflo is not responsible for problems
due to disassembly of base from pump body. Do not pump oil, diesel fuel, gasoline or other flammable liquids with this pump.
Always disconnect power before servicing pump. Always use fuse size specified in specification.
Seacock MUST be closed before removing pump for service.
*Specifications given at design voltage of 13.6V DC per ABYC recommendations.
LIMITED WARRANTY
SHURflo warrants its SHURflo™ Bait Pumps series to be free of defects in material and workmanship under normal use for a
period of two (2) years from the date of manufacture, as indicated on the pump label. SHURflo is not responsible for problems due
to improper installation or maintenance. Returns are to be shipped prepaid to SHURflo. For complete Limited Warranty details
contact SHURflo.
TIPS:
Vibration induced by sea conditions or transportation may cause plumbing or pump hardware to loosen. Check for
system components that may be loose. Many symptoms can be solved by simply tightening.
PUMP WILL NOT START OR NO WATER
• Check electrical connections; fuse, switch and ground connection.
• Check if voltage is present at the pump.
• Check for improper fuse rating or wire size.
• Sea-Cock / thru-hull or valve closed?
• Pump mounted above water level.
• Sea-Cock valve not fully open.
• Check if tank flow adjust valve is closed.
• Check if inlet is clogged.
Troubleshooting
Name Voltage Model #: 0 Ft [0 M] 3 Ft [1 M] 6 Ft [2 M] Max Head Ft [M] Max Amps Fuse Outlet Port
FLOW GPH [LPH] TECHNICAL DATA
1500 *12 V 358-001-00 1800 [6813] 1700 [6434] 1600 [6056] 14 [4.27] 8 10 1-1/8"
2000 *12 V 358-011-00 2200 [8327] 2000 [7570] 1900 [7191] 18 [5.5] 10 15 1-1/8"
1500 24 V 358-101-00 1800 [6813] 1700 [6434] 1600 [6056] 14 [4.27] 4 6 1-1/8"
2000 24 V 358-111-00 2200 [8327] 2000 [7570] 1900 [7191] 18 [5.5] 5 8 1-1/8"
