SICK Lector61x User manual

OPERATING INSTRUCTIONS
Lector61x
Image-based code reader

Described product
Lector61x
Manufacturer
SICK AG
Erwin-Sick-Str. 1
79183 Waldkirch
Germany
Legal information
This work is protected by copyright. Any rights derived from the copyright shall be
reserved for SICK AG. Reproduction of this document or parts of this document is only
permissible within the limits of the legal determination of Copyright Law. Any modifica‐
tion, abridgment or translation of this document is prohibited without the express writ‐
ten permission of SICK AG.
The trademarks stated in this document are the property of their respective owner.
© SICK AG. All rights reserved.
Original document
This document is an original document of SICK AG.
2O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/17IL/2020-04-02 | SICK
Subject to change without notice

Contents
1 About this document........................................................................ 5
1.1 Information on the operating instructions.............................................. 5
1.2 Scope......................................................................................................... 5
1.3 Explanation of symbols............................................................................ 5
1.4 Further information................................................................................... 6
2 Safety information............................................................................ 7
2.1 Intended use............................................................................................. 7
2.2 Improper use............................................................................................. 7
2.3 Internet protocol (IP) technology.............................................................. 8
2.4 Limitation of liability................................................................................. 8
2.5 Modifications and conversions................................................................ 8
2.6 Requirements for skilled persons and operating personnel.................. 8
2.7 Operational safety and particular hazards.............................................. 9
3 Product description........................................................................... 12
3.1 Product ID.................................................................................................. 12
3.2 Scope of delivery....................................................................................... 13
3.3 Product characteristics............................................................................ 14
4 Transport and storage....................................................................... 18
4.1 Transport................................................................................................... 18
4.2 Unpacking.................................................................................................. 18
4.3 Transport inspection................................................................................. 18
4.4 Storage...................................................................................................... 18
5 Mounting............................................................................................. 20
5.1 Mounting instructions............................................................................... 20
5.2 Preparation for mounting......................................................................... 20
5.3 Mounting location..................................................................................... 21
5.4 Mounting the device................................................................................. 27
5.5 Mounting the read cycle sensor (optional).............................................. 28
6 Electrical installation........................................................................ 29
6.1 Safety......................................................................................................... 29
6.2 Wiring instructions.................................................................................... 32
6.3 Connection diagrams............................................................................... 33
6.4 Pin assignments of electrical connections............................................. 35
6.5 Connecting the device.............................................................................. 36
7 Commissioning.................................................................................. 42
7.1 Configuring the device with SOPAS ET.................................................... 42
7.2 Configuring the device via the button without configuration software
(SOPAS ET)................................................................................................ 43
7.3 Initial commissioning................................................................................ 44
CONTENTS
8024830/17IL/2020-04-02 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x 3
Subject to change without notice

8 Maintenance...................................................................................... 46
8.1 Maintenance plan..................................................................................... 46
8.2 Cleaning..................................................................................................... 46
9 Troubleshooting................................................................................. 49
9.1 General faults, warnings, and errors....................................................... 49
9.2 Displaying the status log.......................................................................... 49
9.3 SICK service.............................................................................................. 49
9.4 Repairs...................................................................................................... 49
9.5 Returns...................................................................................................... 49
9.6 Replacing the device................................................................................ 50
10 Decommissioning............................................................................. 52
10.1 Disposal..................................................................................................... 52
11 Technical data.................................................................................... 53
11.1 Features.................................................................................................... 53
11.2 Mechanics/electronics............................................................................. 54
11.3 Performance............................................................................................. 54
11.4 Interfaces.................................................................................................. 55
11.5 Ambient data............................................................................................. 56
12 Accessories........................................................................................ 57
13 Annex.................................................................................................. 58
13.1 EU declaration of conformity / Certificates............................................. 58
13.2 Signal assignment of cables with open cable end at one end.............. 58
13.3 Connection diagrams of connection module CDB650-204.................. 59
13.4 Connection diagrams of connection module CDM420-0006............... 68
13.5 Copyright notices...................................................................................... 77
13.6 General cybersecurity notice................................................................... 77
CONTENTS
4O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/17IL/2020-04-02 | SICK
Subject to change without notice

1 About this document
1.1 Information on the operating instructions
These operating instructions provide important information on how to use devices from
SICK AG.
Prerequisites for safe work are:
•Compliance with all safety notes and handling instructions supplied.
•Compliance with local work safety regulations and general safety regulations for
device applications
The operating instructions are intended to be used by qualified personnel and electrical
specialists.
NOTE
Read these operating instructions carefully to familiarize yourself with the device and its
functions before commencing any work.
The operating instructions are an integral part of the product. Store the instructions in
the immediate vicinity of the device so they remain accessible to staff at all times.
Should the device be passed on to a third party, these operating instructions should be
handed over with it.
These operating instructions do not provide information on operating the machine or
system in which the device is integrated. For information about this, refer to the operat‐
ing instructions of the specific machine.
1.2 Scope
These operating instructions serve to incorporate the device into a customer system.
Instructions are given by stages for all actions required.
These operating instructions apply to all available device types of the product. To obtain
more detailed information on identifying your device type, see "Type code", page 12.
Available device types are listed on the online product page:
•www.sick.com/Lector61x
Commissioning is described using one particular device type as an example and based
on the default parameter settings for the relevant device.
1.3 Explanation of symbols
Warnings and important information in this document are labeled with symbols. Signal
words introduce the instructions and indicate the extent of the hazard. To avoid acci‐
dents, damage, and personal injury, always comply with the instructions and act care‐
fully.
DANGER
… indicates a situation of imminent danger, which will lead to a fatality or serious
injuries if not prevented.
WARNING
… indicates a potentially dangerous situation, which may lead to a fatality or serious
injuries if not prevented.
ABOUT THIS DOCUMENT 1
8024830/17IL/2020-04-02 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x 5
Subject to change without notice

CAUTION
… indicates a potentially dangerous situation, which may lead to minor/slight injuries if
not prevented.
NOTICE
… indicates a potentially harmful situation, which may lead to material damage if not
prevented.
NOTE
… highlights useful tips and recommendations as well as information for efficient and
trouble-free operation.
1.4 Further information
NOTE
Further documentation for the device can be found on the online product page at:
•www.sick.com/Lector61x
There, additional information has been provided depending on the product, such as:
•Model-specific online data sheets for device types, containing technical data,
dimensional drawing, and specification diagrams
•EU declarations of conformity for the product family
•Dimensional drawings and 3D CAD dimension models of the device types in vari‐
ous electronic formats
•This documentation, available in English and German, and in other languages if
necessary
•Other publications related to the devices described here
•Publications dealing with accessories
Documents on request
Overview of command strings for the device.
1 ABOUT THIS DOCUMENT
6O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/17IL/2020-04-02 | SICK
Subject to change without notice

2 Safety information
2.1 Intended use
The Lector61x image-based code reader is an intelligent ID sensor.
The device is used for automatic, stationary identification and decoding of codes on
moving or stationary objects. The device reads all commonly used 1D codes (bar
codes/stacked codes) and 2D codes (matrix codes). The device uses its host interface
to send the read data to a higher-level computer (e.g. PLC) for coordinating further pro‐
cessing.
The device is suitable for industrial and logistics applications that require stable and
fast reading of codes. The device meets the applicable requirements for industrial
robustness, interfaces and data processing.
SICK AG assumes no liability for losses or damage arising from the use of the product,
either directly or indirectly. This applies in particular to use of the product that does not
conform to its intended purpose and is not described in this documentation.
2.1.1 Conditions for specified enclosure rating
To ensure compliance with the specified IP54 enclosure rating of the device during
operation, the following requirements must be met: If these requirements are not met,
the device does not fulfill any specified enclosure rating.
•The two electrical M12 connections must be tightly screwed to the contacted
female connector or male connector.
•The Ethernet connection, if not used, must be sealed with a tightly-fastened pro‐
tective plug (as in the delivery condition).
2.2 Improper use
Any use outside of the stated areas, in particular use outside of the technical specifica‐
tions and the requirements for intended use, will be deemed to be incorrect use.
•The device does not constitute a safety component in accordance with the respec‐
tive applicable safety standards for machines.
•The device must not be used in explosion-hazardous areas, in corrosive environ‐
ments or under extreme environmental conditions.
•The device must not be operated in the temperature range below 0 °C.
•Any use of accessories not specifically approved by SICK AG is at your own risk.
WARNING
Danger due to improper use!
Any improper use can result in dangerous situations.
Therefore, observe the following information:
■Product should be used only in accordance with its intended use.
■All information in these operating instructions must be strictly observed.
■Shut down the product immediately in case of damage.
SAFETY INFORMATION 2
8024830/17IL/2020-04-02 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x 7
Subject to change without notice

2.3 Internet protocol (IP) technology
NOTE
SICK uses standard IP technology in its products. The emphasis is placed on availability
of products and services.
SICK always assumes the following prerequisites:
•The customer ensures the integrity and confidentiality of the data and rights
affected by its own use of the aforementioned products.
•In all cases, the customer implements the appropriate security measures, such as
network separation, firewalls, virus protection, and patch management.
2.4 Limitation of liability
Relevant standards and regulations, the latest technological developments, and our
many years of knowledge and experience have all been taken into account when com‐
piling the data and information contained in these operating instructions. The manufac‐
turer accepts no liability for damage caused by:
■Non-adherence to the product documentation (e.g., operating instructions)
■Incorrect use
■Use of untrained staff
■Unauthorized conversions or repair
■Technical modifications
■Use of unauthorized spare parts, consumables, and accessories
With special variants, where optional extras have been ordered, or owing to the latest
technical changes, the actual scope of delivery may vary from the features and illustra‐
tions shown here.
2.5 Modifications and conversions
NOTICE
Modifications and conversions to the device may result in unforeseeable dangers.
Interrupting or modifying the device or SICK software will invalidate any warranty claims
against SICK AG. This applies in particular to opening the housing, even as part of
mounting and electrical installation.
2.6 Requirements for skilled persons and operating personnel
WARNING
Risk of injury due to insufficient training.
Improper handling of the device may result in considerable personal injury and material
damage.
■All work must only ever be carried out by the stipulated persons.
This product documentation refers to the following qualification requirements for the
various activities associated with the device:
2 SAFETY INFORMATION
8O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/17IL/2020-04-02 | SICK
Subject to change without notice

■Instructed personnel have been briefed by the operator about the tasks assigned
to them and about potential dangers arising from improper action.
■Skilled personnel have the specialist training, skills, and experience, as well as
knowledge of the relevant regulations, to be able to perform tasks delegated to
them and to detect and avoid any potential dangers independently.
■Electricians have the specialist training, skills, and experience, as well as knowl‐
edge of the relevant standards and provisions, to be able to carry out work on elec‐
trical systems and to detect and avoid any potential dangers independently. The
electrician must comply with the provisions of the locally applicable work safety
regulation.
The following qualifications are required for various activities:
Table 1: Activities and technical requirements
Activities Qualification
Mounting, maintenance ■Basic practical technical training
■Knowledge of the current safety regulations in the workplace
Electrical installation,
device replacement
■Practical electrical training
■Knowledge of current electrical safety regulations
■Knowledge of the operation and control of the devices in their
particular application
Commissioning, configura‐
tion
■Basic knowledge of the WindowsTM operating system in use
■Basic knowledge of the design and setup of the described con‐
nections and interfaces
■Basic knowledge of data transmission
■Basic knowledge of 1D technology (bar code) or 2D technology
(Data Matrix code)
Operation of the device for
the particular application
■Knowledge of the operation and control of the devices in their
particular application
■Knowledge of the software and hardware environment for the
particular application
2.7 Operational safety and particular hazards
Please observe the safety notes and the warnings listed here and in other chapters of
this product documentation to reduce the possibility of risks to health and avoid dan‐
gerous situations.
LEDs on the product
The feedback LED, the LED alignment aid, and the status LEDs of the product are clas‐
sified as risk group 0.
The accessible radiation from LEDs of risk group 0 does not pose a risk to eyes or skin.
The product is fitted with LEDs in risk group 1 for object illumination.
SAFETY INFORMATION 2
8024830/17IL/2020-04-02 | SICK O P E R A T I N G I N S T R U C T I O N S | Lector61x 9
Subject to change without notice

CAUTION
Warning! Optical radiation: LED risk group 1
The LEDs may pose a danger to the eyes and skin in the event of incorrect use.
■Protect the eyes and skin against radiation.
■Use suitable eye protection.
■Use protective measures such as a screen to shield the radiation.
■Do not open the housing. Opening the housing will not switch off the light source.
Opening the housing may increase the level of risk.
■Comply with the current national regulations on photobiological security of lamps
and lamp systems.
Time-of-flight sensor (invisible infrared light, distance measurement in configuration
mode)
CAUTION
Optical radiation: Laser class 1
The accessible radiation does not pose a danger when viewed directly for up to 100
seconds. It may pose a danger to the eyes and skin in the event of incorrect use.
■Do not open the housing. Opening the housing may increase the level of risk.
■Current national regulations regarding laser protection must be observed.
Caution – Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure.
For both radiation types:
It is not possible to entirely rule out temporary disorienting optical effects, particularly
in conditions of dim lighting. Disorienting optical effects may come in the form of daz‐
zle, flash blindness, afterimages, photosensitive epilepsy, or impairment of color vision,
for example.
DANGER
Risk of injury due to hot device surface.
The surface of the device can become hot during operation.
•Before performing work on the device (e.g. mounting, cleaning, disassembly),
switch off the device and allow it to cool down.
•Ensure good dissipation of excess heat from the device to the surroundings.
WARNING
Electrical voltage!
Electrical voltage can cause severe injury or death.
■Work on electrical systems must only be performed by qualified electricians.
■The power supply must be disconnected when attaching and detaching electrical
connections.
■The product must only be connected to a voltage supply as set out in the require‐
ments in the operating instructions.
■National and regional regulations must be complied with.
■Safety requirements relating to work on electrical systems must be complied with.
2 SAFETY INFORMATION
10 O P E R A T I N G I N S T R U C T I O N S | Lector61x 8024830/17IL/2020-04-02 | SICK
Subject to change without notice
