Sicor EOM Operation instructions

SICUREZZA COMPAGNIE RIUNITE
EOM
1-0292S
EN
Use and maintenance instructions ............. pág 8
Copyright by
SICOR S.p.A.
Via C. Pisacane 23/A - 20016 Pero (MI) Italy
Printed in Italy
Printed 02/2020 - 9^ Ediz.ne 02/2020

EOM
SICUREZZA COM PAGNIE RIUN ITE
2
Risks against which the PPE protects:
The helmet model EOM described by this use and maintenace instructions protects:
2. Emergency technical assistance services - EN 16473: 2014
3. High altitude technical assistance services - EN 12492: 2012
4. River rescue services - EN 1385: 2012
SICUREZZA COM PAGNIE RIUNI TE
15
EOM
Warranty and Declaration of conformity
6 - WARRANTY
The product is guaranteed according to the legislation in
force on the date of purchase.
The manufacturer:
Sicor S.p.A - Via C. Pisacane n. 23/a - 20016 PERO (MI)
-
ing and white water sports mod. EOM described in this manual, the declaration of conformity is available at the following
address:
https://www.dropbox.com/sh/rx464m5kcot0fus/AAC_4egxPzZxmBe4p1sxqX4ra?dl=0
and also using the following QR code:
7 - DECLARATION OF CONFORMITY

SICUREZZA COMPAGNIE RIUNITE
EOM
3
EN 16471:2014 EN 16473:2014 EN 12492:2012 EN 1385:2012
-30°C
Größen - Taglie
Size - Tamanhos
Tamaños - Tailles
52 ˜64 cm
Made in Italy
DD-MM-YY
SN. XXXXXX
Elmo per il soccorso tecnico
Helmet for technical rescue Casco para rescate tecnico
Capacete para resgate técnico Elmo per antincendio boschivo
Helmets for wildland fire fighting
Casco de incendios forestales
Casco per Alpinisti
Helmet for mountainner
Capacetes para alpinistas
Casco para montñeros
Elmo per canoa - Kayak
e sport in acque torrentizie
Helmet for canoeing
and whitewater sports
Casco para canoa y
rapidos de agua
Capacete para canoa
e esportes em águas
correntes
1-0326S
21
1
1-0293S
1
2
2a
1a
1b
6d
6f
6b
6f
6c
6e
6a
4
5c
5b
5a
3a
7
5e
3b
5d
5f
2
3
4
5
67 8 910
11
Accessories
SICUREZZA COMPAGNIE RIUNITE
14
EOM
5.3 - SAFETY EARMUFFS
(See Figures from 48 to 52)
-
(2) on the connectors (1) provided on the external shell.
-
them up if you do not want to use them.
-
your ears until you hear a click and then turn them upward
-
of the fastening support (2).
5.4 - MESH FACE SCREEN/TRANS-
PARENT FACE SCREEN
(See Figures from 53 to 55)
IMPORTANT
it onto the fastening clips (1) in the fastening supports (2).
Once fastened, the face screen (3) can be adjusted to two
positions: up (A) or down (B).
To remove the face screen, unclip it from the fastening
clips (1) by pulling outwards.
IMPORTANT
This accessory is not compatible with the goggles.
5.5 - NECK PROTECTOR
5.5.a - Fitting/removal
(See Figures from 56 to 61)
- Release the two tabs (1) of the harness (2).
- Release the rear of the harness (2) by pulling upwards
so that the clips are released from the shell.
- Insert the two central straps (3) in the tabs of the two
-
- Fit the two side straps (5) on the harness band.
- For removal work in reverse order.
5.5.b - Use
(See Figures from 62 to 63)
1) Neck and shoulder protection
Position the neck protector (6) behind the neck and on
the shoulders with the side pieces folded back.
2) Neck, shoulder and neck protection.
Position the neck protector (6) behind the neck and on
the shoulders with the side pieces (7) tied around the
neck.

EOM
SICUREZZA COMPAGNIE RIUNITE
4
1-0298S
1-0299S
1-0004S
1-0295S
1-0003S
67
1-0007S 1-0008S
9 10
1
2
1-0296S
3
1
12
1
2
1-0297S
13 14
1-0016S
16
20
1-0013S
17
1-0014S
18
1-0015S
19
1-0294S
8
3
2
11
1-0010S
15
1-0300S
21
1-0020S
23
1-0019S
22
1
1
2
3
6
555
6
7
9
10
6
4
SICUREZZA COMPAGNI E RIUNITE
13
EOM
Accessories
4.5- HELMET LIFE
If properly stored, the EOM helmet has a lifetime of about
8 years.
Depending on the conditions of use, the lifetime may
vary considerably.
IMPORTANT
4.6- DISPOSAL
Strictly comply with the disposal regulations in force.
5 - ACCESSORIES
WARNING
Using unauthorised accessories:
1 Makes the helmet not conform to the current regulations.
2 Leads to forfeiture of the warranty.
3 Makes the user responsible for any accidents.
5.1 - GOGGLES
(See Figures from 39 to 42)
A) Silycone cord
- Insert one of the ends of the silicone cord into the hole
(1) and make a single knot (detail A).
- Run the cord through the cavity (2) and insert it in the
holes on the goggle supports (3). Check that the goggles
are correctly positioned.
- Run the cord through the cavity (2) to the outside of the
shell and insert it in the cavity (4).
- Run the cord through the holes in the goggle supports
(3) and then through the cavity (4).
- Finally, run the cord through the hole (5) and securely
fasten it by making a single knot (detail A).
- Once secured with the cord, the goggles can be used.
B) Flame retardant elastic band
- Insert one end part of the elastic band in the oblique
- slide the elastic band on the rear circumference of the
shell.
- Insert the other end part of the elastic band in the oblique
- Insert the elastic band in the two holes of the lateral at-
If you do not want to use the goggles, push them up onto
the helmet.
You can adjust the goggle pressure on the face by adjusting
the cord length.
5.2 - LAMP
(See Figures from 43 to 47)
-
shell on the dedicated adapters.
-
(2).
-
its position.
- Fit the lamp (3) in the holder (1).
The lamp can be used in four positions: facing down (A) or
facing up (B).

SICUREZZA COMPAGNIE RIUNITE
EOM
5
1-0021S 1-0022S
24 25
1-0301S
26
1-0024S
1-0061S
1-0027S
27
28 29
1-0302S
30
1-0303S
31
1-0022S
34
1-0031S
1-0032S
35
36 37
11
1
4
12
12
22
1
2
2
1
34
1-0024S
32
1-0021S
33
5
6
7
1-0304S
11
10
1-0305S
38
13
12
14
16
15
14
1-0307S
39
1-0308S
40
Maintenance
SICUREZZA COMPAGNI E RIUNITE
12
EOM
4 - MAINTENANCE
4.1 - HELMET DISASSEMBLY
(See Figures from 14 to 27)
WARNING
It is recommended to read through each single paragraph
before proceeding with the disassembly operations.
To proceed with disassembly, place the helmet upside
down on an uncluttered surface in order not to lose any
components.
During the disassembly procedures, position all the parts
removed in an orderly way.
- Pull the strap (1) out of the adjusters (2) and out of the
anti-creep system.
- Release the rear part (3) of the protective mesh (4).
- Release the two tabs (5) of the harness (6).
- Release the rear of the harness (6) by pulling upwards
so that the clips are released from the shell.
- Release the front part (7) of the harness (6) and pull it
upwards so that the clips are released from the shell,
then remove the harness (6) from the helmet.
- Release the retention system by pushing the fasteners
(9) downward and remove the harness with the retention
system.
- Unfasten the clips (10) from the harness (turn and re-
move).
- Remove the mesh (4) releasing it from the respective
fastening pins.
-Release and remove the rear comfort piece (11) by
unfastening the strap tabs.
-Remove the front comfort piece by unfastening the strap
tabs (12).
4.2 - HELMET ASSEMBLY
(See Figures from 28 to 38)
-
bottom to the top.
- Fit the clips (2) of the anti-shock straps (3) making sure
that the strap passes between the clips and the external
shell and refasten the clips (4).
- Fit the front comfort piece (5) on the retention system.
-
-
-
on the helmet and fasten the rear and front fasteners.
- Fit the retention system inserting the front straps (10) in
the adjusters (11) and the rear straps (12) in the anti-
creep system (13).
- Fit the anti-stretch strap (14) of the retention system
using the anti-creep adjuster (15).
The anti-stretch strap (14) stays positioned underneath
the protective mesh (16).
4.3 - HELMET CLEANING AND
CARE
After each use, put the helmet in its bag or in a closed
place (e.g. locker) away from light and humidity.
Clean the helmet as follows:
- Never clean the helmet in the sun.
- Disassemble the helmet as described in Chapter 4.1
-Clean all the parts inside and out using only neutral soap
and lukewarm water.
- Leave to dry at room temperature.
DO NOT USE DRYERS.
- Before reassembling the helmet, check that all the parts
are completely dry.
- Never use abrasive or strong alkaline detergents.
-When the helmet is completely dry, reassemble it as
described in Chapter 4.2
IMPORTANT
Never use solvents or organic liquids such as petrol or al-
cohol!
4.4 - INSPECTION PROCEDURE
Inspect the helmet before and after each use, paying par-
ticular attention to all the fastening points (harness and
retention system). Immediately replace any worn and/or
damaged parts, exclusively using spare parts supplied by
Sicor S.p.A., since only the original spare parts are ho-
mologated and guarantee conformity of the helmet.
- Check that there are no colour changes and/or cracks
on the shell and harness.
-Check that there are no cuts and/or breakage at the
edges and the holes.
- Check that the suspension system is intact by checking
the seams.

EOM
SICUREZZA COMPAGNIE RIUNITE
6
41
1-0306S
3
2
4
5
1
1-0309S
1-0173S
42 43
1-0174S
44
1-0175S
45
1
2
1
1
3
1-0054S
48
1-0310S
49
1-0176S
46
1-0177S
47
A B
2
1
1-0311S
50
1-0312S
51
21-0055S
52
1-0313S
53 1
2
1-0314S
54
1-0315S
55
3
1-0013S
56
1-0014S
57
111
3
3
1-0324S
B
B
41a
A B
SICUREZZA COM PAGNIE RIUNITE
11
EOM
Maintenance
3 - USE AND ADJUSTMENTS
3.1 - INTRODUCTION
- Any improper use not in compliance with the reference
standards shall make the user solely responsible for any
personal harm and invalidate the warranty conditions.
- dedivorpebotdednetninoitcetorpehttahtgninraW
by the helmet can only be ensured when it is properly
part shall not be worn separately.
-In order to provide adequate protection, this helmet must
be adjusted to the head size of the user.
- The helmet has been designed to absorb the energy of
an impact by destroying or partially damaging the shell
and the harness; even if this damage may not immedi-
ately be visible, any helmet that has been subjected to
strong impact must be replaced.
- For your own safety it is advisable to familiarise yourself
with the adjustment systems before using the helmet.
Make several adjustments and fasten and unfasten the
retention system several times so that these actions
become instinctive.
3.2 - HEIGHT ADJUSTMENT
(See Figure 6)
Adjust the helmet in height by changing the depth of the
suspension mesh as follows:
Release the rear tabs of the mesh fastened with strap and
slide them in the slots on the harness.
3.3 - CIRCUMFERENCE ADJUST-
MENT
(See Figures 7-8)
IMPORTANT
The helmet is supplied with the size adjustment band fully
extended.
For proper adjustment follow the sequence described below.
- Put on the helmet and then adjust the size using the
wheel (1).
- For optimal adjustment it is advisable to push down on
the helmet with one hand and then make the adjustment
with the other hand.
- The size adjustment system also acts on the anti-creep
system.
- Pull the two straps (2) that join the chin-strap to the
3.4 - RETENTION SYSTEM AD-
JUSTMENT
3.4.a - First use
(See Figures 9-10)
Chin-strap:
- Adjust in height as described in Chapter 3.2.
- Put on the helmet.
- Adjust the size
(as described in Chapter 3.3)
- Fasten the buckle.
- Slide the adjustment strap (1) in the adjustment cross-
piece of the system (2).
- Again pull the strap (1) so that the system adjusts cor-
rectly.
- Should you be unable to achieve the correct adjustment,
act on the adjusters (point 3) positioned on either side
of the chin-strap and lengthen or shorten the strap as
shown in the image.
3.4.b - Regular use
(See Figures 11-12)
Chin-strap:
- Fasten the chin-strap with the buckle.
Size and anti-creep adjustment:
- Adjust as described in Chapter 3.3.
3.5 - HELMET USE
3.5.a - Ventilation system use (See Fig-
ure 13)
The helmet ventilation system can be adjusted to prevent
Operate the sliding lever on the top of the helmet with one
hand.
Position 1 = Closed
Position 2 = Open
WARNING
Despite the steel spark protection mesh, we advise you to
WARNING
For the use of the helmet in the activity of river rescue, the
ventilation system must be opened.

SICUREZZA COMPAGNIE RIUNITE
EOM
7
1-0058S
61
1-0316S
62
1-0317S
63
1-0303S
60
4
5
4
3
45
6
6
7
1-0015S
58 2
1-0056S
59
4
3
Use and adjustments
10
EOM
Parts Lists
Code Description
5223240401 Helmet shell red colour
5223240101 Helmet shell white colour
5223240301 Helmet shell yellow colour
5223240501 Helmet shell blue colour
5223240201 Helmet shell black colour
5223240009 Helmet shell photoluminescent colour
5223240308 Helmet shell bright yellow colour
5223240808 Helmet shell bright orange colour
R58413 Ventilation system
R58565 Adapters
R62664 Suspension system
R62665 Chin strap
R58418 Suspension mesh
R62666 Size adjustment system
R62667 Rear adjuster
R58421 Front band
R58422 Front comfort piece
R58423 Rear comfort piece
R58425 Silycone cord
R58562 Elastic band - variable
R58424 Two-lens safety goggles
5223050408
5223050308
5223050708
R58566 Lamp holder (Parat)
R62669 Lamp holder (Uk - Peli)
R58430
R58431 Mesh face shield
R58432 Polycarbonate face shield
R58433 Polycarbonate face shield (resistant to
electric arcs)
R58434
R58435 Carrying bag
= The highlighted parts are optional

General regulations
SICUREZZA COMPAGNIE RIUNITE
8
EOM
1 - GENERAL REGULATIONS
1.1 - INTRODUCTION
- Before using this product, carefully read these instruc-
tions for use and those of the associated products.
- Observe exactly the instructions for use indicated in this
information note. The instructions must be understood
and strictly observed both by the people who wear the
helmet and the safety goggles, and by those responsible
for maintenance. Use the product only for the purposes
protects” in this document.
- Do not dispose of the instructions for use. Ensure that
they are retained and appropriately used by the product
user.
- Comply with all local and national rules and regulations
associated with this product.
- Only trained and competent personnel are permitted
to inspect, repair and service the product. It is recom-
mended to contact Sicor for all maintenance activities
and authorized Sicor personnel.
- The helmet and the goggles guarantee the performance
for which they were designed only if they are properly
usedand maintained according to theinstructions in
this manual. Otherwise the protective features cannot
be guaranteed.
- Only authentic Sicor spare parts and accessories and/
or third-party components authorized by Sicor may be
used formaintenance. Otherwise, the proper functioning
- Do not use a faulty or incomplete product. Do not modify
party components not authorized by Sicor.
- The warranties on these products shall become invalid
if the warnings, precautions and instructions contained
in this manual are not followed.
- Incorrect
personal protective equipment or with an accessory other
than supplied by the helmet manufacturer, an helmet
marked as complying with this European Standard might
no longer satisfy all clauses of this European Standard.
- This helmet complies with the requirements of the Eu-
ropean Standards when the chin strap supplied by the
helmetmanufacturer is worn and adjusted in accordance
with these instructions.
- Notify Sicor in the event of any product or component
fault or failure.
1.1.a - How to consult the manual
- This
topics.
An index is given at the beginning of each chapter for
easier consultation. The chapter number is shown at the
bottom left or right of each page and at the top of the
page the topic dealt with in the chapter.
- The following symbols are used in this manual to point
out safety messages:
RISK TO PERSONS
Partial or total inobservance of the rules pointed
out with this symbol may cause serious risks
to the health of the user of the helmet and the
goggles.
IMPORTANT INFORMATION
This symbol indicates important communica-
tions for proper use or maintenance of the
helmet and the goggles.
1.1.b -
(See Figure 1)
1 = Helmet shell
1.a = Ventilation system
1.b = Adapters
2 = Protective goggles (optional)
2.a = Cord
3 = Comfort piece
3.a = Front comfort piece
3.b = Rear comfort piece
4 = Anti-shock straps
5 = Harness:
5.a = Front fasteners
5.b = Band
5.c = Suspension mesh
5.d = Size adjustment system
5.e = Rear fastener
5.f = Adjustment band
6 = Retention system
6.a = Chin-strap
6.b = Anti-creep system
6.c = Anti-creep adjuster
6.d = Rectangular ring
6.e = Quick-release buckle
6.f = Anti-stretch strap
7 = Neck protector (optional)
SICUREZZA COMPAGNIE RI UNITE
9
EOM
Technical data
1.1.c - Spare parts and accessories
IMPORTANT
Only original spare parts and accessories authorised and
Using non-original spare parts and unauthorised ac-
cessories will invalidate the warranty conditions and
relieve SICOR S.p.A. of all responsibility.
WARNING
-
25 mm from the edges of the shell; do not use paints,
petrol or solvents to clean the helmet.
Inobservance of these rules may reduce the levels of
protection and/or the dielectric properties.
- Do not modify or remove any of the constituent compo-
nents of the helmet.
1.1.d Storage
IMPORTANT
• The helmet must be stored in a clean, dry, dark place
away from sources of heat and at a temperature between
+10°C (50°F) and +40°C (104°F).
• The helmet and its accessories must be stored in the
bag provided.
• Never leave the helmet in a vehicle if not in its bag to
prevent needless exposure to the sun (UV rays).
2 - TECHNICAL DATA
2.1 - DIMENSIONS AND WEIGHTS
Helmet weight....................................................... 700 g
Goggles weight..................................................... 116 g
Width .................................................................... 240 mm
Height ................................................................... 295 mm
Length................................................................... 193 mm
Storage temperature................................+10 °C (50 °F) to
................................+40 °C (104 °F)
2.2 - MARKINGS
2.2.a - Helmet
(See Figure 2)
Reference standards:
EN 16471 : 2014 -
EN 16473 : 2014 -
cal rescue
EN 12492:2012 Helmet for mountaineers
EN 1385:2012 Helmet for river rescue
1)
2) Reference instruction manual
3) Sizes
4) Optional requirements
5)
6) CE mark
7) Reference standards
8) Country and date of manufacture
9) Serial number
10) Product description
11) Product name
- If after reading the manual there is any doubt about the
conditions of use or maintenance procedures, do not
hesitate to contact:
SICOR S.p.A.
Via C. Pisacane n. 23/a
20016 PERO (MI)
Tel. [phone]
Fax- [phone]
e-mail [email protected]
internet: http://ww.sicor-sureco.com
- Incorrect
WARNING
